Luxul XFS-1084P User manual

Simply Connected
Use the XFS-1084P to:
Cost-Effectively Expand a Wired Network
Deliver Power and Data for up to Four PoE-Enabled
Network Devices
Simplify the Installation of IP Security, VoIP and
other Network Applications
Quick Install Guide
XFS-1084P
8-Port Fast Ethernet PoE Switch
Luxul
Xen
Xen
TM

a: 14203 Minuteman Drive, Ste 201, Draper, UT 84020-1685
p: 801-822-5450
2
Quick Install Guide
XFS-1084P
Quick Install Guide
Model Number: XFS-1084P
8-Port Fast Ethernet PoE Switch
© 2014 Luxul. All Rights Reserved.
No part of this publication may be modified or adapted in any way,
for any purposes without permission in writing from Luxul. The mate-
rial in this manual is subject to change without notice. Luxul reserves
the right to make changes to any product to improve reliability, func-
tion, or design. No license is granted, either expressly or by implication
or otherwise under any Luxul intellectual property rights. An implied
license only exists for equipment, circuits and subsystems contained
in this or any Luxul product.
DOCUMENT CONVENTIONS
The following graphical alerts are used to indicate notable situations:
NOTE: Tips, hints, or special requirements that you should
take note of.
CAUTION: Care is required. Disregarding a caution can
result in data loss or equipment malfunction.
WARNING!: Indicates a condition or procedure that could
result in personal injury or equipment damage.

3
© Copyright 2014 Luxul. All rights reserved. Trademarks & Registered
Trademarks are property of respective holders.
Simply Connected
FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CONTACT LUXUL
Sales
P: 801-822-5450
E: [email protected]
Technical Support
P: 801-822-5450
E: suppor[email protected]
Package Contents
Please check the contents carefully after you open the packing:
 XFS-1084P 8-Port Fast Ethernet PoE Switch
 Power Adapter and Cord
 Quick Install Guide
If any of the listed items are missing or damaged, please contact
the reseller from whom you purchased the XFS-1084P for return/
replacement.

a: 14203 Minuteman Drive, Ste 201, Draper, UT 84020-1685
p: 801-822-5450
4
Quick Install Guide
XFS-1084P
HARDWARE DESCRIPTION
Front Panel
The front panel of the XFS-1084P includes 8 Link/Activity LEDs, one
power LED, four PoE Status LEDs and one PoE Max LED. Please refer to
the detailed description of these indicators in Section 2.2 below.
XFS-1084P Front Panel View
LED Indicators
The LED indicators of the XFS-1084P include 8 Link/Activity LEDs, one
power LED, four PoE Status LEDs and one PoE Max LED. These LED
indicators show the operating status of the XFS-1084P and each switch
connection.
The following chart shows the LED indicators of the XFS-1084P along
with an explanation of the indicator’s properties:

5
© Copyright 2014 Luxul. All rights reserved. Trademarks & Registered
Trademarks are property of respective holders.
Simply Connected
LED Color Status Description
Power Green ON This indicator lights up when
the XFS-1084P is powered
— OFF If this indicator is not lit, please
check the DC power supply to
ensure proper connection to
the outlet and the XFS-1084P.
PoE Max Red ON Maximum output wattage
reached
— OFF Maximum output wattage not
reached
PoE Status Green ON Delivering PoE power to con-
nected device
OFF No PoE power being delivered
LINK/ACT Green ON Indicates the XFS-1084P is
connected at 100Mbps.
Blinking Indicates the XFS-1084P is
transmitting/receiving data
packets at 100Mbps.
— OFF Indicates the port is not con-
nected to a device.
100Mbps Green ON 100Mbp device connected
—OFF 10Mbp device connected

a: 14203 Minuteman Drive, Ste 201, Draper, UT 84020-1685
p: 801-822-5450
6
Quick Install Guide
XFS-1084P
Rear Panel Layout
The Rear Panel of the XFS-1084P includes eight 10/100Mbps RJ-45
Ethernet ports and one DC power port used for DC power input.
XFS-1084P Rear Panel View
CAUTION: Please use the included power supply. If a
different power supply is used, it could damage
the XFS-1084P
PREPARING FOR INSTALLATION
System Requirements
Ethernet Cables to connect the XFS-1084P to Ethernet enabled
devices
 Power should be AC 100-240V~ 1.4A(Max) 50/60Hz.
Installation Requirements
Install the XFS-1084P in a stable/safe place to avoid any possible
damage
Inspect the AC power cord to ensure that it is correctly connected
and undamaged

7
© Copyright 2014 Luxul. All rights reserved. Trademarks & Registered
Trademarks are property of respective holders.
Simply Connected
To avoid electric shock, DO NOT open the XFS-1084P housing (no
user serviceable parts inside). Opening the XFS-1084P will void your
warranty.
It is recommended that the Grounding connection to the outlet is
functioning properly and the XFS-1084P is positioned away from
direct sun light
Ensure there is sufficient space around the XFS-1084P for proper
ventilation and heat dissipation. It is recommended to have at least
4-6 inches around all sides.
Before Connecting to the Network
Before connecting the XFS-1084P to the network, please check the
following:
 Determine placement location. Do not place any heavy articles on
the XFS-1084P.
 Ensure there is adequate space for proper heat dissipation and
ventilation around the XFS-1084P.
 Power socket should be within 4 feet of the XFS-1084P.
 Check power adapter to confirm safe and secure connection.

a: 14203 Minuteman Drive, Ste 201, Draper, UT 84020-1685
p: 801-822-5450
8
Quick Install Guide
XFS-1084P
XFS-1084P INSTALLATION
Connecting Devices
Use standard Ethernet CAT5, CAT5e or CAT6 cable to connect
the XFS-1084P to a device as described below. The XFS-1084P will
automatically adjust to the characteristics (speed/duplex) of the
device to which it is connected. The PoE function is autosensing.
As long as the powered device is 802.3af compliant, the switch will
provide power.
NOTE: Legacy PoE devices or 802.3at devices that need
more that 15.4Watts can not be powered by the
switch
87654321
PoE
48V 1.25A
Connecting the XFS-1084P to a Device

9
© Copyright 2014 Luxul. All rights reserved. Trademarks & Registered
Trademarks are property of respective holders.
Simply Connected
When a device is properly connected, the Link/Activity LEDs for each
port lights up green/orange. Please refer to the LED Indicators section
for defi nitions and troubleshooting.
Connecting to a Router or Other Switch
Connecting the XFS-1084P to a Router and Devices
When a device is properly connected, the Link/Activity/Speed LEDs
for each port lights up green. Please refer to the LED Indicators section
for defi nitions and troubleshooting.
NOTE: ports 1-4 are the POE ports and should not be used
for the uplink connection

LUX-QIG-XFS-1084P
