Lynx greenMachine HDR Static User manual

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
1 |P a g e
Introduction
This quick reference guide provides information related to the greenMachine HDR Static initial setup and configuration. The greenMachine
HDR Static, 1 RU half 19” rackmount, is a real-time broadcast-quality HDR to SDR, SDR to HDR, or cross-standards HDR to HDR
converter with frame sync supporting formats up to 4K UHD (3840x2160). HDR Static applies color and contrast parameters equally
throughout a specific piece of content, i.e. an average brightness/color range is determined across an entire program.
HDR Static greenMachine processor has an advanced algorithm that overcomes the issues arising from “round-tripping” SDR>HDR>SDR.
The SDR signal at the production end and the distribution end of the round trip are visually identical, making the whole SDR>HDR>SDR
conversion process transparent. Supporting 4 x 3G or 1x 4K/UHD processing channel, HDR Static provides up, down, and cross-
conversions in HDR and SDR curves through appropriate static tone mapping. It also supports Wide Color Gamut (WCG) needs of
broadcasters, and professional AV live events requirement. HDR Static is most suitable for the environments outdoor/ indoor where the
light conditions do not change dynamically.
This Quick Reference Guide is designed to help you setup greenMachine HDR Static and provides the step-by-step instructions to
configure your HDR Static constellation to achieve the best possible up/down/cross conversion between HDR and SDR for your
operations. For additional information, please refer to the “HDR Static Reference Manual.”
Unpacking greenMachine HDR Static
The greenMachine HDR Static comes with the following items:
1x Static HDR Conversion Constellation: GMC-HDR-STATIC-titan
1x greenMachine Titan: GM6840
1x external power supply (RPS 6120)
1x power cord (EU, UK or US)
1x SubD 25 audio adapter PCB
1x quick reference guide
1x warranty card
Quick Reference Guide

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
2 |P a g e
Quick-Setup Guide
The following sections will guide you in setting up a new greenMachine HDR Static. The quick setup is divided into two sections:
Section 1: This section will demonstrate the initial preparation of hardware and software setup
Section 2: This section will demonstrate the HDR Static setup configured in Quad 3G Channel (four discrete 3G SDI) mode or 4K UHD
mode for HDR<>SDR conversion.
Section 1: greenGUI (Software) and greenMachine (Hardware) setup
This section will demonstrate how to setup greenGUI software on a PC or MAC and will also demonstrate how to set up the greenMachine
hardware.
1. greenGUI Installation
If you do not already have the greenGUI software installed on your PC or MAC, then download and install the greenGUI software
from Lynx Technik AG website from the link below:
https://www.lynx-technik.com/downloads/greengui/
Install and start the greenGUI software on your PC or MAC.
2. greenMachine Network Connection
Connect the greenMachine via LAN Port to the same network with your PC or MAC on which the greenGUI is installed.
Power up the greenMachine and wait for it to finish booting.

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
3 |P a g e
greenMachine Static in Quad 3G Config.
greenMachine Static in 4K UHD Config.
3. IP Network Settings
The greenMachine is a networked device and may require network settings for it to be connected to the network. By default, the
IP setting of the greenMachine is set to DHCP. If the network to which greenMachine is connected uses a DHCP server, then the
greenMachine will automatically capture the IP address and other settings. The greenMachine will appear on the greenGUI.
If the network to which greenMachine is connected to does not have a DHCP server, then configure the IP settings manually from
the front panel of the greenMachine as shown in the steps as below:
Press the “System” button to access the Menu
Using the rotary knob, highlight “IP settings” and press to enter
Highlight IP mode and rotate the knob to select “static” in the middle
of the screen and press to enter (default is DHCP mode).
Using the menu system and rotary control, make the required
manual numeric entries for the IP address, Gateway, and Netmask.
Please ask your network/IP support for the settings if needed.
Note : The values given in the pictures above are for demonstration purposes only.
Once IP settings are completed, exit the IP setting menu. The greenMachine will now be visible on the greenGUI
running on your PC or MAC.
1
2
1
2
3
3
4
4
4
4

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
4 |P a g e
greenMachine Static in Quad 3G Config.
greenMachine Static in 4K UHD Config.
4. Video/Audio Connection
Connect your HDR Video Signal to the input port/s provided at the back panel of the greenMachine. A user can either select to
use four 3G SDI inputs or one 12G SDI/fiber input depending on the requirement. greenMachine provides four 3G SDI outputs
or one 12G SDI/fiber output.
For example, if the input video signal from the Camera or any other video source is connected to SDI input 1, on the greenMachine,
on greenGUI Control> Main would display a similar page as shown below:
Connect the input ports on the greenMachine as required, considering the limitation of each input and output port. Check
greenMachine ports detail in the back-panel picture, as shown above.
5. Reference input connection
Connect the video reference input port on the greenMachine to a reference source. In case no external input reference source is
available, the user can take the input video signal as the reference source as shown in the picture below:
greenMachine Static in Quad 3G mode
Config.
greenMachine Static in 4K mode Config.

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
5 |P a g e
6. Deploying Single 4K UHD Channel or Quad 3G channel constellation (Optional*)
Note: To enable zoom in or zoom out, users can use the mouse scroller or can double click.
* A new greenMachine HDR Static comes with the pre-deployed HDR Static constellation. In case the constellation type needs
to be changed, follow the below steps:
On the greenGUI software, click on the Universe
page
Zoom in to greenMachine. Verify the name or the IP
address of the greenMachine for which the
constellation type needs to be changed. (Reconfirm
if the correct greenMachine is selected). In case
there are many greenMachines connected on the
network, double click on the greenMachine box on
the left of the UI on the Rolodex, as shown in the
picture below in blue color, and the system will
zoom on to the correct machine.
On the right pane under the Constellation tab, use
the mouse to scroll down to HDR Static. Press the
left mouse button on the HDR Static box and drag
and drop it on the left inside the HDR Static window.
The user will see the gear Icon if done correctly,
and the window shown in next will appear.
Choose the correct type of HDR Static
constellation from the two options:
•HDR Static 4K
•HDR Static Quad
Click on the Deploy button to deploy the HDR
Static constellation
1
1
2
2
2
3
3
4
4
5
5

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
6 |P a g e
Section 2: HDR Static Configuration
This section will guide you in setting up a new greenMachine HDR Static constellation.
Note: The settings shown in this quick reference guide is for demonstration purpose only. The user should set the values and parameters
depending on the actual operational requirements and preferences. Use mouse scroller to Zoom in/out on the page Control > Main on
greenGUI.
1. HDR Static Video Parameters
Perform the following steps to set up your greenMachine HDR Static video Settings.
Note: To enable zoom in or zoom out, users can use the mouse scroller or can double click.
Go to Control > Main and click on the Video tab as shown
in the picture
The window shown in the picture will appear
Zoom in to Video Convert processing block as shown in the
The window, as shown in the picture, will appear. The page
displays the input characteristics and gives an option of
selecting the parameters for the output.
There are four tabs provided at the top of this window which
are:
Scaler: It provides a high-quality spatial converter with a
powerful region of interest (ROI) selection and scaling.
MetaData: It provides the management of the embedded
metadata of the video signal, which can be monitored and
converted. The selections provided for the MetaData are
Closed Captions, Time Code, Teletext, and Misc.
3G Level A/B: It provides automatic detection of 3G-level A
or Level B inputs and can convert between 3G level A input
signal and 3G Level B dual-link output signals.
It provides a selection for transport format for 3G-SDI
output streams (Auto, Level A, Level B -Dual Link).
For Level B, it provides options to select the stream/s in
which the audio will be embedded, as well as the stream/s
in which the audio control packet will be embedded.
Global Settings: It provides the selection of image content
for the output when no input is present/detected. The
options provided are Test Pattern, Black, or Freeze.
1
1
2
2
3
3
4
4

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
7 |P a g e
Zoom out and zoom in to Image Proc as shown in the picture
The window shown in the picture will appear.
The options provided to the user are:
1. Video Adjust
2. Color Correction
3. HDR
Click on the Video Adjust tab
In the Video Adjust settings, the user is provided with the
options for clipping YCrCb headroom, Horiz Flip, Blanking
(H/V Blanking), and video settings like Gain, Sat, Black, Hue,
and Aperture. Set the parameters as required.
Click on the Color Correction tab
In the Color Correction settings, the user is provided with
the options of changing Gain, Lift, Gamma and Offset in RGB.
It also provides gain and offset adjustments in CMYW. Click
on the tab as shown below and adjust the corresponding
parameter in the settings as required
Click on HDR Static tab
The HDR Static Panel presents Workflow, Processing and
Custom LUTs options
Select Workflow and adjust the parameters as required.
(Check description of each parameter below)
Check the description of each parameter in the HDR Static > Workflow page
For detailed information on processing parameters, refer to the HDR Static reference manual “Operations Mode.”
Setting
Description
Mode
Operation Mode
There are two options provided in Operation Mode which are bypass HDR/SDR,
STATIC and Custom LUT
5
6
5
6
7
7
8
8
9
9
10
10
10

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
8 |P a g e
Bypass HDR/SDR: Selecting this option will bypass the HDR conversion functions
such as transfer characteristics, colorimetry, and ranges. It means the incoming
signal is transparently passed through the system.
Note: In this mode, only “colorimetry” and “range” conversion of SDR signals can be
performed.
STATIC:Selecting this option activates the actual operation of HDR STATIC
constellation. It allows the user to perform up/down/cross conversion between HDR
and SDR.
Custom LUT: The Operation Mode “Custom LUT” allows users to select their own
LUTs to obtain the desired contrast, color, saturation, black and white levels. Users
are provided with 20 slots to upload up to 20 custom LUTs.
For more information on the Operation mode, refer to the HDR Static Reference
manual “Operations Mode.”
Presets
There are several useful presets provided for quick operations. The following presets
are available to the user for selection:
Input
Input Transfer
Characteristics
The following input transfer characteristics are provided: SDR, HLG, PQ-ST2084, PQ-
BT2100, Slog3, Panasonic V-log, Arri LogC, RED Log3G10, Canon C-Log2, BMD
Film
For more information on Transfer characteristics, refer to HDR Static reference
manual “Transfer characteristics.”
Input Colorimetry
The following Colorimetry is provided: BT.2020, BT.709, Sony S-Gamut, ACES, DCI-
P3, Panasonic V-Gamut, BMD Film, Canon Cinema Gamut, Arri Alexa, Red Wide
Gamut
For more information on Colorimetry, refer to the HDR Static reference manual
“Colorimetry / Gamut.”
Input Range
The following input range is provided: Full, Narrow, and Auto
Full: Full Range is the complete range of bits used for representing blacks and
whites. For example, in a 10-bit signal, 0 bit represents the black, and 1023 bit
represents the White.

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
9 |P a g e
Narrow: Narrow Range is the limited range of bits used for representing black and
whites. For example, in a 10-bit signal, 64 bit represents the Black, and 940 bit
represents the White.
Auto:In this mode, the system reads the VPID information on the signal to determine
the “Narrow” or “Full” range.
For more information on range, refer to the HDR Static Reference manual “Signal
Range.”
Mapping
Mapping Type
The tone mapping operation can be performed with two possible approaches
depending on the user cases:
1. Tone Mapping Scene Light
2. Tone Mapping Display Light
3. Direct Mapping Scene Light
4. Direct Mapping Display Light
Tone Mapping is preferred for up-and-down conversion for mapping cameras. In the
case of up-conversion, when the intent is to create a stronger HDR look and in case
of down conversion when the intent is to preserve more contrast, then the Tone
Mapping technique is preferred.
Direct Mapping is used when the intention is to preserve the SDR content and make
up-converted HDR look identical to the original SDR version, or to make the signal
from HDR camera look similar to the signal delivered by an SDR camera operated
without a “knee” function.
Scene Light mapping is used when the goal is to match the colors and relative tones
of HDR and SDR cameras.
Display Light mapping is used when the goal is to preserve the colors and relative
tones, as seen on a reference display.
For more information on Mapping, refer to the HDR Static Reference manual
“Mapping.”
Output
Output Transfer
Characteristics
The output transfer characteristics provided are SDR, HLG, PQ-ST2084, PQ-BT2100,
Slog3.
For more information on Transfer characteristics, refer to HDR Static reference
manual “Transfer characteristics.”
Output Colorimetry
The following output colorimetry is provided: Rec 709, Rec 2020, and Auto
Note: In Auto mode, the output follows the input, and no conversion takes place
For more information on Colorimetry, refer to the HDR Static reference manual
“Colorimetry / Gamut.”
Output Range
The following output range is provided: Full, Narrow, and Auto
Full: Full Range is the complete range of bits used for representing blacks and
whites. For example, in a 10-bit signal, 0 bit represents the black, and 1023 bit
represents the White.
Narrow: Narrow Range is the limited range of bits used for representing black and
whites. For example, in a 10-bit signal, 64 bit represents the Black, and 940 bit
represents the White.
Auto:In this mode, the output follows the input, and no conversion takes place. For
example, if the input range is “Narrow,” then the output range will be “Narrow.”

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
10 |P a g e
For more information on range, refer to the HDR Static Reference manual “Signal
Range.”
Select Processing in the HDR Static tab and adjust the
parameters as required
(Check description of each parameter below)
Check the description of each parameter in the HDR Static > processing page
For detailed information on processing parameters, refer to the HDR Static reference manual “Processing
Parameters.”
Setting
Description
Gain
This parameter is used to adjust the luminance of the overall image. The default value is set
to 0.00 dB and leaves the image unchanged, whilst a value less than 0.00 dB reduces the
brightness, and a value greater than the default value increases the brightness of the image.
Note: Higher value can lead to flattening of the image impression.
+12.00 dB: Extremely increased brightness
00.0 dB: Unchanged
-12.00 dB: Extremely decreased brightness
Default Value: 0.00 dB
If the image appears too dark, e.g. after an SDR-to-HDR up-conversion, a luminance gain can
be used to adjust the image and achieve better matching to the luminance of native HDR
material. This processing can be undone in case of “round-tripping” if the inverse value is
used for the reverse conversion.
Saturation
Due to the contrast conversion and a possible gain adjustment, the brightness component of
the image is altered. The change in the brightness affects the color impression, such as
saturation. If the saturation impression does not match the expectation, then the “saturation”
parameter offers the possibility in adjustment. The default value is set to 1.0, which leaves the
saturation unchanged.
2.0: Extremely increased saturation
1.0: Saturation unchanged
0.0: Extremely reduced saturation
Default Value: 1.0
Select Custom LUTs in the HDR tab to import, export and
set parameters for the Custom LUT.
For more information on Custom LUTs, refer to Custom LUTs Quick
Reference Guide.
11
11
11
12
12

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
11 |P a g e
2. HDR Static Audio settings
Perform the following steps to set up your greenMachine HDR Static audio Settings.
Click on the Audio button
The audio page is displayed on the screen
+
Click on crossbar
The following options are displayed to the users.
Click on the Dembed bar or icon if the audio is de-
embedded from the input video signal or AES bar if an
AES input source is connected to the external audio
interface female Sub-D 25 connector of greenMachine titan.
The following picture shows the crossbar:
Click on the MADI bar or icon to reveal the MADI
crossbar. The following picture shows the MADI crossbar
1
1
2
2
3
3
4
4

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
12 |P a g e
Click on Processing to change input and output audio
settings
Select Inputs and click on the icon if the audio is de-
embedded from the video or if the AES input is
connected, to display the input settings. If MADI input is
connected, then click on to display the MADI audio
settings. Adjust the audio parameters as required.
Select Outputs and adjust the audio parameters as required.
5
5
6
6
7
7

HDR Static Quick Ref Guide Rev 2.0
www.lynx-technik.com
13 |P a g e
