Lyon LS52S User manual

lyon.co.uk/user-instructions
For more detailed user information and to download a PDF copy of these instructions follow the link above or scan the QR code with your smart phone
USER INSTRUCTIONS
Lyon Equipment Limited
Units 3-7,Tebay Business Park,
Old Tebay,
Penrith,
Cumbria, United Kingdom,
CA10 3SS
Tel: [phone]
Email: [e-mail]
Web: lyon.co.uk
© Lyon Equipment 2019
UI_LS52x_17244
Small
Adjustable Comfort Seat
LS52L
LS52S
Large
UI_LS52x_17244.indd 1 18/04/2019 07:58:19
Downloaded from lyon.co.uk

2
This information to be read and kept in
conjunction with the Lyon General User
Instructions supplied with this product.
Quality assurance
Quality management system
assessed and certied as meeting the
requirements of ISO 9001.
Warning
The Adjustable Comfort Seat is not
personal protective equipment.The
Adjustable Comfort Seat must only be
used when attached to a harness and
must never be used alone!
It is not intended to reduce the effects,
or remove the potential for suspension
intolerance.
Nomenclature of parts
1. Seat suspension strap attachment
points
2. Adjustment buckle
3. Side accessory loops
4. Central accessory loop
Use
The LS52 (size S or L) Adjustable
Comfort Seat is intended to provide
additional comfort to those working in a
harness system for extended periods.
This product is not personal protective
equipment. It must only be used by
competent and responsible persons.
Maximum rated load 120 kg.
Check that this product is compatible
with the other components of your
equipment.
Preparing the Adjustable Comfort
Seat for use
Check that this product is compatible
with the other components of your
equipment.
Ensure there is no risk of entanglement
with other items of PPE which may
make them inoperable.
1
2
3
4
UI_LS52x_17244.indd 2 18/04/2019 07:58:19
Downloaded from lyon.co.uk

3
Always carry out a pre-use check of the
Adjustable Comfort Seat before each
use (see inspection).
Attach a suitable EN 362 connector
to each of the seat suspension strap
attachment points.
Attach the Adjustable Comfort Seat
to the harness in accordance with the
user instructions supplied with the
harness.The Adjustable Comfort Seat
should be attached to the dedicated
seat attachment points, or if these are
not provided, the ventral attachment
point of the harness, using the EN 362
connectors.
Ensure the connectors and Adjustable
Comfort Seat do not interefere with
the function or cause any damage to
the harness.
Ensure the gates of connectors are
secured and they do not touch or
interfere with each other.
Adjustment
To adjust the seat suspension straps
always remove the load rst.
To shorten the suspension strap pull the
free end of the strap upwards through
the adjustment buckle.
To lengthen the strap feed the webbing
back through the adjustment buckle.
Ensure the buckle grips the webbing
when the load is re-applied.
Note
It is recommended that the Adjustable
Comfort Seat should be positioned
directly under the top of the thigh.
Positioning the Adjustable Comfort Seat
further down the thigh can affect the
stability of the user.
Positioning the Adjustable Comfort
Seat for walking
Clip the central accessory loop on the
Adjustable Comfort Seat to the rear of
the harness belt using a suitable EN 362
connector.
UI_LS52x_17244.indd 3 18/04/2019 07:58:19
Downloaded from lyon.co.uk

4
Accessory loops
The accessory loops are designed to
provide a convenient point to attach
small items, e.g. knife, adjustable spanner.
The maximum recommended load for
individual loops is 5 kg.The accessory
loops are not individually tested.
Inspection
Adjustable Comfort Seats should be
subject to:
• Pre use checks
• Thorough inspections
• Interim inspections (as appropriate)
The checks should be undertaken in
good light.
Buckles should be checked for any
signs of wear, sharp edges, corrosion,
deformity of defect.
Webbing should be checked for cuts,
abrasion, burn marks, and signs of fading
which may indicate UV damage or
chemical contamination. Check stitching
for broken, cut or worn threads. Check
the buckles function correctly.
Any item showing any defect should be
withdrawn from service immediately.
Lifetime
Adjustable Comfort Seats have a
maximum lifetime of 10 years from date
of manufacture.
Materials
Buckles are stainless steel.
45 mm webbing is polyester.
38 mm webbing is polypropylene.
Seat fabric is polyamide.
Seat insert is marine plywood.
Markings
Manufacturer’s logo
Refer to user
instructions
idN Individual serial
number will be in
the formatYYDDD
12345. The rst two
digits give the year of
manufacture, the next
three digits the day of
the year from 001 to
365 and the ve digits
after is the number in
the series
LS52x Product code
End of document
UI_LS52x_17244.indd 4 18/04/2019 07:58:19
Downloaded from lyon.co.uk

lyon.co.uk/user-instructions
For more detailed user information and to download a PDF copy of these instructions and a Declaration of Conformity follow the link above or scan the QR code with your smart phone
General user
instructions
Lyon Equipment Limited
Units 3-7,Tebay Business Park,
Old Tebay,
Penrith,
Cumbria, United Kingdom,
CA10 3SS
Tel: [phone]
Email: [e-mail]
Web: lyon.co.uk
© Lyon Equipment 2019
UI_GENSCA6_19052
UI_GENSCA6_19052.indd 1 06/03/2019 13:04:18
Downloaded from lyon.co.uk

2
Notied body controlling
manufacture (where applicable)
Where items of Personal Protective
Equipment require an EU type
examination in accordance with
Personal Protective Equipment
(EU) Regulation 2016/425, the body
controlling the manufacture is:
Notied body No. 0598
SGS Fimko Oy,
P.O. Box 30 (Särkiniementie 3),
00211 HELSINKI, Finland.
WARNING
Make sure that you have read and
understood these instructions before
using this equipment.These user
instructions are to be read and kept
along with any other user information
provided.
Activities at height are hazardous and
may lead to injury or death. It is the
user’s responsibility, at all times, to
ensure that they understand the correct
use of any equipment supplied by or
through Lyon Equipment, use it only for
the purposes for which it is designed,
and practice proper safety procedures
including having a rescue plan in case of
emergency.
This product must not be used outside
its limitations, or for any purpose
other than those described in the user
instructions. Misuses forbidden in these
instructions are examples only; many
other misuses may exist which could
lead to injury or death.
Do not use combinations of items of
equipment in which the safe function of
any one item is affected or interferes
with the safe function of another.
Please note, the information in these
user instructions is not exhaustive, and
is not a substitute for comprehensive
instruction and training by a competent
person.
Lyon Equipment is not responsible
for any consequences, whether direct,
indirect or accidental, resulting from the
use of its products. If you are unsure
about the correct use of this product,
please contact us.
Who can use this equipment
This equipment should only be used
by trained, competent and responsible
persons, or the user should be under
the direct supervision of a trained,
competent and responsible person.
Activities at height should not be
undertaken by persons affected by
alcohol or drug dependence, diabetes,
epilepsy, ts, blackouts, fear of heights,
vertigo / dizziness / difculty with
balance, heart disease / chest pain, high
or low blood pressure, impaired limb
function, obesity, psychiatric illness,
musculoskeletal issues, e.g. a bad back.
UI_GENSCA6_19052.indd 2 06/03/2019 13:04:18
Downloaded from lyon.co.uk

3
General instructions for use
Equipment must be checked before
each use, to ensure it is serviceable and
operates correctly. Checks should also
be carried out during use. In addition,
a thorough inspection by a competent
inspector should be carried out in strict
accordance with these user instructions,
and a record kept of these inspections.
This product may be used with any
compatible item of equipment, keeping
in mind the limitations of each item
in the safety chain. It should be noted
that a full body harness is the only type
of harness which may be used in a fall
arrest system.
The anchor device or anchor point
is of primary importance and should
be unquestionably reliable. It should
be strong enough to withstand the
foreseeable maximum load that could
be applied e.g. in the event of a fall.
When selecting an anchor, the
anticipated directions of loading and
potential loads should be taken into
account.
Anchors should be selected and
positioned to allow work to be carried
out in such a way as to minimise the
potential for a fall and potential fall
distance, for example by keeping the
anchor point / device above the user.
Anchors should not have sharp or rough
edges which could damage equipment
(use edge protection if necessary).
On each occasion of use, verify the
free space required beneath the user in
order to avoid an impact.Always try to
place protection so that any fall will be
stopped before the user hits the ground
or any other obstruction. Remember
to allow for rope stretch and slippage
in the belay device or rope ascender /
descender. In a fall arrest situation, the
user must be protected from dynamic
forces of greater than 6 kN in the
event of a fall, e.g. by use of a fall arrest
system incorporating an EN 355 energy
absorber.
Maintaining your equipment
Wash in clean water not exceeding
30°C with pure soap and rinse in
clean cold water. Do not use chemical
products, solvents or detergents – these
should be regarded as harmful.
Due to the difculties in effectively
disinfecting equipment, we recommend
that any contaminated equipment
should be withdrawn from use and
disposed of in a suitable manner.
Equipment must be clean and dry before
storing.Always allow to dry naturally,
away from direct heat. Equipment should
be stored in a cool, dry, well-ventilated
area, away from excessive heat, high
humidity, sharp edges, corrosives,
sunlight or other sources of ultraviolet
light (UV) and other possible causes of
damage.
During transport, this product should
be protected from abrasion, mechanical
damage, chemical contamination, UV
and heat.
UI_GENSCA6_19052.indd 3 06/03/2019 13:04:18
Downloaded from lyon.co.uk

4
Textiles
Always keep textile items at
temperatures between -30°C and
+50°C.
Metal items
Always keep metal items at
temperatures between -20°C and
+60°C.
No alterations, additions or repairs may
be made to this product without the
manufacturer’s prior written consent;
if done, the repair must be carried
out by a competent person for repair
authorised by Lyon Equipment to make
the repair, and in accordance with
specied procedures.
These instructions must be strictly
adhered to.
Inspection
A thorough inspection should be
carried out at least every 6 months by
a competent inspector in accordance
with these user instructions.A record
of these checks should be kept with
the product along with these user
instructions. In addition, interim
inspections should be carried out
where products are used intensively,
or in particularly harsh environments
where damage is more likely to occur,
or where legislation or the type of
equipment make it necessary.
Pre-use and thorough inspections are
essential because the user’s level of
protection depends on the continuing
correct performance of this product.
PPE (Personal Protective Equipment)
inspection training is available from Lyon
Equipment.
Lifetime, and when to withdraw
your equipment from use
Withdraw your equipment from use if
any one of the following applies:
• It shows sign of wear and
tear / damage that may affect
performance
• Markings on the product are no
longer legible
• You suspect it may have
been exposed to chemical
contamination or extreme
temperatures
• It fails a periodic examination
• It has been used to arrest a fall or
has been excessively loaded
• It is more than 10 years after the
date of manufacture (textile items
or items with textile components).
Metal items have a potentially
indenite lifespan if stored
correctly.
• If you have any reason to doubt
that it is safe to use.
It is the responsibility of the competent
inspector to decide whether the
equipment should be put back into use,
or permanently withdrawn from use.
Equipment permanently withdrawn from
use must be destroyed, and should be
recycled where facilities exist.
Certain environmental elements will
considerably accelerate wear: salt, sand,
dust, snow, ice, moisture, chemicals,
sunlight (UV radiation) – list not
exhaustive.
UI_GENSCA6_19052.indd 4 06/03/2019 13:04:18
Downloaded from lyon.co.uk

5
Warning: the safe working life of this
product may be as short as its rst use
in extreme circumstances.
If in doubt, do not hesitate to scrap this
product.
Guarantee
In the event of any defect in materials
or workmanship please return the
product to the dealer, distributor or
manufacturer within 3 years of purchase
for inspection.We will replace or
repair as required.This guarantee does
not cover normal wear and tear or
accidental damage.
Note to resellers
If the product is re-sold outside the
UK and Eire, but within the EU, the
reseller is responsible for providing
instructions for use, maintenance,
periodic examination and for repair in
the language of the country in which the
product is to be used.
If you require the Intrastat commodity
code / customs tariff code or NATO
stock number (where applicable) for
this product, please contact us via
lyon.co.uk
Inspection records
A record must be kept for each
component, subsystem and system,
including name and contact details of
the manufacturer or supplier, product
description, serial number, year of
manufacture, date of purchase, date of
rst use, any other relevant information,
and history of periodic examinations
and repairs, the name and signature of
the competent inspector and the next
due date for inspection.An example of
a suitable equipment record is shown
on this user instruction and can also be
downloaded at lyon.co.uk
Local jurisdiction may dictate that
extra information be recorded in
the inspection record – check your
country’s legal requirements. Some
products may have features which need
special monitoring during periodic
inspections, e.g. wear indicators, in
which case this information should also
be recorded on the inspection record.
UI_GENSCA6_19052.indd 5 06/03/2019 13:04:18
Downloaded from lyon.co.uk

6
This page deliberately left blank
UI_GENSCA6_19052.indd 6 06/03/2019 13:04:18
Downloaded from lyon.co.uk

7
250kg
SWL
Explanation of symbols
Refer to user instructions
Permitted use
Caution
Danger of death
Telephone number
Anchor point
Rope diameter
Cable
SWL
(Safe Working Load)
UI_GENSCA6_19052.indd 7 06/03/2019 13:04:18
Downloaded from lyon.co.uk

Lyon Product Inspection Record
ProductProduct code
description Individual serial number
Year of
manufacture
Date of first use
Purchase date
Manufacturer Lyon Equipment Ltd. Unit 3-7 Tebay Business Park
Old Tebay Penrith CA10 3SS UK Address Other relevant information
Record of inspection and repair
Date Next due dateName and signature of competent inspectorComments
Tel. [phone]
Fax. [phone] [email protected] lyon.co.uk
Length if applicable
All user instructions supplied with this product must be kept as part of the product inspection record
Certificate of conformity number
EN
UI_GENSCA6_19052.indd 8 06/03/2019 13:04:18
Downloaded from lyon.co.uk
