M-Elec ADB-2F45U User manual

２-
p
hase Ste
pp
in
g
Motor Drive
r
ADB-2F45U
Instructions Manual
(For designers' use)
MN0228-1
Please ensure to read and understand this
Instructions Manual before using the product.
Please keep this Instructions Manual at hand
so that it is always available for reference.

ADB-2F45U
Instructions Manual
Introduction
This Instructions Manual describes the safe and proper method of handing
"2-phase Stepping Motor Driver ADB-2F45U" with emphasis on the specifications,
assuming that our readers are engaged in designing of control devices
incorporating stepping motors.
Please ensure to read and understand this Instructions Manual
before using the product.
Please keep this Instructions Manual at hand
so that it is always available for reference.
-2-

ADB-2F45U
Instructions Manual
Descriptions in this manual on safety matters:
This product must be operated and used properly.
Otherwise , or when it is operated and used erroneously, unforeseen accidents
may occur, causing physical injuries or property damages.
Majority of these accidents can be avoided if you are well informed of
hazardous circumstances in advance.
Consequently, this instructions manual describes all the hazardous and
dangerous circumstances and situations which can be foreseen and anticipated
as well as necessary precautions.
All the above descriptions are being titled by the following symbol-marks and
signal-words, namely:
Represents warnings ignorance of which can cause accidents
involving fatal or serious physical injuries.
Represents cautions ignorance of which can cause accidents
involving minor physical injuries or property damages.
󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
-3-

ADB-2F45U
Instructions Manual
Introduction
Descriptions in this manual on safety matters:
CONTENTS PAGE
１． Safety
1-1. Safety Precautions 6
1-2. Safety Information for Handling 7
２． Overview
2-1. Characteristics 10
2-2. Product Configuration 10
2-3. Appearance 10
３． Name and Function of Each Section
3-1. Signal I/O Connector（J1） 11
3-2. DC Input/Motor Output Connector（J2, J3) 12
3-3. POWER LED 12
3-4. O.H.A LED 12
3-5. Operating Section 13
４． Name and Function of Each Section
4-1. Setting STEP TABLE switch and STEP ANGLE SELECT switch 14
4-2. Setting HOLD CURRENT SELECT switch 15
4-3. Setting DRIVE CURRENT SELECT switch 16
4-4. Setting PULSE INPUT TYPE SELECT switch 17
4-5. Setting HOLD SWITCHING TIME SELECT switch 18
５． Installation
5-1. Conditions for Installation 19
5-2. Mounting Method 20
６． Connection
6-1. Overview of Connection Configuration 21
6-2. Connecting Signal I/O Connector（J1） 22
6-3. Connecting DC Input/Motor Output Connector（J2, J3） 23
6-4. Inputting Power 24
７． Confirmation of Setting and Connection
7-1. Check Points 25
-4-

ADB-2F45U
Instructions Manual
PAGE
８． Maintenance and Check-up
8-1. Maintenance and Check-up 26
8-2. Troubleshooting 27
９． Storing and Disposal
9-1. Storing 28
9-2. Disposal 28
１０． Specifications
10-1. General Specifications 29
10-2. I/O Signal
(1) Example Circuit Connection 30
(2) Drive pulse input (CW,CCW) 31
(3) Motor excitation stop input (M.F) 32
(4) Phase signal output (P.O) 33
(5) Overheat alarm signal output and overheat alarm LED (O.H.A) 34
10-3. Dimensions 35
10-4. Applicable Motors 36
10-5. Torque Characteristics 37
10-6. Conforming to Europe standards 41
The main parts which revised by this manual
-5-

ADB-2F45U
Instructions Manual
１．Safety
１－１．Safety Precautions
(1) This product is not designed or manufactured for application for equipment
requiring high level of reliability such as equipment related to nuclear
energy, aeronautics-related equipment, automobiles, ships, medical appliances
directly handling the human body and equipment that might seriously affect
properties.
(2) Do not use or keep the product in explosive or corrosive environments,
in the presence of flammable gases, locations subjected to splashing water,
fine particles, soot, steam, or exposed to radiation or direct sunshine.
Doing so may cause injury or fire.
(3) For the driver's power supply, use a DC power supply with reinforced insulation
on its primary and secondary sides.
Failure to do so may cause electric shock.
(4) This product is designed for use within machinery, so it should be installed
within an enclosure.
Failure to do so may cause injury.
(5) Do not transport, move, install the product, perform connections or inspections
when the power is on.
Doing so may cause electric shock, injury or fire.
(6) Only qualified personnel are allowed to transport, move, install the product,
perform connections or inspections.
Failure to do so may cause injury or fire.
(7) Do not touch the driver during operation or immediately after stopping.
Doing so may cause burn on the skin due to overheating of the driver.
(8) Ensure to use this product according to the method specified
in the Instructions Manual and within the specifications.
(9) Depending on the operational conditions, the stepping motor may step out when
it is on holding-state or driving-state.
In particular, the load in transport may fall if the motor steps out on the
vertical drive (such as the Z-axis).
Start operation after test run for deliberate confirmation of operation.
(10) Provide fail-safe measures so that the entire system may operate in a safe
mode even in cases of the external power supply failure, disconnection of the
signal line, or any failure on the driver.
󲨘󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
-6-

ADB-2F45U
Instructions Manual
１－２．Safety Information for Handling
●Overall:
Do not touch the driver during operation
or immediately after stopping.
it may cause burn on the skin due to
overheating of the driver.
●When setting up the STEP ANGLE SELECT switch:
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of the motor.
Ensure correct setting.
●When setting up the HOLD CURRENT SELECT switch:
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
●When setting up the DRIVE CURRENT SELECT switch:
Erroneous setting may cause burn on the
skin, injury or damage to the motor due to
overheating of the motor.
Ensure correct setting.
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
-7-

ADB-2F45U
Instructions Manual
●When setting up the PULSE INPUT TYPE SELECT switch:
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of the motor.
Ensure correct setting.
●When installing:
Overheating may cause fire.
Mount it on a noncombustible member.
Keep it away from combustibles.
●When connecting the DC Input/Motor Output Connectors (J2, J3):
Erroneous connection may cause
breakage of the motor or the driver.
Correctly connect the DC Input/Motor
output connector.
●When inputting power:
Breakage of the machine or injury is
apprehended due to unexpected behavior of
the motor. Maintain the state where
emergency stop is enabled at any time.
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
-8-

ADB-2F45U
Instructions Manual
●When inputting the motor excitation stop (M.F) signal:
Deterioration of the holding power with
the motor may cause breakage of the machine
or injury.
Check safety before inputting.
●When the overheat alarm (O.H.A) signal is output:
Overheating may cause fire.
Stop operation upon output of this signal.
●When the overheat alarm (O.H.A) LED comes on:
Overheating may cause fire.
Stop operation when this LED comes on.
●When performing maintenance and checking:
Injury or fire is apprehended due to
unexpected behavior.
Do not replace fuse.
Do not disassemble, repair or modify.
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
-9-

ADB-2F45U
Instructions Manual
２．
O
verv
i
ew
２－１．Characteristics
ADB-2F45U is a driver for a 2-phase stepping motor with DC+24V input.
Driving method is unipolar constant current type.
It can drive a 2-phase stepping motor of unipolar winding ranging from
󲨨󲨦󲨰󲨹󲨧󲩨󲩠󲩙󲩫󲩝󲨘󲩬󲩧󲨘󲨪󲨦󲨨󲨧󲩨󲩠󲩙󲩫󲩝󲨦
Step angles can be selected from fourteen step angles ranging from 1 division to
󲨩󲨨󲨨󲨘󲩜󲩡󲩮󲩡󲩫󲩡󲩧󲩦󲨘󲩧󲩞󲨘󲩬󲩠󲩝󲨘󲩚󲩙󲩫󲩡󲩛󲨘󲩙󲩦󲩟󲩤󲩝󲨦
HOLD CURRENT and DRIVE CURRENT can be set up.
２－２．Product Configuration
The product consists of the main frame and the accessories.
●ADB-2F45U One unit
●Housing for J1 (51103-1000:Molex) One unit (accessory)
●Housing for J2 (51067-0200:Molex) One unit (accessory)
●Housing for J3 (51067-0600:Molex) One unit (accessory)
●Contact for J1 (50351-8100:Molex) 12 contacts (accessories,2 for spares
)
●Contact for J2,J3 (50217-9101:Molex) 10 contacts (accessories,2 for spares
)
２－３．Appearance
-10-

ADB-2F45U
Instructions Manual
３．Name and Function of Each Section
３－１．Signal I
/
O Connector（Ｊ１）
J1
CW+
●Directs the motor to operate CW.
CW-
CCW+
●Directs the motor to operate CCW.
CCW-
M.F+
●Shuts off output current to drive the motor.
M.F-
P.O ●Outputs the signal when the motor-excitation
state is the excitation home position.
R.GND
O.H.A ●Outputs the signal when internal temperature
of the driver has reached approx. 70℃ or more.
R.GND
3
2
1
ADB-2F45U
4
6
5
10
9
8
7
CW drive pulse signal input terminal
CCW drive pulse signal input terminal
Motor excitation stop signal input terminal
Phase signal output terminal
GND terminal for P.O signal.
Overheat alarm signal output terminal
GND terminal for O.H.A signal.
-11-

ADB-2F45U
Instructions Manual
３－２．DC Input
/
Motor Output Connector（Ｊ２，Ｊ３）
ADB-2F45U
J3
●Outputs current to drive the motor.
●Power input terminal.
DC power supply is connected.
３－３．POWER LED
POWER LED(GREEN) comes on upon inputting power.
３－４．O.H.A LED
O.H.A LED（RED）comes on when internal temperature
of the driver has reached approx. 70℃ or more.
6
A.COM 5
B.COM
4B
1A
A
B
2
3
0V DC- 2
J2
DC+24V DC+ 1
Motor output terminal
DC input terminal
-12-

ADB-2F45U
Instructions Manual
３－５．Operating Section
4
3
2
1
4
3
2
1
4
3
2
1
4
3
2
1
STEP ANGLE SELECT switch
Sub adjustment switch Use it with OFF.
Name of Operating Section Function
Use it with OFF.
Factory Setting
〔ON(5S)〕
SC：〔OFF〕
SB：〔ON〕
3：〔OFF〕
Factory Setting
4：〔OFF〕
Selects a step angle.
Name of Operating Section Function Factory Setting
Factory SettingName of Operating Section Function
DRIVE CURRENT
SELECT switch 〔No.5〕
Selects DRIVE CURRENT.
STEP ANGLE SELECT switch
HOLD CURRENT SELECT switch H1：〔ON〕
Selects HOLD CURRENT. H2：〔OFF〕
Name of Operating Section Function
HOLD CURRENT SELECT switch
STEP TABLE switch Selects STEP TABLE.
Sub adjustment switch 1：〔OFF〕
STEP ANGLE SELECT switch SA：〔OFF〕
Sub adjustment switch
Sub adjustment switch
Use it with OFF.
Use it with OFF.
2：〔OFF〕
HOLD SWITCHING TIME
SELECT switch
DRIVE/HOLD CURRENT automatic switching
time is selected. 〔OFF(150ms)〕
PULSE INPUT TYPE SELECT
switch Selects a pulse input type. 〔OFF(2P)〕
Name of Operating Section Function Factory Setting
Sub adjustment switch Use it with ON.
Sub adjustment switch Use it with ON.
〔ON(IH)〕
Sub adjustment switch Use it with ON.
Sub adjustment switch Use it with ON.
-13-

ADB-2F45U
Instructions Manual
４．Function Set-up by Use
４－１．Setting STEP TABLE switch and STEP ANGLE SELECT switch
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of motor.
Ensure correct setting.
The step angle is set up with the S.T SEL switch and
the STEP SEL switch.
The step angle can be selected from fourteen different
types of step angles.
Set S.T SEL switch with power OFF.
The switches are factory-set to [50 divisions].
(1) Turn power [OFF].
(2) Set the step angle required by combining the S.T SEL switch
and the STEP SEL switch.
●Relationship between the S.T SEL switch, the STEP SEL switch and the step
angle.
(Factory setting)
1/2 0.9
ON
ON ON OFF
1/1 1.8
1/
Divisions
Step angle(°)
SC SB SA 1.8°motor
ON
OFF
1/100 0.018
OFF
1/25 0.072
1/50 0.036
OFF
1/10 0.18
1/20 0.09
ON ON ON
ON ON OFF
1/2.5 0.72
1/5 0.36
1/
Divisions
Step angle(°)
1.8°motor
STEP SEL switch
SC SB SA
ON OFF ON
ON OFF
ON OFF OFF
OFF ON
ON
ON ON
STEP SEL switch
OFF OFF OFF
0.45
ON OFF OFF 1/8 0.225
ON OFF ON 1/4
OFF ON ON 1/16
S.T SEL switch〔ON：5S〕
S.T SEL switch〔OFF：2S〕
OFF OFF ON 1/64
0.1125
OFF ON OFF
- -
OFF OFF OFF - -
0.028125
1/32 0.05625
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
-14-

ADB-2F45U
Instructions Manual
４－２．Setting HOLD CURRENT SELECT switch
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
HOLD CURRENT is set up with the HOLD I. SEL switch.
The ratio of HOLD CURRENT to DRIVE CURRENT can be selected.
The switch is factory-set to [approx 40%].
(1) Set the HOLD I.SEL switch to the ratio of HOLD CURRENT to DRIVE CURRENT
required.
●Relationship between the HOLD CURRENT.
HOLD CURRENT
DRIVE CURREN
T
（Factory setting）
●
HOLD CURRENT changes relative to DRIVE CURRENT setting.
The ratio of HOLD CURRENT [100%] represents the same as the setting for
DRIVE CURRENT.
●
The effective range of the HOLD I.SEL switch varies according to the setting
of the DRIVE I.SEL switch.
●
The greater the ratio of HOLD CURRENT grows, the more heat the motor
generates when is on holding-state.
× 100
100
50
－
40
＝
DRIVE I.SEL〔No.0～No.2〕
Ratio of
HOLD CURRENT(%)
HOLD I.SEL switch
ON ON
OFF OFF
OFF ON
ON OFF
DRIVE I.SEL〔No.3～No.9〕
HOLD I.SEL switch Ratio of
HOLD CURRENT(%)
H2 H1
H1H2
ON 100
OFF OFF 30
OFF ON 40
－
ONON
50
OFFON
40
ONOFF
30
OFFOFF
R
atio of HOLD CURRENT（％）
DRIVE I.SEL〔No.A～No.F〕
H1H2
Ratio of
HOLD CURRENT(%)
HOLD I.SEL switch
ON OFF 50
ON
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
-15-

ADB-2F45U
Instructions Manual
４－３．Setting DRIVE CURRENT SELECT switch
Erroneous setting may cause burn on the
skin, injury or damage to the motor due to
󲩧󲩮󲩝󲩪󲩠󲩝󲩙󲩬󲩡󲩦󲩟󲨘󲩧󲩞󲨘󲩬󲩠󲩝󲨘󲩥󲩧󲩬󲩧󲩪󲨦
Ensure correct setting.
DRIVE CURRENT is set up with the DRIVE I.SEL switch.
The switch is factory-set to [No.5].
(1) Set the switch No. to the setting specified in the table "10-4. Applicable Motors."
● Relationship between the DRIVE I.SEL switch and DRIVE CURRENT.
(Factory setting)
Switch No. A/phase
０
１
0.50
0.60
２
３
0.70
0.80
４
５
0.90
1.00
６
７
1.10
1.20
８
９
1.30
1.40
Ａ
Ｂ
1.50
1.60
Ｃ
Ｄ
1.70
1.80
Ｅ
Ｆ
1.90
2.00
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
-16-

ADB-2F45U
Instructions Manual
４－４．Setting PULSE INPUT TYPE SELECT switch
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of motor.
Ensure correct setting.
Pulse input method is set up with the SPI SEL switch.
Set this switch with power OFF.
The switch is factory-set to [2P].
(1) Turn power [OFF].
(2) Set the SPI SEL [2P/1P] switch.
●When the motor is operated with two pulse signal inputs of CW and CCW,
set the SPI SEL switch to [OFF(2P)].
●When the motor is operated with the pulse signal and direction signal
input, set the SPI SEL switch to [ON(1P)].
● In the case that 1-pulse input method is selected, the CCW terminal becomes
direction signal input designating the direction of the motor rotation.
Drive pulse set to the CW terminal(CW+,CW-).
● The input timing is same with 2-pulse input method and 1-pulse input method .
As for input timing, refer to "10-2. (2)Drive pulse input（CW, CCW)"
（Factory setting）OFF 2PULSE (2P)
SPI SEL Input type
ON 1PULSE (1P)
󲨘󲨻󲨹󲩍󲩌󲩁󲩇󲩆
CCW terminal(CCW+,CCW-)
direction set
Photo-cou
p
ler OFF： CCW direction
Photo-cou
p
ler ON ： CW direction
-17-

ADB-2F45U
Instructions Manual
４－５．Setting HOLD SWITCHING TIME SELECT switch
DRIVE/HOLD CURRENT automatic switching time is set up
with the DHT SEL switch.
The switch is factory-set to [150ms].
(1) Set the DHT SEL switch.
（Factory setting）
Hold Switching
Time
DHT SEL
ON
OFF
16ms
150ms
-18-

ADB-2F45U
Instructions Manual
５．
I
nsta
ll
at
i
on
５－１．Conditions for Installation
Overheating may cause fire.
Mount it on a noncombustible member.
Keep it away from combustibles.
(1) Designed for incorporating into equipment used indoors, this product requires
to be installed in the following environment:
●Indoors (where it is not exposed to direct sun).
●Where ambient temperature and humidity are controlled within the range set
out in the specifications.
●Where there is no explosive, corrosive or inflammable gas.
●Where it can be protected from dust, salt or iron powder.
●Where the product main frame is not exposed to direct vibration or shock.
●Where it is not exposed to splashes of water, oil or chemicals.
(2) Install the driver at least 15mm away from other equipment.
(3) Considering heat release, control the ambient temperature around the driver
within the specified value.
●
Take measures against accumulation of heat such as allowing generous space
around the driver or installing a fan so that heat release is taken care of.
●
Install the driver securely in contact with metal or other substance with
adequate heat conductivity.
(4) In the case that the overheat alarm signal is output, perform the cooling measure
of the mounting plate is enlarged or compulsion air cooling etc.
Use the driver on the condition that the overheat alarm signal is not output.
(5) Do not allow standing or placing anything heavy on the product.
ADB-2F45U ADB-2F45U
󲨘󲩏󲨹󲩊󲩆󲩁󲩆󲨿
15mm or more
15mm or more
15mm or more
15mm or more
-19-

ADB-2F45U
Instructions Manual
５－２．Mounting Method
The round holes on the main body are used.
The following items are required:
(1) Fix the product at the two round holes on the main body.
●Mounting example
2●M-3 screw (8mm or more in length):
2
2
●M-3 spring washer:
●M-3 flat washer:
-20-
