M-system R5-MS User manual

BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■PACKAGE INCLUDES:
Potentiometer input module ............................................. (1)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
POINTS OF CAUTION
■CONFORMITY WITH EU DIRECTIVES
• The equipment must be mounted inside the instrument
panel of a metal enclosure.
• The actual installation environments such as panel con-
figurations, connected devices, connected wires, may af-
fect the protection level of this unit when it is integrated
in a panel system. The user may have to review the CE
requirements in regard to the whole system and employ
additional protective measures to ensure the CE conform-
ity.
■HOT INSERTION/REMOVAL OF MODULES
• Removing or replacing modules does not affect other mod-
ules on the same backplane. It is possible to replace them
without removing the power supply. However, replacing
multiple modules at once may greatly change line voltage
levels. We recommend that you replace them one by one.
■GENERAL PRECAUTIONS
• DO NOT set the switches while the power is supplied.
The switches are used only for maintenance without the
power.
■ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
INSTALLATION
Use the Installation Base (model: R5-BS).
POTENTIOMETER INPUT MODULE MODEL R5-MS
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-6146 Rev.2 P. 1 / 3
INSTRUCTION MANUAL

COMPONENT IDENTIFICATION
■FRONT VIEW
RUN LED
Zero/Span Adj.
Mode Selector
5
4
3
2
1
0
9
8
7
6
456
123
RUN
SET
SET Button
Euro Type
Connector Terminals
■ZERO/SPAN ADJ. MODE SELECTOR ROTARY SW
SW MODE FUNCTION RUN LED
0 (*) Run Output % proportional to the Input % Red/Green ON *1
1 Input 1 0% adjust Apply 0% input at Input 1 and press SET Red Blinking
2 Input 1 100% adjust Apply 100% input at Input 1 and press SET Red Blinking
3 Input 2 0% adjust Apply 0% input at Input 2 and press SET Green Blinking
4 Input 2 100% adjust Apply 100% input at Input 2 and press SET Green Blinking
5 – 9 Not used
(*) Factory setting
*1. RUN indicator: Bi-color (red/green) LED; Red when the bus A operates normally; Green when the bus B operates normally; Amber
when both buses operate normally.
• Zero/Span Adjustment Modes
Run Mode
Normal operating mode
Input 0% Adjustment Mode
Apply the actual 0% input and press SET.
Input 100% Adjustment Mode
Apply the actual 100% input and press SET.
• How to Operate
1) Start up in Monitor Mode (SW position = 0) and wait for 2 or 3 seconds.
2) Switch to another mode and go through the adjustments.
3) Reset the switch to the position ‘0’ so that the new setting is stored in the internal memory.
• Cautions on the LEDs
1) Mode switching from Run to another mode becomes effective when SET button is touched and the LED for the respective
mode starts blinking after the rotary switch setting has been changed.
2) Mode switching back to Monitor becomes effective automatically in a few seconds after the switch is reset to ‘0’ and is con-
firmed with the LED stopping blinking.
PC CONFIGURATOR
With configurator software, settings shown below are available.
Refer to the software manual of R5CON for detailed operation.
■CHANNEL INDIVIDUAL SETTING
PARAMETER AVAILABLE RANGE DEFAULT SETTING
Zero Scale -32000 to +32000 0
Full Scale -32000 to [phone]
Bias [Zero Adj.] -320.00 to +320.00 0.00
Gain [Span Adj.] -32000 to +32000 1.0000
R5-MS
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-6146 Rev.2 P. 2 / 3

TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■EXTERNAL DIMENSIONS unit: mm (inch)
456
123
6.5
(.26)
90 (3.54) LOCKING CLAMP
90 (3.54) 5.6
(.22)
18 (.71)
POSITIONING GUIDE
*Euro type connector terminals (4, 5 and 6) provided only with 2-ch. option.
*
■CONNECTION DIAGRAM
INPUT 1
INPUT 2
BUS CONNECTOR
INTERNAL POWER
*For dual redundant communication.
Note: The section enclosed by broken line is with 2-ch. option.
+
–
1
2
3
2
1
POTENTIOMETER
max.
min. 3
+
–
4
5
3
2
1
POTENTIOMETER
max.
min. 6
INTERNAL
BUS A
INTERNAL
BUS B*
WIRING INSTRUCTIONS
■EURO TYPE CONNECTOR TERMINAL
Applicable wire size: 0.2 to 2.5 mm2
Stripped length: 7 mm
R5-MS
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-6146 Rev.2 P. 3 / 3
