M7 DJS-101A User manual

GERNERAL SAFETY RULES
GERNERAL POWER TOOL
SAFETY WARNINGS
WARNING:
!
Read all safety warnings and instructions!
WORK AREA SAFETY
ELECTRICAL SAFETY
Failure to follow the warnings and instructions
may result in electric shock, re and / or
serious injury.
SAVE ALL WARNINGS AND
INSTRUCTIONS FOR FUTURE
REFERENCE.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
1. Keep the work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
1. Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs
and matching outlets will reduce risk of
electric shock.
2. Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
4. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging the
power tool. Keep the cord away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a ground-fault circuit
interrupter (GFCI) protected supply. Use of
a GFCI reduces the risk of electric shock.
1. Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use the tool while tired
or under the inuence of drugs, alcohol, or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment
such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection,
used for appropriate conditions, will reduce
personal injuries.
3. Prevent unintentional starting. Ensure
that the switch is in the o󰀨-position before
connecting to a power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your nger
on the switch or energizing power tools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part
of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
PERSONAL SAFETY
1

GERNERAL SAFETY RULES
POWER TOOL USE AND CARE BATTERY TOOL USE AND CARE
6. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
7. Use the power tool, accessories, tool bits,
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations di󰀨erent from
those intended could result in a hazardous
situation.
8. Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do
not allow for safe handling and control of
the tool in unexpected situations.
1. Recharge only with the charger specied
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of re when used with another
battery pack.
2. Use power tools only with specically
designated battery packs. Use of any other
battery packs may create a risk of injury
and re.
3. When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a re.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, ush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
5. Do not use a battery pack or tool that
is damaged or modied. Damaged
or modied batteries may exhibit
unpredictable behavior resulting in re,
explosion or risk of injury.
6. Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught
in moving parts.
7. If devices are provided for the connection
of dust extraction and collection facilities,
ensure that these are connected and
properly used. Use of these devices can
reduce dust-related hazards.
8. Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause
severe injury within a fraction of a second.
1. Do not force the power tool. Use the
correct power tool for your application. The
correct power tool will do the job better
and more safely at the rate for which it was
designed.
2. Do not use the power tool if the switch
does not turn it on and o󰀨. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
3. Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
4. Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
5. Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may a󰀨ect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
2

SAFETY INSTRUCTIONS
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May be
used in conjunction with other symbols or pictographs.
Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could
result in minor or moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
SAVE THESE INSTRUCTIONS!
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols and the explanations with them deserve your careful attention and understanding. The
symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings
they give are no substitutes for proper accident prevention measures.
Be sure to read and understand all safety instructions in this manual,
including all safety alert symbols such as “DANGER,” ”WARNING,” and “CAUTION”
before using this tool. Failure to following all instructions listed below may result in
electric shock, re, and/or serious personal injury.
WARNING:
!
!
DANGER:
!
WARNING:
!
CAUTION:
!
SERVICE
6. Do not expose a battery pack or tool to re
or excessive temperature. Exposure to re
or temperature above 130 °C (265 °F) may
cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside
the temperature range specied in the
instructions. Charging improperly or at
temperatures outside the specied range
may damage the battery and increase the
risk of re.
Storage Recommendations
1. The best storage place is one that is cool
and dry, away from direct sunlight and
excessive heat or cold.
2. For long storage, it is recommended to
store a fully charged battery pack in a coo
dry place out of the charger for optimal
results.
Note : The battery pack will need to be
recharged before use.
Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the
power tool is maintained.
3

SAFETY SYMBOLS
Some of these following symbols may be used on this tool. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the tool better and
more safely.
SYMBOL Name Designation / Explanation
Volts Voltage
Amperes Current
Hertz Frequency (Cycles Per Wecond)
Watts Power
Alternating Current Type Of Current
Direct Current Type Or Characteristic Of Current
No-load Speed Rotational Speed At No Load
Pounds Weight
Class II Construction
Wear Safety Goggles
Double Insulated Construction
The operation of any
power tool can result in foreign objects
being thrown into your eyes, which can
result in severe eye damage. Before
beginning power tool operation, always
wear safety goggles or safety glasses
with side shields and a full-face shield
when needed. We recommend a Wide
Vision Safety Mask for use over eye-
glasses or standard safety glasses with
side shields. Always use eye protection
which is marked to comply with ANSI
Z87.1.
Per Minute Revolutions, Strokes, Surface Speed
Orbits, etc., Per Minute
To ensure safety and reliability, all repairs should be performed by a
qualied service technician.
V
A
Hz
W
.../min
lbs
n
WARNING:
!
WARNING:
!
4

SPECIFIC SAFETY RULES
1. To reduce the risk of electric shock or
damage to the chargers and batteries,
use only with the m7 battery packs and
chargers listed below:
2. Hold the power tool by its insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring or its own cord. Contact with a “live”
wire will make exposed metal parts of the
tool “live” and shock the operator.
3. Use clamps or another practical way to
secure and support the workpiece to a
stable platform. Holding the work by hand
or against your body leaves it unstable and
may lead to loss of control.
4. When using the jigsaw, use safety
equipment including safety goggles or
shield, ear protection, dust mask and
protective clothing including safety gloves.
5. Ensure that the lighting is adequate.
6. Do not use the saw unless the guards are
in place.
7. Keep the shoe plate on the workpiece.
8. Do not put pressure on the saw, such that
it slows the motor down. Allow the saw
blade to cut without pressure. You will get
better results and you will be taking better
care of your tool.
9. Keep the area free of tripping hazards.
10. Do not let anyone under 18 years operate
this jigsaw.
11. Only use blades in good condition.
12. Before cutting, check that there is
su󰀩cient clearance for the blade under
the workpiece.
13. Only use blades in good condition.
14. Do not touch the blade after operation, it
will be very hot.
15. Keep your hands away from under the
workpiece.
16. Never use your hands to remove sawdust,
chips or waste close to the blade.
17. Rags, cloths, cord, string and the like
should never be left around the work
area.
18. Avoid cutting nails. Inspect the workpiece
and remove all nails and other foreign
objects before beginning sawing.
19. Never reach over the blade to remove
waste or o󰀨 cuts.
20. Do not attempt to free a jammed blade
before rst switching o󰀨 the machine.
21. If you are interrupted when operating the
saw, complete the process and switch o󰀨
before looking up.
22. Periodically check that all nuts, bolts and
other xings are properly tightened.
23. Do not store materials or equipment
above a machine in such a way that they
could fall into it.
24. Do not secure the jigsaw upside down in
a vice or work bench and use it as a saw
bench. This can lead to serious injury.
SPECIFIC SAFETY RULES FOR
CORDLESS JIG SAW
Battery pack Charger
DB-1840
DB-1850
DB-1850P
DC-18A
5

SAFETY RULES FOR CHARGER
1. Before using battery charger, read all
instructions and cautionary markings in
this manual and on the battery charger, the
battery and the product using the battery
to prevent misuse of the products and
possible injury or damage.
2. Do not use the charger outdoors or expose
it to wet or damp conditions. Water entering
the charger will increase the risk of electric
shock.
3. Use of an attachment not recommended or
sold by the battery-charger manufacturer
may result in a risk of re, electric shock or
injury to persons.
4. Do not abuse the cord or charger. Never
use the cord to carry the charger. Do not
pull the charger cord to disconnect the plug
from receptacle. Damage to the cord or
charger could occur and create an electric
shock hazard. Replace damaged cords
immediately.
5. Make sure that the cord is located so that it
will not be stepped on, tripped over, come
in contact with sharp edges or moving
parts, or otherwise subjected to damage
or stress. This will reduce the risk of
accidental falls, which could cause injury
and damage to the cord, which could then
result in electric shock.
6. Keep cord and charger from heat to
prevent damage to housing or internal
parts.
7. Do not allow gasoline, oils, petroleum-
ased products, etc. to come in contact
with plastic parts. These materials contain
chemicals that can damage, weaken, or
destroy plastic.
CAUTION:
!
To reduce the risk of electric shock or
damage to the charger and battery, charge
only those lithium-ion rechargeable batteries
as specially designated on your charger’s
label. Other types of batteries may burst,
causing personal injury or damage.
SPECIFIC SAFETY RULES
•Lead from lead-based paints
•Crystalline silica from bricks, cement, and
other masonry products
•Arsenic and chromium from
chemicallytreated lumber
People with electronic devices, such as
pacemakers, should consult their physician(s)
before using this product. Operation of
electrical equipment in close proximity to a
heart pacemaker could cause interference or
failure of the pacemaker.
Some dust created by
power sanding, sawing, grinding, drilling
and other construction activities contains
chemicals known to the state of California
to cause cancer, birth defects or other
reproductive harm. Some examples of
these chemicals are:
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to lter out microscopic particles.
DANGER:
!
WARNING:
!
6

8. An extension cord should not be used
unless absolutely necessary. Use of an
improper extension cord could result
in a risk of re and electric shock. If an
extension cord must be used, make sure
that:
9. Do not operate the charger with a
damaged cord or plug, which could cause
shorting and electric shock. If damaged,
have the charger repaired or replaced
by an authorized service technician at
Service Center.
10. Do not operate the charger if it has
received a sharp blow, been dropped, or
has otherwise been damaged in any way.
Take it to an authorized service technician
at Service Center for an electrical
check to determine if the charger is in
good working order.
11. Do not disassemble the charger. Take it
to an authorized service technician at a
. Service Center when service or repair
is required. Incorrect reassembly may
result in a risk of electric shock or re.
12. Unplug the charger from the electrical
outlet before attempting any maintenance
or cleaning to reduce the risk of electric
shock.
13. Disconnect charger from the power
supply when not in use. This will reduce
the risk of electric shock or damage to the
charger if metal items should fall into the
opening. It will also help prevent damage
to the charger during a power surge.
14. Risk of electric shock. Do not touch the
uninsulated portion of output connector or
uninsulated battery terminal.
The pins on plug of extension cord are the
same number, size and shape as those of the
plug on charger.
The cord is properly wired and in good
electrical condition.
The size is large enough for AC ampere
rating of charger as specied below:
The Cord Length (Feet) 25’ 50’ 100’
Cord Size (AWG) 16
NOTE: AWG = American Wire Gauge
15. Save these instructions. Refer to them
frequently and use them to instruct others
who may use this tool. If you lend this
tool to someone else, also lend these
instructions to them to prevent misuse of
the product and possible injury.
Some dust created by power Cutting contains
chemicals known to cause cancer, birth
defects or other reproductive harm. Some
examples of these chemicals are:
WARNING:
!
lead from lead-based paintslead from
lead-based paints
Arsenics and chromium from chemically
reacted lumber.reacted lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area, and
work with approved safety equipment.
7

Lock-o󰀨 Button
Cutting Angle Guide
Blade Clamp
Lever
Tool-less Blade
Clamp
Trigger Switch
Blade Guard
Blade
Hex Key
Shoe Plate
Blade Roller
Guide
Parallel Guide
Locking Screw
LED Worklight
Orbital Control lever
OVERVIEW
SPECIFICATIONS
Rated Voltage 18 V d.c.
No load Speed 0-2200 SPM
Blade stroke distance 1 in. (25 mm)
Cutting angle range 0-45°
Blade compatibility “ T” and “U” shank
Max. cutting capacity
65mm on wood
10mm on aluminum
6mm on steel
Charger input (V) 220-240~
Allowable temperature range (°C) 5-40
Weight (without battery) 4lbs. 3oz.
Sound Pressure (dBA)
Sound pressure (Uncertainty K = 3 dB(A))
Sound power level (Uncertainty K = 3 dB(A))
Vibration level (m/s²)
(Uncertainty K = 1.5 m/s²)
84.6 dBA
94.3 dBA
2.3 m/s²
8

1. LED FUNCTIONS OF CHARGER
2. POWER BAR
3. LOW-BATTERY CAPACITY INDICATOR
4. WHEN TO CHARGE THE BATTERY
PACK
This Lithium-Ion battery pack is equipped with a POWER BAR, which is used to display the
battery pack’s remaining run time. Press the POWER BAR button to display the LED lights.
The LED lights will stay lit for approximately 4 seconds.
NOTE: The POWER BAR can be used whether the battery is attached or removed from tool.
• If LED worklights on the POWER BAR
begins to rapidly and continuously ash
when the trigger switch on the wrench is
depressed, the battery pack’s power has
run out, and the battery pack should be
recharged.
•Unlike other battery pack types, Lithium-
Ion battery packs deliver fade-free
power for their entire run time. The
tool will not experience a slow, gradual
loss of power as you work. To signal
that the battery pack is at the end of its
run time and needs to be charged, the
power to the tool will drop quickly. The
POWER BAR will begin to display four
ashing LED lights when the battery
is completely discharged. When this
happens, remove the tool from the
workpiece, and charge the battery pack
as needed.
• Use the POWER BAR to determine when
you need to recharge the battery pack.
• You can “top-o󰀨” your battery pack’s charge
before starting a big job or long period of
use.
NOTE: The POWER BAR may also display
four ashing LED lights due to an overload or
high temperature situation.
The Lithium-Ion battery can be charged at
any time and will not develop a “memory”
when charged after only a partial discharge.
It is not necessary to run down the battery
pack charge before recharging. Remove the
battery pack from the tool when convenient
for you and your job.
LED INDICATOR
HI/LO TEMP.
(SEE MANUAL)
DEFECTIVE
BATTERY
BATTERY
CHARGING
BATTERY
FULL
BATTERY PACK
Hot/Cold battery On O󰀨 Charging will begin when battery
returns to 0°C-40°C
Defective Flashing O󰀨 Battery pack or Charger is
defective
Charging O󰀨 Flashing Charging
Fully charged O󰀨 On Charging is complete
Maintenance charging
RED LED GREEN LED ACTION
40-59% Charge
60-79% Charge
80-100% Charge
20-39% Charge
Under 20% Charge
Completely Discharged
High/Low Temperature
9

ASSEMBLY
UNPACKING
CONTENTS
If any part is broken or missing, do not
attempt to plug in the power cord or operate
the tool until the broken or missing part is
replaced. Failure to do so could result in
possible serious injury.
Do not attempt to modify this circular saw
or create accessories not recommended
for use with this saw. Any such alteration or
modication is misuse and could result in
a hazardous condition leading to possible
serious injury.
To prevent accidental starting that could
cause serious personal injury, always remove
the battery pack from the circular when
assembling parts.
1. Carefully remove the tool and any
accessories from the carton. Make sure
that all items listed in the packing list are
included.
2. Inspect the tool carefully to make sure that
no breakage or damage occurred during
shipping.
3. Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the tool.
•Cordless Jig Saw
•Parallel Guide
•3pcs Blades
•Hex Key and Operator’s Manual
WARNING:
!
WARNING:
!
WARNING:
!
10

ASSEMBLY
TO ATTACH THE BATTERY PACK
(FIG.1) SWITCHING ON AND OFF (FIG. 2)
VARIABLE SPEED TRIGGER
SWITCH (FIG. 2)
ELECTRIC BRAKE
TO ATTACH THE BATTERY PACK
(FIG.1)
Align the raised rib on the battery pack with
the grooves on the bottom of the jig saw and
then attach the battery pack to the jig saw.
When placing the battery pack in the tool, be
sure that the raised rib on battery pack aligns
with the groove on the jig saw and that the
latches snap into place properly. Improper
assembly of the battery pack can cause
damage to internal components.
Allow the blade to come to a complete stop
before setting the jigsaw down.
This tool has a variable speed switch that
delivers higher speed with increased trigger
pressure. Speed is controlled by the amount
of switch trigger depression.
NOTICE: Use the variable speed feature for a
short time only. Do not continuously operate
the tool at di󰀨erent speeds. It may damage
the switch.
To stop the jig saw, release the trigger switch
and allow the tool to come to a complete
stop. The electric brake quickly stops the
saw blade stroke. This feature engages
automatically when you release the trigger
switch .
To turn the jig saw ON, keep the lock-o󰀨
button depressed and squeeze the trigger
switch. To turn it OFF, release the trigger
switch.
1. Depress the battery-release button located
on the front of the battery pack to release
battery pack.
2. Pull the battery backward and remove it
from the tool.
FIG. 1 FIG. 2
CAUTION:
!CAUTION:
!
11

ASSEMBLY
LED WORKLIGHT (FIG. 3)
Allow the blade to cool after use. The blade
can become dangerously hot.
1. Remove the battery pack.
2. Press down on the blade clamp lever to
remove the blade.
3. The clamp stays open when the blade is
removed; it automatically locks when you
push in another blade, providing for very
easy one-hand blade change.
1. Remove the battery pack.
2. Turn the tool upside down and press the
blade clamp lever as far as it can go; the
lever will not rebound back.
3. Insert the blade into the slot until it locks
into place automatically
The LED worklight, located above the tool-
less blade clamp, provides additional lighting
on the surface of the workpiece for operation
in lower-light areas. The LED worklight will
come on automatically when the trigger
switch is depressed, and it will turn o󰀨 when
the trigger switch is released.
To obtain the best performance from the saw,
it is important to select the correct blade for
the particular application and type of material
you wish to cut. By doing this, you will get a
smoother, faster cut and prolong blade life.
The jigsaw has orbital action whereby the
blade roller guide moves back and forth to
make the blade swing slightly as it cuts.
Orbital action increases the speed of cut but
may result in a rougher nish to the cut in
some materials.
INSTALLING SAW BLADE (FIG. 4)
BLADE SELECTION
REMOVING SAW BLADE (FIG. 4)
FIG. 4
FIG. 3
FIG. 5
LED
Worklight
CAUTION:
!
12

Always ensure that the jigsaw is switched
o󰀨 and the battery pack is removed before
making any adjustments.
1. Loosen the hex screw located on the
underside of the tool using hex key.
2. Move the shoe plate backwards so that the
teeth on the plate no longer engage with
the retaining teeth and the shoe can be
tilted to the left or right.
3. Select 15°, 30° or 45° to the left or right or
select 0°, and push the shoe plate forward
so that the teeth on the plate mesh with the
retaining teeth.
4. Retighten the hex screw.
The angle selected can be read on the cutting
angle guide on the shoe plate.
For accurate work it is necessary to make
a trial cut, then measure the work and reset
the angle with the shoe plate moved a little
towards the rear so that the teeth on the plate
do not mesh with the retaining teeth.
Repeat the trial cut and reset the angle
setting until the correct setting is achieved.
The parallel guide ts into the shoe plate and
is locked in place by the locking screw.
Use the parallel guide to guide the jigsaw
along a straight line which can be an edge
of a workpiece or a piece of straight timber
clamped to the workpiece.
OPERATION
Set the orbit control lever to one of the four
settings according to degree of orbit action
required:
0 No orbit action
1 Minimal orbit action
2 Medium orbit action
3 Maximum orbit action for the most
aggressive action, for quick cutting plywood
or soft material.
Experiment on a piece of scrap material to
determine the optimum orbit action setting.
ADJUSTING THE SHOE
FOR ANGULAR CUTTING
(FIG. 6&FIG. 7)
FIG. 6
FIG. 7
PARALLEL GUIDE (FIG. 8)
FIG. 8
CAUTION:
!
13

OPERATION
MAKING A CUT (FIG. 9)
STRAIGHT CUTING
PLUNGE CUTTING (FIG. 10)
By changing the position of the guide and
using the same straight edge as a guide, it is
possible to quickly and easily make parallel
cuts in the workpiece.
NOTICE: When adjusting the cutting angle,
you can move the parallel guide locking
screw to the left or right.
1. Turn on the jigsaw and allow the blade to
reach maximum speed. Do not allow the
blade to contact the workpiece until it has
reached full speed.
2. Slowly guide the jigsaw forward using both
hands, keeping the shoe plate at against
the workpiece.
NOTICE: Use only enough pressure to keep
the blade cutting. Do not force the cutting;
allow the blade and the saw to do the work.
A straight cut can be made by clamping
a piece of wood or a straight edge to the
workpiece and guiding the edge of the saw
against it. Make the cut from one direction
only. NEVER cut halfway and then complete
the cut from the opposite end.
The straight cut can be also made by using
the parallel guide supplied.
FIG. 9
FIG. 10
Plunge cutting is useful and time-saving for
making rough openings in soft materials. It
makes it unnecessary to drill a hole for an
inside or pocket cut.
1. Draw lines for the opening you want to cut.
2. Hold saw rmly and tilt it forward so the toe
of the saw foot rests on the workpiece.
3. Make sure that the blade is well clear of
the workpiece.
4. Start the saw and then gradually lower the
blade into the workpiece, rmly holding
the toe of the saw base to prevent side
wobble.
5. Keeping the toe of the foot on the
workpiece, slowly pivot the saw downward
like a hinge until the blade cuts through
and the base rests at on the workpiece.
6. Begin sawing in the usual manner along
the cut line.
BATTERY CHARGING
The battery is supplied partially charged. To
ensure full capacity of the battery, completely
charge the battery in the battery charger
before.
A fully discharged battery pack will charge
in 50 minutes for DB1850 in a surrounding
temperature between 32° F (0° C) and 104°
F (40° C).
14

CLEANING
Using compressed air may be the most
e󰀨ective cleaning method. Always wear
safety goggles when cleaning tools using
compressed air. Never use detergent or
alcohol.
MAINTENANCE
WARNING:
!
When servicing, use only identical
replacement parts. Use of any other parts
may create a hazard or cause product
damage.
Before performing maintenance or cleaning,
remove the battery pack from the jig saw.
1. The tool may be cleaned most e󰀨ectively
with compressed dry air. Always wear
safety goggles when cleaning tools with
compressed air.
2. Use a small brush or the air discharge of a
small vacuum cleaner brush to clear dust
or debris from the air vents on the motor
housing.
3. Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to
damage from various types of commercial
solvents. Use clean cloths to remove dirt,
dust, oil, grease, etc.
4. Lubricate the roller guide from time to time
with a drop of oil. It will extend the life of
the roller.
1. Charge the Lithium-Ion battery pack with
the correct charger.
2. Connect the charger to a power supply.
3. Align the raised ribs of the battery pack
with the slot in the charger.
4. Slide the battery pack onto the charger.
5. The charger will communicate with the
battery pack to evaluate the condition of
the battery pack.
6. The POWER BAR LED lights will cycle
from right to left during charging. This is
part of the normal charging operation.
7. After charging is complete, the green
LED on the charger will come on and the
POWER BAR LED lights will go displayed
when the POWER BAR button is pressed
while the battery pack is on the charger.
8. The battery pack will fully charge if left on
the charger, but it will not overcharge.
NOTE: For your convenience, the charger
can operate with most generators and
inverters rated at 300 watts or higher.
CAUTION:
!
15

TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The saw does not work Battery pack is exhausted Charge the battery pack
Blade cannot be removed Saw dust in the slot Clean the clamp slot with brush
1. Tool, accessories and packaging should be sorted for environment-friendly recycling.
2. Power tools and accessories at the end of their service life still contain large amounts of valuable
raw materials and plastics which can likewise be fed back into a recycling process.
3. Some dust created by working contains harmful chemicals must be collected by special garbage
re- cycle site.
1. In case of warranty, repair or the purchase of spare parts, always contact an authorized service
center. Attach the service card and the invoice.
2. The warranty does not cover normal wear, overloading or abnormal use of the product.
SERVICE
ENVIRONMENT PROTECTION
NO
ACCESSORIES
16
