Mac Medical PTF1000 Operating instructions

1
PT1000and PTF1000 WHEEL STRETCHER
IFU - 024 Rev.A 2/20/2015
A: Receiving Inspection
• The customer is responsible for making sure the
loading dock at their facility can accommodate a
shipping carton approximately 70” inches (1.778 m)
long and 40” (1.016m) inches wide.
• The customer must also provide transportation
equipment (forklift, etc.) for a carton weighing
approximately 400 lbs (181.4 kg).
Inspection
1. Receiving area must meet all State and Local
regulations prior to unpacking.
2. Customer must inspect carton both before and
after unpacking to determine if any items were
damaged during shipping.
A. All damaged items must be listed on
the Bill of Lading.
B. The serial number and model number
shown on the carton label must match
the numbers on the Bill of Lading and
the Invoice.
3. Were Shock Indicators used on the carton?
The readings from shock indicators, if damage
to the carton exists, are to be recorded on the
Bill of Lading.
4. Customer is responsible for the proper disposal
of all packing materials. The disposal of these
items must meet all State and Local regulations.
Unpacking the Stretcher
Retain all shipping materials until stretcher is
completely unpacked and inspected for damage.
1. Remove metal bands holding the bottom and
top of the shipping carton together. See
Figure 2.
CAUTION: Eye protection must meet ANSI-Z87.1-
2010 guidelines and be worn during the
un-banding of the carton. The metal
bands, when cut, can cause severe
injuries to the eyes.
3. Remove metal staples holding the top and
bottom of the carton to its sides.
4. Remove the top of the carton.
4. Remove metal staples making the flaps
around the top edge of the carton.
5. Remove metal staples attaching the sides of
the carton to the bottom of the carton.
6. Remove the sides of the carton by lifting them
straight up from the bottom tray.
Preparations for using the PT1000 and PTF1000 Stretchers
Figure 1: Stretcher in Shipping Carton
IFU-024-1-00001
Figure 2: Shipping Carton with Bands Removed
IFU-024-1-00002
STAPLES
STAPLES CARTON
STIFFNERS
Figure 3: Removing Staples and Stiffeners
IFU-024-1-00005

2
PT1000and PTF1000 WHEEL STRETCHER
IFU - 024 Rev.A 2/20/2015
7. Lift stretcher straight up from bottom tray of
the shipping carton and remove it.
CAUTION: The PT1000 Stretcher weighs
approximately 225 pounds (102 kg)
and the PTF1000 Stretcher weighs
approximately 275 pounds (124.7 kg).
The weights vary due to the different
bed sizes and options available.
This requires two or more people to
lift the stretcher out of the carton.
Failure to follow this precaution can
result in injury to personnel and
damage to the stretchers.
8. Remove plastic covering.
9. The PT1000 or PTF1000 Stretcher is now
ready for use.
Visual Inspection
1. Thoroughly inspect stretcher for any damage
not discovered in original unpacking.
2. Inspect all moving assemblies to make sure
that the stretcher is ready for use.
A. Inspect all four casters and make sure
they function properly.
B. All casters must make contact with the
floor at the same time.
C. Inspect both Release Pedals for proper
movement.
D. Inspect Brake Pedal Assembly to make
sure the brakes will stop the stretcher.
E. Engage and retract both Hydraulic
Cylinders to make they properly lift and
lower the stretcher as needed.
F. The Hydraulic Cylinders must reach
maximum height within 23 to 28
strokes.
G. PTF1000 Stretcher only: The 5th-
Wheel, when engaged, must make
solid contact with the floor.
Clean and Discard
1. All shipping and packing materials must be
discarded in compliance with Local and State
regulations.
2. Stretcher must be wiped down with a mild
soap and water solution to remove any debris
that may have accumulated during shipping.
3. Stretchers, when not in use, MUST not be
stacked on top of each other in storage.
4. Stretchers that are stored and not uncrated,
MUST not be double-stacked in storage.
Preparation for Use
1. Remove the mattress from the large plastic
bag. The head-end of the mattress has large
diagonal corners and should be placed over
the short end of the table.
2. The bottom of the mattress has two adhesive
strips. Remove the protective backing, turn
the mattress over and press it into place. This
will keep the mattress from making any
unwanted movement.
3. Find and unwrap the IV Pole laying in the
bottom tray of the stretcher.
4. Install IV Pole onto the stretcher. The IV Pole
can be installed into any of four locations and
is held securely in place.
Figure 4: Stretcher Removed from Carton
IFU-024-1-00005
