Mac Medical SS32 User manual

INSTRUCTION MANUAL
Read and understand all of the instructions and safety information in
this manual before operating this product.
MAN-004 Rev G 02/2019
© 2019 MAC Medical, Inc.
SS Series Surgical Scrub Sinks
Installation - Operation - Maintenance - Cleaning
OSHPD
Pre-Approved
SS32 Model
SS64 Model
SS96 Model
C

Instruction Manual
MAN-004 2www.macmedical.com
KEEP THIS MANUAL
DESCRIPTION OF PRODUCT
This manual covers manual knee operated and Infrared self-activated Surgical Scrub Sink models -
• SS32 - single basin
• SS64 - double basin
• SS96 - triple basin
PURPOSE OF THIS MANUAL
This user manual details the installation, operation maintenance and cleaning of the MAC Medical Surgical
ScrubSinks.Thismanualalsocontainsgeneralspecications,warningsandcautions.
Table of Contents
Warnings and Cautions Icon Key 3
GeneralSpecications 4
InLineFlowSwitchTimerController(S0130-01)-Specications,SwitchRatingandWiringDiagram 5
Switch Timer Controller Maintenance 5
SinkDimensions-SS32,SS64,SS96Models 6
Installation 7
Installing and Operating the Soap Spout 8
RecommendedMountingSpecications-SS32-SingleBasin 9
RecommendedMountingSpecications-SS64-DoubleBasin 10
RecommendedMountingSpecications-SS96-TripleBasin 11
ConnectDrainPipetoDrainandPlumbingtoWaterLines 12
Plumbing Install Instructions 12
Preventative Maintenance 13
Troubleshooting 13
ReplacementPartsforManualKneeOperatedandInfraredSelf-ActivatedSinkPlumbing 14
PlumbingAccess(ManualKneeOperatedSinksOnly) 15
Infrared Controls (for Infrared Self-Activated Sinks only) 15
Installation 15
Operation 15
Instructions for Cleaning Stainless Steel Surgical Scrub Sinks 16
Optional IR Timer Assembly 17
Installing Optional Electronic Sink Timer Display 17
TimerOperationDisplayandProgramming 18
Timer Battery Replacement 19
In-lineWallCarrierMountAssembly-SingleBasinSinks(part#S0001) 20
In-lineWallCarrierMountAssembly-DualBasinSinks(Part#S0002) 21
In-lineWallCarrierMountAssembly-TripleBasinSinks(Part#S0003) 22
Limited Lifetime Warranty 23

Instruction Manual
MAN-004 3www.macmedical.com
Warnings and Cautions Icon Key
The following is a list identifying the various warning and caution icons used in this manual.
Icon Type Icon Description
Warnings (Red triangle with an exclamation point) indicate the potential for
minor to severe injuries up to and including death to personnel.
Cautions (Yellow triangle with an exclamation point) indicate the potential
minor injury to personnel and damage to equipment.
Note: The exclamation point will not be visible where only equipment
damage is present.
Burn Hazard Warnings (Yellow triangle with radiating lines) indicate a potential burn injury to
personnel.
Electrical Warnings
(Yellow triangle with a lightning bolt) indicate a possible shock hazard
is present.
Severe shock hazards shall be a lightning bolt in a red triangle.
Warnings and Cautions When Installing or Operating This Product
Priortoinstallationoroperation,theusermustreadthesewarningsandcautions.
The following is a list of the safety precautions that must be observed when operating this equipment.
WARNING-INJURY HAZARD -
REPAIRS AND ADJUSTMENTS should be only attempted by experienced service agents fully acquainted with
thisequipment.Theuseofinexperienced,unqualiedpersonstoservicetheequipment,ortheinstallationof
unauthorized parts, could cause serious personal injury, or result in costly damage. Always unplug power cord
from power source prior to attempting any repairs or servicing.
WARNING - Burn Hazard
DONOTCHANGEtemperaturesettingsonthermostaticmixingvalve,unlessyouareatrainedmechanic.
ANYREPAIRormodicationofmixingvalvemayaffectthehightemperaturesetting.Theinstallermustcheck
operating temperature before sink is back in operation.
CAUTION-POSSIBLE EQUIPMENT DAMAGE -
When cleaning the sink - See complete Cleaning Instructions in this manual.
NOTE: This product is to be used strictly for the purpose it was designed for. If this product is used in a manner
notspeciedbyMACMedical,theprotectionprovidedbytheequipmentmaybeimpaired.MACMedical
disclaims all liability for the consequences of this product being used for purposes other than its intended
design.Productmodicationormisusecanbedangerous.MACMedicaldisclaimsallliabilityforthe
consequencesofproductalterationsormodications,aswellasfortheconsequenceswhichmightresult
from the combination of this product with other products, whether supplied by MAC Medical or by or by other
manufacturers,unlesssuchacombinationhasbeenspecicallyendorsedbyMACMedical.

Instruction Manual
MAN-004 4www.macmedical.com
General Specications
1. Material:
a. Sink basin and sink top: 14 gauge, 300 series stainless steel
b. Sink skirt: 18 gauge, 300 series stainless steel.
2. Plumbing Material
a. 1/2” copper or brass pipe
b. Sink is furnished with in-line check valves on supply lines.
3. Utility requirements:
a. Cold water - 20 to 50 psig 70º F max
b. Hotwater-20to50psig120ºFto140ºF
c. Waterlinesshouldbeushedcleanbeforewaterconnectionsaremade.
d. It shall be the customers responsibility:
• toensurebyuseofpressureregulatorsorothermeans,thatmaximumspeciedpressuresarenot
exceeded.
• to ensure that water supplies are properly protected for internal cross connection control in
accordance with local building and plumbing requirements.
• to eliminate water hammer conditions should they occur in the service piping.
4. Power requirements (for sinks with optional infrared sensor operations)
a. 120Volt,60Hz,singlephase,3.0ampGFICprotectedelectricaloutlet(byothers)
b. 220VAC,60Hz,singlephase1.5amp
c. to be installed per local building codes.
5. Sink Weight
a. Single basin - 130 lbs
b. Doublebasin-230lbs
c. Triple basin - 320 lbs
6. Sink Certications
a. ULandcULcertied
b. CaliforniaOSHPDpre-approvedwhenmountedonastructurallysoundwall.
7. Mixing Valve Specications
a. Connections-1/2”NPTInletsand1/2”NPTTopOutlet
b. Capacity(withoutcheckstops)-5.25gpm[19.9L/min-at45psidifferential(310kPa)withhotwater
supply between 140° - 180° F (60° - 82° C) and 50/50 mix}] - (±0.25 gpm [0.95 L/min])
c. MaximumHotWatersupplyTemperature-190°F(88°C)
d. MinimumHotwatersupplytemperature(notapplicabletolowtemperaturehotwatervalves-5°F(2.8°
C) above set point
e. TemperatureRanges-ASSE1016TypeT:65-115°F(18-46°C);ASSE1016TypeT/P:90-110°F(32-43°C)
f. MaximumOperatingPressure-125psig(862kPa)
g. MaximumStaticPressure-125psig(862kPa)
h. Compliant-ASSE1016-T-P
i. Certiied-CSAB125

Instruction Manual
MAN-004 5www.macmedical.com
Service Compatible liquids
Wetted materials Housing:brass;Piston:polysulfone;Spring:316SS;O-Ring:Fluoroelastomer,Other:Epoxy.
Temperature Limits -20 to 225°F (-29 to 107°C).
PressureLimits 1000 psig (68.9 bar).
Accuracy ±10% of set point.
Repeatability ±1%.
Switch Type* SPDT,20VA
ElectricalRating .17A@120VAC,.08A@240VAC,.13A@120VDC,.06A@240VDC.
ElectricalConnection 18AWG,24"(60.96cm),Polymericleadwires.
ProcessConnection 1/4"femaleNPT.
Mounting Orientation Any position. Set points shown are based on vertical, inlet down position.
Required Filtration 50 microns or better.
Weight 0.66 lb (301 g).
Agency Approval CE
InLine Flow Switch Timer Controller (S0130-01) - Specications, Switch Rating and Wiring Diagram
NOTE:Thisfeature(Fig.1)isavailableonlyonInfraredActivatedScrubSinks.
Thisisanexplosion-proofbrassowswitch,actuationsetpoint0.50GPM(1.89LPM),andcalibratedforwaterat
standardconditions.Itisusedforaccuratedetectionofexcessiveorinsufcientowrates.
*Switch Ratings
Max Resistive Load
Switch Timer Controller Maintenance
Accumulation of foreign debris should periodically be removed from these
switches. Occasional “wipe-down” cleaning when excessive contamination is
present is all that is normally required.
To Clean: Remove unit from system and disassemble as shown below. Clean
all parts, reassemble and reinstall unit.
Note:50micronltrationisrecommended.
This unit was calibrated in a vertical position, with lead wires up. Install unit in piping system, using standard
pipettingprocedures.Besuretokeepthreadsealingcompoundoutofunit.Makesurethatowisinproper
direction - marked “IN” and “OUT” on housing. See wiring diagrams for electrical connections.
CAUTION: See “Switch Ratings” before connecting power.
CAUTION: Flowsettingsforthisswitchisnormallycalibratedusingwater@+70°Fonincreasingow.Water-
calibrated units are not recommended for air/gas applications.
VA Volts Amps AC AmpsDC
20 0-30 .4 .3 120 .17 .13
240 .08 .06
A
C
B
Pin Connections for
Units with MS Receptacle
Typical Wiring Diagram
Piston
Inlet
Fitting
Housing
Spring
O-Ring
Fig. 1: In-line Flow Timer Controller

Instruction Manual
MAN-004 6www.macmedical.com
Sink Dimensions - SS32, SS64, SS96 Models
Fig. 2: SS32 - single basin
Fig. 3:SS64-DualBasin
Fig. 4:SS96-TripleBasin

Instruction Manual
MAN-004 7www.macmedical.com
Installation
1. Carefully uncrate the scrub sink. The mounting hardware is under the sink, secured to the shipping materials.
Besuretoremoveallhardwarebeforediscardingpackaging.
2. Check water supply and waste terminal locations -
A. Besureallconnectionsaresafelyaccessibletothesinkandinproperworkingcondition.NOTE:For
proper sink operation the hot water temperature must be 120° F.
B. Install sink near a hot water source.
3. Locate Infrared sensor activated sinks near a 110/120V outlet power source.
4. Attach wall mount sink support brackets to the wall.
A. “Z”Bracketsformountingthesinktothewallcomewiththesink(Fig.
5).RecommendedmountingspecicationsforZbracketsshownin
Fig. 13 (SS32), Fig. 16 (SS64), and Fig. 19 (SS96) on page 9 through
page 11.
B. IMPORTANT: For wall mounted units, the wall structure must be
capable of supporting the load.
C. Optional wall mounting systems (in-wall chair carrier and pedestal
style)andtheirmountingspecicationsshowninFig.15(partS0001for
sink SS32), Fig. 18 (part S0002 for sink SS64), and Fig. 21 (part S0003 for
sink SS96) on page 9 through page 11.
5. Install the soap spout on the sink (See page 8).
6. MountthesinkbodyontotheZBracketsthatwereattachedtothewall.
A. With the help of an assistant, slide the sink over the “Z” brackets until it
locks securely into place (Fig. 6 - Fig. 7, Z brackets shown in green).
7. Connect the drain pipe to the drain
8. Connect the water supply to the plumbing (page 12).
Fig. 5: Z brackets
Fig. 6: Z brackets on sink Fig. 7: Cross section showing Z bracket on sink

Instruction Manual
MAN-004 8www.macmedical.com
Installing and Operating the Soap Spout
To prevent damage during shipment, the soap dispenser is stored inside the
sinkbasin.SoapDispensertubingisalsoincluded.Thedispenserspoutshould
be installed before hanging the sink.
1. To install - remove the bushing (Fig. 8 - Item 3 shown in green).
2. Feed the spout (item 1) through the small hole at the top of the sink (Fig.
9). The nut (item 2) should rest on top of the sink.
3. Re-install the bushing onto the spout from inside the cabinet (Fig. 10).
4. Attach the soap tubing to the spout and soap pump (circled in red) as
shown in Fig. 11 and Fig. 12.
ToOperatetheSoapPump-pressthesoapspoutdownrepeatedlytostart
theowofthesoap.
Fig. 8: Soap Spout with nut and bushing
Fig. 9: Install Soap Spout Fig. 10: Secure spout with bushing
Fig. 11: Install soap dispenser tubing Fig. 12: Close-up of soap pump with tubing attached

Instruction Manual
MAN-004 9www.macmedical.com
Recommended Mounting Specications - SS32 - Single Basin
For the assembly drawing of In-line wall carrier mount (S0001), see page 20.
Fig. 13: Z bracket mounting locations - SS32
Fig. 14: In-line wall carrier mount - S0001
Fig. 15: In-line wall carrier mounting locations - SS32

Instruction Manual
MAN-004 10 www.macmedical.com
Recommended Mounting Specications - SS64 - Double Basin
For the assembly drawing for the In-line Wall Carrier Mount (S0002), see page 21.
Fig. 16: Z bracket mounting locations - SS64
Fig. 17: In-line wall carrier mount - S0002
Fig. 18: In-line wall carrier mounting locations - SS64

Instruction Manual
MAN-004 11 www.macmedical.com
Recommended Mounting Specications - SS96 - Triple Basin
For the assembly drawing of the In-Line Wall Carrier Mount (S0003), see page 22.
Fig. 19: Z bracket mount locations - SS96
Fig. 20:In-linewallcarriermount-S0003
Fig. 21: In-line wall carrier mounting locations - SS96

Instruction Manual
MAN-004 12 www.macmedical.com
Connect Drain Pipe to Drain and Plumbing to Water Lines
Localbuildingorplumbingcodesmayrequiremodicationstotheinformationprovided.Youare
required to consult the local building and plumbing codes prior to installation. If the information provided here
is not consistent with local building or plumbing codes, the local codes should be followed. This product must
be installed by a licensed contractor in accordance with local codes and ordinances.
FAILURETOCOMPLYWITHPROPERINSTALLATIONANDMAINTENANCEINSTRUCTIONSCOULDCONTRIBUTE
TOVALVEFAILURE.
Thishotwatermastertemperingvalvecannotbeusedfortemperingwatertemperatureatxtures.Severe
bodily injury (i.e., scalding or chilling) and/or death may result depending upon system water pressure changes
and/orsupplywatertemperaturechanges.ASSEstandard1016,1069or1070listeddevicesshouldbeusedat
xturestopreventpossibleinjury.
This hot water tempering valve is designed to be installed at or near the boiler or water heater. They are not
designedtocompensateforsystempressureuctuationsandshouldnotbeusedwhereASSEstandard1016,
1069 or 1070 devices are required. These valves should never be used to provide “anti-scald” or “anti-chill”
service.
The components of the system must be of materials with a construction capable of withstanding the high limit
output temperatures of the water heating source.
Need for Periodic Inspection and Yearly Maintenance:Periodicinspectionandyearlymaintenancebya
licensed contractor is required. Corrosive water conditions, temperatures over 200°F, unauthorized adjustments
or repair could render the valve ineffective for service intended. Regular checking and cleaning of the valve’s
internal components and check stops helps assure maximum life and proper product function. Frequency of
cleaning and inspection depends upon local water conditions.
Plumbing Install Instructions
PlumbingInstallationshouldbeinaccordancewithacceptedplumbingpractices.Installationandeld
adjustment are the responsibility of the installer.
1. Flush all pipes thoroughly before installation.
2. Connect sink drain pipe to drain connection.
3. Close both hot and cold water shutoff valves upstream of the tempering valve.
4. Bleedpressurefromthesystem.
5. Routecoppertubingorpipingtotvalvedimensions.
6. Remove tailpieces from the valve and make sure union nuts are over the tubing/piping before connecting
to the tailpiece.
A. Note: If soldering, remove unions and gaskets from valve body prior to soldering to prevent damage to
valve from excessive heat.
7. Flushpipingagain,installvalveusingltergasketonhotandcoldwaterinletsandbergasketonmixed
water outlet.
8. Turn on the cold and hot water. If any leaks are observed, tighten connections as necessary to stop leaks
before proceeding.
9. After the plumbing installation is complete, the water pressure can be adjust to avoid excess splash. The
pressurecanbecontrolledbyadjustingtheowwiththeowcontrolvalve.Seeitem#4oftheplumbing
diagram for the manual knee operated plumbing on page 14.

Instruction Manual
MAN-004 13 www.macmedical.com
Preventative Maintenance
Every 6 months -
1. Check and adjust the temperature setting.
Every 12 months -
1. Shut off water supply
2. Open up checkstops.
3. Clean strainers and check for free movement of checkstop poppet.
4. Replace seals if cracked, cut, or worn.
5. Re-assemble.
6. Adjust stem to desired temperature.
Troubleshooting
1. Iftheowofwaterislessthandesired--
A. Valves upstream from supply not fully open
B. Low supply pressures
C. Accumulationoflimedepositisinhotwaterpipes,restrictingtheowofwater
D. Checkstops not fully open
E. Clogged strainer screens in the checkstops
F. Clogged cartridge
2. Flow of water is completely cut off --
A. Valves upstream from supply completely closed
B. Failure of cold water supply pressure (mixing value is designed to shut off on a cold water supply
failure).
C. Checkstops completely closed.
3. Flow is untempered hot or cold water--
A. Accumulationoftimedepositsinhotwaterpipes,restrictingtheowofhotwater.
B. Thermostaticactuatorfailure;replacewithnewthermostaticactuator
C. Hotandcoldwatersuppliesareconnectedtothewrongports
4. Maximumtemperaturespeciedforthemixingvalvecannotbeobtained--
A. Accumulationoflimedepositsinhotwaterpipesrestritingtheowofhotwater.
B. Hotwatersupplytemperatureistoolow
5. Variable discharge temperature occurs--
A. Extremepressurevariationsinsupplylines
B. valve operating below minimum capacity requirements.

Instruction Manual
MAN-004 14 www.macmedical.com
8
Replacement Parts for Manual Knee Operated and Infrared Self-Activated Sink Plumbing
Bothplumbingcongurationsshownbelowindicatewhichpartsarereplaceable.Seetablebelowfor
replacement part numbers.
Item # Description Knee Operated Part # Infrared Activated Part #
1 Spout for both knee operated or infrared activated plumbing SS0132-01
2 Thermostatic Mixing Valve for both knee operated or infrared activated plumbing S0009
3MixingValveHandle for both knee operated or infrared activated plumbing S0010
41/2”BalanceFlowControlValve S0024 Solenoid Valve (for Infrared) S0013
5 Knee Operated Water Valve S0029 Infrared Sensor S0012
6 Inline Flow Switch Timer for infrared activated plumbing S0130-01
7 Checkstop Strainer (L/R) for both knee operated or infrared activated plumbing S0011
8 Swivel Aerator for both knee operated or infrared activated plumbing S0032
9 Soap Spout for both knee operated or infrared activated plumbing S0041
10 SoapPumpKit for both knee operated or infrared activated plumbing S0028
11 Check Valve for both knee operated or infrared activated plumbing S0131
12 SinkDividers(notshown) for dual and triple basin sinks S0034
Fig. 22: Manual knee operated sink plumbing Fig. 23:InfraredSelf-ActivatedSinkPlumbing

Instruction Manual
MAN-004 15 www.macmedical.com
Plumbing Access ( Manual Knee Operated Sinks Only)
1. Open the knee panel door by depressing the latch at the bottom of the panel door (Fig. 24).
2. Swing the door fully open to access the hinges (Fig. 25).
3. Pushthehingepinsinwardtoreleasethedoorfromthehinges(Fig.26).
Infrared Controls (for Infrared Self-Activated Sinks only)
Installation
The sinks are supplied with a 24V power transformer(s) that connects
to a standard duplex outlet (110/120V outlet required).
Single basin sinks have one sensor, dual basin sinks have two sensors
(one for each basin) and triple basin sinks have three sensors (one for
each basin).
1. Plugthetransformer(s)intotheoutlet.
2. AredLEDwillashinthesensorwindow(Fig.29-circledinred).
A. Important:Donotinterruptthesensorbeamuntilthelight
turns off.
Operation
The sensors are pre-set and equipped with a logic board. The sensors
determines the range during initialization period (The time after initial
power until the light turns off is approximately 5 minutes). The range is
approximately 12-14” in front of the sensor and is 25 degrees at peak.
Duringtheinitializationperiod,thesensorsallowforxedobjectsthat
may be within the sensors’ range. The sensors are equipped with a 2
second on/off delay, and no-time-out feature. This prevents the sink
from turning on when walking past at a normal pace and no-time-
out allows for an uninterrupted scrub.
4. To re-attach the door, push in the hinge pins
andtthetopcornersofthekneepanel
door onto the left and right hinge leaves (Fig.
27-circledinred).Whenthedoorisretted,
release the hinge pins to secure the door to
the sink.
5. The knee panel door should rotate freely on
its hinges. Rotate the door back down on its
bottom latch to close it (Fig. 28).
Fig. 24:Pushdownkneepaneldoorlatch Fig. 25:Doorinfullyopenedposition
Fig. 26:Pushhingesinward
Fig. 27: Left - right hinge leaves
Fig. 28:Doorshouldrotatefreelyonhinges
Fig. 29: Location of infrared sensor

Instruction Manual
MAN-004 16 www.macmedical.com
Instructions for Cleaning Stainless Steel Surgical Scrub Sinks
Stainless steel sinks must be cleaned on a regular basis to prevent any unnecessary damage to the stainless
steel surfaces.
When cleaning Ssainless steel sinks, make sure to use the proper approved cleaning agents and cleaning
materials.
CAUTION
DO NOT USE these Cleaning Materials CAUTION
DO NOT USE these Cleaning Agents
AbrasivePads HardWater(waterwithapHreadingabove7.0).
Scrapers HydrochloricAcid
Steel Wool Steam or high pressure water
WireBrushes BleachoranycompoundscontainingchlorineorSoldium
hypochlorate, or ammonium chloride salts.
Approved cleaning materials and agents
• Soft, clean lint-free cloth
• Non-abrasive cleaning pads
• Soft bristle brush
• Mild detergents
• SodiumBicarbonate(bakingsoda)
• Distilledwater(pHrating7)aloneorwithamilddetergent
• White vinegar (in a spray bottle)
• Isopropyl Alcohol
• Hospital-gradenon-bleachdisinfectants
• Cleaners approved for use on stainless steel
Cleaning Stainless Steel Surfaces
1. Using a damp, lint-free cloth and approved cleaner, wipe down the entire exterior surface of the stainless
steel sinks. Using a damp, lint-free cloth with distilled water and a mild detergent, wipe down the entire
exterior surface of the stainless steel sinks.
2. Let cleaned sinks air dry.
Cleaning Decals or Printed Labels
• Use only distilled water and a mild detergent applied with a clean, dry lint-free cloth to clean decals or
printed labels.
• Cleaning agents can remove or smear any printing from decals and print labels.
• Cleaning agents can damage plastic materials used in manufacturing covers for electronic items such as
infrared sensor face.

Instruction Manual
MAN-004 17 www.macmedical.com
Optional IR Timer Assembly
An electronic IR Timer Assembly (S0202-SST-KT) can be purchased and installed
on Infrared Activated surgical scrub sinks.
Theinstallationwouldrequiresomemodicationofthesinktopinorderto
install.
Installing Optional Electronic Sink Timer Display
1. To mount the timer housing on the sink top,
drill 3 holes using the hole dimension sizes and
locations as shown in the illustration (below).
Two holes are for mounting the timer housing,
oneforthreadingthe3ow-switchtimerwiresto
the top side for connection to the timer read-
out.
2. Placeagrommetinthe0.38diameterwire
threading hole. (Grommet to be supplied by
others.)
3. Mount the timer housing to the top of the sink in
the 0.31 diameter drilled holes. Mounting studs
(0.25 diameter) are provided on the housing.
Secure to sink top with the provided hex nuts.
4. Threadthe3ow-switchtimerwiresthroughthe
drilled hole on top of the sink (Fig. 32 - circled in
red).
5. Connect the 3 timer wires (black, red and
orange) to the timer read-out terminal
connections as shown in Fig. 33.
6. Programthetimerasshownonpage18.
Fig. 30: IR Timer Assembly for IR scrub sinks
Ø0.31
Ø.31
Ø0.38
Sink Back Side
Sink Back Side
Sink Left Side
Red Wire
5
6
7
8
4
3
2
1
Orange Wire
Black Wire
Fig. 31:Drilllocationsonsinktop
Fig. 32: Thread wires thru grommet hole
Fig. 33: Wiring diagram for timer

Instruction Manual
MAN-004 18 www.macmedical.com
Timer Operation Display and Programming
Time Display: Accumulates time when the timing start input is active. Timing will not take place when the
external or front panel reset is active. The leftmost digit is the time value legend.
Down Key: When the program input is active this key is used to scroll through the menu items. After a menu item
has been chosen for editing, the down key is used to set the value for the currently selected
(ashing)digit.
Next/Reset Key: ResetstheaccumulatedtimeifFrontPanelResetisenabledinProgrammingMode.Whenthe
programinputisactivethiskeyisusedtoselectamenuitemforediting(leftmostdigitwillbegintoash)and
then move to the desired digit to be changed.
Programming -
Programmingparameterscanbeaccessed,whentheProgramEnableinputisactive,bypressingtheDown
key.ToeditaparameterusetheDownkeytoscrolluntilthedesiredparameterappearsonthescreen.
PressingtheNextkeywillcausetheleftmostdigitofthatvaluetobegintoash.UsetheNextandDownkeysin
combination to choose individual digits and change their value.
Front Panel Reset Enable: When active (ON) the time value, when being displayed, can
be reset by pressing the Next/Reset key. If set to OFF, the time value can only be reset
through the remote input.
Time Format: Sets the units in which the elapsed time will be accumulated. Use the next
keytoscrollthroughtheavailablechoices:Seconds,Minutes(_____._),Hours(____
_._),Hours:Minutes:
Seconds.
Note: On initial start-up, as well as after any programming changes, it is necessary to
reset the unit before begining operation
VEEDER-ROOT
R
1. Time Display 3. Next/Reset Key
345678S
2. Down Key
EAGLE SIGNAL
o n
_ _ _ _ _ _
S .
1 .

Instruction Manual
MAN-004 19 www.macmedical.com
Timer(S0050)-SpecicationsandTerminalConnections
ThetimerisanElapsedTimeIndicatorwhichispoweredbyaninternal3voltlithiumbattery.Itcomespre-
assembled in its housing and ready for mounting to the sink.
Specication Description
Start/Stop Input NPN,ContactClosure;Accumulatestimewhenconnectedtocommon;LowState:<1.0
VDC,HighState:>2.0VDC(28VDCmax)
Security Input Allows access to panel reset and programming features
Remote Reset Input NPNorContactClosuretocommon;levelsensitive
PowerSource Singleordual3VLithiumbattery;typical5yearslifew/singlebattery,10years
w/dual batteries
Ranges & Resolution Seconds, minutes to 1/10, hours to 1/10,hours: minutes: seconds
Display 12mmhigh,SupertwistLCD;7digits;“LowBat”indicator
Backlighting GreenIlluminationoverwholeviewablearea.Requires10to28VDCpowersource
Dimensions&Mounting Seedimensionspicturebelow.PanelMountwithsuppliedmountingbracketandgasket
Connections Screw terminals
Weight Approximately 64 grams (2.25 ounces)
Rear Terminal Connections
Timer Battery Replacement
The unit is shipped with one CR ½ AA size 3V Lithium battery, which is pre-
installed.
To change the battery, remove the battery cover by pushing inward and
down. Install the battery in either of the two slots. The unit runs on a single
battery, and the second slot is provided to allow for installing a new battery
before removing the old one, retaining count total and program data. The unit
can also be run on two batteries to extend the battery life to 10 years.
Once the battery is in place the unit will go into a self test mode, and all the
segmentsontheLCDdisplaywillbeilluminated.Theselftestmodeisexitedby
depressingtheNextkey,whichwillthendisplaythemodelnumber(6).Depress
the Next key again to ready the unit for operation.
Timer Dimensions (without metal housing)
5
6
7
8
4
3
2
1
72mm (2.83")
68mm (2.66")
33mm
(1.30")
36mm
(1.42")
5. Front Panel Program Enable - Allows access to
program mode when tied to common
6. Not Used
7. Not Used
8. DC Supply Input - For backlighting
1. Common
2. Not Used
3. Timing Enable - NPN or dry
contact inputs
4. Remote Reset - Resets time value
when tied to common
5
6
7
8
4
3
2
1
+
-
10 - 28 VDC
-
+TTAB
+ BATT -
Battery Slots

Instruction Manual
MAN-004 20 www.macmedical.com
In-line Wall Carrier Mount Assembly - Single Basin Sinks ( part #S0001)
This drawing shows how the in-line wall carrier for single basin scrub sinks is assembled.
NOTE: To ensure stability, MAC Medical recommends that the In-line Wall Carrier Mount Assembly be tied into
the existing wall support structure. All applicable local and state building codes should be adhered to when
mounting this unit.
3/8 U BOLTS
HDW0003-01
QTY (6)
3/8 FLAT WASHER
HDW0001-01
QTY (12)
3/8 HEX NUT
HDW0002-01
QTY (12)
1/4 HEX NUT
HDW0002-02
QTY (33)
1/4 ALL THREAD ROD
HDW0004-01
QTY (11)
BOTTOM CARRIER PLATE
SMS0052-01
QTY (1)
TOP CARRIER PLATE
SMS0051-01
QTY (1)
SINK SUPPORT
SMS0050
QTY (2)
