MadStad Engineering MadStad User manual

Please read this entire manual before proceeding with installation.
What is in the box:
(1) Set of preassembled MadStad adjustable windshield brackets
(2) Aluminum wedge blocks
Pre-assembled quick-release posts:
(4) M6 button screws
(4) Aluminum spool tops
(4) Aluminum spool bottoms
(8) Small o-rings
Windshield Hardware:
(4) M5 x 25 Phillips screws
(4) M5 (#10) plastic flat washers
(4) M5 soft rubber washers
Adjustable Windshield Mount
Can-Am Ryker

Tools Needed:
- 4 mm Allen wrench (hex
key), ball-end if possible
- #2 Phillips screwdriver
Step 1:
The MadStad system
attaches to the screw holes
in the front of your
instrument cluster as seen
here. You will be attaching
the aluminum wedges and
pre-assembled spools as
shown below, using a 4mm
Allen wrench, preferably a ball-end wrench. Do not tighten the screws fully until
the brackets have been attached and seated (this will be in Step 2).

Step 2:
The adjustable brackets get attached to
the quick-release posts as shown in the
photo at right. Each bracket has a
spring-loaded locking key. Make sure
that the locking keys are rotated all the
way to the front of the bike as seen here.
Once the brackets are fully seated
onto the posts, lift and rotate the
locking key so that the round hole fits
over the bottom post, and the short
curved edge snaps down under the
upper post. See photo below.
You might have to shift the bracket
and posts slightly to get the locking
keys to seat completely. MAKE
SURE that the keys are fully seated
over the bottom posts and down flat
against the brackets.

Step 3:
Tighten the post screws down with an
M4 Allen wrench (see photo at right).
Repeat on the other side, and then
bracket installation is complete. To
remove the brackets from the posts, lift
up on the back side of the locking key
as seen here and rotate down and all the
way forward. The brackets can now
slide up and off of the posts, however
leave them attached for the final step of
attaching the windshield.
Windshield Installation
Once bracket adjustment is complete, the windshield attaches to the brackets
with Phillips screws and rubber washers as shown below. Pre-install each screw
with a flat washer and rubber washer into the four windshield holes as shown
below before attempting to attach the windshield onto the MadStad brackets.
You will also want to make sure the brackets are both set in the same position
(fully down and tilted back for example). Set the shield on the brackets putting
the screws into the rubber well nuts. Tighten by hand until about ¼” of the screw
tip is sticking out the back side of the well nut. At that point the well nut should
have swelled up and the shield should be held snugly.

Adjusting the MadStad Brackets
The knob screws release the brackets allowing the windshield to slide and tilt.
These knob screws must always be tightened securely before riding. DO NOT
attempt to adjust the brackets while riding! You must come to a complete stop
before making adjustments. Also make sure that you do not set the windshield
in such a way that causes your handlebars or hand guards (if installed) to hit the
windshield when turning, or before reaching full lock.
To make adjustments, loosen the knobs 1 turn for height adjustment and 3-4
turns for angle adjustment. Set the windshield so the top edge is at about your
chin level as you look straight ahead while seated on the bike. Set the angle at
approximately 60 degrees. (Use the angle guide on the back page of this manual
as a guide.) Tighten the knobs and go for a ride to see if you now have smooth
airflow over and around your helmet. Do this on a calm day if at all possible;
windy days make it hard to judge the airflow. Don’t ever try to adjust the mount
while in motion!
NOTE: The knobs have a tapered shoulder that must seat itself into the angle
adjustment slots when you tighten them. You may have to wiggle the brackets
slightly to get the knob to seat in there but once you do that is what locks the
shield into position.
To try a different windshield position, bring the motorcycle to a complete stop
and out of traffic. Loosen the two knob screws and tilt the windshield forward
or back one or two notches, and/or adjust it up or down if necessary. Re-tighten
the knobs and go for another ride. Continue experimenting with different
positions you find a combination of height and angle that eliminates buffeting
and gives a smoother ride.
NOTE: To open your front storage compartment fully you do NOT need to
remove the windshield system. Simply loosen the knobs adjustment knobs 3-4
turns then lift the windshield all the way up and tilt it all the way back. This
will give you just enough clearance to open that compartment door.

Pivot Screws
The MadStad mount has a pivot screw on each set of brackets, located near
the center of the bottom bracket. If you wish to adjust the tightness of this
pivot screw or move it to an alternate pivot position, use a 4mm Allen wrench
and a 10mm socket or wrench to make the adjustment. If you tighten the lock
nut completely you will not be able to slide the brackets.
Quick Release
Once the windshield is installed you can remove it along with both brackets as
one unit, and re-install it that way. Simply lift and rotate both locking keys
down and fully forward, then grab the shield by the bottom or sides and slide
(wiggle) the brackets up and slightly forward off of their posts. Installing them
back onto the posts will take a little extra care to align the bracket slots with
the posts, and a little extra wiggling to make sure they are fully seated. Rotate
the locking keys back onto position and if they aren’t quite aligned, either
snap them down with a little extra pressure or wiggle the brackets down some
more until the keys snap fully down. DO NOT drive the vehicle if both
locking keys are not fully seated over the bottom posts.
Notes on Windshield Angle
Most windshields work best when set at a 55-60 degree angle. We have
provided an angle guide on the back page of this manual so that you can
check and see if your shield is set somewhere in this range.
To check your shield angle, your bike should be in an upright position either
on a center stand or held up by a helper. Set the spine (folded edge) of the
manual against the front of the shield. If the large arrow marked 60° is
pointing straight up, then your shield is at a 60 degree angle. (See diagram on
Page 5.) A little farther back and your angle would somewhere between 55
and 60 degrees. Anywhere in this range is fine for your initial test ride. On
some bikes a more vertical angle works better, so don’t be afraid to
experiment later if tilting the shield back doesn’t seem to be ideal.

Disclaimer
Neither MadStad Engineering nor its owners shall be liable for any
damages, consequential or inconsequential, resulting from the use of
our products. Installation of any of our products constitutes acceptance
of these terms.
It is the responsibility of the user to make sure all fasteners are
tightened securely, the windshield is mounted properly and the
adjustment knobs are tightened snugly before putting the motorcycle in
motion. MadStad systems ARE NOT intended to be adjusted while the
vehicle is in motion; you must pull over out of the way of traffic and
come to a complete stop before making any changes. The user must
never place the windshield in such a position as to interfere with the
safe and complete movement of the handlebars and controls.
Returns and Warranty
If you are not satisfied with your new windshield system you have 30
days to return it. Full details are available on our web site at
www.madstad.com. If purchased from a dealer then please contact the
dealer for their return policy.
MadStad adjustable brackets carry a lifetime warranty against
manufacturing defects. This does not include cosmetic issues nor any
parts that inherently wear out or degrade over time such as rubber and
plastic parts. Windshields, deflectors and other similar plastic parts are
warrantied for 1 year against manufacturing defects, not against
cosmetic issues or issues related to normal wear and tear.

MadStad Engineering, Inc.
1451 E. Jefferson St.
Brooksville, FL 34601
Phone: [phone]
Web Site: http://www.madstad.com
Email: [email protected]
Thank you for your support, and ride safely!
August 3, 2019
