Magicfx COMBINER RACK MFX3224 Operating manual

SFX SAFETY PART02292 rev 01-00
USER AND INSTALLATION MANUAL
ENGLISH
COMBINER
19" RACK.
®

MAGICFX®SFX SAFETY COMBINER 19" RACK —User and Installation Manual
INTRODUCTION
This manual contains all information required for the intended use of the equipment.
Deviation from the described intended use can result in a hazardous situation and/or
property damage.
DESCRIPTION
Product code MFX3224 ARM / DMX+ARM
connector
Neutrik® etherCON,
RJ45 (in&out)
Voltage 100 – 250 Vac
50 / 60 Hz Size (LxWxH) 24 cm x 19" x 1U
Power consumption 120 W Weight 4.15 kg
Power connector Neutrik® powerCON TRUE1
(in)
Mounting options 19" 1U rack
Technical data
The COMBINER 19" RACK is a spltter and booster device for the safety signal of the
ARM SYSTEM. The COMBINER 19" RACK acts as a slave of the connected ARM
CONTROLLER, which is the master of the safety line.
The COMBINER 19'' RACK is equipped with four (2x2) outputs that each can be
combined with a DMX signal to make a ARM+DMX output. The 19'' 1U rack size makes
it easy to combine with a DMX splitter.
For more information about the ARM SYSTEM and to learn how to congure a
complete safety system, refer to the ARM SYSTEM Conguration Manual (PART02323).
For more information about the ARM CONTROLLER and to learn how to correctly set
up and use the ARM SYSTEM, refer to the ARM CONTROLLER User and Installation
Manual (PART01882).
ARM IN
M6 SAFETY
EYE
POWER
CONNECTORS
FRONT
BACK
GROUP A/B
ARM OUT DMX IN DMX+ARM OUT DMX IN DMX+ARM OUT
GROUP A
SLAVE LINE 1MASTER LINE
GROUP B
ARM SIGNAL LED (red)
DMX SIGNAL LED (green)
SLAVE LINE 2
ARM SIGNAL LED (red)
DMX SIGNAL LED (green)
Main parts
© 2022 MAGICFX®
All rights reserved.

MAGICFX®SFX SAFETY COMBINER 19" RACK —User and Installation Manual
LED indicator Light Meaning
ARM signal LED O The system is disarmed: The SFX machines cannot be operated.
Red The system is armed: The SFX machines can be operated normally.
Red
ashing
The emergency stop button is actuated or a line interruption
outside of the controller is detected. The output of the SFX
machines is disabled.
DMX signal LED Green The COMBINER BOX is receiving a DMX signal.
LED indicators
INSTALLATION
WARNING Make sure that you are familiar with and comply with the instruc-
tions from the user and installation manuals of each relevant
ARM SYSTEM component and each connected SFX machine.
NOTICE Insert a TERMINATOR in the last ARM output of each master and
each slave line to close the safety circuit. The ARM SYSTEM will not
work when a line remains open.
Install the COMBINER 19" RACK in the ARM safety circuit and connect the COMBINER
19" RACK to a power source. Check the installation variants on the next page for
connection details.
SOFTWARE SETTINGS
Make sure that the DMX/RDM settings on each SFX machine matches your wiring
setup. If the DMX signal runs separately over 5-pole XLR cables, make sure that XLR is
selected as DMX INPUT in the menu. If a combined DMX and ARM signal runs over
the ARM data (EtherCON) cables, make sure that ARM is selected as DMX INPUT in the
menu.
CORRECT DISPOSAL
This symbol on the product and / or accompanying documents means
that used electrical and electronic products should not be mixed with
general household waste. For proper treatment, recovery and recycling,
please take this product to designated collection points where it will be
accepted free of charge. Alternatively, in some countries you may be able
to return your products to your local retailer upon purchase of an
equivalent new product. Disposing of this product correctly will help save
valuable resources and prevent any potential negative eects on human
health and the environment, which could otherwise arise from
inappropriate waste handling. Please contact your local authority for
further details of your nearest designated collection point. Penalties may
be applicable for incorrect disposal of this waste, in accordance with your
national legislation.

MAGICFX®SFX SAFETY COMBINER 19" RACK —User and Installation Manual
AUse the COMBINER 19" RACK in combination with one ARM CONTROLLER to split
a master line into four DMX+ARM slave lines. The slave signals are also boosted.
BUse the COMBINER 19" RACK in combination with two ARM CONTROLLERs. For
each ARM CONTROLLER, the master line is split into two DMX+ARM slave lines.
The slave signals are also boosted.
DMX CONTROLLER
ARM CONTROLLER
DMX
POWER
terminator
insert
terminator
ARM
master
DMX + ARM
slave
COMBINER
19” RACK
DMX SPLITTER
POWER
COMBINER
19” RACK
DMX SPLITTER
DMX CONTROLLER
ARM CONTROLLER A
DMX
ARM CONTROLLER B
terminator
terminator
terminator
insert
terminator
insert
terminator
ARM
master
DMX + ARM
slave
