Magicfx STADIUMSHOT III Operating manual

STADIUMSHOT III.
USER AND INSTALLATION MANUAL
CONFETTI & STREAMER FX PART01839 rev 01-02
ENGLISH

DISCLAIMER
WARNING Read this manual carefully before installing and/or using this
product. Failure to read the manual and to follow the printed
instructions may lead to personal injury and/or damage to the
product.
© 2022 MAGICFX®
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by
means of printing, photocopying or by any other means, without the prior written
approval of MAGIC FX.
MAGIC FX reserves the right to modify specications stated in this manual.
TRADEMARKS
Any brand names mentioned in this manual are registered trademarks of their
respective owners.
LIABILITY
MAGIC FX accepts no liability for claims from third parties arising from unauthorised
use, use other than that stated in this manual, and use other than in accordance with
the General Conditions registered at the Chamber of Commerce.
We further refer to the General Conditions. These are available on request, free of
charge.
Although considerable care has been taken to ensure a correct and comprehensive
description of all relevant components, the manual may nonetheless contain errors
and inaccuracies.
Should you detect any errors or inaccuracies in the manual, we would be grateful if
you would inform us. This helps us to further improve our documentation.
2 MAGICFX®STADIUMSHOT III —User and Installation Manual

MAGICFX®STADIUMSHOT III —User and Installation Manual 3
TABLE OF CONTENTS
Introduction 4
Target group 4
Language 5
Abbreviations 5
Revision table 5
1 Description 6
1.1 Main parts 7
1.2 Technical data 8
  
1.4 ARM control 10
1.5 DMX control 10
1.6 Display panel 11
1.7 RDM capability 12
1.8 Accessories 13
1.9 Input & Output 13
2 Safety 14
2.1 General safety rules 14
2.2 Transport 14
2.3 Compressed air 15
2.4 Outdoor use 15
2.5 Rigging 15
2.6 Noise level 15
2.7 Confetti/streamers 15
2.8 Safety symbols 16
2.9 Precautions for operation 16
3 Installation and use 18
3.1 Install the machine 18
3.2 Connect the machine 23
3.3 Fill with confetti and/or streamers 25
3.4 Fill with pressurized air 26
3.5 Shoot with DMX or pyro 27
3.6 Use the emergency stop 28
3.7 Clean up 29
4 Maintenance 33
4.1 Cleaning 33
  
5 Troubleshooting 36
6 Correct disposal 36
7 EC Declaration of Conformity 37

INTRODUCTION
Congratulations! You have bought a great new product from MAGIC FX.
This manual contains all information required for the intended use of the equipment.
Deviation from the described intended use can result in a hazardous situation and/or
property damage.
This manual includes notes and warnings on safe operation of the equipment. These
notes and warnings are accompanied by the following icons. Read them attentively!
DANGER Indicates a hazardous situation that, if not avoided, will result in
death or serious injury. This signal word is to be limited to the most
extreme situations.
WARNING Indicates a hazardous situation that, if not avoided, could result
in death or serious injury.
CAUTION Indicates a hazardous situation that, if not avoided, could result
in minor or moderate injury.
NOTICE Indicates information considered important, but not hazard-
related (e.g. messages relating to property damage).
TARGET GROUP
This manual is targeted at authorised personnel in the event industry that install and
operate the STADIUMSHOT III and the required ARM SYSTEM.
Authorised personnel are those who:
• Are appointed by their supervisor to install and/or operate STADIUMSHOT III
and the related ARM SYSTEM at the event.
• Are trained in recognizing and avoiding hazards related to SFX applications
at events.
• Are familiar with the safety instructions of each involved ARM SYSTEM
component.
• Are familiar with and abide by the applicable local, national and
international laws and regulations.
4 MAGICFX®STADIUMSHOT III —User and Installation Manual

MAGICFX®STADIUMSHOT III —User and Installation Manual 5
LANGUAGE
This document contains the original instructions in English. In case you require other
languages please contact MAGIC FX.
ABBREVIATIONS
Abbreviation Description
SFX Special eects
DMX Digital Multiplex
RDM Remote Device Management
ARM SYSTEM MAGICFX®SFX SAFETY ARM SYSTEM
ARM CONTROLLER MAGICFX®SFX SAFETY ARM CONTROLLER
E-STOP MAGICFX®SFX SAFETY E-STOP
TERMINATOR MAGICFX®SFX SAFETY TERMINATOR
STADIUMSHOT III MAGICFX®STADIUMSHOT III
Abbreviations
REVISION TABLE
Doc nr Revision Date Description Author Approved
PART01839 01-00 05-03-2020 Initial release CSK PvdW
PART01839 01-01 02-10-2020 Accessories NvE LL
PART01839 01-02 10-11-2022 Updated ARM SYSTEM TF PvdW

6 MAGICFX®STADIUMSHOT III —User and Installation Manual
1 DESCRIPTION
The STADIUMSHOT III is a special eects machine that shoots confetti or streamers into
the air. The STADIUMSHOT III is intended for outdoor use. At the desired moment the air
ows from the tank via the barrel out of the machine. This results in the confetti or
streamers leaving the output pipe at high velocity into the air up to 40 metres far*.
The machine is equipped with an onboard compressor to pressurize the air tank. The
pressure can be set via the machine’s display to accommodate dierent venues.
When the machine is loaded with MAGICFX®CONFETTI or STREAMERS, a single push
on the physical button on the STADIUMSHOT III will charge the air tank to the set
pressure, and maintain the pressure at the set value until the shot is red. If for any
reason the pressure drops, and cannot be compensated, the system will block the
shot for safety reasons.
The STADIUMSHOT III is operated with DMX and RDM, or with an external low voltage
pyro controller (24 V). The STADIUMSHOT III can be operated in sequence with
multiple machines. Furthermore, the STADIUMSHOT III is congured for safety control
with an ARM SYSTEM.
* The output distance depends on input material, air pressure and environmental
conditions.

MAGICFX®STADIUMSHOT III —User and Installation Manual 7
1.1 MAIN PARTS
VALVE ACTIVATION
LED
COMPRESSOR
ON/OFF BUTTON
INDEX PLUNGER
TOP COVER
OUTPUT PIPE
STRAP PLATE
REMOVABLE HANDLE
WITH AIRFILTER
BRAKE
COUPLING WITH
LOCKING CLAMPS
PRESSURE GAUGE
DMX INPUT & OUTPUT
(5-POLE)
FX WARNING LED
POWER INPUT & OUTPUT
(100-250 VAC) ARM CONTROLLER
INPUT & OUTPUT
SCREEN & BUTTONS
VENT VALVE
PYRO INPUT (24 VDC)
Main parts

8 MAGICFX®STADIUMSHOT III —User and Installation Manual
1.2 TECHNICAL DATA
Product Product Name STADIUMSHOT III
Product Code MFX0408
Product Type CONFETTI & STREAMER FX
Main
Dimensions
Length 600 mm 23.6 in
Width 400 mm 15.8 in
Height 870 mm 34.3 in
Weight Weight 86 kg 189.6 lb
Environment Minimum Temperature -10 °C 14 °F
Maximum Temperature 70 °C 158 °F
Humidity (Relative) 20 % to 90 % (non condensing)
Electrical Voltage Input (Vac) 100 – 250 Vac
Voltage Frequency 50 – 60 Hz
Power Consumption (Vac) 350 W
Power Connector (Vac) Neutrik®powerCON TRUE1 (in & out)
Controlling Control Options DMX / 24 Vdc
Control Protocols DMX512-A (ANSI E1.11) RDM (ANSI E1.20)
Control Connectors Neutrik®5-pole male / female XLR /
4 mm banana socket
Safety
controlling
ARM Connector Neutrik®etherCON, RJ45 (in&out)
 Congure Options On Device & RDM
Pressure
tank
Maximum Pressure 8 bar 116 psi
Volume 10.9 L 2.9 gal
Usage Consumable(s) MAGICFX® CONFETTI & STREAMERS
Technical data
1.3 PRODUCT IDENTIFICATION
Type plate
1

MAGICFX®STADIUMSHOT III —User and Installation Manual 9
Main Menu
DMX Start Address (1–512)
DMX Enable Address (1–512)
DMX Footprint
Lock/Unlock Controller
Reset Errors
Configuration Display Dimmer (ON/OFF)
Factory Defaults (YES/NO)
Pressure (4-8 Bar)
Display Dimmer (ON/OFF)
Output Distance (0-255)
Unique ID (HHHHHHHHHHHH)
Bootloader CRC
Serial Number (DDDDD)
Build Date
Uptime (DDDD:HH:MM:SS)
Effect Time (DDDD:HH:MM:SS)
Status Display
DMX Start Address (1–512)
DMX Enable Address (1–512)
DMX Footpr
DMX Enable
DMX input (XLR/ARM)
int
Lock/Unlock Controller
Reset Errors
DMX/RDM Settings
RDM (ON/OFF)
Error History Type (Alarm/Error)
Output Distance (0-255)
Unique ID (HHHHHHHHHHHH)
Bootloader CRC
Serial Number (DDDDD)
Build Date
Uptime (DDDD:HH:MM:SS)
Shots Fired (XXXX)
Pump time (DDDD:HH:MM:SS)
Information
Shots Fired (XXXX)

10 MAGICFX®STADIUMSHOT III —User and Installation Manual
1.4 ARM CONTROL
NOTICE The STADIUMSHOT III cannot be operated without connection to
an ARM CONTROLLER in an ARM SYSTEM.
The STADIUMSHOT III is congured for safety control with an ARM SYSTEM. The
STADIUMSHOT III cannot be operated without the safety signal from the control unit of
the ARM SYSTEM: The ARM CONTROLLER. When there’s no signal, the air valve from the
tank is switched o. The pressurized air can’t leave the tank, preventing the
STADIUMSHOT III from producing any high-risk SFX output. As a result, any related
hazard/or property damage is stopped and prevented.
The ARM CONTROLLER is equipped with a key switch to arm/disarm the connected
SFX machine(s), an emergency stop button, and a reset button. The ARM SYSTEM is
wired with EtherCON cables that carry the safety signal from the ARM CONTROLLER.
For more information about the ARM SYSTEM and to learn how to congure a
complete safety system, refer to the ARM SYSTEM Conguration Manual (PART02323).
For more information about the ARM CONTROLLER and to learn how to correctly set
up and use the ARM SYSTEM, refer to the ARM CONTROLLER User and Installation
Manual (PART01882).
1.5 DMX CONTROL
The STADIUMSHOT III is controlled with 1 enable adress and 1 operational address.
DMX Address Address range
Enable address 1 – 512
Start address (Trigger) 1 – 512
DMX addresses
The enable address cannot be the same as the operational address. Operating of
these addresses results in the following:
DMX Address DMX Value (decimal) Result
Enable address
0 99 Device disabled
100 154 Device enabled
155 255 Device disabled
Start address
(Trigger)
0 199 No output
200 255 Fire
Operation of the DMX addresses
When you link multiple machines with DMX, we advise you to use the same enable
address for all machines.

MAGICFX®STADIUMSHOT III —User and Installation Manual 11
CAUTION Always plug in a DMX Terminator into the DMX output of the nal
unit in the control sequence. Using a DMX Terminator improves
signal reliability.
1.6 DISPLAY PANEL
INFORMATION
ERROR HISTORYCONFIGURATION
DMX/RDM SETTINGS
Display panel
The display panel is located on the backside of the STADIUMSHOT III. Check the
following menu structure for all options in the menu. Use the buttons for navigation
and selection. The le-hand LED blinks red when DMX is active. The right-hand LED
continuously lights red when an error is present.
Menu function Explanation
Lock/Unlock
Controller
Holding the Lock button for more than 5 seconds will “lock” the
display functions. Meaning buttons will not respond. This to avoid
accidental change of parameters via display.To unlock, hold the
Unlock button for more than 5 seconds.
Reset Errors
In case there is a locking error present, this button will reset the
appliance. If the fault does not persist, the locking error will not
reappear.
DMX Start
Address (1-512)
Setting the DMX start address. DMX Enable Address (1-512)
Setting the DMX Enable Address. DMX Footprint This parameter
indicates the DMX footprint, in other words the amount of
sequential channels used by the appliance. This does not
include the enable channel.
DMX input
(XLR/ARM)
Make sure that the DMX/RDM settings on your machine match
your wiring setup. If the DMX signal runs separately over 5-pole
XLR cables, make sure that XLR is selected. If a combined DMX
and ARM signal runs over the ARM data (EtherCON) cables,
make sure that ARM is selected.
RDM (On/O) Use this function to turn on/o the RDM functionality.
Pressure
(4-8 Bar) Use this function to set the pressure between 4 and 8 bar.
Pyro Input
Control (On/O)
Use this function to switch between the powered control modes
DMX and pyro.
Display Dimmer
(On/O)
Turn display dimmer on or o. If turned on, the display is dimmed
automatically 30 seconds aer the last button push.

12 MAGICFX®STADIUMSHOT III —User and Installation Manual
Factory Defaults
(Yes/No) Restores the appliance factory default settings.
Type
(Alarm/Error)
Toggle between the occurred locking error (Alarm) list, and
blocking error (Error) list. Locking errors need intervention by
user, although they are “auto-reset” 3 times before the appliance
remains in error until reset by user. Blocking errors clear when the
triggering fault disappears. 16 locked, and 16 blocked errors are
logged. Top of the list shows the last occurring error.
Serial Number
(DDDDD) Appliance serial number as also printed on the appliance label.
Unique ID
(HHHHHHHHHHHH)
UID number as the appliance appears in the RDM device list
aer running discovery.
Soware Version Installed soware version.
Soware CRC CRC of the functional soware.
Bootloader CRC CRC of the bootloader soware.
Build Date Release date of functional soware.
Up-Time
(DDDD:HH:MM:SS)
Time counter which indicates how long the appliance has been
powered in total.
Shots Fired Number of shots red with DMX.
Pump Time
(DDDD:HH:MM:SS)
Time counter which indicates how long the pump has been on
in total.
Menu functions
1.7 RDM CAPABILITY
Remote Device Management Protocol (RDM) is an enhancement of the DMX512
communication protocol. RDM can be used for conguration and status monitoring
while DMX512 takes care of the default controlling. For RDM you will need a RDM
compatible controller. The following RDM parameters are supported by the
STADIUMSHOT III.
Parameter ID Discovery GET SET
DISC_UNIQUE_BRANCH X
DISC_MUTE X
DISC_UN_MUTE X
DEVICE_INFO X
SUPPORTED_PARAMETERS X
SOFTWARE_VERSION_LABEL X
DEVICE_MODEL_DESCRIPTION X
MANUFACTURER_LABEL X
SLOT_DESCRIPTION X
SENSOR_DEFINTION X

MAGICFX®STADIUMSHOT III —User and Installation Manual 13
Parameter ID Discovery GET SET
SENSOR_VALUE X
DMX_START_ADDRESS X X
IDENTIFY_DEVICE X X
DEVICE_LABEL X X
FACTORY_DEFAULTS X X
RESET_DEVICE X
RDM parameters
RDM parameters are subject of change due to soware updates. Contact MAGIC FX
for the latest information and updates.
1.8 ACCESSORIES
Code Product Included
MFX0404 COMPRESSION CAPS TAPE 50 m X 50 mm
MFX0407 25 CAPS + 25 CORES FOR MAGICFX®STADIUMSHOT
MFX0423 STADIUMSHOT III SECURE STRAP
MFX0424 STADIUMSHOT III RAIN COVER
MFX0313 Schuko to Neutrik®powerCON TRUE1 - cable 1.5 m
Accessories
For information about the accessories of the ARM CONTROLLER (MFX3220), refer to the
ARM CONTROLLER User and Installation Manual (PART01882).
1.9 INPUT & OUTPUT
The output pipe has a payload of 5 litres and can be lled with MAGICFX®confetti or
streamers. The maximum load per shot depends on the type of input material. The
output distance depends on the type of input material and the load.
Consumable Amount Max. Output
distance Min. Pressure
MAGICFX®PAPER CONFETTI 2 kg 20 m 66  4 bar 58 psi
MAGICFX®METALLIC CONFETTI 3 kg 20 m 66  4 bar 58 psi
MAGICFX®STREAMERS 20 m x 5 cm 8 Polybags 40 m 131  8 bar 116 psi
MAGICFX®STREAMERS 20 m x 2.5 cm 9 Polybags 40 m 131  8 bar 116 psi
MAGICFX®STREAMERS 10 m x 5 cm 15 Polybags 35 m 115  8 bar 116 psi
MAGICFX®STREAMERS 10 m x 2.5 cm 18 Polybags 35 m 115  8 bar 116 psi
MAGICFX®STREAMERS 10 m x 1.5 cm 20 Polybags 35 m 115  8 bar 116 psi
Projectile types and related loads and output
NOTICE Wind and other weather circumstances will inuence the output
distance. The given values are estimated values.

14 MAGICFX®STADIUMSHOT III —User and Installation Manual
2 SAFETY
The machine has been designed and constructed in such a manner that it can be
used safely. This applies to the use, the circumstances and the regulations as
described in this documentation. Reading this documentation and following the
instructions are therefore necessary for everyone who is authorised to work with the
machine.
The machine must be used in surroundings that:
• Have a stable temperature of between -10 and 70 °C.
• Have a relative humidity degree between 20 % and 90 % (non condensing).
• Are free of dust, corrosive gases and high concentrations of organic vapours.
• Are not situated in the vicinity of a source of vibration.
2.1 GENERAL SAFETY RULES
• Only authorised persons may carry out work with the STADIUMSHOT III.
• Do not use the STADIUMSHOT III if there are people or animals in the direct
output.
• Do not use the STADIUMSHOT III if alterations have been made other than by
or on behalf of MAGICFX®.
• Make sure that children, unauthorised people and animals do not obtain
access to the STADIUMSHOT III.
• Make sure there are no freestanding objects or objects that can be damaged
by the machine within the output distance.
• Make sure that streamers and/or confetti cannot come into contact with
high-voltage lines/power pylons, as this can result in electrocution.
• Do not connect more units to a single electrical circuit than the installed fuse
is able to handle. (Calculate the summed load with the electrical data from
Chapter 1)
• Do not remove any safeguards, safety caps and safety symbols.
• All required safety devices must be in good condition and function properly.
• Ensure sucient lighting of the surroundings.
• Keep the workplace clean.
2.2 TRANSPORT
• Check the pressure level on the tank pressure meter before every transport. If
necessary depressurize the system by opening the vent valve.
WARNING Do not transport or move the STADIUMSHOT III when the tank is
pressurized. Transporting or moving the machine when
pressurized can result in death or serious injury.

MAGICFX®STADIUMSHOT III —User and Installation Manual 15
2.3 COMPRESSED AIR
• If an external air source is used, always use an inspected and certied
professional compressor with an air output of maximum 8 bar to ll the tank.
Carefully read the manual of the compressor before use.
• Never leave the tank pressurized for more than 15 minutes.
• The machine is equipped with a pressure relief valve that automatically
depressurizes the system when the maximum allowed pressure of 8 bar is
exceeded. Nevertheless regularly check the tank pressure meter to make sure
the pressure in the tank is stable and does not exceed 8 bar. If necessary
depressurize the system by opening the ventilation valve.
2.4 OUTDOOR USE
The STADIUMSHOT III is designed for outdoor use.
WARNING The STADIUMSHOT III can be used indoors in large event halls and
arenas. Please refer to page 17.
2.5 RIGGING
Please follow the European and national guidelines for safe rigging and trussing.
2.6 NOISE LEVEL
The environmental noise level as measured at the ear is greater than 70 dB(A). This
level of noise is only reached during the short instances that the output is active.
Always wear hearing protection when you are within 5 metres of the machine during
operation.
2.7 CONFETTI/STREAMERS
WARNING Always shoot streamers at a minimum of 8 bar pressure to unfold
them completely. Shooting streamers at a lower pressure can
lead to death or serious injury.
WARNING Using any other objects other then MAGICFX® CONFETTI or
STREAMERS or other approved MAGICFX® consumables can lead
to death or serious injury.

16 MAGICFX®STADIUMSHOT III —User and Installation Manual
2.8 SAFETY SYMBOLS
Symbol Meaning
Read the manual carefully before use!
Wear certied ear protection!
Safety symbols
2.9 PRECAUTIONS FOR OPERATION
WARNING Using a damaged or an improper installed machine can lead to
death, serious injury or property damage. Always inspect the
machine thoroughly before operation.
WARNING Unauthorized operation of the machine can lead to death,
serious injury or property damage. Never leave the machine and
the power switch unattended when the machine is ready for use.
WARNING Do not use the STADIUMSHOT III if alterations have been made
other than by or on behalf of MAGICFX®.
DANGER Make sure that streamers and/or confetti cannot come into
contact with high-voltage lines/power pylons, as this can result in
electrocution.
WARNING Missing or obscured safety symbols on the machine can lead to
death, serious injury or property damage. Make sure all safety
symbols are correctly in place and visible, see Section 2.7.
CAUTION Always install the output pipe before operating the machine.

MAGICFX®STADIUMSHOT III —User and Installation Manual 17
WARNING Make sure there are no objects near the output that can be
damaged or overthrown by the STADIUMSHOT III.
DANGER Always keep the output zone as shown in the image below clear
of all people, animals and objects. Not doing so results in death
or serious injury.
WARNING Always create a safety zone around the machine with a radius of
5 meters / 16.5 feet. Make sure unauthorized personnel, animals
and objects are clear of this area. Not doing so can result in
death or serious injury.
5 m / 16.5 ft
40 m / 131 ft.
45˚
Confetti Streamers
20 m / 66 ft.
45˚

18 MAGICFX®STADIUMSHOT III —User and Installation Manual
3 INSTALLATION AND USE
3.1 INSTALL THE MACHINE
1 Bring the cased machine to the desired location.
2 Place the machine in its nal position and set the brakes.

MAGICFX®STADIUMSHOT III —User and Installation Manual 19
3 Apply a lashing ratchet to the strap plates on the side of the machine to xate
the machine and prevent it from moving.
WARNING Always make sure to properly xate the machine on a stable
and suited surface. Not doing so can result in death or serious
injury.
NOTICE Do not apply more than 100 kg on the strap plate. The ightcase
may break down.
4 Unlock and remove the ightcase cover.

20 MAGICFX®STADIUMSHOT III —User and Installation Manual
5 Remove the output pipe.
6 Pull the locking clamps downwards to unlock and rotate them upwards.
