Magicfx SNOWCASE Series Operating manual

SNOWCASE.
®
SNOW FX PART01729 rev 01-00
USER AND INSTALLATION MANUAL
ENGLISH
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 1 14-10-2019 08:11:22

2MAGICFX®SNOWCASE —User and Installation Manual
DISCLAIMER
WARNING Read this manual carefully before installing and/or using this
product. Failure to read the manual and to follow the printed
instructions may lead to personal injury and/or damage to the
product.
© 2019 MAGICFX®
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by
means of printing, photocopying or by any other means, without the prior written
approval of MAGIC FX.
MAGIC FX reserves the right to modify specications stated in this manual.
TRADEMARKS
Any brand names mentioned in this manual are registered trademarks of their
respective owners.
LIABILITY
MAGIC FX accepts no liability for claims from third parties arising from unauthorised
use, use other than that stated in this manual, and use other than in accordance with
the General Conditions registered at the Chamber of Commerce.
We further refer to the General Conditions. These are available on request, free of
charge.
Although considerable care has been taken to ensure a correct and comprehensive
description of all relevant components, the manual may nonetheless contain errors
and inaccuracies.
Should you detect any errors or inaccuracies in the manual, we would be grateful if
you would inform us. This helps us to further improve our documentation.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 2 14-10-2019 08:11:22

MAGICFX®SNOWCASE —User and Installation Manual 3
TABLE OF CONTENTS
Disclaimer 2
Trademarks 2
Liability 2
Foreword 4
Language 4
Revision table 4
1 Meet the MAGICFX®SNOWCASE! 5
1.1 Main parts 6
1.2 Technical data 7
1.3 Product identication 7
1.4 FX uids 8
1.5 Manual mode 8
1.6 DMX control 8
1.7 Display panel 9
1.8 RDM capability 12
1.9 Accessories 12
2 Snow safely! 13
2.1 General safety rules 13
2.2 Indoor use 13
2.3 Rigging 13
2.4 Noise level 14
2.5 Safety symbols 14
2.6 Precautions for operation 14
3 Let’s snow! 16
3.1 Install the machine 16
3.2 (Re)place the jerrycan with snow uid 17
3.3 Mount the truss bracket and hose 20
3.4 CongureManualmode 23
3.5 Snow in Manual mode 23
3.6 Connect power and setup DMX 24
3.7 Setup multiple machines in a sequence with DMX 25
3.8 Snow with DMX 26
3.9 Clean up 27
4 Maintenance 30
5 Troubleshooting 30
6 Correct disposal 30
7 EC Declaration of Conformity 31
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 3 14-10-2019 08:11:22

4MAGICFX®SNOWCASE —User and Installation Manual
FOREWORD
Congratulations! You have bought a great new product from MAGIC FX.
This manual contains all information required for the intended use of the equipment.
Deviation from the described intended use can result in a hazardous situation and/or
property damage.
This manual includes notes and warnings on safe operation of the equipment. These
notes and warnings are accompanied by the following icons. Read them attentively!
DANGER Indicates a hazardous situation that, if not avoided, will result in
death or serious injury. This signal word is to be limited to the most
extreme situations.
WARNING Indicates a hazardous situation that, if not avoided, could result
in death or serious injury.
CAUTION Indicates a hazardous situation that, if not avoided, could result
in minor or moderate injury.
NOTICE Indicates information considered important, but not hazard-
related (e.g. messages relating to property damage).
LANGUAGE
This document contains the original instructions in English. In case you require other
languages please contact MAGIC FX.
REVISION TABLE
Doc nr Revision Date Description Author Approved
PART01729 01-00 10-10-2019 Initial release CSK SVG
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 4 14-10-2019 08:11:22

MAGICFX®SNOWCASE —User and Installation Manual 5
1 MEET THE MAGICFX®SNOWCASE!
The MAGICFX® SNOWCASE is a special eects machine that creates a simulated snow
eect. The machine launches snow into the air at a set distance and density.
The machine pumps snow uid from a jerrycan to the snow head. The snow uid
leaves the snow head through a cone formed mesh. This creates the snow eect.
The MAGICFX® SNOWCASE is a very exible machine. It can be operated with the
eect coming straight from the machine itself, or an extension hose can be
connected. This gives the user the possibility to create the eect in dicult to reach
places such as high up in the truss. In both use cases the user has a wide variety to
set the eect angle.
The MAGICFX® SNOWCASE is outtted for operation:
• in Manual mode with multiple options (e.g setting a timer and the output
distance);
• with DMX and optionally RDM;
• in sequence with multiple machines.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 5 14-10-2019 08:11:22

6MAGICFX®SNOWCASE —User and Installation Manual
1.1 MAIN PARTS
SNOW CABINET LID
SNOW HEAD
CONE MESH
ANGLE PIN
FLIGHTCASE
DISPLAY WITH BUTTONS
AND LED INDICATORS
FX LED INDICATOR
DMX INPUT & OUTPUT
(5-POLE)
POWER INPUT & OUTPUT
(220  240 Vac)
SNOW CABINET
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 6 14-10-2019 08:11:23

MAGICFX®SNOWCASE —User and Installation Manual 7
1.2 TECHNICAL DATA
Product Product Name MAGICFX®SNOWCASE
Product Code MFX1701
Product Type FOAM FX
Main
Dimensions
Length 800 mm 31.5 in
Width 600 mm 23.6 in
Height 1000 mm 39.4 in
Weight Weight 81 kg 178.6 lb
Environment Minimum Temperature 0 °C 32 °F
Maximum Temperature 50 °C 122 °F
Humidity (Relative) 20 % to 90 % (non condensing)
Electrical Voltage Input 210 – 240 Vac
Voltage Frequency 50 – 60 Hz
Power Consumption 1150 W
Power Connector Neutrik®powerCON TRUE1 (in & out)
Controlling Control Options DMX / Manual / Timer
Control Protocols DMX512-A (ANSI E1.11)
RDM (ANSI E1.20)
Control Connectors Neutrik®5 pole male / female XLR
Conguring Congure Options On Device & RDM
Usage Consumable(s) MAGICFX®SNOWCASE - SNOW FLUID
Consumable Consumption MAGICFX® SNOWCASE - SNOW FLUID:
1 L/min
Technical data
1.3 PRODUCT IDENTIFICATION
Type plate
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 7 14-10-2019 08:11:23

8MAGICFX®SNOWCASE —User and Installation Manual
1.4 FX FLUIDS
The MAGICFX®SNOWCASE uses MAGICFX® SNOWCASE - SNOW FLUID to create the
snow eect. The uid is delivered in a jerrycan. Do not use other uids than those that
are approved and supplied by MAGIC FX, see following table.
Code Typeofuid Volume
MFX3032 MAGICFX®SNOWCASE - SNOW FLUID 20 litre
Approved FX Fluids
1.5 MANUAL MODE
Manual mode gives the user the possibility to control the machine without the need
for DMX and an external lighting console. A simple sequence of eect on and o
times, and desired distance and density can be set via the manual mode menu on
the display panel.
Manual operation menu items Values
Manual mode ON / OFF
Run timer 0 – 600 (s)
Pause timer 0 – 600 (s)
Ouput density 0 – 255
Output distance 0 – 255
Manual mode
1.6 DMX CONTROL
When connected to DMX and with Manual mode OFF the MAGICFX®SNOWCASE is
controlled with 1 safety address and 2 operational addresses:
DMX Address Address range
Safety address 1 – 512
Start address (Eect distance) 1 – 511
Start address + 1 (Eect density) 2 – 512
DMX addresses
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 8 14-10-2019 08:11:23

MAGICFX®SNOWCASE —User and Installation Manual 9
The safety address cannot be the same as (one of) the operational address(es).
Operating of these addresses results in the following:
DMX Address DMX Value (decimal) Result
Safety address
0 99 Device disabled
100 154 Device enabled
155 255 Device disabled
201 255 Extract snow uid
Start address
(Eect distance) 0 255 Eect distance
Start address + 1
(Eect density)
0 9 No output
10 255 Variable snow output
Operation of the DMX addresses
When you link multiple machines with DMX, we advise you to use the same Safety
address for all machines.
CAUTION Always plug in a DMX Terminator into the DMX output of the nal
unit in the control sequence. Using a DMX Terminator improves
signal reliability.
1.7 DISPLAY PANEL
FLUID USE
CONFIGURATIONMANUAL OPERATION
DMX/RDM SETTINGS
INFORMATION
ERROR HISTORY
Display panel
The display panel is located on the backside of the MAGICFX®SNOWCASE. Check the
following menu structure for all options in the menu. Use the buttons for navigation
and selection. The le-hand LED blinks red when DMX is active. The right-hand LED
continuously lights red when an error is present.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 9 14-10-2019 08:11:23

10 MAGICFX®SNOWCASE —User and Installation Manual
Status Display
Main Menu
DMX Start Address (1–512)
DMX Safety Address (1–512)
DMX Footprint
Lock/Unlock Controller
Reset Errors
DMX/RDM Settings
continues on next page
Configuration
RDM (ON/OFF)
Run Timer (0–600 (s))
Output Density (0-255)
Manual Mode (ON/OFF)
Manual Operation Pause Timer (0–600 (s))
Output Distance (0-255)
Factory Defaults (YES/NO)
Current Use (l/min.)
Fluid Use Cycle Used (l)
Cycle Average (l/min)
Display Dimmer (ON/OFF)
Extract Fluid (ON/OFF)
Total Used (l)
Cycle Reset (YES/NO)
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 10 14-10-2019 08:11:23

MAGICFX®SNOWCASE —User and Installation Manual 11
Menu function Explanation
Lock/Unlock
Controller
Holding the Lock button for more than 5 seconds will “lock” the
display functions. Meaning buttons will not respond. This to avoid
accidental change of parameters via display.To unlock, hold the
Unlock button for more than 5 seconds.
Reset Errors
In case there is a locking error present, this button will reset the
appliance. If the fault does not persist, the locking error will not
reappear.
DMX Start
Address (1-512) Setting the DMX start address.
DMX Safety
Address (1-512) Setting the DMX safety address.
DMX Footprint
This parameter indicates the DMX footprint, in other words the
amount of sequential channels used by the appliance. This does
not include the safety channel.
RDM (On/O) This function turns on/o the RDM functionality.
Manual Mode
(On/O)
This turns manual mode on or o. Via manual mode the user is able to
control the SNOWCASE without the need for a DMX lighting console.
Run Timer [sec]
(0-600)
This parameter represents the on time duration of the on/o cycle
of the eect.
Unique ID (HHHHHHHHHHHH)
Bootloader CRC
Serial Number (DDDDD)
Build Date
Information
Soware Version
Soware CRC
Uptime (DDDD:HH:MM:SS)
Effect Time (DDDD:HH:MM:SS)
Error History Type (Alarm/Error)
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 11 14-10-2019 08:11:23

12 MAGICFX®SNOWCASE —User and Installation Manual
Pause Timer
[sec] (0-600)
This parameter represents the o time duration of the on/o cycle
of the eect.
Output
Distance (0-
255)
Setting of the distance the snow is blown away. The 0-255 range is
comparable to the lighting console fader running from 0 upto
255.
Output Density
(0-255)
Setting of the snow density. The 0-255 range is comparable to the
lighting console fader running from 0 upto 255.
Extract Fluid
(On/O)
This function empties the uid hoses of the snowCase by running
the pump in reverse for a certain time.
Display Dimmer
(On/O)
Turn display dimmer on or o. If turned on, the display is dimmed
automatically 30 seconds aer the last button push.
Factory
Defaults (Yes/
No)
Restores the appliance factory default settings.
Total Used [l] Indicates the total amount of snow uid used since rst use of the
machine.
Curr Use [l/
min] Indicates the current snow uid consumption.
Cycle Used [l] Indicates the total amount of snow uid used since the cycle was
reset.
Cycle Avg [l/
min]
Indicates the average snow uid consumption since the cycle
was reset.
Cycle Reset
(Yes/No) When set to Yes, this resets the cycle numbers above.
Type (Alarm/
Error)
Toggle between the occured locking error (Alarm) list, and
blocking error (Error) list. Locking errors need intervention by user,
although they are “auto-reset” 3 times before the appliance
remains in error until reset by user. Blocking errors clear when the
triggering fault disappears. 16 locked, and 16 blocked errors are
logged. Top of the list shows the last occurring error.
Serial Number
(DDDDD) Appliance serial number as also printed on the appliance label.
Unique ID
(HHHHHHHHHHHH)
UID number as the appliance appears in the RDM device list aer
running discovery.
Soware
Version Installed soware version.
Soware CRC CRC of the functional soware.
Bootloader
CRC CRC of the bootloader soware.
Build Date Release date of functional soware.
Up-Time
(DDDD:HH:MM:SS)
Time counter which indicates how long the appliance has been
powered in total.
Eect-Time
(DDDD:HH:MM:SS)
Time counter which indicates how long the eect has been activated
in total.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 12 14-10-2019 08:11:23

MAGICFX®SNOWCASE —User and Installation Manual 13
1.8 RDM CAPABILITY
Remote Device Management Protocol (RDM) is an enhancement of the DMX512
communication protocol. RDM can be used for conguration and status monitoring
while DMX512 takes care of the default controlling.
For RDM you will need a RDM compatible controller. The following RDM parameters
are supported by the MAGICFX®SNOWCASE.
Parameter ID Discovery GET SET
DISC_UNIQUE_BRANCH X
DISC_MUTE X
DISC_UN_MUTE X
DEVICE_INFO X
SUPPORTED_PARAMETERS X
SOFTWARE_VERSION_LABEL X
DEVICE_MODEL_DESCRIPTION X
MANUFACTURER_LABEL X
SLOT_DESCRIPTION X
SENSOR_DEFINTION X
SENSOR_VALUE X
DMX_START_ADDRESS X X
IDENTIFY_DEVICE X X
DEVICE_LABEL X X
FACTORY_DEFAULTS X X
RESET_DEVICE X
RDM parameters
RDM parameters are subject of change due to soware updates. Contact MAGIC FX
for the latest information and updates.
1.9 ACCESSORIES
Code Product Included
MFX1702 MAGICFX® SNOWCASE HOSE 5 m
MFX1703 MAGICFX® SNOWCASE HOSE 10 m
MFX1704 MAGICFX® SNOWCASE HOSE TRUSS BRACKET
Accessories
Please contact MAGIC FX for additional possibilities.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 13 14-10-2019 08:11:23

14 MAGICFX®SNOWCASE —User and Installation Manual
2 SNOW SAFELY!
The MAGICFX®SNOWCASE has been designed and constructed in such a manner
that it can be used safely. This applies to the use, the circumstances and the
regulations as described in this documentation. Reading this documentation and
following the instructions are therefore necessary for everyone who is authorised to
work with the MAGICFX®SNOWCASE.
The MAGICFX® SNOWCASE must be used in surroundings that:
• Have a stable temperature of between 0 and 50 °C.
• Have a relative humidity degree between 20 % and 90 % (non condensing).
• Are free of dust, corrosive gases and high concentrations of organic vapours.
• Are not situated in the vicinity of a source of vibration.
2.1 GENERAL SAFETY RULES
• Only authorised persons may carry out work with the MAGICFX®SNOWCASE.
• Do not use the MAGICFX®SNOWCASE if there are people or animals in the
direct output.
• Make sure there are no objects in the direct output that can be damaged by
the MAGICFX®SNOWCASE (e.g. by getting wet).
• Make sure that children, unauthorised people and animals do not obtain
access to the MAGICFX®SNOWCASE.
• Do not connect more units to a single electrical circuit than the installed fuse
is able to handle. (Calculate the summed load with the electrical data from
Chapter 1)
• Do not remove any safeguards, safety caps and safety symbols.
• All required safety devices must be in good condition and function properly.
• Ensure sucient lighting of the surroundings.
• Keep the workplace clean.
2.2 INDOOR USE
The MAGICFX®SNOWCASE is designed for outdoor use and use in well-ventilated
indoor spaces.
WARNING Do not use the MAGICFX®SNOWCASE in poorly ventilated
conned spaces. Exposure to high levels of MAGICFX® SNOWCASE
- SNOW FLUID can cause skin and airway irritation.
2.3 RIGGING
Please follow the European and national guidelines for safe rigging and trussing.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 14 14-10-2019 08:11:23

MAGICFX®SNOWCASE —User and Installation Manual 15
2.4 NOISE LEVEL
The environmental noise level measured at 1 m from the nozzle of the product is 100
dB(A). The noise level measured surrounding the product is between 75 and 82 dB(A)
with a hose. Without a hose, the noise level measured surrounding the product is
between 72 and 78 dB(A). This level of noise is only reached during the short
instances that the snow eect is active. Therefore hearing protection is not necessary.
WARNING Do not operate the MAGICFX®SNOWCASE close to yourself or to
others for a long period of time. If you experience any hearing
loss or ringing in the ears, you should immediately stop using the
unit.
2.5 SAFETY SYMBOLS
Symbol Meaning Position
Read the manual carefully
before use!
Front panel near the display
Safety symbols
2.6 PRECAUTIONS FOR OPERATION
WARNING Using a damaged or an improper installed machine can lead to
death, serious injury or property damage. Always inspect the
machine thoroughly before operation.
WARNING Missing or obscured safety symbols on the machine can lead to
death, serious injury or property damage. Make sure all safety
symbols are correctly in place and visible, see Section 2.4.
WARNING Always follow the instructions as noted on the jerrycans.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 15 14-10-2019 08:11:23

16 MAGICFX®SNOWCASE —User and Installation Manual
WARNING Always create a safety zone of 5 m in front of the MAGICFX®
SNOWCASE when the snow comes directly from the snow output.
The oor can get slippery due to spilled snow uid. A safety
zone clear of objects is also necessary for an eective
output.
CAUTION Do not tip over the machine. This can damage the machine.
CAUTION Remove the (snow uid) jerrycan when transporting the
MAGICFX® SNOWCASE. The jerrycan can tip over and spill uid in
the snow cabinet.
CAUTION Walk carefully when approaching the machine. The oor can be
slippery due to spilled snow uids.
NOTICE Transport the MAGICFX® SNOWCASE only on at surfaces.
NOTICE Do not use other uids than those that are approved and
supplied by MAGIC FX, see Section 1.4.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 16 14-10-2019 08:11:23

MAGICFX®SNOWCASE —User and Installation Manual 17
3 LET’S SNOW!
3.1 INSTALL THE MACHINE
1 Bring the MAGICFX®SNOWCASE to the desired location.
2 Unlock and remove the top cover.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 17 14-10-2019 08:11:24

18 MAGICFX®SNOWCASE —User and Installation Manual
3 Take the necessary safety precautions, see Section 2.5.
4 Place the MAGICFX® SNOWCASE in its nal position and set the brakes.
3.2 (RE)PLACETHEJERRYCANWITHSNOWFLUID
WARNING Always follow the instructions as noted on the jerrycans.
1 Make sure that the machine is not in operation (FX LED indicator is dimmed).
2 Open the snow cabinet lid. Disconnect and remove an empty jerrycan if
present.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 18 14-10-2019 08:11:24

MAGICFX®SNOWCASE —User and Installation Manual 19
3 Place a jerrycan with snow uid in the snow cabinet and remove and save the
lid.
4 Connect the snow lid inside the cabinet.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 19 14-10-2019 08:11:25

20 MAGICFX®SNOWCASE —User and Installation Manual
5 Close the snow cabinet lid.
6 Pull the angle pin to adjust the angle of the snow head.
7 Let go of the angle pin when satised with the angle.
8 In case of multiple machines: Repeat steps 1 – 7 for each machine.
MAGICFX_SNOWCASE_UM-IM_EN_v01-00_A5.indd 20 14-10-2019 08:11:25
