Magicfx Power Drop User manual

PRODUCTCODE : MFX1501
VERSION : 1.0
DATE : 03.06.2012

User Documentation MAGICFX® Power Drop
Page 1
1. CONGRATULATIONS!
You have purchased a Power Drop, a great and innovative product from MAGICFX®.
MAGIC FX is a Dutch manufacturer of professional special effects machinery and equipment. We
have specialized in special effects since we established our business in 1995. All products are
manufactured under the brand name MAGICFX®, which has acquired an excellent reputation for
quality and reliability. All products are manufactured in accordance with the European Machinery
Directive. MAGIC FX handles the entire production in-house from concept to finished product. We take
care of the design, prototyping and manufacturing process.
MAGICFX® products are used by special effects professionals around the world and distributed by a
dealer network across more than 80 countries.
You can rely on MAGICFX® for excellent effects!
We work hard to keep you, our customer, satisfied.
Congratulations and a lot of success and amazing shows with your new MAGICFX® Power Drop!

Version 1.0
Page 2
2. CE MARKING
NOTE:
We must assume that you, your employees and others who use or come
into contact with the machine are familiar with how the machine should
be utilized. This specifically pertains to the proper use, maintenance and
repair of the machine as described in this user manual. This also means
that employees should be qualified to use machinery through training or
experience.
It is required that the user of this product has followed a training for the
correct use of this product. Trainings are provided by MAGIC FX.
DANGER WARNING:
The Power Drop must only be used according to the prescriptions and
instructions in this manual. Consult MAGIC FX if there are any doubts
about usage.
Disclaimers:
MAGIC FX B. V. specifically disclaims liability for unsafe situations, accidents and damages caused
by:
-Ignoring warnings or prescriptions displayed on the Power Drop or in this documentation.
-Using the equipment for other purposes or situations than specified in this documentation.
-Modifications to the Power Drop. This includes the use of non-original spare parts.
-Improper maintenance.
-Unauthorized removal of safety covers and/or safety devices.
-Improper use of the machine.
MAGIC FX B.V. is not liable for any damages due to failures of the Power Drop.
© Copyright 2012
All rights reserved. No part of this manual may be reproduced, stored in a retrieval system or
transmitted in any form or by any means, electronic, mechanical, photocopied, recorded or otherwise
without the prior written permission of MAGIC FX B.V.
MAGIC FX reserves the right to make modifications at any time without having to notify the customer
beforehand. The content of this manual may also be modified.
For additional information about maintenance, repair, and so on, please contact your supplier’s
technical department. This manual was written with the utmost care. MAGIC FX cannot be held liable
for errors contained in this document or consequences thereof.

User Documentation MAGICFX® Power Drop
Page 3
3. DECLARATION OF CONFORMITY
DECLARATION OF CONFORMITY
(according to Annex IIA of the Machinery Directive)
With respect to the Machinery Directive.
MAGIC FX B.V.
Industrieweg 16
5281 RW Boxtel
The Netherlands
Hereby declares under our sole responsibility:
We are the manufacturer of the product:
MFX1501 - MAGICFX®Power Drop
to which this declaration pertains and it is in conformity with the
provisions of the following guidelines:
-Machinery Directive 2006/42/EG
-Low Voltage Directive 2006/95/EG
-EMC Directive 2004/108/EG
The following harmonized standards are applicable:
-NEN-EN-ISO 12100-1
-NEN-EN-ISO 12100-2
City: Boxtel
Date : 08-06-2010
Name: MAGIC FX
Director: B. Veroude

Version 1.0
Page 4
4. FOREWORD
This manual provides pertinent information about the MAGICFX® Power Drop. The information in this
manual is important with respect to the proper and safe operation of the Power Drop. If you are not
familiar with the installation, operation, preventive maintenance, etc., of the Power Drop then read this
manual in its entirety. MAGIC FX also urges all new users (operators, installers, maintenance staff and
possibly cleaning staff) to receive training on the equipment using this manual as the basis for the
training.
MAGIC FX recommends you keep the original of this manual and its attachments in a secure central
location, and, keep another copy of this manual close to the workplace where the Power Drop will be
used.
If you are well acquainted with the proper handling of the equipment then keep this manual handy for
reference.
The following conventions are used in this manual to draw your attention to specific information or
actions.
TIP:
This provides you with suggestions and advice on how to perform tasks
in an easier or more convenient way.
NOTE:
This is a note providing supplemental information that alerts you to
possible problems.
CAUTION:
This indicates that the equipment may be damaged if procedures are not
carried out in the proper manner.
DANGER WARNING:
This indicates that you may cause yourself injury, possibly serious, if
procedures are not carried out in the proper manner.

User Documentation MAGICFX® Power Drop
Page 5
TABLE OF CONTENTS
1. CONGRATULATIONS!.................................................................................... 1
2. CE MARKING................................................................................................... 2
3. DECLARATION OF CONFORMITY................................................................. 3
4. FOREWORD .................................................................................................... 4
5. INTRODUCTION .............................................................................................. 6
5.1 DESCRIPTION OF THE POWER DROP AND ITS USAGE .................................................. 6
5.2 NECESSARY ACCESSORIES............................................................................................... 6
6. SAFETY ........................................................................................................... 7
6.1 INTRODUCTION..................................................................................................................... 7
6.2 GENERAL SAFETY RULES................................................................................................... 7
6.3 WARNINGS............................................................................................................................. 7
7. PARTS ............................................................................................................. 8
8. ACCESSORIES................................................................................................ 9
9. PREPARATION FOR USE............................................................................... 9
10. INSTALLING.................................................................................................. 10
11. USAGE........................................................................................................... 13
12. TURNING OFF............................................................................................... 14
13. TROUBLESHOOTING ................................................................................... 15
14. TECHNICAL SPECIFICATIONS.................................................................... 15
15. MAINTENANCE ............................................................................................. 15
16. GUARANTEE................................................................................................. 15

Version 1.0
Page 6
5. INTRODUCTION
5.1 DESCRIPTION OF THE POWER DROP AND ITS USAGE
The Power Drop is an device specially developed for dropping backdrops from as truss construction.
The Power Drop is developed to drop a larger range of object like balloons or banners.
Should you use the equipment in any way other than just described then you release your supplier
from all liability.
5.2 NECESSARY ACCESSORIES
The following parts are required with the Power Drop:
Manual
MFX0308 –POWER CABLE
MFX0309 –POWER LINK CABLE
Table 5.1

User Documentation MAGICFX® Power Drop
Page 7
6. SAFETY
6.1 INTRODUCTION
The Power Drop should be located and used in an environment that preferably:
-Has a fairly constant temperature between 0 and 30ºC.
-Has a relative humidity not exceeding a maximum of 75%.
-Is reasonably free of dust, corrosive gases, and high concentrations of organic vapors.
-Does not contain any source of vibrations in the environment.
The Power Drop is designed and constructed so that it can be used in a safe manner. Specifically, this
refers to the usage, situations, and prescriptions for the device as described in this documentation. It
is the responsibility of all persons authorized to use the Power Drop to read and follow the instructions
in this manual.
6.2 GENERAL SAFETY RULES
-Ensure that the Power Drop is not accessible to children, unauthorized persons, or animals!
-Do not touch the Power Drop when it is operational or turned on. Even if the device is not in
operation it might be ready to activate.
-Safety devices must not be removed or rendered inoperative.
-All required safety devices should be in good working order and functioning properly.
-Ensure that there is adequate lighting in the environment.
-Keep the workplace clean.
-Only authorized persons may work with the Power Drop.
6.3 WARNINGS
There are several warnings displayed on the Power Drop to which the following restrictions apply:
-The text must not be removed or otherwise spoilt. The operator should regularly check that the
warnings are in good condition.
-The operator must ensure that the text is always visible and legible and that it remains so.
DANGER WARNING:
Any missing, damaged, or illegible text or icons must be replaced.

Version 1.0
Page 8
7. PARTS
1. LED indicator
2. Drop lever
3. Safetyhook
4. Power in & out
5. Reset pin
6. Truss clamp
1
2
3
4
5
6

User Documentation MAGICFX® Power Drop
Page 9
8. ACCESSORIES
MFX1502 –CURTAIN CLAMP
MFX3102 –SAFETY CABLE
MFX1504 –SET PRO
Table 8.1
You can order the above parts from:
9. PREPARATION FOR USE
Unpack the Power Drop. Dispose of packaging material without causing harm to the environment.
Check the device for any possible damage. You must report any damage to the device to MAGIX FX.
MAGIC FX B.V.
Industrieweg 16
NL-5281 RW BOXTEL
The Netherlands
T. [phone]
F. [phone]
W. http://www.magicfx.eu
E. [e-mail]

Version 1.0
Page 10
10. INSTALLING
CAUTION:
This indicates that the equipment may be damaged if procedures are not
carried out in the proper manner.
DANGER WARNING:
The MAGICFX® Power Drop may only be installed by authorized adults.
Prepare the Power Drop for use as follows:
Connect the First Power Drop with the
shuko to powerCON cable.
3.
1m
Use the width of the backdrop or the
object u want to drop to determine the
location of the first Power Drop
Place between the first and the last with
an interval of 1 meter the other Power
Drops. This ensures a tight backdrop and
enough solidity.
2.
Mount the Power Drop in a sturdy truss
Construction.
Make sure the Power Drop is
perpendicular to the ground.
1.

User Documentation MAGICFX® Power Drop
Page 11
Now u can secure your backdrop in the
Power Drops .
If the backdrop has rings in it u can hook
it over the drop lever and lock in the drop
lever. Continue this until the entire
backdrop is locked in.
7.
Disconnect the Power Drops from the
power source and add a power switch to
control the Power Drops.
Make sure the switch is able to switch the
current used by the Power Drops.
6.
Connect the Power Drops to a 230VAC
power source to check if all the Power
Drops are connected. If all the Power
Drops are connected in the right way all
LED indicators light up.
5.
To connect the next Power Drop use the
powerCON to powerCON cable.
Never use more than 25 Power Drops in
series on a standard 16 Amp outlet.
4.

Version 1.0
Page 12
Always use a safety cable to ensure the
Power Drop to the construction.
On the Power Drop there is a safety hook
for a safety cable.
If u want to release the backdrop
manually use the reset pin on the back of
the Power Drop.
By pressing the reset pin up the drop
lever will be released.
Next use the same procedure as in step 7.
9.
If the backdrop doesn’t include rings u
can use the special curtain clamps.
The curtain clamp can be secured to the
backdrop by placing it over the edge f the
backdrop and locking it in its place.
8.

User Documentation MAGICFX® Power Drop
Page 13
11. USAGE
TIP:
This provides you with suggestions and advice on how to perform tasks
in an easier or more convenient way.
CAUTION:
This indicates that the equipment may be damaged if procedures are not
carried out in the proper manner.
DANGER WARNING:
The MAGICFX® Power Drop may only be operated by authorized adults.
The Power Drop may only be operated if all parts are entire and in good
working order and properly connected/installed.
Operate the Power Drop as follows:
When the Power Drop is connected to
a power source the drop lever will
release.
Press the switch to provide the Power
Drop with power.
Make sure the Power Drop is
activated before releasing the button
(min 1 sec.)
U can also control the Power Drop by
DMX using an switch pack.
1.

Version 1.0
Page 14
12. TURNING OFF
Turn off the Power Drop as follows:
Store the Power Drop in its flightcase to
prevent damage.
3.
Unscrew the truss clamp from its
construction and unlock the safety cable
from the Power Drop.
2.
Disconnect the powerCON cable from the
Power Drop
1.

User Documentation MAGICFX® Power Drop
Page 15
13. TROUBLESHOOTING
- The Power Drop does not drop when activated
Make sure the Power Drop is powered by checking if the indicator LED will light up. If so check if the
load is under 20Kg. if this doesn’t resolve the problem try to power the Power Drop for a longer period.
- The Power Drop still does not work after troubleshooting
Always contact your dealer or the MAGIC FX technical department if you have any doubts or
questions about the operation of or other issues related to the Power Drop.
14. TECHNICAL SPECIFICATIONS
Dimensions
and weight
Length:
135mm (5.3”)
Width:
76mm (3.0”)
Height:
74mm (2,9”)
Weight:
0,9Kg (2.0lbs.)
Power
Input:
20,0Kg (44.1lbs.)
Output:
AC 230V~50-60Hz
Consumption:
AC 230V~50-60Hz
Fuse:
100W (idle)
15. MAINTENANCE
To prolong the life of the Power Drop for as long as possible, you must regularly clean it and test that it
functions properly.
Regardless of the reason, contact MAGIC FX if the Power Drop does not work properly
DANGER WARNING:
Never replace parts yourself. Always consult MAGIC FX when needed.
16. GUARANTEE
The MAGIC FX Power Drop has a 3 year factory guarantee.
-The guarantee is annulled should the Power Drop be used for purposes other than intended or for
applications that are not listed in the manual.
-The guarantee is annulled should the device be used incorrectly or in a manner contrary to its
instructions.
-The guarantee is annulled if the device is altered without the permission of its supplier.
