Magiglo ARIA User guide

Users,
Installation & Servicing
Instructions
MUST BE LEFT WITH THE USER
ARIA
Models:
Aria 16”
Aria 18”
Fuel Effect Options:
Coal Effect – NG and LPG
Pebble Effect – NG and LPG
Control Options:
Manual BM Control
Upgradeable Manual Control
Remote Control
Optimum Control
Trim Switch Control
Total Control
For use on Natural Gas (G20) at a supply pressure of 20mbar
or Propane (G31) at a supply pressure of 37mbar in GB and IE
(Dependent upon model)

Manufacturer Contact Details:
Burley Magiglo
Lands End Way
Oakham, Rutland, LE15 6RB
Tel: [phone]
Fax: [phone]
General E-Mail: [e-mail]
Web Site: www.magiglo.co.uk
Technical Support: Direct Dial on [phone] or email: [e-mail]
Burley Magiglo Document Number:
BMF245.91 CAS
Revision Date:
23 September 2009
Copyright:
This documentation is copyrighted by Burley Magiglo ©2009.
No part of this document may be copied, photocopied or reproduced in any form or by any
means without permission in writing from Burley Magiglo.
Magiglo is a registered trademark of Burley Appliances Ltd
Service Warranty:
In the unlikely event of a defect in materials or workmanship occurring within one year of
purchase, Burley Magiglo will arrange to repair or replace the item free of charge.
Any claims under this warranty must be made through the retailer from whom the product
was purchased.
As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter
into discussions with the purchaser until the retailer has inspected any claim and deemed
it to be valid.
Burley Magiglo reserve the right to refuse service or make a charge for any service call,
when a defect is due to installation error or misuse.
Extended warranty (if purchased) commences after the first year; please see separate
registration for further information.
Appliance Details:
For future reference, please complete the following information at the time of installation.
Model and Serial Number details may be found on the data plate as shown.
Serial Number
Model
Installation Date
Installed By
Model
Serial
Number

Page i
Contents
1.General Information...........................................................................................................1
1.1.Important Note About ODS Pilot ................................................................................3
1.2.Fire Fret Dimensions..................................................................................................3
2.User Instructions ...............................................................................................................5
2.1.Lighting Procedure.....................................................................................................5
2.1.1.Lighting Procedure (Manual BM Control) ............................................................6
2.1.2.Lighting Procedure (Upgradeable Manual Control) .............................................7
2.1.3.Lighting Procedure (Remote Control)..................................................................8
2.1.4.Lighting Procedure (Optimum Control and Trim Switch Control).........................9
2.1.5.Lighting Procedure (Total Control).....................................................................10
2.1.6.Manual Operation (Total Control) ......................................................................11
2.2.Battery Replacement (Remote Control & Total Control)..........................................12
2.2.1.Handset..............................................................................................................12
2.2.2.Receiver Unit .....................................................................................................12
2.3.Battery Replacement (Optimum Control).................................................................13
2.4.Battery Replacement (Trim Switch Control).............................................................13
2.5.Fuel Effect Layout ....................................................................................................14
2.5.1.Coal Effect Layout..............................................................................................15
2.5.2.Pebble Effect Layout..........................................................................................17
2.6.Fitting the Trim .........................................................................................................19
2.6.1.Elegance Trim (Preparation)..............................................................................19
2.6.2.Elegance Trim (Fitting).......................................................................................20
2.6.3.Box Trim.............................................................................................................20
2.7.Home Improvements................................................................................................20
2.8.Cleaning and Care Instructions................................................................................21
2.8.1.Cleaning the Fire-Bed and the Imitation Coals/Pebbles....................................21
2.8.2.Cleaning the Pilot...............................................................................................22
2.8.3.Cleaning the Fire Back.......................................................................................22
2.8.4.Black Painted Metal Surfaces............................................................................22
2.8.5.Brass or Chrome Surfaces.................................................................................23
2.8.6.Stainless Steel...................................................................................................23
2.8.7.Care of Ceramic Backs......................................................................................23
3.Installation Instructions ..................................................................................................25
3.1.General Safety Requirements..................................................................................25
3.2.Flue and Chimney Requirements.............................................................................25
3.3.General Dimensions.................................................................................................26
3.4.Technical Data .........................................................................................................26
3.4.1.16” Aria (All Controls).........................................................................................26
3.4.2.18” Aria (All Controls).........................................................................................26
3.5.Appliance Location...................................................................................................27
3.6.Ventilation.................................................................................................................28
3.7.Contents Checklist ...................................................................................................28
3.8.Installation Procedure...............................................................................................29
3.8.1.Preparing the Firebox ........................................................................................29
3.8.2.Preparing the Fireplace Opening.......................................................................30
3.8.3.Connecting the Gas Supply...............................................................................31
3.8.4.Fitting the Firebox..............................................................................................31
3.8.5.Continuation of Installation - Remote Control Model ......................................... 33
3.8.6.Continuation of Installation - Optimum Control Model .......................................34
3.8.7.Continuation of Installation - Trim Switch Control Model...................................35
3.8.8.Continuation of Installation - Total Control.........................................................35

Page ii
3.8.9.Commissioning ..................................................................................................36
3.8.10.Checking for Spillage.........................................................................................37
3.8.11.Instructing the User............................................................................................37
4.Servicing Instructions.....................................................................................................39
4.1.General Requirements.............................................................................................39
4.2.Servicing Instructions...............................................................................................39
4.3.Replacing Parts........................................................................................................41
4.3.1.Fire Back Replacement......................................................................................41
4.3.2.Burner Board Replacement ...............................................................................42
4.3.3.Pilot Assembly Replacement.............................................................................42
4.3.4.Control Valve Replacement (BM or Mertik GV34))............................................43
4.3.5.Motor Replacement (Remote Control / Optimum Control Models / Trim
Switch Models)...................................................................................................44
4.3.1.Control Valve Replacement (Total Control).......................................................45
4.3.2.Replacing Receiver (Total Control)....................................................................45
4.3.3.Programming Handset to Receiver....................................................................45
4.4.Installation and Operational Troubleshooting...........................................................46
4.5.Schematic Wiring Diagram (Trim Switch and Optimum Control) .............................48

Page 1
1.GENERAL INFORMATION
Introduction
1. This appliance is suitable for installation in GB and IE and should be installed in
accordance with the rules in force.
In GB, the installation must be carried out by a Gas Safe Registered Installer registered for
working on this type of appliance. It must be carried out in accordance with the relevant
requirements of the:
•Gas Safety (Installation and Use) Regulations.
•The appropriate Building Regulations either The Building Regulations, The
Building Regulations (Scotland), Building Regulations (Northern Ireland).
•The Current I.E.E. Wiring Regulations.
Where no specific instructions are given, reference should be made to the relevant British
Standard Code of Practice (see item 2).
In IE, the installation must be carried out by a Competent Person and installed in
accordance with the current edition of I.S.813 “Domestic Gas Installations”, the current
Building Regulations and reference should be made to the current ETCI rules for electrical
installation.
On completion of an installation in IE, it is necessary to complete a “Declaration of
Conformity” to indicate compliance to I.S.813.
2. The installation of the fire should also follow the recommendations of the following current
British Standards (or equivalent):
BS 5871: Pt 2 Installation of ILFE gas fires
BS 6891 Pipe work installation
BS 5440: Pt 1 and 2 Flues and Ventilation
3. In other EC countries equivalent rules in force must be used.
4. It is important for correct combustion of this fire that the imitation fuel is placed in
accordance with the instructions given in this and associated booklets. Only approved
imitation fuel, available from Burley Magiglo., should be used with this appliance.
5. It is recommended that a fire guard complying with BS 8423 be fitted for the protection of
young children, the elderly or infirm.
6. The Aria 18” models are intended for decorative purposes only.
7. The user is warned not to throw any rubbish onto the fire or to disturb the fuel bed.
8. The user is advised that the ceramics used within this appliance require extra care whilst
cleaning. Please refer to the Cleaning Instructions.
9. It is important for this fire to be serviced regularly. An annual service is recommended.
Efficiency Declaration
The efficiency of Aria 16” has been measured as specified in BS 7977: Part 1 and the result is
49.9%*. The gross calorific value of the fuel has been used for this efficiency calculation. The
test data from which it has been calculated has been certified by Advantica Ltd. The efficiency
value may be used in the UK Government’s Standard Assessment Procedure (SAP) for
energy rating of dwellings (* 55.4% net efficiency).

Page 2
Ventilation Requirements
1. For Aria 16” models, normal adventitious ventilation is usually sufficient to satisfy the
ventilation requirements of these appliances. In GB reference should be made to BS 5871
Part 3, and in IE reference should be made to the current edition of I.S.813 which makes
clear the conditions that must be met to demonstrate that sufficient ventilation is available.
2. The Aria 18” models require a minimum of 100cm2ventilation in the room where the fire is
installed when installed in Great Britain (GB) and in IE, reference should be made to the
current edition of I.S.813 which makes clear the conditions that must be met to
demonstrate that sufficient ventilation is available.
3. If provided, any purpose provided ventilation must be checked periodically to ensure it is
free from obstructions.
4. When fitting the fire in Northern Ireland (NI), purpose provided ventilation must be
provided in accordance with the rules in force.
5. In other EC countries equivalent rules in force must be used.
Gas Supply
1. This range of decorative gas fires are suitable for use with either Natural Gas (G20) at
20mbar supply pressure, or LPG (G31) at 37mbar supply pressure (please check
appliance data plate for compatibility).
2. A separate means of isolating the gas supply should be provided near to the appliance to
facilitate servicing. For this an isolating valve has been supplied.
Electrical Supply
Not applicable to this range of appliances.

Page 3
1.1. 0B Important Note About ODS Pilot
This fire is fitted with an ODS pilot which causes the appliance to shut down in the event of a
reduction of oxygen (e.g. caused by poor ventilation) in the room. Should this happen, follow
the lighting instructions to re-light the fire. In the event that the fire should shut down again,
do NOT attempt to re-light it but contact your gas installer for remedial action to be taken.
Under no circumstances should it be adjusted or put out of action by the installer
or the user. In case the pilot needs replacing, only the approved part (listed in the
spare parts list) should be fitted. Note: if any part of the pilot assembly becomes
faulty the complete assembly will need replacing.
1.2. 1BFire Fret Dimensions
All models can be used with the Burley Magiglo range of frets or any other fire fret that
falls within the dimensions shown below
Minimum opening
(free air) in fire fret
Minimum opening
(free air) in ash pan cover
Figure 1
Fire Front Specification
16” Model 18” Model
Height to Centre (A) Maximum 9 Inches (23cm) 9 Inches (23cm)
Minimum 7.5 Inches (19cm) 7.5 Inches (19cm)
Ash Pan Cover Height (B) Maximum 3.5 Inches (9cm) 3.5 Inches (9cm)
Minimum 2.5 Inches (6.4cm) 2.5 Inches (6.4cm)
Ash Pan Cover Free Air Opening Minimum 5 sq. Inches
(32.3cm2) 5 sq. Inches
(32.3cm2)
Fire Fret Free Air Opening Minimum 15 sq. Inches
(97cm2) 18 sq. Inches
(116cm2)
Ash Pan Cover Length (C) Maximum 13.5 Inches (34cm) 15.5 Inches (40cm)
Minimum 12.5 Inches (32cm) 14.5 Inches (37cm)

Page 4
This page is left intentionally blank

Page 5
2.USER INSTRUCTIONS
2.1. 2BLighting Procedure
Your fire will be fitted with one of the following different types of gas control valves. Identify the
control system on your fire as shown and follow the appropriate operating instructions in the
appropriate section.
Control Valve Operation Control Type
+Manual =
Manual BM
Control
See
Section X2.1.1X
on Page X6X
+Manual =Upgradeable
Manual Control
See
Section X2.1.2X
on Page X7X
+
=
Remote
Control
See
Section X2.1.3X
on Page X8X
+=
Optimum
Control
See
Section X2.1.4X
on Page X9X
+=
Trim Switch
Control
See
Section X2.1.4X
on Page X9X
+=Total
Control
See
Sections
X2.1.5X& X2.1.6X
on Pages
X10X& X11X

Page 6
2.1.1. 23BLighting Procedure (Manual BM Control)
1. Ensure that the arrow on the control
knob is pointing towards the OFF
position as shown in XFigure 2X. Press in
the knob and slowly turn anti-clockwise
until a click is heard. The spark should
now light the pilot. On first lighting, it
may require several attempts to allow the
pilot light to be purged of air.
2. The pilot can be viewed either at the
front centre of the fire, or to the right
hand side.
3. Once the pilot flame is established, hold
the control knob in for approximately 10-
20 seconds and release. The pilot
should now remain alight. Repeat the
procedure if necessary.
4. The arrow should now be pointing to the
PILOT position as shown in XFigure 3X.
5. If the spark unit fails to light the pilot, the
appliance may be lit manually by
applying a lighted match or taper to the
pilot jet and following the above
procedure.
NOTE: No attempt should be
made to relight the fire for at
least 3 minutes after the pilot
flame has been extinguished
either intentionally or
unintentionally.
6. Once the pilot is established, the main
burner can be operated by turning the
control knob anti-clockwise. The preset
minimum is found with the arrow in the 9
o’clock position as shown in XFigure 4X.
7. The preset maximum (as shown in
XFigure 5X) is found by turning the control
knob fully anti-clockwise. The control is
infinitely variable between the two preset
limits.
8. To extinguish the main burner, push the
control knob in and turn clockwise until
the arrow is in the PILOT position, then
release.
9. To extinguish the pilot, push the control
knob in and turn it clockwise until the
arrow is in the OFF position, then
release.
Figure 2 - Off Position
Figure 3 - Ignition Position
Figure 4 - Minimum Position
Figure 5 - Maximum Position

Page 7
2.1.2. 24BLighting Procedure (Upgradeable Manual Control)
1. Whilst pushing the IGNITION KNOB in
(see XFigure 6X), turn it anticlockwise to
the pilot flame position as shown in
XFigure 7X. During this process, the spark
ignition will have operated and lit the pilot
flame. On lighting the pilot flame
continue to depress the ignition knob for
a further 10 - 12 seconds then slowly
release. The pilot flame should stay
alight. If the flame goes out repeat the
procedure above to establish the pilot.
2. If the spark unit fails to light the pilot, the
appliance may be lit manually by
applying a lighted match or taper to the
pilot jet and following the above
procedure.
3. Turn the IGNITION KNOB anticlockwise
to the main flame position as shown in
XFigure 8X.
4. Turn the GAS RATE ADJUSTING KNOB
fully anticlockwise (until you reach the
stop position) i.e. the maximum gas rate.
See XFigure 9X.
5. The main burner will have cross-lit from
the pilot.
6. Now the gas rate can be adjusted to the
desired setting by turning the GAS RATE
ADJUSTING KNOB to any position
between the pre-set high and low.
7. To switch off the main burner turn the
IGNITION KNOB to the ‘Pilot burner only
Position’ as shown in XFigure 7X. The
appliance may be left in this standby
mode if desired.
8. To turn the pilot off turn the Ignition Knob
on the control valve fully clockwise to ‘¦’
position.
NOTE: No attempt should be
made to relight the fire for at
least 3 minutes after the pilot
flame has been extinguished
either intentionally or
unintentionally.
Ignition knob
Gas rate adjusting knob
Figure 6 - Off Position
Figure 7 – Pilot burner only
Figure 8 – Main burner operational, but gas flow off
Figure 9 - Main Burner operational & Maximum Gas
Rate

Page 8
2.1.3. 25BLighting Procedure (Remote Control)
1. Press the bottom button on the remote
handset until clicking is heard on the
valve, and the gas rate adjustment knob
is at the off position.
2. With gas available at the valve press the
IGNITION KNOB in and turn it
anticlockwise to the pilot flame position.
A click of the piezo igniter will be heard
and a spark will appear at the electrode.
At the same time the gas will flow to the
pilot burner and should be ignited by the
spark. Repeat the procedure until the
pilot flame is established.
3. Keep the knob pressed in for a further 10
- 12 seconds and slowly release it. The
pilot flame should stay alight. If the flame
goes out repeat the procedure above to
establish the pilot.
4. If the spark unit fails to light the pilot, the
appliance may be lit manually by
applying a lighted match or taper to the
pilot jet and following the above
procedure.
5. Turn the IGNITION KNOB
anticlockwise to the Main Burner
Operation position as shown in XFigure
10X.
6. Using the HANDSET (as shown in
XFigure 11X) press and hold both the top
and the small button together until the
main burner goes to full rate and clicking
can be heard from the valve. During this
process the main burner will ignite from
the pilot.
7. By pressing the two buttons together (to
increase the gas rate) and the lower
button only (to decrease the gas rate)
the valve can be manipulated to select
the desired gas rate between maximum
and minimum. By pressing the buttons
in short bursts you will be able to adjust
the gas rate in small steps.
8. To turn the fire off, continuously press
the lower button until the flame dies
down and clicks can be heard from the
valve. Release the button as soon as the
clicks are heard.
9. The fire can safely be left in this position
at all times, however to prevent
unauthorised or accidental use (say by
children) it is recommended to turn the
IGNITION KNOB to the pilot flame
position by turning it 90 degrees
clockwise. To turn the pilot off, turn the
IGNITION KNOB fully clockwise.
NOTE: The clicking sound
made by the valve is the
operation of the valve clutch,
and indicates either maximum
or minimum positions.
IGNITION
KNOB
FULL RATE
POSITION
MAIN BURNER
OFF POSITION
PILOT ONLY
POSITION
MAIN BURNER
OPERATION
GAS RATE
ADJUSTMENT
KNOB
Figure 10 – Gas Valve
Press these
two buttons
together to
increase
gas rate
Press this
button to
decrease
gas rate
Figure 11 - Handset Operation
NOTE: No attempt should be
made to relight the fire for at
least 3 minutes after the pilot
flame has been extinguished
either intentionally or
unintentionally.

Page 9
2.1.4. 26BLighting Procedure (Optimum Control and Trim Switch Control)
1. Ensure the main burner is off by pressing
the button on the trim marked
(‘small flame/dot’) until clicking is heard
on the valve (see XFigure 12X/XFigure 13X).
2. With the gas available at the valve press
in the IGNITION KNOB and turn it
anticlockwise to the pilot flame position
(see XFigure 14X). A click of the piezo
igniter will be heard and a spark will
appear at the electrode. At the same
time the gas will flow to the pilot burner
and will be ignited by the spark. Repeat
the procedure until the pilot flame is
established.
3. Keep the knob pressed in for a further 10
- 12 seconds and slowly release. The
pilot flame should stay alight. If the
flame goes out repeat procedure above
to establish the pilot.
4. If the spark unit fails to light the pilot, the
appliance may be lit manually by
applying a lighted match or taper to the
pilot jet and following the above
procedure.
5. Turn the IGNITION KNOB anticlockwise
to the main flame position.
6. Press and hold the (‘large flame’)
button (in XFigure 12X/XFigure 13X) until
clicking is heard (fully open).
7. The main burner will have cross-lit from
the pilot.
8. Now the gas rate can be adjusted to the
desired setting by pressing the
(‘small flame/dot’) button. Any rate
between the pre-set high and low can be
obtained using the two buttons.
9. To switch off the main burner press and
hold the (‘small flame/dot’) button
until clicking is heard from the valve
(OFF position).
10. The fire can safely be left in this position
at all times, however to prevent
unauthorised or accidental use (say by
children) it is recommended to turn the
IGNITION KNOB to the pilot flame
position by turning it 90 degrees
clockwise. To turn the pilot off, turn the
IGNITION KNOB fully clockwise.
NOTE: The clicking sound
made by the valve is the
operation of the valve clutch,
and indicates either maximum
or minimum positions.
TRIM HIGH
LOW
OFF
/
Figure 12 – Trim Switch
Figure 13 - Wall Switch
IGNITION
KNOB
GAS RATE
ADJUSTING
KNOB
GAS VALVE
Figure 14
NOTE: No attempt should be
made to relight the fire for at
least 3 minutes after the pilot
flame has been extinguished
either intentionally or
unintentionally.

Page 10
2.1.5. 27BLighting Procedure (Total Control)
1. Ensure that gas is available at the valve
and the ON/OFF switch in the ON
position (–).
2. Simultaneously press and hold the
(red circle) and (large flame)
buttons until a short acoustic signal
confirms the start sequence has begun,
then release the buttons (see XFigure
16X).
3. Continuing signals confirm the ignition is
in process. Once the pilot is lit the gas
rate adjusting knob automatically
turns to high gas rate. The main
burner cross-lights from the pilot.
4. To adjust the gas rate to desired setting
press the (large flame) to increase the
flame height or (small flame) to
decrease the flame height on the
handset (see XFigure 16X). For fine
adjustment tap the or buttons.
5. To leave the burner in the standby
mode press the (small flame) until the
main burner goes out. In the standby
mode the pilot stays alight.
6. To turn off the main burner and the pilot
press the ‘OFF’ button on the hand set.
WARNING: Ensure that the fire
is operated only whilst present
in the room where it is fitted.
Manual
Knob
Gas Rate
Adjusting
Kno
b
ON/OFF Switch
NO
MAN
ON
OFF
Figure 15
Press
these two
buttons
together to
light the
burner
Once lit
use this
button to
increase
gas rate
Oncelit
usethis
buttonto
decrease
gas rate
Figure 16

Page 11
2.1.6. 28B Manual Operation (Total Control)
In emergency the appliance can be operated
manually as follows:
1. Turn the Gas Rate Adjusting knob fully
clockwise to the OFF position. A clicking
sound will be audible, but this is perfectly
alright.
2. Turn the Manual knob clockwise to MAN
position (see XFigure 17X).
3. Ensure that the ON/OFF switch is in the
ON (–) position.
4. Using a rigid slender object (like a
screwdriver) depress the pilot valve
operator through the large hole in the
knob (see XFigure 18X) and light the pilot
using a match or lighted taper.
5. Keep the valve operator depressed for a
further 10 seconds and slowly release.
The pilot should stay alight. Repeat step
4 if necessary.
6. Turn Manual knob anticlockwise to ON
position.
7. Turn the Gas Rate adjusting knob
anticlockwise to ON position to turn the
main burner on. Adjust this knob to get
the desired gas rate between maximum
and minimum.
8. To turn the main burner off but, leaving
the pilot on, turn the Gas Rate adjusting
knob fully clockwise past the OFF
position.
9. To turn the pilot off place the ON/OFF
switch to OFF (O) position.
MAN
NO
ON/OFF Switch
Manual
Knob
Gas Rate
Adjusting
Knob
ON
OFF
Figure 17
MAN
NO
Gas Rate
Adjusting
Knob
ON
OFF
Figure 18
NOTE: No attempt should be
made to relight the fire for at
least 3 minutes after the pilot
flame has been extinguished
either intentionally or
unintentionally.

Page 12
2.2. 3BBattery Replacement (Remote Control & Total
Control)
2.2.1. 29BHandset
1. On the reverse of the handset remove
the battery cover by pressing down at
the top of the cover and sliding down.
2. Remove and unclip the old battery and
replace with a new PP3 9V battery.
3. Replace the cover.
Press here and
slide down
Figure 19
2.2.2. 30BReceiver Unit
1. Remove the receiver unit from under the
fire burner (or from wherever positioned
if mounted remotely) and remove the
battery compartment cover (see XFigure
20X).
2. Replace the old batteries with new ones,
ensuring they are inserted in the correct
polarity.
3. Replace the cover on the receiver unit,
ensuring that it is securely closed.
4. Return the receiver unit to its original
mounting position.
Figure 20
CAUTION: With the exception of battery replacement, the battery receiver must
be located within the heat shield at all times.

Page 13
2.3. 4BBattery Replacement (Optimum Control)
1. The battery pack is mounted inside the
wall-mounting box behind the wall switch
plate.
2. To change the batteries remove the two
small screws securing the wall plate
using a small screwdriver.
3. Remove the battery pack from the wall
box and replace the spent batteries with
new ones (4 off 1.5V AA batteries)
ensuring correct polarity.
4. Insert the battery pack back into the wall
box and refit the wall plate ensuring that
it is the right way up.
5. Secure with screws.
REAR OF WALL
PLATE
CABLE TO
VALVE
BATTERY
PACK
(4 x 1.5 VAA
BATTERIES)
LOW/OFF
SWITCH
HIGH
SWITCH
brown brown
brown
blue
blue
blue white
black
Figure 21
2.4. 5BBattery Replacement (Trim Switch Control)
1. Remove ash pan cover to gain access to
controls.
2. Slide out the battery holder from under
the fire.
3. Replace all batteries with new ones (4 x
AA batteries required). Ensure that the
batteries are inserted with correct
polarity in the holder.
4. Replace the battery holder into the
battery compartment.
5. Return the ash pan cover.
TR AY
FIXING
SCREW TRAY FIXING
SCREW
CONTROL
VALVE
GAS INLETSLOT
COVER
GAS
INLET
RECEIVER/
BATTERY
PACK
PILOT
FIXING
SCREWS
HEAT
SHIELD
POWER
SUPPLY
PLUGS
GROMMET
PRESS.
TEST
POINT
Figure 22
CAUTION: With the exception of battery replacement, the battery holder must be
located within the heat shield at all times.

Page 14
2.5. 6BFuel Effect Layout
You fire has been supplied with either Coal or Pebble effect. Please refer to the relevant
section for instructions on how to arrange the imitation fuels.
Fuel Effect Tray Type Refer to
Coal Effect Natural Gas & LPG Section X2.5.1X
Pebble Effect Natural Gas Section X2.5.2X
It is recommended that the imitation fuel be left alone once the desired flame pattern has been
achieved. Constant moving of the imitation fuel will cause the fuel to disintegrate
and/or cause discolouration.
RCF Advice:
This product may use Components (Coals, Pebbles & Ceramic backs)
containing Refractory Ceramic Fibres (RCF), which are man-made vitreous
silicate fibres. Excessive exposure to this material may cause irritation to eyes,
skin and respiratory tract.
Therefore during installation and servicing we recommend that you use a HEPA
filtered vacuum to remove any dust and soot accumulated in and around the fire
before and after working on the fire, to ensure that the release of fibres from
these RCF articles is kept to a minimum.
We recommend that you should follow the normal hygiene rules of not smoking,
eating or drinking in the work area.
When replacing Components containing Refractory Ceramic Fibres (RCF), we
recommend that the replaced items are not broken up, but are sealed within
heavy duty polythene bags, and clearly labelled as RCF waste. RCF waste may
be disposed of in suitably licensed landfill sites.
WARNING: Do not touch the fire when it is alight. The fire will remain very hot
for a while after extinguishing.
Some sooting on the pebbles may be observed. This is perfectly normal.
Periodically operating the Fire at various rates will burn this soot away. If
excessive sooting is observed, this is an indication that the pebbles are laid
incorrectly – please refer to instructions.

Page 15
2.5.1. 31BCoal Effect Layout
This fire is supplied with three different types
of ceramic coals packed in separate bags as
follows: -
16” 18”
Random Coals 19 21
Small Square Coals 6 8
Medium Square Coals 4 5
(Quantities shown are pcs)
Proceed with the coal layout as follows: -
1. Unpack the bag of Medium Square
Coals and place them equally, as far
back as possible on the matrix. Refer to
XFigure 23X.
2. Now unpack the large bag containing
Random Coals.
3. For 16”, choose the largest 5 triangular
shaped coals and place 3 coals on the
middle 3 ribs as shown in the figure.
4. For 18”, choose the largest 6 triangular
shaped coals and place 4 coals on the
middle 4 ribs.
5. Place them such that the fronts of the
coals are in line with the front edges of
the ribs. Place the other two coals
similarly on the extreme two ribs
ensuring that they do not fall into the
channels. If necessary support them
against the adjoining coals.
6. Unpack the bag of Small Square Coals
and starting from left hand side press
each coal gently onto the spike
diagonally approximately 15mm into the
tray. Ensure that the flat smooth surface
of the coal is on the top. Also ensure
that none of the holes are blocked. The
coals should be pressed in all the way
and there should be small gaps between
the coals (see XFigure 25X)
Medium square
coals equally
spaced all
the way
back
Figure 23
Large triangular
random coals
GAPS
RIBS CHANNELS
Figure 24
Small square coals
Figure 25

Page 16
7. Now place 5 more Random Coals on
top of the Small Square Coals as shown
in figure below ensuring that they are
stable in position and do not topple over
onto the burner or to the front. Place
them such that the flat surfaces are at
the top and bottom.
8. The next step is to place further 6
Random Coals in such a way that they
are bridging between the front coals and
the coals placed in step X1X. Leave gaps
between coals. Ensure that none of the
coals fall onto the burner. See XFigure
27Xfor the layout.
9. Finally place 3 (for 16”) or 4 (for 18”)
Random Coals at the back ensuring that
the gaps left previously in step X1Xare not
blocked by the coals.
10. Packing the coals too tightly together will
result in a poor flame picture. The best
results come from a ‘loose’ fuel build.
11. After the appliance has been allowed to
warm up (operated on high setting for
10-15 minutes), small adjustments (using
a small pair of tongs) may be made to
the top layer to achieve the desired
flame picture.
12. It is recommended that the coals be left
alone once the desired flame picture has
been achieved. Constant moving of the
coals causes the coals to disintegrate
and/or cause discolouration.
WARNING: Do not touch the
fire when it is alight. The fire
will remain very hot for a while
after extinguishing.
Small random
coals
Figure 26
GAPS
Random
coals
Figure 27
Random
coals
Figure 28
