MAGNER100 USER MANUAL
Magner INT 2
- Contents –
Warning ...……………..…………………………………………………………………………3
Appearance……………..…………………………………………………………………………4
1. Display Description …………………………………………………………………………5
2. Key Operation Description …………………………………………………………………6
3. Basic Operation
3-1. COUNT Mode .................................................................................................... 8
3-2. EURO Mode....................................................................................................... 9
3-3. USD Mode ....................................................................................................... 10
3-4. Local Currencies Mode.................................................................................. 10
4. Operation Mode I
4-1. BATCH Mode .................................................................................................. 11
4-2. CF Mode ....................................................................................................... 12
4-3. ADD Mode ....................................................................................................... 12
4-4. GRAND TOTAL Mode..................................................................................... 16
5. Operation Mode II
5-1.MIX Mode.......................................................................................................... 20
5-2.SP Mode............................................................................................................ 20
5-3.SP VERS Mode................................................................................................. 21
5-4.SG Mode ........................................................................................................... 21
6. USER Mode ………………………………………………………………………………….22
SPECIFICATION………………………………………………………………………………….24
Error Code List ………………………………………………………………………………….25
Maintenance ………………………………………………………………………………….26

MAGNER100 USER MANUAL
Magner INT 3
- Important Safety Precautions -
9Do not plug several products in one multi-outlet.
9Do not bend the cable by force or leave it under any heavy object.
9Install the machine on the stable surface
9Unplug the machine before it is moved
9Do not pull the cable it unplugged.
9Do not plug in or unplug with your hands wet.
9Use only approved accessories and do not try to disassemble, repair or remodel it for
yourself.
9Do not let coin or other foreign objects in the machine.
9Do not keep and operate the machine at a place with high temperature and humidity.
- Warning-
Adjust the Gap Adjustment Knob before you start to count the notes.
Do not let coin or other foreign objects in the machine.
When folded note is inserted or notes are placed wrong on the HOPPER, the
machine does not work properly.
Before counting, adjust the HOPPER GUIDE.
If you catch Rear Cover Knob when you move the machine, it will be possible
setup value is changed or fatal error caused.
When you close the Front Cover, be careful not to get hurt.
Do not look at directly of UV sensor in Upper and Lower Module.
Do not push all sensors on Upper and Lower Module.

MAGNER100 USER MANUAL
Magner INT 4
Appearance
Gap Adjustment Knob
USB
Power Switch
Power Connector
RS232 Port
External Display Port
Hopper Guide
Hopper
LCD Display Window
Release Button
Stacker Pocket

MAGNER100 USER MANUAL
Magner INT 5
1. Display Description
Operation Mode
Counterfeit Detection.
Note number of Stacker
Currency: Currency mark which the machine can count now.
Total Value: Total value of counted notes.
BATCH Number: Selected Batch number
Speed: Counting Speed in COUNT Mode
ADD/G.TOTAL Mode
MIX CF
€ 0
0
B100 S1000 ADD
Currency
Operation Mode
Total Value
BATCH Number
A
DD
/
G.TOTAL Mode
Note number
of Stacker
Counterfeit Detection
Speed

MAGNER100 USER MANUAL
Magner INT 6
2. Key Operation Description
~ Number Key for selecting Batch number and Shortcut Key.
Clear Batch number to 0.
Counterfeit detection function key (Operation Mode) & double
detection function key (COUNT Mode)
Select Currency
Select ADD Mode and G.TOTAL Mode.
Select Batch number which was selected already.
1. Select Counting Speed in COUNT Mode.
2. Select denomination in SG Mode. 3. Enter Engineer Mode.
1. Select Operation Mode.
2. Enter USER Mode
Print counting result to print or screen.
1. Clear counting result on the screen.
2. Exit sub Mode.

MAGNER100 USER MANUAL
Magner INT 7
Shortcut Key (Long Key Operation)
If press and hold down Number Key, you can select special currency or mode directly.
Go to COUNT Mode.
Go to EURO (local currency 1) Mode.
Go to USD (local currency 2) Mode.
Go to local currency 3 Mode.
Go to local currency 4 Mode.
Go to local currency 5 Mode.
Go to local currency 6 Mode.
Go to NORMAL COUNT Mode.
Go to ADD Mode.
Go to GRAND TOTAL Mode.

MAGNER100 USER MANUAL
Magner INT 8
3. Basic Mode
3-1. COUNT Mode
When press LEVEL Key,
DDL is changed.
DDL means Double Detection Level in Count Mode.
User can select 1~8 levels.
- DDL 1~2 : For local currency.
- DDL 3 : For Euro
- DDL 4 : For USD
- DDL 8 : If the notes are darker than EURO or USD or the notes are so old,
user can select this level to detection double notes. But when
counts normal notes in this level, the machine do not detect the
double notes. Please take care.
Double Detection Level
COUNT
CNT DLL:3 L|+
●++++++|H
UVL:3 L|+
●++++++| H
0
B100 S 900 --
Display shows as below.
Press CURRENCY Key and
select COUNT Mode.
User can count all currencies without
recognition and detection.
COUNT
CNT DLL:3
DP|+●++++++| LP
0
B100 S 800 --

MAGNER100 USER MANUAL
Magner INT 9
3-2. EURO Mode
COUNT
CNT DLL:3 L|+
●++++++|H
UVL:3 L|+
●++++++| H
0
B100 S 900 --
UV Level
When press and hold down
LEVEL Key, you can change
UVL.
Press MODE Key and move
cursor to UVL.
Change UVL.
Save data and exit CF UV
MODE.
In COUNT Mode, machine has adjust UV Level function for detecting white paper.
User can select 1~8 levels.
According to thickness of notes, UV Level is different.
Before counting, please check and adjust Level first.
Display shows as below.
Press CURRENCY Key and
select EURO Mode.
Press MODE Key and select
Operation Mode.
In this Mode, the machine can recognize and
detect EURO currency.
MIX CF
€ 0
0
B100 --

MAGNER100 USER MANUAL
Magner INT 10
3-3. USD Mode
3-4. Local Currencies Mode
Display shows as below.
Press CURRENCY Key and
select local currency.
Press MODE Key and select
Operation Mode.
MIX CF
LC
0
B100 --
Note!
Machine only can count notes in Local currencies Mode except WON
(Korea) Mode.
Display shows as below.
Press CURRENCY Key and
select USD Mode.
Press MODE Key and select
Operation Mode.
MIX CF
$
0
B100 --
In this Mode, the machine can recognize and
detect USD currency.
