Magnetic MHTM FlowMotion mTripod-ML User manual

Operating Instructions
Turnstile
MHTM™ FlowMotion®
mTripod
Doc.ID: 5817,0026EN
Version 03

2
mTripod
MAGNETIC AUTOCONTROL GMBH
Grienmatt 20
D-79650 Schopfheim
Germany
Phone [phone]
Fax [phone]
[email protected]
www.magnetic-access.com
Original Operating Instructions
This document is available as PDF in the Magnetic Autocontrol download area
(www.magnetic-access.com). Authorisation is required for download.

3
mTripod
Contents
Contents
1 Notices on the document 7
1.1 Purpose and contents of this operating instructions 7
1.2 Reading and storing the operating instructions 7
1.3 Non-observance of the operating instructions 8
1.4 Symbols and illustrations used in the operating instructions 8
1.4.1 Warning notes and notices 8
2 Safety 10
2.1 Intended use 10
2.2 Changes and modifications 10
2.3 Target groups 11
2.3.1 Operator and its responsibility 11
2.3.2 Personnel - activities and qualifications 12
2.4 Personal protective equipment 13
2.5 Symbols on the device 14
2.6 For your safety 14
2.7 To protect the environment 15
2.8 Emergency opening of the pedestrian gate 15
3 Technical data 16
3.1 Dimensions and design 16
3.1.1 mTripod-ML 16
3.1.2 mTripod-MS 18
3.2 Clearances and line configuration to be maintained 19
3.3 Electrical connection 20
3.4 Operating conditions 20
3.5 Emissions 20
3.6 Control unit MGC 21
4 Design and function 22
4.1 Design 22
4.2 Function 23

4
mTripod
Contents
5 Receipt of goods, transport and storage 24
5.1 Receipt of goods 24
5.2 Safety during transport 24
5.3 Transport 25
5.4 Storage 26
6 Unpacking, scope of delivery and identification 27
6.1 Unpacking 27
6.2 Scope of delivery 28
6.3 Identification 29
6.3.1 Type plate 29
7 Installation and mounting 30
7.1 Safety during installation and mounting 30
7.2 Mounting variants 31
7.3 Steps to be taken 33
7.4 Building foundation and laying empty conduits 33
7.4.1 Requirements foundation 33
7.4.2 Requirements empty conduits 34
7.4.3 Building foundation and laying empty conduits 34
7.4.4 Foundation and empty conduit plan and
reinforcement mTripod FMTP-ML 35
7.4.5 Foundation and empty conduit plan and
reinforcement mTripod FMTP-MS 37
7.5 Base frames FURA100 and FURA101 39
7.6 Base plate FlowMotion 40
7.7 Base frames FURA102 and FURA104 41
7.8 Aligning the pedestrian gate 42
7.9 Preparing mTripod for mounting and electrical connection 42
7.10 Mounting of the mTripod 45
7.10.1 Mounting variant 1 (direct mounting) 45
7.10.2 Mounting variant 2 48
7.10.3 Mounting variant 3 53
7.10.4 Mounting variant 4 57
7.11 Assembling mTripod 60
7.12 Dismounting and mounting the cover 65
7.13 Opening and closing the housing 67
7.14 Checking mounting 68

5
mTripod
Contents
8 Electrical connection 69
8.1 Safety during electrical connection 69
8.2 Installing electrical protective devices 70
8.3 Connecting the mains cable 71
8.4 Connect customer's control lines 72
8.4.1 Connecting emergency opening contacts 73
8.5 Installing and connecting customer access-control devices 73
8.6 Checking the electrical connections 75
9 Commissioning 76
9.1 Safety during commissioning 76
9.2 Putting the pedestrian gate into operation 76
9.3 Switching the pedestrian gate on and off 77
9.4 Parameterising the pedestrian gate 78
10 Log book 78
11 Operation 79
12 Cleaning and maintenance 79
12.1 Cleaning the pedestrian gate 79
12.2 Maintenance schedule 80
13 Corrective action 80
14 Spare parts and repair 81
15 Customer service 81
16 Decommissioning 82
16.1 Safety during decommissioning 82
16.2 Taking the pedestrian gate out of service 82
17 Dismounting and disposal 83
17.1 Safety during dismounting and disposal 83
17.2 Dismounting and disposal of pedestrian gate 83
18 EU-Declaration of Conformity 84
Index 85

6
mTripod

7
mTripod
Notices on the document
1 Notices on the document
1.1 Purpose and contents of this operating instructions
These operating instructions provide all the information required for the
product in the various phases of its life cycle.
This operating instructions contains the following information: Design and
function, transport and storage, unpacking and delivery, installation and
mounting, electrical connection, commissioning, operation, cleaning and
maintenance, decommissioning, dismounting and disposal.
IMPORTANT!
For parameterisation see separate document "Description of
control unit MGC for mTripod (Doc.ID: 5817,0025)".
1.2 Reading and storing the operating instructions
Prerequisite for secure work is compliance with all indicated safety notes,
warning notes and instructions. In addition, the local accident prevention
regulations, general safety regulations and local environmental regulations
applicable to the area of application of the product must be observed.
Carefully read these operating instructions before starting any work! The
operating instructions are a product component and must be kept in direct
proximity of the product, well accessible to the personnel at all times.
When passing the product on to third parties, these operating instructions
must also be handed over.

8
mTripod
Notices on the document
1.3 Non-observance of the operating instructions
Magnetic declines all liability for personal injury and material damage caused
by not observing the operating instructions.
This applies in particular to damage caused by:
› Improper use
› Use of non-qualified personnel
› Use of non-approved components
› Arbitrary modifications
› Inappropriate mounting and installation
› Incorrect operation
› Defective or unperformed maintenance and repairs
› Use of non-approved spare parts
› Operating a defective product
1.4 Symbols and illustrations used in the operating instructions
1.4.1 Warning notes and notices
Warning notes are characterised by pictograms in these instructions. A warning
note starts with a signal word that expresses the extent of the hazard.
It is absolutely essential to observe the warning notes and to proceed with
caution in order to prevent accidents as well as bodily injuries and property
damage.
Warning Notes
DANGER
The signal word DANGER points to an immediately dangerous
situation, which leads to death or severe injuries if it is not
avoided.
WARNING
The signal word WARNING points to a potentially dangerous
situation, which can lead to death or severe injuries if it is not
avoided.

9
mTripod
Notices on the document
CAUTION
The signal word CAUTION points to a potentially dangerous
situation, which can lead to minor injuries if it is not avoided.
NOTICE
The signal word NOTICE points to a potentially harmful situation,
which leads to property damage if it is not avoided.
Notes and recommendations
IMPORTANT!
The signal word IMPORTANT highlights useful notes and
recommendations as well as information for an efficient and
trouble-free operation.

10
mTripod
Safety
2 Safety
2.1 Intended use
The Magnetic turnstile mTripod is designed for the control of persons entering
or leaving an area with restricted access.
The turnstile is intended for passage of persons who can pass the turnstile
safely, speedily and without any help. Separate means of access must be
provided for persons who cannot pass through the turnstile safely, quickly or
without assistance, such as small children, elderly people or people with
disabilities. Children under 14 years of age may only pass through the turnstile
under the supervision of an adult.
The turnstile may only be mounted on non-flammable floors.
The turnstile may only be operated within the temperature range indicated on
the type plate.
Misuse
Any use differing from or beyond this is considered improper use. Magnetic is
not liable for any resulting personal injury or damage to property.
For example, the following applications are regarded as improper use:
› Use of the turnstile by unaccompanied children under 14 years of age.
› Use of the turnstile by persons who cannot pass the turnstile safely, quickly
or without assistance.
› Use of the tturnstile without released passage. This means that the blocking
arms are forced to rotate.
› Mounting of the turnstile on flammable ground.
2.2 Changes and modifications
Modifications and conversions to the product, to an attachment or to one of
the components can lead to unforeseen dangers. Magnetic's written approval
must be obtained before any technical modifications or alterations are made to
the product or any of its components.

11
mTripod
Safety
2.3 Target groups
2.3.1 Operator and its responsibility
The operator must comply with the statutory obligations regarding work safety.
In addition to the safety instructions and warning notes in this operating
instructions, the valid safety, accident prevention and environmental
protection regulations must be observed.
In particular, the operator must:
› determine additional danger in a danger analysis
› implement the necessary behavioural requirements in work instructions for
operation with the product at the operating location
› regularly verify throughout the product time of use that the work
instructions drawn up by him comply with the current state of the
regulations
› adapt the working instructions to any new provisions, standards and usage
conditions - where required.
› clearly regulate the responsibilities for all work on the product and with the
product such as mounting, commissioning, operation, cleaning,
maintenance, etc.
› ensure that personal protective equipment is worn
› ensures that all employees who work with the product or on the product
have read and understood the operating instructions.
Furthermore, the operator must train personnel regarding the use of the
product at regular intervals and provide information on possible dangers.
Furthermore, the operator is responsible for:
› the product is always in perfect technical condition.
› the product is maintained at specified maintenance intervals
› the product is only operated within the permitted temperature range.
The operator is also responsible for ensuring that the danger area of the
product cannot be accessed by any unauthorised persons under any
circumstances.

12
mTripod
Safety
2.3.2 Personnel - activities and qualifications
Only authorised, trained and sufficiently qualified personnel may work on and
with the product. The personnel must know and have understood the
operating instructions and the required operating procedures.
Designation Qualification
Transport equipment operator › Has professional experience as a transport equipment
operator or warehouse and transport worker.
› Has a valid driving licence for the required industrial
truck, e.g. forklift.
› Knows the necessary regulations.
› Can evaluate the work assigned to him, recognise
possible dangers and take appropriate safety measures.
Technician › Has completed training as a systems mechanic,
machinery technician, installation mechanic, installation
technician or has comparable technical training.
› Has completed training as an electrical safety expert.
› Has additional knowledge and experience.
› Knows the relevant technical terms and regulations.
› Can evaluate the work assigned to him, recognise
possible dangers and take appropriate safety measures.
Magnetic MHTM™ FlowMotion®
service expert
› Meets all the requirements of the technician.
› Trained and authorised by Magnetic.
Operator › Trained by the operator.
Table 1: Qualifications of personnel

13
mTripod
Safety
Task Transport
equipment
operator
Technician Magnetic
service expert
Operator
Transporting X X – –
Unpacking X X X –
Laying the foundation – X – –
Mounting – X X –
Electrical connection – X X –
Parameterisation – X X –
Commissioning 1) – X X –
Operating – X X X
Cleaning – X X X
Servicing – X X –
Troubleshooting – X X –
Repairing – X X –
Decommissioning – X X –
Dismounting – X X –
Disposing – X – –
1) According to the supplied log book MHTM™ FlowMotion® mTripod
Table 2: Activities and qualifications
2.4 Personal protective equipment
It is necessary to wear personal protective equipment when dealing with the
product so as to minimise health hazards.
Before carrying out any work, properly dress in the necessary protective
equipment such as work clothes, protective gloves, safety shoes and wear
during work.

14
mTripod
Safety
2.5 Symbols on the device
Warning of electric voltage!
The warning sign indicates dangerous areas with dangerous
electric voltage. Non-observance of the warning signs causes
severe injuries or death. The work to be carried out may only be
carried out by a qualified electrician or an electrical safety
expert.
This warning sign is fixed at the following point:
› At the terminals, under the cover.
2.6 For your safety
Mortal danger by electric voltage!
Touching live parts can be lethal. Damage to the insulation or to
individual components can be lethal.
› If the insulation or any parts are damaged, switch off the
power supply at once and initiate repair.
› Only qualified electricians or electrical safety experts may
carry out work on the electrical system.
› Before commencing any work, switch off power supply and
secure against restarting. Test for absence of voltage.
› Perform the electrical installation in accordance with the
applicable regulations.
› Protective devices that are required according to national and
local regulations, e.g. residual current devices, must be
provided. These protective devices must be provided by the
customer.
› Observe the information on the type plate.
› Close all covers after all work is completed.
› Keep moisture and dust away from live parts. Intruding
moisture and dust may cause a short circuit.
› If the electrical connection is made during precipitation, e.g.
rain or snow, prevent the intrusion of moisture by means of
suitable protective covers.
› During or after a lightning strike into the system, there is
danger to life if the components are touched or during a stay
in the immediate vicinity of the system. When mounting
outside, do not install and mount the pedestrian gate during
thunderstorms.

15
mTripod
Safety
2.7 To protect the environment
Improper disposal!
Improper disposal can result in damage to the environment.
› Dispose of the product in accordance with local and national
laws and regulations.
› Sort resources and supply them to recycling.
2.8 Emergency opening of the pedestrian gate
äPage 73, chapter 8.4.1.

16
mTripod
Technical data
3 Technical data
3.1 Dimensions and design
3.1.1 mTripod-ML
55°
A A
Mag00811a
1300
1239.5
290
1050
882
90
180
180
110
38
515
A
100
44
60
80
Fig. 1: Dimensions FMTP-ML (dimensions in mm)
A Dimensions for customer access-control device

17
mTripod
Technical data
Designation Value
Dimensions
(length x width x height)
1300 mm x 290 mm x 1050 mm
äPage 16, Fig. 1.
Passage width 515 mm
Weight › Turnstile complete: Approx. 70 kg
› Base frame FURA100 1): 11.0 kg
› Base frame FURA102 1): 17.5 kg
Material › Housing: mDure
› Base frame 1): Stainless steel
› Base plate 1): Stainless steel
Housing colour, standard › Side parts: basalt
› Frame: anthracite
1) Optional
Table 3: Dimensions and design – mTripod FMTP-ML

18
mTripod
Technical data
3.1.2 mTripod-MS
55°
A A
Mag00924a
730
670
290
1050
882
90
180
180
110
38
515
A
100
44
60
80
Fig. 2: Dimensions FMTP-MS (dimensions in mm)
A Dimensions for customer access-control device

19
mTripod
Technical data
Designation Value
Dimensions
(length x width x height)
730 mm x 290 mm x 1050 mm
äPage 18, Fig. 2.
Passage width 515 mm
Weight › Turnstile complete: Approx. 56 kg
› Base frame FURA102 1): 5.5 kg
› Base frame FURA104 1): 10.0 kg
Material › Housing: mDure
› Base frame 1): Stainless steel
› Base plate 1): Stainless steel
Housing colour, standard › Side parts: basalt
› Frame: anthracite
1) Optional
Table 4: Dimensions and design – Tripod FMTP-MS
3.2 Clearances and line configuration to be maintained
Mag00817a
11
50
1050
882
515290
50
Fig. 3: Clearances and line configuration to be maintained
1 Minimum distance 50 mm

20
mTripod
Technical data
3.3 Electrical connection
Designation Value
Power supply 100 to 240 V AC ± 10 %, 50 to 60 Hz
Current consumption at 240 V AC 1.0 A
Current consumption at 100 V AC 2.1 A
Max. performance 174 W
Duty cycle 100 %
Table 5: Electrical connection
3.4 Operating conditions
Designation Value
Operating temperature range –30 to +55 °C
Storage temperature range –30 to +55 °C
Relative humidity Maximum 95 %, non-condensing
IP rating IP 54
Table 6: Operating conditions
3.5 Emissions
Designation Value
Airborne sound pressure level (LpA) ≤ 70 dB (A)
Table 7: Emissions
