Oxgard CUBE C-04-s User manual

VOZROZHDENIE LLC
OKPD 2 26.30.50.110
TU 26.30.50-007-33120038-2017
APPROVED BY
VZR.235900.000 LU
TURNSTILE
CUBE С-04 MODEL
C-04-s, C-04-K, C-04-Ks, C-04-N, C-04-Ns, C-04-NK, C-04-NKs
VZR.235900.000 IM
INSTALLATION MANUAL
42 sheets
2020

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
2
TABLE OF CONTENTS
1General instructions....................................................................................................................... 4
2Safety precautions.......................................................................................................................... 5
3Preparing the product for installation ........................................................................................... 6
3.1 Procedure for transporting the product to the installation place .............................................. 6
3.2 Rules for unpacking the product............................................................................................. 6
3.3 Rules for visual inspection of the product ............................................................................... 6
3.4 Product installation place requirements.................................................................................. 8
3.5 Procedure for checking compliance of the installation place................................................... 9
4Installation and dismantling of the product ................................................................................ 10
4.1 Equipment required.............................................................................................................. 10
4.2 Product installation............................................................................................................... 11
4.3 Dismantling the product........................................................................................................ 15
5Connecting and setting the product............................................................................................ 16
5.1 Power connection................................................................................................................. 20
5.2 Control panel connection...................................................................................................... 21
5.3 Access control and management system connection (optional)............................................ 22
5.4 Control panel connection to the ACS controller .................................................................... 27
5.5 Connecting the card collector............................................................................................... 29
6Comprehensive inspection .......................................................................................................... 34
6.1 Visual inspection and verification of the product readiness for use....................................... 34
7Acceptance of the installed product............................................................................................ 35
APPENDIX A —Brief description of CAN2.0 data bus...................................................................... 36
APPENDIX B —Position of mounting holes relative to the external dimensions of the turnstile . 37
APPENDIX C —Turnstile connection diagram.................................................................................. 38
APPENDIX D —Block diagrams of ACS using a card collector....................................................... 39

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
3
This Installation Manual (IM) applies to Oxgard Cube С-04 turnstile and its
variants (hereinafter referred to as the product). Product firmware version:
FW v.d 4
IM defines rules and a procedure for installation and commissioning of the
product.
Before installing the product, please read the Operation Manual
VZR.235900.000 OM as well.
Due to constant work on improving the product, changes to its design may
be made, which are not represented in this IM revision.
A card collector can be integrated into the turnstile.
The following abbreviations are used in this document:
OM —Operation Manual;
IM —Installation Manual;
PSU —power supply unit;
CP —control panel;
ACS —access control system;
SFAS —security and fire alarm system;
NCC —normally closed connection;
NOC —normally open connection.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
4
1 GENERAL INSTRUCTIONS
For general safety when assembling and installing the product, take into
account all the recommendations and instructions contained herein.
Before starting installation work, completely de-energize the product.
DO NOT:
INSTALL THE POWER SUPPLY UNIT INSIDE THE TURNSTILE
HOUSING AS IT MAY RESULT IN ELECTRIC SHOCK TO PERSONS.
INSTALL THE TURNSTILE OUTSIDE DRY AND HEATED ROOMS.
PREVENT OR ACCELERATE MOVEMENT OF THE TURNSTILE ARMS.
APPLY PASTES AND LIQUIDS CHEMICALLY AGGRESSIVE TO
MATERIALS OF THE HOUSING WHEN CLEANING THE PRODUCT.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
5
2 SAFETY PRECAUTIONS
Installation should be carried out with observance of “Regulations for
Operation of Consumer Electrical Installations” and “Safety Regulations for
Operation of Consumer Electrical Installations”.
The product shall only be installed by qualified personnel trained in
handling of electrical devices and instructed on safety precautions when handling
the electrical installations with voltages of up to 1000V.
ATTENTION: FAILURE TO COMPLY WITH THE SAFETY
REQUIREMENTS SPECIFIED IN THIS SECTION CAN RESULT IN DEATH AND
DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF PERFORMANCE
OF THE PRODUCT AND/OR AUXILIARY EQUIPMENT.
ATTENTION: MANUFACTURER WAIVES ANY RESPONSIBILITY
FOR DEATH AND DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF
PERFORMANCE OF THE PRODUCT AND/OR AUXILIARY EQUIPMENT IF
USER FAILS TO COMPLY WITH THE SAFETY REQUIREMENTS SPECIFIED
IN THIS SECTION, AND ALSO VOIDS THE PRODUCT WARRANTY.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
6
3 PREPARING THE PRODUCT FOR INSTALLATION
3.1 Procedure for transporting the product to the installation place
The product in the original package can be transported without range
limitation by air, enclosed road and rail transport provided it is protected against
direct exposure to precipitation and dust.
In order to avoid moisture condensation after transportation at subzero
temperatures, the product shall be pre-held in a room with normal climatic
conditions for 12 hours.
Loading and unloading operations should be carried out in compliance with
safety regulations.
3.2 Rules for unpacking the product
3.2.1 Perform visual inspection of the packaging. There should be no
visible damage on the package.
3.2.2 Open the transportation box, unpack and check completeness of
the product:
1) turnstile stand;
2) CP with cable;
3) Keys for locks (4 pcs).
3.3 Rules for visual inspection of the product
3.3.1 Check completeness of the product.
Completeness shall be checked according to the Logbook
VZR.235900.000 LB.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
7
3.3.2 Visually inspect the product. There should be no visible damage
on the product.
3.3.3 If any damage is found, prepare a Claim Report.
3.3.4 Figure 1 –overall dimensions of the turnstile.
Figure 1 –Overall dimensions of the turnstile

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
8
3.4 Product installation place requirements
ATTENTION: TO AVOID WAVING AND/OR OVERTURNING DURING
OPERATION, INSTALL THE TURNSTILE SECURELY. IN CASE OF PRODUCT
INSTALLATION ON LOW STRENGTH FLOOR - TAKE MEASURES FOR
FLOORS STRENGTHENING IN THE PLACE OF INSTALLATION.
Figure 2 –when installing the turnstile, it is necessary to consider the
possible free travel of the arm (it makes 6 degrees on each side in STOP mode).
Figure 2 –Possible free travel of the arm in STOP mode

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
9
3.5 Procedure for checking compliance of the installation place
ATTENTION: THE PASSAGE ZONES SHALL BE ARRANGED TO
ALLOW RECORDING OF PASSAGES DURING TURNSTILE OPERATION
UNDER ACS CONTROL AND TO AVOID UNAUTHORIZED PASSAGES.
3.5.1 Figure 3 –turnstile passage zone arrangement and guidelines on
product orientation.
Recommended scheme
Not recommended scheme
Figure 3 –Turnstile passage zone arrangement.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
10
4 INSTALLATION AND DISMANTLING OF THE PRODUCT
4.1 Equipment required
Equipment to be used for the turnstile installation:
1) electric hammer drill;
2) 10 mm carbide drill bit for drilling anchor holes in the floor (we recommend to use the
anchor with the screw of the FH 10/10 SK type);
3) S5 hollow head screw hex wrench;
4) slot head screwdriver;
5) plumb or level;
6) steel shims for turnstile leveling;
7) round file;
8) side-cutting pliers.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
11
4.2 Product installation
ATTENTION: THOROUGHLY READ THIS SECTION OF THE MANUAL
BEFORE INSTALLING THE PRODUCT.
Figure 4 –Main panels of the turnstile
Figure 4 –to gain access to all the required turnstile assemblies, it is
necessary to partially disassemble it –dismantle the card collector containers (1),
top (3) and side covers (2) of the turnstile, as described in Section 3.5 of the OM.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
12
4.2.1 Prepare a horizontal area at the product installation site.
4.2.2 Prepare a chase or cable conduit going from the site to the place
of installation of the PSU, CP and, where necessary, to the ACS and SFAS
connection point.
4.2.3 Turnstile installation site.
Figure 5 –prepare 6 holes, 11 mm in diameter, in the floor for anchors of
two turnstile stands.
1- turnstile mounting holes;
2- cable entry hole
Figure 5 –Turnstile stand
Position of mounting holes relative to the overall dimensions of the turnstile
is shown in Appendix B.
The depth of the embedded hole is 120 mm, it should exceed the anchor
length by 5 mm. Insert anchors into the holes.
Figure 6 –turnstile mounting dimensions.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
13
1 –cable entry holes
Figure 6 –Turnstile mounting dimensions
4.2.4 Figure 6 –lead the cables through the hole (1) in the bottom
plate of the turnstile stands.
4.2.5 Lay the CP connection cable, PSU cable and, if provided, the
ACS and SFAS cables in the cable conduit or chase.
4.2.6 Install the turnstile onto the prepared site.
4.2.7 Route the cables from the CP, PSU and, if necessary, ACS and
SFAS cables into the turnstile housing.
Secure the cables with cable ties.
Figure 7 –cable routing (1) is indicated by dotted lines, cable entry hole
for the top cover (2).

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
14
1 - cable runs;
2 - cable entry hole
Figure 7 –Laying of control and power cables
4.2.8 Align the holes in the turnstile stands with the floor anchors.
Check the verticality of installation in 2 planes, if necessary, use steel
gaskets of required thickness for correct installation of the turnstile.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
15
Fasten the turnstile stands with 6 screws, screwing them into the
corresponding anchors using a spanner or open-end wrench with a size for 10
mm nut.
Figure 4 –install the side (2) and top (3) covers, card collector containers
(1) of the turnstile.
4.2.9 Remove the protective film from the turnstile housing.
4.3 Dismantling the product
4.3.1 Dismantle the product as follows for sending it for calibration or
repair:
1) turn the product power off;
2) disconnect the product from power supply;
3) disconnect the product cable part from auxiliary cables;
4) dismantle the product from the installation site.
4.3.2 Before packing, clean the product from dust and dirt.
4.3.3 Put the product in a packing box.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
16
5 CONNECTING AND SETTING THE PRODUCT
Appendix C –Turnstile connection diagram. Connect the PSU, CP, and
ACS using the cross-board.
Figure 8 –location of boards under the top cover on the turnstile stand.
1 - Indication control board;
2 - Card collector control board;
3 - Encoder board;
4 - Place of controller installation;
5 - Control board;
6 -Card collector;
7 - Readers
Figure 8 –Location of boards under the top cover
To connect the turnstile and access all necessary pins, remove the top
cover.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
17
To do this, open with a key and remove both containers located inside the
turnstile stands, release 4 studs (Figure 9 –1) securing the top cover and remove
the cover in the indicated direction.
1 –cover fastening studs
Figure 9 –Dismantling the turnstile top cover
Figure 10 –the appearance of the control board and layout of the
connectors for connecting the PSU, CP, ACS and SFAS is shown. Control board
location (Figure 8 –5).

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
18
Figure 10 –Appearance of the control board
Table 1 shows the turnstile operating modes, they are set using the BUT
button.
To select the required turnstile mode, it is necessary to:
- press and hold the BUT button until a short beep. The turnstile operating
mode is selected based on the number of short beeps.
- it is necessary to release the BUT button after the required number of
signals, a long beep, which indicates that the desired mode has been written into
the controller memory, will sound.
- when the power is off, the selected mode is not reset.

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
19
Table 1 shows the turnstile operating modes with different number of
signals after pressing the BUT button.
Table 1 –Turnstile operating mode
Turnstile
operating
mode
number
Number of short beeps after
pressing the BUT button
Turnstile operating mode
0 (simple
press)
Reboot (the mode is similar to turning the
turnstile on/off)
1
1
Factory reset:
- pulse control mode of the turnstile
- the turnstile enters the STOP mode after
being switched on
- the turnstile enters the “ANTIPANIC” mode
when controlled using the ACS, after the AP
and GND terminals get connected
- the turnstile is controlled by the control
panel, the status of the buttons is
transmitted to ACCESS OUT outputs (p.
5.4)
2
2
- switching between the pulse and potential
control modes of the turnstile (p. 5.3)
3
3
- the turnstile enters the mode of free
passage to the left after being switched on.
4
4
- the turnstile enters the mode of free
passage to the right after being switched on.
5
5
- activation of the “ANTIPANIC” input after
the AP and GND terminals are
closed/opened
6
6
Disabling/enabling of the control panel
7
7
Possibility to switch the relay terminals into
hold or passage counting mode, in
“ANTIPANIC” mode
8
8
- test mode for checking the turnstile
performance

VZR.235900.000 IM
Cube С-04 Turnstile
Installation Manual
20
5.1 Power connection
DO NOT:
USE THE POWER SUPPLY UNITS WITH AN OUTPUT CURRENT BELOW
3.0 A.
CONNECT THE TURNSTILE USING POWER CABLE WITH CROSS-
SECTION BELOW 1.5 MM2WHEN LENGTH OF THE SUPPLY CABLE IS
MORE THAN 10 M –IT IS RECOMMENDED TO USE CABLE WITH CROSS-
SECTION OF 2.5 MM2.
ATTENTION: IT IS NOT RECOMMENDED TO INSTALL POWER SUPPLY
UNIT AT A DISTANCE OF MORE THAN 25 M FROM THE TURNSTILE.
The turnstile is powered by 12 V DC power supply. The maximum
consumption is 3.0 A. The PSU should be selected on the basis of these
parameters.
It should also be taken into account that voltage drop increases when the
supply cable length is increased (operating voltage range is provided in the
Operation Manual VZR.235900.000 OM).
Install PSU in a place providing easy operator access.
Connect the PSU cable to POWER +12U and GND terminal group on the
control board. Make sure that the cable is securely connected. Make sure that
the cable is securely connected.
