MAJORITY SNO-BAR-BLK Manual

SNO-BAR-BLK
MAJORITY
SNOWDON
Wireless Audio Soundbar
Instrucons Guide

Controls And Funcons���������������������������������������������� 1
What’s In The Box?��������������������������������������������������� 4
Box Contents������������������������������������������������������������� 4
Instrucons Guide �����������������������������������������������������5
Placing TV or Vision Device��������������������������������������� 5
Mode Indicator lights������������������������������������������������ 5
Connecons�������������������������������������������������������������� 6
Using the Opcal Input��������������������������������������������� 7
Using the MP3 LINK Connecon (Line In)����������������� 8
Connecng to the Mains Supply������������������������������� 9
Bluetooth Operaon������������������������������������������������ 10
Playing Audio Wirelessly�������������������������������������������11
Troubleshoong ������������������������������������������������������ 12
Warranty ����������������������������������������������������������������� 13
Safety Informaon��������������������������������������������������� 14
Watch video tutorials and register
your product for a FREE 3-year warranty
at www.majorityradios.co.uk
Contents
3YEAR
WARRANTY

1
Controls And Funcons
Side View / Control Buttons
Back View / Connections
1. Switch on and o the unit
2. Select the modes
3. Volume up
4. Volume down
5. Bluetooth pair button
6. Line in socket
1. AUX socket
2. OPTICAL IN socket
3. DC IN (18V) socket

2
Remote Control
1. Power On/O
Switch the unit between on and
Standby mode
2. BT button
Bluetooth input buttons
3. Music/Movie/Dialog
buttons
Press the button to select a
desired music mode: Music,
Movie, Voice
4. Treble+/Treble- buttons
(It must be in mode of Music)
5. Back button
Skip backwards to the
beginning of the track or to
the previous track in Bluetooth
mode
6. OPTICAL button
Optical in button
7. PAIR/MUTE button
One touch to silence the unit or
restore the sound
Press and hold 2 seconds to
select PAIR mode
8. LINE button
Line In for 3.5mm input
9. AUX button
AUX for RCA L/R input
10. BASS+/BASS- buttons
(It must be in mode of Music)
11. VOL +/- buttons
Adjust the volume
12. Play/Stop button
Play/pause/resume playback in
Bluetooth mode
13. Skip button
Skip forwards to the next track
in Bluetooth mode
Controls And Funcons

3
Using the remote control
The remote control sensor at the front of the soundbar is
sensitive to the remote control’s commands up to a maximum of
6 metres away and within a maximum arc of 40 degrees.
Please note that the operating distance may vary depending on
the brightness of the room.
Remote control battery replacement
Remove the battery compartment located
on the back of the remote control.
The unit comes standard with a battery
installed. To avoid discharging it, it is locked
with a plastic tape. Remove the tape to
activate the battery.
If you have to change, insert a CR2025 3V
battery, observing the correct polarity.
Replace the battery compartment.
Controls And Funcons

4
What’s In The Box?
1. Majority Snowdon Soundbar
2. Remote Control
3. Adapter
4. RCA Stereo Audio Cable
5. 3.5mm to 3.5mm Audio cable
6. Instructions Guide
Box Contents

5
The unit supports a TV with dimensions between 24 and 50 inches.
Placing TV or Vision Device
Mode Indicator lights
Instrucons Guide
Ensure the TV or Vision Device is placed properly. Turning
the volume loud may cause the device to fall down.
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR
!
State Indicator Lights
Power o Red
Optical mode Yellow
AUX mode White
Line in mode Green
Bluetooth ready Flashing blue
Bluetooth connected Blue

6
Instrucons Guide
Using the AUX Connection
Use the RCA Stereo Audio Cable to connect the TV’s stereo
RCA(L/R). Audio output socket to the AUX(L/R) Sockets of the
unit.
Then press the AUX button on the remote control or press the
source button on the unit to choose the AUX function.
Turn on your television set to use the YW-S05.
Connections

7
Using the Optical Input
Instrucons Guide
You will need: An audio source with an Optical Audio Output and a Digital
Optical Audio cable (not included)
Connect the Digital Optical Audio cable to the optical output on
the audio source and to the Optical Input on the speaker bar.
Press the POWER button on side panel or POWER button directly
on the remote control to switch on the unit.
Press the OPTICAL button on the remote control to switch
to Optical mode or one touch SOURCE button on main unit
repeatedly to select the Optical mode. The mode indicator LED
will turn Yellow.
Using the native controls on your connected device, make
sure the audio settings are set to PCM or Optical Audio and are
turned On.
Audio from the connected audio source will now be played
through the speakers.

8
Instrucons Guide
Plug one end of a 3.5mm audio input cable (included) into the
Line in on the unit. Before use, disconnect any cables connected
to the Stereo RCA Inputs.
Plug the other end of the cable into the audio output/
headphone output on an MP3 player or other audio source.
Press the POWER button on side panel or POWER button directly
on the remote control to switch on the unit.
One touch the SOURCE button repeatedly or directly press LINE
in button on remote control to enter LINE in mode. The mode
indicator will turn green.
Audio played through the connected device will now be heard
through the speakers.
Using the MP3 LINK Connection (Line In)

9
Instrucons Guide
Ensure that the power supply voltage is in the voltage of
100V~240V.
This unit is designed to use adapter.
Connecting the unit to any other power source may cause
damage to the unit.
Unwind the mains cable to its full length. Connect the mains
plug to a mains socket. Make sure the mains plug is fully inserted
into the mains socket.
The mains plug/appliance coupler is used as the disconnect
device, the disconnect device must remain readily operable.
Connect the Adapter to the unit and AC Socket.
Connecting to the Mains Supply
Ensure all audio connecons of the unit are connected before connecng
to the mains power socket.
Unplug the power cord from the outlet when the unit is use for an
extended period of me.
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR
!

10
Instrucons Guide
Pairing a Bluetooth Device for the First Time
Press the POWER button on the unit or the POWER button on
the remote control to switch on the unit.
Select and press the BT button directly on the remote control or
press the SOURCE button repeatedly to enter Bluetooth mode,
indicated by a ashing blue light.
Using the native controls on your Bluetooth device, select the
“YW-S05”in your Bluetooth settings to pair.
If your device requests a password, enter the default“0000”. Refer
to the “user’s manual” for your specic device for instructions on
pairing and connecting Bluetooth devices.
When successfully paired and connected, a beep will issue from
the unit and the Pairing Indicator will display a solid blue light.
After initial pairing, the unit will stay paired unless unpaired
manually by the user, or until it is erased due to a reset of the
device.
Soundbar has Bluetooth connected to a device, you can press
MUTE/PAIR button 3 seconds to exit this device in order to pair
the device with another Bluetooth device.
If your device should become unpaired or you nd it is unable to
connect, repeat the above steps.
Bluetooth Operation

11
Follow the instructions for Pairing a Bluetooth Device.
Use the native controls on the connected Bluetooth Device to
select a track.
To play, pause or skip the selected track, use the native controls
on the connected Bluetooth Device.
Audio played through the connected Bluetooth device will now
be heard through the speakers.
Instrucons Guide
Playing Audio Wirelessly

12
If the Soundbar does not work properly as desired, please check
the following checklist. Maybe it is just a minor problem, you can
x it by yourself.
Troubleshoong
Troubleshooting
Malfunction Possible causes/measures
No power / function
Check whether the power is switched on or
o at the wall.
Check whether the power adaptor is
properly connected to power outlet or not.
No sound
Check whether unit is set to MUTE or not.
Check whether MODE is correctly selected
or not.
Check whether cables are properly installed
or not.
No sound from bluetooth
connection
Check whether you have pressed PAIR
button before pairing.
Check whether external device requires
password “” to start with.
Function disturbance Switches o and unplugs the unit. Leaves it
for  minutes and switches it on again.
Remote control does not work
[properly]
Check whether the battery run out or not.
Replaces a new one if necessary.
Check whether there is obstacle on the
front of remote sensor or not.
No sound when connection
and switches to OPTICAL IN
mode
Check and ensures the audio setting of the
input source (e.g. TV,game console,DVD
player, etc.)is set to PCM mode while using
digital connection (such as Optical,HDMI
and COAXIAL)

13
Specicaons
Specications
Power Supply DC 18V 1.A
Frequency Response Hz-KHz
SNR dB
Separation dB
Bluetooth V3.0
Dimension (WxHxD) xx
Net Weight .kg
Warranty
All products come with a standard 12 month warranty. All items
must be registered on www.majorityradios.co.uk for the
warranty to be valid. Once on the web page, use the menu to
nd “ register your product”. You will also be given the chance
to extend your warranty for an additional 24 months, free of
charge.

14
1. Read these instructions.
2. Keep these instructions. Instructions are also
available for download at www.majorityradios.co.uk
3. Heed all Warnings
4. Follow all instructions
5. Do no clean the apparatus near or with water
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9. Protect the power from being walked on or pinched
particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
10. Only use attachments/accessories specied by the
manufacturer.
11. Unplug this apparatus during light storms or when
unused for long periods of time.
12. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in a way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to the rain or moisture, does not
operate normally or has been dropped.
13. No naked ame sources, such as lit candles, should
be placed on the apparatus.
14. Dispose of used electrical products and batteries
safely according to your local authority and
regulations.
ADDITIONAL WARNINGS
The apparatus shall not be exposed to dripping or
splashing and no objects lled with liquid, such as
vases, shall be places on the apparatus.
Main plug is used to disconnect device and it should
remain readily operable during intended use. In order
to disconnect the apparatus from the main mains
completely, the mains plug should be disconnected
from the main socket outlet completely.
Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
RECYCLING ELECTRICAL PRODUCTS
You should now recycle your waste electrical goods and
in doing so help the environment.
This symbol means an electrical product should
not be disposed of with normal household waste.
Please ensure it is taken to a suitable facility for
disposal when nished with.
IMPORTANT: Please read all instructions carefully
before use and keep for future reference.
Risk of electric shock.
Do not open
Read all instructions carefully before use
and keep for future reference
When servicing, use only identical
replacement parts
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
!
!
Safety Informaon
IMPORTANT: Please read all instrucons carefully
before use and keep for future reference
!

www.majorityradios.co.uk
