Makita DUS054 User manual

EN Cordless Garden Sprayer INSTRUCTION MANUAL 2
FRCA Pulvérisateur de Jardin Sans-Fil MANUEL D’INSTRUCTION 18
ESMX
Fumigador Inalámbrico para Jardín MANUAL DE INSTRUCCIONES 34
DUS054
IMPORTANT: Read Before Using.
IMPORTANT: Lire avant usage.
IMPORTANTE: Lea antes de usar.

2English
1
8
13
2
9
3
10 11 12
5
4
6
16
17
14
15
7
English (Original instructions)
1 Head switch cock 2 Extension nut 3 Handle 4 Measuring cup
5 Spray wand bracket 6 Shoulder strap 7 Battery cover 8 Adjustable spray head
9 Spray wand 10 Lever 11 Hose 12 5L tank
13 Indicator lamps 14 On/off switch 15 Spray wand holder 16 Locking lever
17 Hook (for attaching the spray wand) - - - -

3English
SPECIFICATIONS
Model DUS054
Rated voltage D.C. 18 V
Tank capacity 5 L (1.3 Gal.)
Hose length 1.7 m (67")
Total extendable length 50 - 70 cm (19-3/4" - 27-1/2")
Nozzle type 2-Head (Switchable to 1 head)
Max. working pressure 0.3 MPa
Working pressure with standard nozzle Max. Approx. 0.26 Mpa
Min. Approx. 0.13 Mpa
Flow rate with standard nozzle Max. Approx. 0.91 L/min (0.24 GPM)
Min. Approx. 0.47 L/min (0.12 GPM)
Nozzle tting screw G 1/4"
Dimensions (L × W × H) 343 × 182 × 368 mm (13-1/2" x 7-1/8" x 14-1/2")
Net weight 3.2 - 3.5 kg (7.1 - 7.7 lbs)
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications may differ from country to country.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heaviest
combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Battery cartridge BL1820B / BL1830 / BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or re.
WARNING: Do not use a corded power supply such as battery adapter or portable power pack with
this machine. The cable of such power supply may hinder the operation and result in personal injury.
Symbols
The followings are symbols used for the equipment. Be sure that you understand their meaning before use.
Wear ear protection. Warning
Wear a breathing mask. Wear eye protection.
Wear safety footwear. Wear protective gloves.
Do not use in the rain or leave the sprayer outdoors while raining.
Read instruction manual.
volts
direct current

4English
Important safety instructions
WARNING: When using electric gardening
appliances, basic safety precautions should
always be followed to reduce the risk of re,
electric shock, and personal injury, including the
following:
READ ALL INSTRUCTIONS.
1. Avoid Dangerous Environment - Do not use
appliances in damp or wet locations.
2. Don’t Use In Rain.
3. Keep Children Away - All visitors should be kept
at a distance from work area.
4. Dress Properly - Do not wear loose clothing or
jewelry. They can be caught in moving parts. Use
of rubber gloves and substantial footwear is rec-
ommended when working outdoors. Wear protec-
tive hair covering to contain long hair.
5. Use Safety Glasses – Always use face or dust
mask if operation is dusty.
6. Use Right Appliance - Do not use appliance for
any job except that for which it is intended.
7. Avoid Unintentional Starting - Do not carry
appliance with nger on switch. Be sure switch is
off before inserting battery pack.
8. Do not Force Appliance - It will do the job better
and with less likelihood of a risk of injury at the rate
for which it was designed.
9. Do not Overreach - Keep proper footing and
balance at all times.
10. Stay Alert - Watch what you are doing. Use com-
mon sense. Do not operate appliance when you
are tired.
11. Store Idle Appliances Indoors - When not in use,
appliances should be stored indoors in dry, and
high or locked-up place out of reach of children.
12. Maintain Appliance With Care - Keep cutting
edge sharp and clean for best performance and
to reduce the risk of injury. Follow instructions for
lubricating and changing accessories. Keep han-
dles dry, clean, and free from oil and grease.
13. Check Damaged Parts - Before further use of the
appliance, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform its intended function.
Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting, and
any other condition that may affect its operation.
A guard or other part that is damaged should be
properly repaired or replaced by an authorized
service center unless indicated elsewhere in this
manual.
Cordless Garden Sprayer
Safety Warnings
WARNING: Risk of re or explosion. Do not
spray ammable liquids such as gasoline. Look
for this symbol reference on the container.
WARNING: Some spray created from products
used with the sprayer contains chemicals known
to cause cancer, birth defect of other reproductive
harm.
Some examples of these chemicals are:
· compounds in fertilize
· compounds in insecticides, herbicides, and pesticides;
· arsenic and chromium from chemically treated lumber.
Follow directions on containers of all such products.
To reduce your exposure to these chemicals, wear
approved safety equipment such as face masks that
are specially designed to filter out sprays, gloves, and
other appropriate protective equipment.
■ Before using any pesticide or other spray mate-
rials in this sprayer, read the label on its original
container thoroughly and follow its directions.
Some spray materials are dangerous and should
not be used in this sprayer, as they can damage the
sprayer and cause serious bodily injury or property
damage.
■ Electric shock hazard. Never spray toward electri-
cal outlets.
■ Do not use commercial grade chemicals or
chemicals for commercial or industrial pur-
poses. Use only consumer grade water-based lawn
and garden chemicals.
■ Do not pour hot or boiling liquids into the tank.
These can weaken or damage the hose or tank.
■ Spray area must be well ventilated.
■ Avoid spraying on windy days. Spray can be
accidentally blown onto plants or objects that should
not be sprayed.
■ Store the sprayer in a secure, well-ventilated
indoor space with the uid tank empty.
■ Do not use caustic (alkali) self-heating or cor-
rosive (acid) liquids in this sprayer. These can
corrode metal parts or weaken the tank and hose.
■ Know the contents of the chemical being
sprayed. Read all Material Safety Data Sheets
(MSDS) and container labels provided with the
chemical. Follow the chemical manufacturer s
safety instructions.
■ Do not leave residue or spray material in the
tank after using the sprayer. Clean after each use.
■ Do not smoke while using the sprayer, or spray
where spark or ame is present.

5English
■ Risk of injection. Do not discharge directly against
skin.
■ To reduce the risk of electric shock, do not put
the sprayer into water or other liquid. Do not
place or store the sprayer where it can fall or be
pulled into a tub or sink.
■ Maintain this product. Thoroughly inspect both
the inside and outside of the sprayer and exam-
ine the components before each use. Check for
cracked and deteriorated hoses, leaks, clogged
nozzles, and missing or damaged parts. If dam-
aged, have the product repaired before use.
Many accidents are caused by poorly maintained
products.
■ Disconnect the battery from the unit before
draining, cleaning, or storing the sprayer. Such
preventive safety measures reduce the risk of acci-
dental starting.
■ Always wear eye protection with side shields
or goggles marked to comply with ANSI Z87.1.
Failure to do so could result in uids entering your
eyes resulting in possible serious injury.
■ Protect your lungs. Wear a face or dust mask
when using the sprayer. Following this rule will
reduce the risk of serious personal injury.
■ Battery tools do not have to be plugged into
an electrical outlet; therefore, they are always
in operating condition. Be aware of possible
hazards when not using your battery tool or
when changing accessories. Remove battery
pack when tool is not in use. Following this rule
will reduce the risk of electric shock, re, or serious
personal injury.
■ Do not place battery tools or their batteries near
re or heat. This will reduce the risk of explosion
and possibly injury.
■ Do not crush, drop or damage battery pack. Do
not use a battery pack or charger that has been
dropped or received a sharp blow. A damaged
battery is subject to explosion. Properly dispose of a
dropped or damaged battery immediately.
■ Batteries can explode in the presence of a
source of ignition, such as a pilot light. To reduce
the risk of serious personal injury, never use any
cordless product in the presence of open ame. An
exploded battery can propel debris and chemicals. If
exposed, ush with water immediately.
■ Do not charge battery tool in a damp or wet
location. Following this rule will reduce the risk of
electric shock.
■
For best results, your battery tool should be
charged in a location where the temperature is
more than 10 °C (50 °F) but less than 40 °C (104 °F).
To reduce the risk of serious personal injury, do not
store outside or in vehicles.
■ Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in
contact with your skin, wash immediately with
soap and water. If liquid gets into your eyes,
ush them with clean water for at least 10 min-
utes, then seek immediate medical attention.
Following this rule will reduce the risk of serious
personal injury.
■ Do not use battery-operated appliance in rain.
■ Do not use battery-operated appliance in rain.
Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings, bracelets, and keys. The battery or
conductor may overheat and cause burns.
■ Do not dispose of the battery(ies) in a re. The
cell may explode. Check with local codes for possi-
ble special disposal instructions.
■ Do not open or mutilate the battery(ies).
Released electrolyte is corrosive and may cause
damage to the eyes or skin. It may be toxic if
swallowed.
■ Avoid Dangerous Environment - Don’t use appli-
ances in damp or wet locations.
■ Use Right Appliance - Do not use appliance for
any job except that for which it is intended.
■ Don’ t Force Appliance - It will do the job better
and with less likelihood of a risk of injury at the rate
for which it was designed.
■ Store Idle Appliances Indoors - When not in use,
appliances should be stored indoors in dry, and high
or locked-up place - out of reach of children.
■ Maintain Appliance With Care - Keep clean for
best performance and to reduce the risk of injury.
Follow instructions for changing accessories.
Inspect appliance cord, and if damaged, have it
repaired by an authorized service facility. Keep
handles dry, clean, and free from oil and grease.
■ Check Damaged Parts - Before further use of the
appliance, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform its intended function.
Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting, and any
other condition that may affect its operation. A guard
or other part that is damaged should be properly
repaired or replaced by an authorized service center
unless indicated elsewhere in this manual.
