Makita DFT024F User manual

DFT024F
DFT025F
DFT060F
EN Cordless Screwdriver INSTRUCTION MANUAL 4
ZHCN 充电式起子机 使用说明书 12
ID Obeng Listrik Tanpa Kabel PETUNJUK PENGGUNAAN 21
MS Pemutar Skru Tanpa Kord MANUAL ARAHAN 30
VI Máy Vặn Vít Cầm Tay Hoạt
Động Bằng Pin TÀI LIỆU HƯỚNG DẪN 39
TH   47

1
2
3
Fig.1
1
2
Fig.2
1
Fig.3
1
Fig.4
1
AB
Fig.5
1
Fig.6
1
Fig.7
1
2
Fig.8
2

1
23
Fig.9
Fig.10
12
Fig.11
132
Fig.12
1
2
2
Fig.13
Fig.14
3

4ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: DFT024F DFT025F DFT060F
Fastening
torque
Hard joint 0.5 - 2 N•m 1.5 - 6.5 N•m
Soft joint 0.5 - 2 N•m 1.5 - 6.5 N•m
No load speed (RPM) 260 - 1,600 min-1 100 - 1,300 min-1
Dimensions
(L x W x H)
with BL1815N battery 161 mm x 75 mm x 242 mm
with BL1860B battery 161 mm x 75 mm x 258 mm
Rated voltage D.C. 18 V
Net weight 1.2 - 1.5 kg
Applicable USB cable 661432-2
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydi󰀨erfromcountrytocountry.
• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Battery cartridge BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
andchargersmaycauseinjuryand/orre.
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Read instruction manual.
Ni-MH
Li-ion
Only for EU countries
Due to the presence of hazardous com-
ponents in the equipment, waste electrical
and electronic equipment, accumulators
and batteries may have a negative impact
on the environment and human health.
Do not dispose of electrical and electronic
appliances or batteries with household
waste!
In accordance with the European Directive
on waste electrical and electronic equip-
ment and on accumulators and batteries
and waste accumulators and batteries,
as well as their adaptation to national law,
waste electrical equipment, batteries and
accumulators should be stored separately
and delivered to a separate collection point
for municipal waste, operating in accor-
dance with the regulations on environmen-
tal protection.
This is indicated by the symbol of the
crossed-out wheeled bin placed on the
equipment.
Intended use
The tool is intended for screw driving in wood, metal
and plastic.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
serious injury.
Save all warnings and instruc-
tions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.

5ENGLISH
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However, users of pacemakers and other similar
medical devices should contact the maker of their
device and/or doctor for advice before operating
this power tool.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication. A moment of inattention while operating
power tools may result in serious personal injury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
3. Prevent unintentional starting. Ensure the
switch is in the o󰀨-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a
second.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and o󰀨. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool. Power tools are dangerous in the
hands of untrained users.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may a󰀨ect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Many accidents are caused by poorly maintained
power tools.

6ENGLISH
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
foroperationsdi󰀨erentfromthoseintendedcould
result in a hazardous situation.
8. Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for
safe handling and control of the tool in unexpected
situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled. The entangle-
ment of cloth work gloves in the moving parts may
result in personal injury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
onetypeofbatterypackmaycreateariskofre
when used with another battery pack.
2. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
may exhibit unpredictable behaviour resulting in
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
perature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions. Charging improperly or at temperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
3. Follow instruction for lubricating and chang-
ing accessories.
Cordless screwdriver safety
warnings
1. Hold the power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden wir-
ing. Fasteners contacting a “live” wire may make
exposed metal parts of the power tool “live” and
could give the operator an electric shock.
2. Always be sure you have a rm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool rmly.
4. Keep hands away from rotating parts.
5. Do not touch the bit or the workpiece immedi-
ately after operation; they may be extremely
hot and could burn your skin.
6. Always secure workpiece in a vise or similar
hold-down device.
7. Make sure there are no electrical cables, water
pipes, gas pipes etc. that could cause a hazard
if damaged by use of the tool.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product.
MISUSE or failure to follow the safety rules stated
in this instruction manual may cause serious
personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper with the battery
cartridge.Itmayresultinare,excessiveheat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.

7ENGLISH
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge. Such conduct may result in a
re,excessiveheat,orexplosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
Tapeormasko󰀨opencontactsandpackupthe
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
sive heat, explosion, or leak of electrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge. It may result in poor performance or
breakdown of the tool or battery cartridge.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near high-voltage electri-
cal power lines. It may result in a malfunction or
breakdown of the tool or battery cartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causingres,personalinjuryanddamage.Itwill
also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridgermlymaycausethemtoslipo󰀨yourhands
and result in damage to the tool and battery cartridge
and a personal injury.
►Fig.1: 1. Red indicator 2. Button 3. Battery cartridge
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator as
showninthegure,itisnotlockedcompletely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
it may accidentally fall out of the tool, causing injury to
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.

8ENGLISH
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
►Fig.2: 1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
cate the remaining battery capacity. The indicator lamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydi󰀨erslightly
from the actual capacity.
NOTE:Therst(farleft)indicatorlampwillblinkwhen
the battery protection system works.
Tool / battery protection system
The tool is equipped with a tool/battery protection sys-
tem.Thissystemautomaticallycutso󰀨powertothe
motor to extend tool and battery life. The tool will auto-
matically stop during operation if the tool or battery is
placed under one of the following conditions:
Overload protection
When the tool/battery is operated in a manner that
causes it to draw an abnormally high current, the tool
stopsautomatically.Inthissituation,turnthetoolo󰀨
and stop the application that caused the tool to become
overloaded. Then turn the tool on to restart.
Overheat protection
When the tool/battery is overheated, the tool stops
automatically. In this situation, let the tool/battery cool
before turning the tool on again.
Overdischarge protection
When the battery capacity is not enough, the tool stops
automatically. In this case, remove the battery from the
tool and charge the battery.
Switch action
WARNING: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the “OFF" position when released.
To start the tool, simply pull the switch trigger. Release
the switch trigger to stop.
►Fig.3: 1. Switch trigger
NOTE: For approximately one second after fastening,
the tool does not work even with the switch pulled.
Lighting up the front lamp
►Fig.4: 1. Lamp
CAUTION: Do not look in the light or see the
source of light directly.
Pull the switch trigger to light up the lamp. The lamp
keeps on lighting while the switch trigger is being pulled.
The lamp goes out approximately 10 seconds after
releasing the switch trigger.
NOTE:Useadryclothtowipethedirto󰀨thelensof
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
Reversing switch action
►Fig.5: 1. Reversing switch lever
CAUTION: Always check the direction of
rotation before operation.
CAUTION: Use the reversing switch only after
the tool comes to a complete stop. Changing the
direction of rotation before the tool stops may dam-
age the tool.
CAUTION: When not operating the tool,
always set the reversing switch lever to the neu-
tral position.
This tool has a reversing switch to change the direction
of rotation. Depress the reversing switch lever from the
A side for clockwise rotation or from the B side for coun-
terclockwise rotation.
When the reversing switch lever is in the neutral posi-
tion, the switch trigger cannot be pulled.

9ENGLISH
LED indicator / Beeper
►Fig.6: 1. LED indicator
LED indicator / Beeper on the tool shows the following functions.
Function Status of the tool Status of the LED indicator/beeper Action to be taken
LED indicator Beeper
Check of the LED indi-
cator, light and beeper
operation
When the battery
cartridge is installed,
the tool checks for its
LED indicator, light and
beeper.
Lightsuprstingreen,
next red.
(And then the light
comes on.)
A series of very short
beeps
–
Detection of switch
trigger operation when
installing battery
When the battery car-
tridge is installed with
the switch trigger pulled,
the tool stops to avoid
unintentional start.
Blinks in red and green
alternatively.
A series of short beeps Release the switch
trigger.
Auto-stop with fastening
completion
The tool setting has
been achieved and the
tool has stopped.
Lights up in green for
approximately one
second.
– –
Alarmagainstinsu󰀩-
cient fastening
The tool has not com-
pleted the tool setting
because the switch
trigger has released
before reaching the
set values. Otherwise,
the settings of “Failure
Criteria for Phase” has
been achieved.
Lights up in red. A long beep Retighten the screw.
Intermission between
the phases
The tool is in the inter-
mittingperiodcongured
by the setting of “Shift to
the next Phase”.
Lights up or blinks in
green (depending on
settings)
– –
Double-hitting detection When the operator
starts to re-fasten an
already-fastened screw,
the tool detect it and
stops.
Lights up in red. A long beep –
Alarm for low battery
capacity
The battery power
became low and it is
time to replace the
battery cartridge.
Blinks in red slowly. A series of long beeps Replace the battery with
fully charged one.
Auto-stop with low
remaining battery
capacity
The battery power is
almost used up and the
tool stopped.
Lights up in red. A long beep Replace the battery with
fully charged one.
Anti-reset of controller The battery voltage
dropped abnormally for
some reason, and the
tool stopped.
Blinks in red and green
alternatively.
A series of short beeps Replace the battery with
fully charged one.
Overheat protection The motor or the control-
ler heated up abnormally
and the tool stopped.
Blinks in red quickly. A series of short beeps Remove the battery car-
tridge immediately and
cool the tool down.
Failure to detect heat
of motor
The detection unit of
the motor fails to detect
the heat because the
cord has broken or other
reasons.
Blinks in red quickly. A series of short beeps Remove the battery
cartridge and cool the
tool down. If the indicator
does not stop, ask your
local Makita Service
Center for repair.
Motor failure detection Motor failure has been
detected. At this time,
tool does not work.
Blinks in red and green
alternatively.
A series of short beeps Ask your local Makita
Service Center for repair.
Maintenance alarm A maintenance time has
come according to your
preset number of screws
driven.
Blinks in yellow. –Reset the alarm with the
application software.
Alarm for unavailable
data communication
(with the tool in connec-
tion with PC)
Data cannot be
exchanged between the
tool and PC in spite of
the connection.
Blinks in yellow. –Restart the application
software and re-connect
the USB cable.

10 ENGLISH
Function Status of the tool Status of the LED indicator/beeper Action to be taken
LED indicator Beeper
Indication that data com-
munication is available
(with the tool in connec-
tion with PC)
The tool is connected to
PC and data communi-
cation is available.
Blinks in green. – –
Adjusting the fastening torque
When you wish to drive machine screws, hex bolts,
etc. with the predetermined torque, adjust the fastening
torque as follows.
1. Open the change plate by hand so that you can
see a hole.
►Fig.7: 1. Change plate
2. Pull the switch trigger and release it so that the
adjust ring rotates and the hole becomes visible. And
then remove the battery cartridge.
3. Use an optional adjust grip to adjust the fastening
torque. Insert the pin of the adjust grip into the hole
in the front of the tool. And then, turn the adjust grip
clockwise to set a greater fastening torque, and coun-
terclockwise to set a smaller fastening torque.
►Fig.8: 1. Adjust grip 2. Hole for adjust grip
4. Insert the battery cartridge and be sure that a
fastening torque has been set up by using a fastening
torque tester.
5. Close the change plate by hand securely.
Adjusting no-load speed and
revolution angle etc.
You can adjust the no-load speed, number of turn, etc.
of the tool with your computer. Install the application
software in your computer and connect it to the tool with
an USB cable.
►Fig.9: 1. USB port 2. USB cover 3. USB cable
NOTICE: Make sure that the USB cover closed
when fastening.
NOTE: Use the makita genuine USB cable to con-
nect your computer to the tool. Refer to the section
“SPECIFICATIONS”.
NOTE: For the application software, please contact
Makita sales representative.
ASSEMBLY
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before carrying out any work on the tool.
Installing or removing driver bit/
socket bit
►Fig.10
Use only driver bit/socket bit that has inserting portion
showninthegure.Donotuseanyotherdriverbit/
socket bit.
For tool with shallow driver bit hole
A=12mm
B=9mm
Use only these type of driver
bit. Follow the procedure 1.
(Note) Bit-piece is not
necessary.
For tool with deep driver bit hole
A=17mm
B=14mm
To install these types of driver
bits, follow the procedure 1.
A=12mm
B=9mm
To install these types of driver
bits, follow the procedure 2.
(Note) Bit-piece is necessary
for installing the bit.
Procedure 1
For tool without one-touch type sleeve
►Fig.11: 1. Driver bit 2. Sleeve
To install the driver bit, pull the sleeve in the direction of
the arrow and insert the driver bit into the sleeve as far
as it will go.
Then release the sleeve to secure the driver bit.
For tool with one-touch type sleeve
To install the driver bit, insert the driver bit into the
sleeve as far as it will go.
Procedure 2
In addition to Procedure 1, insert the bit-piece into the
sleeve with its pointed end facing in.
►Fig.12: 1. Driver bit 2. Bit-piece 3. Sleeve
To remove the driver bit, pull the sleeve in the direction
of the arrow and pull the driver bit out.
NOTE: If the driver bit is not inserted deep enough
into the sleeve, the sleeve will not return to its original
position and the driver bit will not be secured. In this
case, try re-inserting the bit according to the instruc-
tions above.
NOTE:Whenitisdi󰀩culttoinsertthedriverbit,pull
the sleeve and insert it into the sleeve as far as it will
go.
NOTE: After inserting the driver bit, make sure that it
isrmlysecured.Ifitcomesout,donotuseit.
Installing hook
Optional accessory
The hook is useful to hang the tool. Install the hook to
the holes on the tool body.
►Fig.13: 1. Hook 2. Hole

11 ENGLISH
OPERATION
Screwdriving operation
CAUTION: Make sure that the bit is inserted
straight in the screw head, or the screw and/or bit
may be damaged.
Place the point of the driver bit in the screw head and
apply pressure to the tool. Then switch the tool on.
When the clutch cuts in, the motor will stop automati-
cally. Then release the switch trigger.
►Fig.14
Limits of fastening capacity
Use the tool within the limits of fastening capacity. If you
use the tool beyond the limits, the clutch does not work.
And the tool cannot deliver enough fastening torque.
For model DFT024F / DFT025F
0.5 2.01.0 1.5
360°
300°
240°
180°
120°
60°
30°
1
3
2
N•m
1. Range of fastening capacity 2. Rotation angle
3. Torque
For model DFT060F
1.5 6.5
4.0
360°
300°
240°
180°
120°
60°
30°
1
3
2
N•m
1. Range of fastening capacity 2. Rotation angle
3. Torque
NOTE: The rotation angle is the angle from the point
that the bolt is tightened in 50% of desired torque to
the point that the bolt is tightened in 100% torque.
NOTE: Use of a cold battery cartridge may give
warning for battery capacity by LED indicator and
beeper and stop the tool immediately, even if it is fully
charged. In this case, the fastening capacity may be
inferiortothespecicationonthismanual.
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or attachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Adjust grip
• Protector (Natural, Red, Blue, Yellow, Green)
• USB cable
• Hook
• Lock nut (Red, Blue, Yellow)
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
di󰀨erfromcountrytocountry.

12
中文简体
中文简体 (原本)
规格
型号： DFT024F DFT025F DFT060F
紧固转矩 硬质紧固点 0.5 - 2 N•m 1.5 - 6.5 N•m
软质紧固点 0.5 - 2 N•m 1.5 - 6.5 N•m
空载速度（RPM）260 - 1,600 /min 100 - 1,300 /min
尺寸（长 ×
宽×高）
带BL1815N电池 161 mm ×75 mm ×242 mm
带BL1860B电池 161 mm ×75 mm ×258 mm
额定电压 D.C. 18 V
净重 1.2 - 1.5 kg
适用USB电缆 661432-2
• 生产者保留变更规格不另行通知之权利。
• 规格可能因销往国家之不同而异。
• 重量因附件（包括电池组）而异。根据EPTA-Procedure 01/2014，最重与最轻的组合见
表格。
适用电池组和充电器
电池组 BL1815N / BL1820B / BL1830B /
BL1840B / BL1850B / BL1860B
充电器 DC18RC / DC18RD / DC18RE / DC18SD /
DC18SE / DC18SF / DC18SH
• 部分以上所列电池组和充电器是否适用视用户所在地区而异。
警告： 请仅使用以上所列电池组和充电器。使用其他类型的电池组或充电器可能会导
致人身伤害和／或失火。
符号
以下显示本设备可能会使用的符号。在使用
工具之前，请务必理解其含义。
阅读使用说明书。
Ni-MH
Li-ion 仅限于欧盟国家
由于本设备中包含有害成分，
因此废弃的电气和电子设备、
蓄电池和普通电池可能会对环
境和人体健康产生负面影响。
请勿将电气和电子工具或电池
与家庭普通废弃物放在一起处
置！
根据欧洲关于废弃电气电子设
备、蓄电池和普通电池、废弃
的蓄电池和普通电池的指令及
其国家层面的修订法案，废弃
的电气设备、普通电池和蓄电
池应当单独存放并递送至城市
垃圾收集点，根据环保法规进
行处置。
此规定由标有叉形标志的带轮
垃圾桶符号表示。

13
中文简体
用途
本工具用于在木材、金属和塑料中拧紧螺丝。
安全警告
电动工具通用安全警告
警告： 阅读随电动工具提供的所有安全
警告、说明、图示和规定。不遵照以下所列
说明会导致电击、着火和／或严重伤害。
保存所有警告和说明书以备查
阅。
警告中的术语“电动工具”是指市电驱动（有
线）电动工具或电池驱动（无线）电动工具。
工作场地的安全
1. 保持工作场地清洁和明亮。杂乱和黑暗
的场地会引发事故。
2. 不要在易爆环境，如有易燃液体、气体
或粉尘的环境下操作电动工具。电动工
具产生的火花会点燃粉尘或气体。
3. 操作电动工具时，远离儿童和旁观者。注
意力不集中会使你失去对工具的控制。
电气安全
1. 电动工具插头必须与插座相配。绝不能
以任何方式改装插头。需接地的电动工
具不能使用任何转换插头。未经改装的
插头和相配的插座将降低电击风险。
2. 避免人体接触接地表面，如管道、散热
片和冰箱。如果你身体接触接地表面会
增加电击风险。
3. 不得将电动工具暴露在雨中或潮湿环境
中。水进入电动工具将增加电击风险。
4. 不得滥用软线。绝不能用软线搬运、拉
动电动工具或拔出其插头。使软线远离
热源、油、锐边或运动部件。受损或缠
绕的软线会增加电击风险。
5. 当在户外使用电动工具时，使用适合户
外使用的延长线。适合户外使用的电线
将降低电击风险。
6. 如果无法避免在潮湿环境中操作电动工
具 ，应 使 用 带 有 剩 余 电 流 装 置（ RCD）保
护的电源。RCD的使用可降低电击风险。
7. 电动工具会产生对用户无害的电磁场
（EMF）。但是，起搏器和其他类似医
疗设备的用户应在操作本电动工具前咨
询其设备的制造商和／或医生寻求建议。
人身安全
1. 保持警觉，当操作电动工具时关注所从
事的操作并保持清醒。当你感到疲倦，
或在有药物、酒精或治疗反应时，不要
操作电动工具。在操作电动工具时瞬间
的疏忽会导致严重人身伤害。
2. 使用个人防护装置。始终佩戴护目镜。
防护装置，诸如适当条件下使用防尘面
具、防滑安全鞋、安全帽、听力防护等
装置能减少人身伤害。
3. 防 止 意 外 起 动 。在 连 接 电 源 和 /或电池包、
拿起或搬运工具前确保开关处于关断位
置。手指放在开关上搬运工具或开关处于
接通时通电会导致危险。
4. 在电动工具接通之前，拿掉所有调节钥
匙或扳手。遗留在电动工具旋转零件上
的扳手或钥匙会导致人身伤害。
5. 手不要过分伸展。时刻注意立足点和身
体平衡。这样能在意外情况下能更好地
控制住电动工具。
6. 着装适当。不要穿宽松衣服或佩戴饰品。
让你的头发和衣服远离运动部件。宽松衣
服、佩饰或长发可能会卷入运动部件。
7. 如果提供了与排屑、集尘设备连接用的
装置，要确保其连接完好且使用得当。
使用集尘装置可降低尘屑引起的危险。
8. 不要因为频繁使用工具而产生的熟悉感而
掉以轻心，忽视工具的安全准则。某个粗
心的动作可能在瞬间导致严重的伤害。
9. 使用电动工具时请始终佩带护目镜以免伤
害眼睛。护目镜须符合美国ANSI Z87.1、
欧洲EN 166或者澳大利亚／新西兰的AS/
NZS 1336的规定。在澳大利亚／新西兰，
法律要求佩带面罩保护脸部。
雇主有责任监督工具操作者和其他近工
作区域人员佩带合适的安全防护设备。

14
中文简体
电动工具使用和注意事项
1. 不要勉强使用电动工具，根据用途使用
合适的电动工具。选用合适的按照额定
值设计的电动工具会使你工作更有效、
更安全。
2. 如果开关不能接通或关断电源，则不能
使用该电动工具。不能通过开关来控制
的电动工具是危险的且必须进行修理。
3. 在进行任何调节、更换附件或贮存电动
工具之前，必须从电源上拔掉插头和/或
卸下电池包（如可拆卸）。这种防护性
的安全措施降低了电动工具意外起动的
风险。
4. 将闲置不用的电动工具贮存在儿童所及
范围之外，并且不允许不熟悉电动工具
和不了解这些说明的人操作电动工具。
电动工具在未经培训的使用者手中是危
险的。
5. 维护电动工具及其附件。检查运动部件是
否调整到位或卡住，检查零件破损情况和
影响电动工具运行的其他状况。如有损
坏，应在使用前修理好电动工具。许多
事故是由维护不良的电动工具引发的。
6. 保持切削刀具锋利和清洁。维护良好地
有锋利切削刃的刀具不易卡住而且容易
控制。
7. 按照使用说明书，并考虑作业条件和要
进行的作业来选择电动工具、附件和工
具的刀头等。将电动工具用于那些与其
用途不符的操作可能会导致危险情况。
8. 保持手柄和握持表面干燥、清洁，不得
沾有油脂。在意外的情况下，湿滑的手
柄不能保证握持的安全和对工具的控制。
9. 使用本工具时，请勿佩戴可能会缠结的
布质工作手套。布质工作手套卷入移动
部件可能会造成人身伤害。
电池式工具使用和注意事项
1. 仅使用生产者规定的充电器充电。将适
用于某种电池包的充电器用到其他电池
包时可能会发生着火危险。
2. 仅使用配有专用电池包的电动工具。使用
其他电池包可能会产生伤害和着火危险。
3. 当电池包不用时，将它远离其他金属物
体，例如回形针、硬币、钥匙、钉子、
螺钉或其他小金属物体，以防电池包一
端与另一端连接。电池组端部短路可能
会引起燃烧或着火。
4. 在滥用条件下，液体可能会从电池组中溅
出；应避免接触。如果意外碰到液体，用
水冲洗。如果液体碰到了眼睛，还应寻求
医疗帮助。从电池中溅出的液体可能会发
生腐蚀或燃烧。
5. 不要使用损坏或改装过的电池包或工具。
损坏或改装过的电池组可能呈现无法预测
的结果，导致着火、爆炸或伤害。
6. 不要将电池包暴露于火或高温中。电池
包暴露于火或高于130 ℃的高温中可能
导致爆炸。
7. 遵循所有充电说明。不要在说明书中指
定的温度范围之外给电池包或电动工具
充电。不正确或在指定的温度范围外充
电可能会损坏电池和增加着火的风险。
维修
1. 让专业维修人员使用相同的备件维修电
动工具。这将保证所维修的电动工具的
安全。
2. 决不能维修损坏的电池包。电池包仅能由
生产者或其授权的维修服务商进行维修。
3. 上润滑油及更换附件时请遵循本说明书
指示。
充电式起子机安全警告
1. 当进行作业时紧固件可能会接触到隐藏的
电线，请握住电动工具的绝缘抓握表面。
紧固件接触到“带电”的电线时，工具上
曝露的金属部分可能也会“带电”，并使
操作者触电。
2. 请务必确保立足稳固。
在高处使用工具时确保下方无人。
3. 请牢握本工具。
4. 手应远离旋转的部件。
5. 操作之后，请勿立刻触摸起子头或工件，
因为它们可能会非常烫而导致烫伤皮肤。
6. 请务必用虎钳或类似夹紧装置固定工件。
7. 请确保不存在电缆、水管、煤气管道等，
如果其因使用本工具而受损，可能会引起
危险。
请保留此说明书。
警告： 请勿为图方便或因对产品足够熟
悉（由于重复使用而获得的经验）而不严格
遵循相关产品安全规则。
使用不当或不遵循使用说明书中的安全规则
会导致严重的人身伤害。

15
中文简体
电池组的重要安全注意事项
1. 在使用电池组之前，请仔细通读所有的说
明 以 及（ 1） 电 池 充 电 器 ，（ 2）电 池 ，以 及
（3）使用电池的产品上的警告标记。
2. 切勿拆卸或改装电池组。否则可能引起
火灾、过热或爆炸。
3. 如果机器运行时间变得过短，请立即停
止使用。否则可能会导致过热、起火甚
至爆炸。
4. 如果电解液进入您的眼睛，请用清水将
其冲洗干净并立即就医。否则可能会导
致视力受损。
5. 请勿使电池组短路：
(1) 请勿使任何导电材料碰触到端子。
(2) 避免将电池组与其他金属物品如钉
子、硬币等放置在同一容器内。
(3) 请勿将电池组置于水中或使其淋雨。
电池短路将产生大的电流，导致过热，
并可能导致起火甚至击穿。
6. 请勿在温度可能达到或超过50°C（122°F）
的场所存放以及使用工具和电池组。
7. 即使电池组已经严重损坏或完全磨损，也
请勿焚烧电池组。电池组会在火中爆炸。
8. 请勿对电池组射钉，或者切削、挤压、抛
掷、掉落电池组，又或者用硬物撞击电池
组。否则可能引起火灾、过热或爆炸。
9. 请勿使用损坏的电池。
10. 本工具附带的锂离子电池需符合危险品
法规要求。
第三方或转运代理等进行商业运输时，
应遵循包装和标识方面的特殊要求。
有关运输项目的准备作业，咨询危险品
方面的专业人士。同时，请遵守可能更
为详尽的国家法规。
请使用胶带保护且勿遮掩表面的联络信
息，并牢固封装电池，使电池在包装内
不可动。
11. 丢弃电池组时，需将其从工具上卸下并
在安全地带进行处理。关于如何处理废
弃的电池，请遵循当地法规。
12. 仅将电池用于Makita（牧田）指定的产
品。将电池安装至不兼容的产品会导致
起火、过热、爆炸或电解液泄漏。
13. 如长时间未使用工具，必须将电池从工
具内取出。
14. 使用工具期间以及使用工具之后，电池组
温度可能较高易引起灼伤或低温烫伤。处
理高温电池组时请小心操作。
15. 在使用工具后请勿立即触碰工具的端子，
否则可能引起灼伤。
16. 避免锯屑、灰尘或泥土卡入电池组的端
子、孔口和凹槽内。否则可能导致工具
或电池组性能下降或故障。
17. 除非工具支持在高压电源线路附近使用，
否则请勿在高压电源线路附近使用电池
组。否则可能导致工具或电池组故障或
失常。
18. 确保电池远离儿童。
请保留此说明书。
小心： 请仅使用Makita（牧田）原装电
池。使用非Makita（牧田）原装电池或经过
改装的电池可能会导致电池爆炸，从而造成
火灾、人身伤害或物品受损。同时也会导致
牧田工具和充电器的牧田保修服务失效。
保持电池最大使用寿命的提示
1. 在电池组电量完全耗尽前及时充电。发
现工具电量低时，请停止工具操作，并
给电池组充电。
2. 请勿对已充满电的电池组重新充电。过
度充电将缩短电池的使用寿命。
3. 请在10 °C - 40 °C（50 °F - 104 °F）的
室温条件下给电池组充电。请在灼热的
电池组冷却后再充电。
4. 不使用电池组时，请将其从工具或充电
器上拆除。
5. 如果电池组长时间（超过六个月）未使
用，请给其充电。
功能描述
小心： 调节或检查工具功能之前，请务
必关闭工具的电源并取出电池组。
安装或拆卸电池组
小心： 安装或拆卸电池组之前，请务必
关闭工具电源。
小心： 安装或拆卸电池组时请握紧工具
和电池组。否 则 它 们 可 能 从 您 的 手 中 滑 落 ，导
致工具和电池组受损，甚至造成人身伤害。
►图片1: 1. 红色指示器 2. 按钮 3. 电池组
拆卸电池组时，按下电池组前侧的按钮，同
时将电池组从工具中抽出。

16
中文简体
安装电池组时，要将电池组上的舌簧与外罩上
的凹槽对齐，然后推滑到位。将其完全插入到
位，直到锁定并发出咔哒声为止。若能看到图
示中的红色指示器，则说明未完全锁紧。
小心： 务必完全装入电池组，直至看不
见红色指示器为止。否则，它可能会从工具
中意外脱落，从而造成自身或他人受伤。
小心： 请勿强行安装电池组。如果电池
组难以插入，可能是插入方法不当。
显示电池的剩余电量
仅限带指示灯的电池组
►图片2: 1. 指示灯 2. CHECK（查看）按钮
按电池组上的CHECK（查看）按钮可显示
电池剩余电量。指示灯将亮起数秒。
指示灯 剩余电量
点亮 熄灭 闪烁
75%至
100%
50%至
75%
25%至
50%
0%至
25%
给电池
充电。
电池可
能出现
故障。
注： 在不同的使用条件及环境温度下，指
示灯所示电量可能与实际情况略有不同。
注： 当电池保护系统启动时，第一个（最
左侧）指示灯将闪烁。
工具／电池保护系统
本工具配备有工具／电池保护系统。该系统可自
动切断电机电源以延长工具和电池寿命。作业
时，如果工具或电池处于以下情况，工具将会自
动停止运转。
过载保护
以导致异常高电流的方式操作工具／电池时，工
具会自动停止运转。在这种情况下，请关闭工具
并停止导致工具过载的应用操作。然后开启工
具重新启动。
过热保护
工具／电池过热时，工具会自动停止。在这种
情况下，请待工具／电池冷却后再开启工具。
过放电保护
电池电量不足时，本工具自动停止运转。此
时，请取出工具中的电池并予以充电。
开关操作
警告： 在将电池组插入工具之前，请务
必检查开关扳机是否能扣动自如，松开时能
否退回至“OFF”（关闭）位置。
启动工具时，只要扣动开关扳机即可。松开
开关扳机工具即停止。
►图片3: 1. 开关扳机
注： 紧固后约一秒钟之内，即使扣动开关
工具也不会作业。
点亮前灯
►图片4: 1. 照明灯
小心： 请勿直视灯光或光源。
扣动开关扳机点亮照明灯。在扣动开关扳机
期 间 此 灯 保 持 常 亮 。松 开 开 关 扳 机 约 10秒后，
灯将熄灭。
注： 请使用干布擦拭灯头灰。注意不要刮
花灯头，否则会降低亮度。
反转开关的操作
►图片5: 1. 反转切换柄
小心： 操作前请务必确认工具的旋转方
向。
小心： 只有当工具完全停止转动后方可
使用反转开关。如果在工具停止之前改变旋
转方向，可能会损坏工具。
小心： 不使用工具时，请务必将反转切
换柄置于空档位置。

17
中文简体
本工具设有反转开关，可改变旋转方向。
自A侧按压反转切换柄可进行顺时针方向旋
转；自B侧按压则进行逆时针方向旋转。
反转切换柄处于空档位置时，开关扳机无法
扣动。
LED指示灯／蜂鸣器
►图片6: 1. LED指示灯
工具上的LED指示灯／蜂鸣器会显示以下功能。
功能 工具的状态 LED指示灯／蜂鸣器的状态 采取的措施
LED指示灯 蜂鸣器
检查LED指示
灯、灯和蜂鸣器
的工作情况
安装了电池组
时，工具会检查
LED指示灯、灯
和蜂鸣器。
首先呈绿色亮
起，接着呈红色
亮起。
（然后灯亮
起。）
一连串非常短促
的蜂鸣声
–
安装电池时检查
开关扳机的操
作情况
扣动开关扳机并
安装电池组时，
工具会停止运转
以免意外启动。
呈红色和绿色交
替闪烁。
一连串短促的
蜂鸣声
松开开关扳机。
紧固完成时自
动停机
工具达到了设定
值并已停止。
呈绿色亮起约
1秒的时间。
– –
紧固不足的警报 工具未达到设定
值，原因是在工
具达到设定值之
前松开了开关
扳机。或者，达
到了“Failure
Criteria for
Phase”的设
定值。
呈红色亮起。 一声较长的
蜂鸣声
重新拧紧螺丝。
在两个阶段之
间中断
工具处于“Shift
to the next
Phase”设置的
中断时间。
呈绿色亮起或绿
色闪烁（由设置
决定）
– –
双击检测 当操作人员再次
拧紧已拧紧的螺
丝时，工具会
进行检测并停止
运转。
呈红色亮起。 一声较长的
蜂鸣声
–
低电池电量
的警报
电池电量变低，
需更换电池组。
呈红色缓慢
闪烁。
一连串较长的
蜂鸣声
更换充满电的
电池。
剩余电池电量低
时自动停机
电池电量几乎用
尽且工具停止。
呈红色亮起。 一声较长的
蜂鸣声
更换充满电的
电池。
控制器反重置 电池电压因某些
原因异常降低且
工具停止。
呈红色和绿色交
替闪烁。
一连串短促的
蜂鸣声
更换充满电的
电池。

18
中文简体
功能 工具的状态 LED指示灯／蜂鸣器的状态 采取的措施
LED指示灯 蜂鸣器
过热保护 电机或控制器异
常发热且工具
停止。
呈红色快速
闪烁。
一连串短促的
蜂鸣声
立即拆下电池组
并冷却工具。
检测电机热
量失败
由于导线损坏或
其他原因，导致
电机检测装置未
能检测热量。
呈红色快速
闪烁。
一连串短促的
蜂鸣声
取出电池组并冷
却工具。若指示
灯仍然闪烁，请
交由当地Makita
（牧田）维修中
心进行维修。
电机故障检测 检测到电机故
障。此时工具不
工作。
呈红色和绿色交
替闪烁。
一连串短促的
蜂鸣声
请当地的
Makita（牧田）
维修服务中心进
行修复。
保养警报 根据预设的从动
螺丝数，保养时
间已到。
闪烁黄色。 –通过应用软件重
置警报。
不可用数据通信
的警报（工具与
PC连接）
即使工具与PC相
连，工具和PC之
间也不能进行数
据交换。
闪烁黄色。 –重新启动应用
软件并重新连接
USB电缆。
数据通信可用的
指示（工具与PC
连接）
工具已连接至
PC且数据通信
可用。
闪烁绿色。 – –
调节紧固转矩
当您想要以预定的转矩拧动机器螺丝、六角
螺栓等时，请如下调节紧固转矩。
1. 手动打开转换板，以使孔可见。
►图片7: 1. 转换板
2. 扣动开关扳机然后将其释放，以使调节
环旋转和孔可见。然后拆下电池组。
3. 使用选购的调节把手调节紧固转矩。将调
节把手的销插入工具前部的孔中。然后，顺
时针转动调节把手以设定更大的紧固转矩，
逆时针转动以设定更小的紧固转矩。
►图片8: 1. 调节把手 2. 调节把手的孔
4. 插入电池组，并确保使用紧固转矩测试
器设定了紧固转矩。
5. 手动关紧转换板。
调节空载速度和旋转角度等。
您可以通过电脑调节工具的空载速度和旋转
次数等。将应用软件安装至电脑并用USB电
缆将电脑连接至工具。
►图片9: 1. USB端口 2. USB盖
3. USB电缆
注意： 紧固时务必确保USB盖已闭合。
注： 使用Makita（牧田）原装USB电缆将
电脑连接至工具。请参阅“规格”章节。
注： 关于应用软件，请联系Makita（牧田）
销售代表。

19
中文简体
装配
小心： 对工具进行任何装配操作前，请
务必关闭工具电源，并取出电池组。
起子头／套筒起子头的安装或拆卸
►图片10
请仅使用具有图示插入部分的起子头／套筒
起子头。切勿使用任何其他类型的起子头／
套筒起子头。
对于配备浅起子头孔的工具
A=12 mm
B=9 mm
仅使用此类型的起
子头。应按步骤1进
行。（注）不需要
备有起子头元件。
对于配备深起子头孔的工具
A=17 mm
B=14 mm
要安装此类起子头
时 ，应 按 步 骤 1进行。
A=12 mm
B=9 mm
要安装此类起子头
时，应按步骤2进
行。（注）安装起
子头时需要备有起
子头元件。
步骤1
对于不带单触类型套筒的工具
►图片11: 1. 起子头 2. 套筒
安装起子头时，应沿箭头的方向拉动套筒并
将起子头一直插到套筒最里端。
然后松开套筒以固定起子头。
对于带单触类型套筒的工具
安装起子头时，应将其插入套筒，尽量将其
推到底。
步骤2
除步骤1之外，还应将起子头元件插入套筒，
并使其尖端朝向套筒内部。
►图片12: 1. 起子头 2. 起子头元件 3. 套筒
拆卸起子头时，应沿箭头方向拉动套筒并将
起子头拉出。
注：如果起子头未充分插入套筒中，套筒将
不能退回至原位，从而无法固定起子头。此
时，应根据上述说明重新插入起子头。
注：当起子头难以插入时，请拉套筒并将起
子头插入套筒，尽量将其推到底。
注： 插入起子头后，请务必确保其紧固。如果
脱 落 出 来 ，则 请 勿 使 用 。
安装挂钩
选购附件
挂钩用于悬挂工具。将挂钩安装至工具主体
上的孔。
►图片13: 1. 挂钩 2. 孔
操作
旋紧螺丝的操作
小心： 务必要将起子头平直地插入螺丝
头端，否则会损坏螺丝和／或起子头。
将起子头的尖端放进螺丝头部并对工具施加压
力。然后启动工具。当离合器被卡住时，电机将
自 动 停 止 。然 后 ，松 开 开 关 扳 机 。
►图片14
紧固能力限值
使用工具时请勿超过其紧固能力限值。如果
超过工具的紧固能力限值，则离合器停止工
作。工具无法提供足够的紧固转矩。
DFT024F / DFT025F型号
0.5 2.01.0 1.5
360°
300°
240°
180°
120°
60°
30°
1
3
2
N•m
1. 紧固能力范围 2. 扭转角度 3. 转矩

20
中文简体
DFT060F型号
1.5 6.5
4.0
360°
300°
240°
180°
120°
60°
30°
1
3
2
N•m
1. 紧固能力范围 2. 扭转角度 3. 转矩
注：扭转角度指从螺栓以所需转矩的50%拧
紧到以100%转矩拧紧时两点之间的角度。
注： 使用冰冷的电池组可能会使LED指示灯
和蜂鸣器发出电池电量警告并使工具立即停
止 运 转 ，即 使 该 电 池 组 已 充 满 电 。在 这 种 情 况
下，紧固能力可能会低于本手册中的规格。
保养
小心： 检查或保养工具之前，请务必关
闭工具电源并取出电池组。
注意： 切勿使用汽油、苯、稀释剂、酒精
或类似物品清洁工具。否则可能会导致工具
变色、变形或出现裂缝。
为了保证产品的安全与可靠性，维修、任何
其他的维修保养或调节需由Makita（牧田）
授权的或工厂维修服务中心完成。务必使用
Makita（牧田）的替换部件。
选购附件
小心： 这些附件或装置专用于本说明书
所列的Makita（牧田）工具。如使用其他厂
牌附件或装置，可能导致人身伤害。仅可将
附件或装置用于规定目的。
如您需要了解更多关于这些选购附件的信息，
请咨询当地的Makita（牧田）维修服务中心。
• 调节把手
• 保护装置（本色、红色、蓝色、黄色、
绿色）
•USB电缆
• 挂钩
• 锁紧螺母（红色、蓝色、黄色）
•Makita（牧田）原装电池和充电器
注： 本列表中的一些部件可能作为标准配
件包含于工具包装内。它们可能因销往国
家之不同而异。
