Parts Breakdown HR4001C
Page 1 of 4 2/8/2008

Parts Breakdown HR4001C
Fig # Part ID Part Name Quantity
1 286272-3 TOOL HOLDER CAP, HR4001C 1
1 286285-4 N/A 1
2 231984-3 RING SPRING 25, HR5001C 1
3 267272-2 FLAT WASHER 28, HM0860C 1
4 419015-0 CHUCK COVER, HR4001C 1
5 419002-9 SPACER, HR4001C 1
6 324548-1 CHUCK RING, HR4001C 1
7 231984-3 RING SPRING 25, HR5001C 1
8 419016-8 RELEASE COVER, HR4001C 1
9 419017-6 LOCK SLEEVE GUIDE, HR4001C 1
9 419760-7 LOCK SLEEVE GUIDE, HR4001C 1
10 267298-4 FLAT WASHER 45, HR4001C 1
10 267336-2 FLAT WASHER 45, HR4001C 1
11 262116-1 URETHAN RING 45, HR4001C 1
12 421911-0 SEAL SHEET, HR4001C 1
13 154621-1 BARREL CPL., HR4001C 1
14 922353-6 H. S. H. BOLT M6X30,HR5001C 4
15 154624-5 BARREL COVER CPL.,HR4001C 1
16 345579-7 SPRING GUIDE, HR4001C 1
17 233431-0 COMP. SPRING 48, HR4001C 1
18 345579-7 SPRING GUIDE, HR4001C 1
19 310161-1 TOOL RETAINER, HR4001C 1
20 310161-1 TOOL RETAINER, HR4001C 1
21 165407-8 N/A 1
21 165446-8 LOCK SLEEVE, HR4010C 1
22 324542-3 TOOL HOLDER, HR4001C 1
23 266437-3 N/A 1
23 922128-3 H.S. HEAD BOLT M4X16,4324 1
24 213317-4 O RING 20, HR4000C 1
25 213392-0 FLUORIDE RING 25, HR4000C 1
26 213281-9 X-RING 18, HR4001C 1
27 324569-3 IMPACT BOLT, HR4001C 1
28 421901-3 RUBBER RING 17, HR4001C 1
29 324573-2 RING 17, HR4001C 1
30 419003-7 SLIDE SLEEVE, HR4001C 1
31 324571-6 STRIKER, HR4001C 1
32 213962-5 O RING 22, HR4001C 1
33 331709-6 RING 33, HR4001C 1
34 233448-3 COMP. SPRING 37, HR4001C 1
35 227486-5 S. BEVEL GEAR 25,HR4001C 1
35 227509-9 STRAIGHT BEVEL GEAR, HR4001C 1
36 419005-3 CONNECTING ROD, HR4001C 1
37 213379-2 O RING 21, AG125 1
38 213962-5 O RING 22, HR4001C 1
39 419004-5 PISTON, HR4001C 1
40 256197-5 PIN 7, JR3020 1
41 233937-8 RING SPRING 31, HR4001C 1
42 257268-1 RING 33, HR4001C 1
43 213406-5 O RING 30, HR5000 1
44 213406-5 O RING 30, HR5000 1
45 233935-2 RING SPRING 32, HR4001C 1
46 324570-8 CYLINDER 28.5, HR4001C 1
62 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 4
63 233432-8 COMP. SPRING 7, HR4001C 2
65 911133-5 P.H. SCREW M4X18, N9501B 6
66 266192-7 TAPPING SCREW 4X14, 2012NB 2
67 419009-5 LOCK BUTTON, HR4001C 1
68 233436-0 COMP. SPRING 3, HR4001C 2
69 266192-7 TAPPING SCREW 4X14, 2012NB 1
70 419020-7 CHANGE LEVER, HR4001C 1
Page 2 of 4 2/8/2008

Parts Breakdown HR4001C
71 419007-9 CRANK LEVER, HR4001C 1
72 317925-4 CRANK CAP COVER, HR4001C 1
73 419030-4 CRANK CAP, HR4001C 1
74 421908-9 SEAL RING, HR4001C 1
75 419019-2 LINK PLATE GUIDE, HR4001C 1
76 345582-8 LINK PLATE, HR4001C 1
80 154625-3 CRANK HOUSING CPL.,HR4001C 1
81 423345-3 CUSHION PLATE, HR4001C 1
82 419008-7 FIX GUIDE, HR4001C 2
83 213262-3 O RING 18, 5005BA 1
84 419006-1 LINK LEVER, HR4001C 1
85 911511-9 P.H. SCREW M4X10, HR4001C 1
86 324550-4 CRANK SHAFT, HR4001C 1
87 211332-2 BALL BEARING 6004LLU, HR3000C 1
88 961060-6 RETAINING RING S-20, 2708 1
89 226605-0 HELICAL GEAR 38, HR4001C 1
90 253180-3 F. WASHER 10, 6222DWE 1
91 421907-1 SEAL RING, HR4001C 1
92 154623-7 GEAR HOUSING CPL., HR4001C 1
93 233433-6 COMP. SPRING 5, HR4001C 2
95 419018-4 CHANGE PLATE, HR4001C 1
96 210005-4 BALL BEARING 608DDW, 9031 1
97 345581-0 CUP WASHER 8, HR4001C 1
98 233936-0 CONICAL COMP. SPR. 19-27,HR4001C 1
99 324549-9 DRIVING FLANGE, HR4001C 1
103 211323-3 BALL BEARING 6904LLU, HR2420 1
104 135086-6 TORQUE LIMITER ASS'Y, HR4001C 1
105 265995-6 TAPPING SCREW 4X18, 4323K 1
106 419036-2 HANDLE COVER, HR4001C 1
108 650567-4 SWITCH, HR4001C 1
109 154626-1 SWITCH HOLDER CPL.,HR4001 1
112 419028-1 SWITCH LEVER, HR4001C 1
113 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 4
116 861489-5 NAME PLATE, HR4001C 1
117 419039-6 HANDLE, HR4001C 1
122 638407-6 LEAD UNIT, HR4001C 1
123 419010-0 LENS, HR4001C 1
124 266192-7 TAPPING SCREW 4X14, 2012NB 1
125 631656-4 CONTROLLER, HR4001C 1
126 419024-9 CORD LAMP BASE, HR4001C 1
127 687169-3 STRAIN RELIEF, HP1621F 1
128 266192-7 TAPPING SCREW 4X14, 2012NB 1
129 266192-7 TAPPING SCREW 4X14, 2012NB 1
130 265995-6 TAPPING SCREW 4X18, 4323K 4
131 682560-0 CORD GUARD 10, HM1202C 1
132 664276-9 CORD (2X16X16 SJ), HR5000 1
133 265995-6 TAPPING SCREW 4X18, 4323K 2
134 419032-0 REAR COVER, HR4001C 1
135 931303-0 HEX NUT M6, 2012 1
136 253047-5 F. WASHER 6, 2708 1
137 241876-8 FAN 76, HM1100C 1
138 419022-3 FAN GUIDE, HR4001C 1
139 194160-9 CARBON BRUSH CB-350,HR4001C 1
140 638393-1 BRUSH HOLDER UNIT, HR4001C 1
141 154619-8 MOTOR HOUSING CPL., HR4001C 1
142 324390-0 SHOULDER SLEEVE 6, HR4001C 1
143 210005-4 BALL BEARING 608DDW, 9031 1
144 681650-6 INSULATION WASHER, HR4000C 1
145 625736-6 FIELD 115V, HR4001C 1
146 266095-5 TAPPING SCREW 5X55, 5044KB 2
147 513631-1 ARMATURE ASS'Y 115V, HR4001C 1
Page 3 of 4 2/8/2008

Parts Breakdown HR4001C
148 419021-5 BAFFLE PLATE, HR4001C 1
149 253084-9 F. WASHER 12, 5014NB 1
150 211137-0 BALL BEARING 6201LLU,4140 1
151 213231-4 OIL SEAL 15, HR4500C 1
152 331596-3 SLEEVE 12, HR4500C 1
153 419034-6 CRANK HSG. COVER, HR4001C 1
154 266192-7 TAPPING SCREW 4X14, 2012NB 1
155 419026-5 SWITCH BOX, HR4001C 1
156 263027-3 RUBBER PIN 4, HM0860C 1
157 651418-4 SWITCH, JN1601 1
158 232209-8 LEAF SPRING, HM0860C 1
159 154635-0 SLIDE LEVER CPL.,HR4001C 1
160 419027-3 CONTROL PLATE, HR4001C 1
161 421939-8 SPONGE SHEET, HR4001C 1
1,001 134890-0 SIDE HANDLE 68 ASS'Y,HR4000C 1
1,002 134803-1 GRIP 36 ASS'Y, HR4040C 1
1,003 154678-2 PLASTIC T. CASE, HR4001C 1
1,004 181573-3 BIT GREASE, HR2400 1
1,005 443122-7 CLOTH F/WIPING OIL, HR4001C 1
5,001 810134-9 N/A 1
