Parts Breakdown PW5001C
Page 1 of 3 2/8/2008

Parts Breakdown PW5001C
Fig # Part ID Part Name Quantity
1 417236-8 PIN CAP, 3706 1
1 418067-8 PIN CAP, PW5001C 1
2 233072-2 COMPRESSION SPRING 8, 9523NB 1
3 153488-4 GEAR HOUSING CPLT., PW5001C 1
3 153718-3 GEAR HOUSING CPL.,PW5001C 1
4 961052-5 RETAINING RING S-12, 9218PBL 1
5 210105-0 BALL BEARING 6001LLU, PW5001C 1
5 211131-2 BALL BEARING 6001DDW,9218PBL 1
6 253084-9 F. WASHER 12, 5014NB 1
7 652014-1 P.H. SCREW M4X8, 2708 1
8 317736-7 GEAR HOUSING COVER, PW5001C 1
9 240033-5 FAN 57, BO6040 1
10 515266-4 ARMATURE ASS'Y 115V, PW5001C 1
11 681656-4 INSULATION WASHER, GD0800C 1
12 253823-7 F. WASHER 7, LS1011 1
13 210027-4 BALL BEARING 627DDW, BO6040 1
14 421738-8 LABYRINTH RUBBER RING 22, BO6040 1
15 267756-0 WAVE WASHER 6, 9561CV 1
16 688117-5 MAGNET SLEEVE, GD0800C 1
17 259039-2 SELF LOCK 6, 3707FC 1
18 418452-5 BAFFLE PLATE, PW5001C 1
19 266258-3 TAPPING SCREW 4X70, 9563CV 2
20 344871-8 RETAINER, GD0800C 2
21 417237-6 INSULATION COVER, GD0800C 2
22 626546-4 FIELD 115V, PW5001C 1
23 265995-6 TAPPING SCREW 4X18, 4323K 2
24 687063-9 STRAIN RELIEF, 4323K 1
25 632999-7 SWITCH BLOCK, GD0800C 1
26 654532-5 TERMINAL BLOCK, 9523NB 1
27 651418-4 SWITCH, JN1601 1
28 687113-0 COVER, GD0800C 1
29 682559-5 CORD GUARD 8, 6824 1
30 699025-5 POWER SUPPLY CORD UNIT, PW5001C 1
31 816399-1 INDICATION LABEL, PW5001C 1
32 418453-3 REAR COVER, PW5001C 1
32 158195-4 REAR COVER, PW5001C 1
33 265995-6 TAPPING SCREW 4X18, 4323K 1
34 860103-0 NAME PLATE, PW5001C 1
35 266256-7 TAPPING SCREW PT3X10, GD0800C 4
36 643765-7 BRUSH HOLDER, PW5001C 1
37 191978-9 CARBON BRUSH SET CB-318,GD0800C 1
38 417813-6 SWITCH KNOB, BO6040 1
40 418512-3 MOTOR HOUSING, PW5001C 1
40 153757-3 MOTOR HOUSING CPL.,PW5001C 1
41 643765-7 BRUSH HOLDER, PW5001C 1
42 233071-4 COMPRESSION SPRING 4, JN1601 1
43 417186-7 SWITCH LEVER, 9563CV 1
44 631594-0 CONTROLLER, PW5001C 1
45 265995-6 TAPPING SCREW 4X18, 4323K 1
46 345372-9 PLATE, PW5001C 1
47 245031-4 HOSE, PW5001C 1
48 154649-9 COCK CPLT., PW5001C 1
48 153716-7 COCK CPL.,PW5001C 1
49 331669-2 HOSE JOINT, PW5001C 1
50 213107-5 O RING 12, JR3000V 1
51 743079-5 RUBBER PAD 100, PW5001C 1
51 743079-5 RUBBER PAD 100, PW5001C 1
52 324407-9 NOZZLE, PW5001C 1
53 324408-7 SPINDLE, PW5001C 1
54 254202-2 KEY 4, 9924DB 1
Page 2 of 3 2/8/2008

Parts Breakdown PW5001C
55 265490-6 HEX BOLT M4 X 16, 9560CV 4
56 153717-5 HOUSING W/O BEARING, PW5001C 1
57 211129-9 BALL BEARING 6201DDW, N9501B 1
58 285841-7 BEARING RETAINER 19-33, 9566CV 1
59 213673-2 O RING 52, 9561CV 1
60 227455-6 SPIRAL BEVEL GEAR 38, PW5001C 1
61 961052-5 RETAINING RING S-12, 9218PBL 1
62 256459-1 PIN, 9561CV 1
63 213048-5 O RING 6, 9561CV 1
64 266257-5 TAPPING SCREW M4X28, 9561CV 4
65 162235-2 COVER, PW5001C 1
66 267126-3 FLAT WASHER 22, 6913D 1
67 261128-1 RUBBER WASHER 12, PW5001C 1
68 261127-3 TEFLON WASHER 10, PW5001C 1
1,001 152490-4 GRIP 36, 9227C 1
1,002 265083-9 F.H. SCREW M8X11, BO6040 2
1,003 417322-5 HEAD COVER, 9564CVL 1
1,004 781008-0 WRENCH 17, 9217SPC 1
1,005 418507-6 FRONT GRIP, PW5001C 1
1,006 783204-6 HEX WRENCH, 3705, HR5000 1
1,007 941201-0 F. WASHER 8, 5037NB 2
1,008 922422-3 H.S.H. BOLT M8X16, 3901 2
5,001 154662-7 DUST COVER CPL., PW5001C 1
5,002 345587-8 BAND A, PW5001C 1
5,003 345588-6 BAND B, PW5001C 1
5,004 251391-4 P.H.SCREW M5X16,9523NB 2
5,005 810229-8 N/A 1
Page 3 of 3 2/8/2008
