Parts Breakdown 5008MGA
Page 1 of 3 2/8/2008

Parts Breakdown 5008MGA
Fig # Part ID Part Name Quantity
1 266283-4 H.S.H.BOLT M8X20, 5007MG 1
2 224409-4 OUTER FLANGE 35, 5008MGA 1
3 224411-7 INNER FLANGE 35, 5008MGA 1
4 257279-6 RING 16, 5007MG 1
5 961201-4 RETAINING RING S-42, 5037NB 1
6 266398-7 T.SACREW BINF CT 4X12, 5007MG 1
7 272252-5 LEVER 65, 5007MG 1
8 318175-4 SAFETY COVER, 5008MGA 1
9 231848-1 TENSION SPRING 4, 5008MGA 1
10 345422-0 SPACER, 4131 1
11 285848-3 BEARING RETAINER 23-36, 5007MG 1
12 211275-8 BALL BEARING 6003DDW, LS1013 1
13 911223-4 P.H. SCREW M5X16, 4301BV 2
14 318056-2 HOUSING W/O BEARING,5007MG 1
15 324690-8 SPINDLE, 5007MG 1
16 226662-8 HELICAL GEAR 43, 5008MGA 1
17 211031-6 BALL BEARING 608LLB, HR2400 1
18 213623-7 O RING 46, 5007MG 1
19 596291-4 FIELD ASSY 115V, 5007MGA 1
20 266397-9 T.SCREW BIND 5X50, 5007MG 2
21 419548-5 BAFFLE PLATE, 5007MG 1
22 211031-6 BALL BEARING 608LLB, HR2400 1
23 681625-5 INS. WASHER, HR2400 1
24 517761-0 ARMATURE ASS'Y 115V, 5008MGA 1
25 240003-4 FAN 80, 2012NB 1
26 231297-2 COMP. SPRING 9, LS1011 1
27 345717-1 SHAFT LOCK, 5007MG 1
28 286275-7 CAP, 5007MG 1
29 267280-3 FLAT WASHER 15, LS1011N 1
30 211236-8 BALL BEARING 6002DDW,BO5001 1
31 261132-0 URETHANE WASHER 26, 5007MG 1
32 188447-9 BLADE CASE SET, 5008MGA 1
33 819234-2 MAKITA LOGO PLATE, 5007MG 1
34 251247-1 P.H. SCREW M6X20, 5037NB 1
35 262552-1 RUBBER SLEEVE 6, 5007MG 1
36 419553-2 HANDLE COVER, 5007MG 1
37 551187-6 N/A 1
38 682564-2 CORD GUARD, 5007NLK 1
39 266326-2 TAPPING SCREW PT 4X18, MT240 2
40 687124-5 STRAIN RELIEF, MT240 1
41 654531-7 TERMINAL BLOCK 2P, N900 1
42 631709-9 LIGHT CIRCUIT, 5007MG 1
44 651190-8 SWITCH, 5007MGA 1
45 158099-0 MOTOR HOUSING CPL.,5007MG 1
46 266326-2 TAPPING SCREW PT 4X18, MT240 5
47 331719-3 PIPE 9, 5007MG 1
48 941201-0 F. WASHER 8, 5037NB 1
49 272253-3 LEVER 56, 5007MG 1
50 252199-9 HEX. NUT M8-13, 5007MG 1
51 257953-6 BOW STOP RING E-12, 5007MG 1
52 188448-7 REAR COVER SET, 5007MG 1
53 266326-2 TAPPING SCREW PT 4X18, MT240 2
54 819237-6 MAKITA LOGO LABEL, 5007MG 1
55 911268-2 P.H. SCREW M5X45, HP2010N 3
56 864006-0 NAME PLATE, 5008MGA 1
57 419550-8 FRONT GRIP, 5007MG 1
58 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
59 181047-4 CARBON BRUSH SET 154,5402A 1
60 257953-6 BOW STOP RING E-12, 5007MG 1
61 272253-3 LEVER 56, 5007MG 1
Page 2 of 3 2/8/2008

Parts Breakdown 5008MGA
62 252199-9 HEX. NUT M8-13, 5007MG 1
63 941201-0 F. WASHER 8, 5037NB 1
64 345835-5 ANGLER GUIDE, 5008MGA 1
65 256480-0 SHOULDER PIN 6-7, MT581 1
66 257759-2 SLEEVE 6, 5007MG 1
67 941101-4 F. WASHER 5, JR3000V 1
68 922261-1 H.S.H. BOLT M5X40, LS1011 1
69 266396-1 F.S.N.BOLT M8X24, 5007MG 1
70 331719-3 PIPE 9, 5007MG 1
71 345833-9 DEPTH GUIDE, 5008MGA 1
72 256480-0 SHOULDER PIN 6-7, MT581 1
73 266237-1 C.S.N. BOLT M8X90,5007MG 1
74 266229-0 HEX.SCREW M5X8, 4200N 1
75 158424-5 BASE CPL., 5008MGA 1
76 266229-0 HEX.SCREW M5X8, 4200N 1
77 251370-2 PAN HEAD SCREW, LS1030 1
78 419549-3 DIAL 27, 5007MG 1
79 216008-6 STEEL BALL 4.0, 6820V 1
80 233314-4 COMPRESSION SPRING 4, 6827 1
81 266229-0 HEX.SCREW M5X8, 4200N 1
82 251858-2 SCREW M6X15, 5037NB 1
83 253811-4 F. WASHER 5, 5012B, 6891D 1
85 450351-5 SPACER, 5007MG 2
1,001 164095-8 GUIDE RULE, 4200H 1
1,002 783204-6 HEX WRENCH, 3705, HR5000 1
1,003 D-21521 8-1/4 SAW BLADE, 5008FA 1
