Parts Breakdown 5057KB
Page 1 of 3 2/8/2008

Parts Breakdown 5057KB
Fig # Part ID Part Name Quantity
1 851831-8 NAME PLATE, 5057KB 1
2 911148-2 P.H. SCREW M4X25, 5057KB 4
3 911273-9 P.H. SCREW M5X50, HR2400 3
4 181047-4 CARBON BRUSH SET 154,5402A 1
5 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
6 153920-8 MOTOR HOUSING CPL., 5057KB 1
6 151554-1 MOTOR HOUSING, 5007S 1
7 651161-5 SWITCH, 5057KB-T1 1
7 651168-1 SWITCH, 5057KB 1
7 651172-0 SWITCH, 5007FK 1
8 266020-6 TAPPING SCREW,PT4X12,9046 1
9 682505-8 CORD GUARD, 2711 1
10 664276-9 CORD (2X16X16 SJ), HR5000 1
11 687001-1 STRAIN RELIEF, 6013BR 1
11 687063-9 STRAIN RELIEF, 4323K 1
12 265995-6 TAPPING SCREW 4X18, 4323K 2
13 410201-6 HANDLE COVER, 5057KB 1
14 210005-4 BALL BEARING 608DDW, 9031 1
15 681625-5 INS. WASHER, HR2400 1
16 596066-1 FIELD ASS'Y 115V, 5057KB 1
17 266046-8 T. SCREW FLANGE PT5X50,HR2010 2
18 516606-9 ARMATURE ASS'Y 115V, 5057KB 1
19 415603-1 FAN GUIDE, 5007NBA 1
20 163113-9 SHAFT LOCK, 5057KB 1
21 213102-5 DUST SEAL 12, 5057KB 1
22 211129-9 BALL BEARING 6201DDW, N9501B 1
23 421676-4 RUBBER CAP, 5057KB 1
24 231823-7 TENSION SPRING 4, 5057KB 1
25 344759-2 OPEN LEVER, 5057KB 1
26 931402-8 HEX NUT M8, 5037NB 1
27 911106-8 P.H. SCREW M4X8, NHP1310 1
28 341415-5 LOCK PLATE, 5057KB 1
29 341416-3 LEVER PLATE, 5057KB 1
30 267003-9 F. WASHER 8, 5057KB 1
30 253766-3 FLAT WASHER 8, 5057KB 1
31 941201-0 F. WASHER 8, 5037NB 1
32 251267-5 P.H. SCREW M6, LS1013 1
33 151873-5 GEAR HOUSING CPL.,5057KB 1
33 152926-3 GEAR HOUSING COMPLETE 1
33 153302-4 GEAR HOUSING COMPLETE,5057KB 1
33 317167-0 GEAR HOUSING, 5057KB-T1 1
34 262523-8 RUBBER SLEEVE 6, 5044KB 1
35 212052-1 N. BEARING 1010, HK1810 1
36 961055-9 RETAINING RING S-15, 5057KB 1
36 961055-9 RETAINING RING S-15, 5057KB 1
37 226532-1 HELICAL GEAR 39, 5007NLK 1
37 221647-9 HELICAL GEAR, M513 1
38 257064-7 RING 15, 5037NB 1
39 962153-2 RETAINING RING R-35,HP2030 1
40 211228-7 BALL BEARING 6202DDW, HM1303B 1
41 323897-3 SPINDLE, 5057KB-T1 1
41 324133-0 SPINDLE, 5057KB 1
41 324257-2 SPINDLE, 5057KB 1
42 254032-1 WOODRUFF KEY 5, 5037NB 1
43 317187-4 HOUSING W/O BEARING, 5057KB 1
44 911126-2 P.H. SCREW M4X16, 5057KB 4
45 213319-0 OIL SEAL 20, 5057KB 1
46 344758-4 LABYRINTH RING, 5057KB 1
47 344808-5 THICKNESS RING, 5057KB 1
48 231806-7 TENSION SPRING 4, 5037NB 1
Page 2 of 3 2/8/2008

Parts Breakdown 5057KB
49 317159-9 SAFETY COVER, 5057KB 1
50 344760-7 SUB PLATE, 5057KB 1
51 911111-5 P.H. SCREW M4X10, LS1011 2
52 961201-4 RETAINING RING S-42, 5037NB 1
53 224151-7 INNER FLANGE, 5007FK 1
54 224275-9 OUTER FLANGE, 5620DWA 1
55 251644-1 H.F.H. BOLT M8X20, 5037NB 1
56 911106-8 P.H. SCREW M4X8, NHP1310 1
57 931402-8 HEX NUT M8, 5037NB 1
58 341415-5 LOCK PLATE, 5057KB 1
59 341416-3 LEVER PLATE, 5057KB 1
60 267003-9 F. WASHER 8, 5057KB 1
60 253766-3 FLAT WASHER 8, 5057KB 1
61 251858-2 SCREW M6X15, 5037NB 1
62 317160-4 ANGULAR PLATE, 5057KB 1
63 252103-8 HEX. LOCK NUT M5-8, 5007FK 1
64 911108-4 P.H. SCREW M4X8, LS1013 1
65 344762-3 INDICATION PLATE, 5057KB 1
66 265075-8 PAN HEAD SCREW M5, 5057KB 1
67 344763-1 ANGULAR GUIDE, 5057KB 1
67 345491-1 ANGULAR GUIDE, 5057KB 1
68 266227-4 C.S.N. BOLT M8X28, 5057KB 1
69 256442-8 SHOULDER PIN 6-7, 5007NHK 1
70 265965-5 C.S.N. BOLT M8X24, 5277NB 1
71 163409-8 DEPTH GUIDE, 5057KB 1
72 317186-6 BASE, 5057KB 1
73 266180-4 SCREW M5X12,5037NB-T2 1
73 266213-5 H.S.H. SCREW M5X12,2012NB 1
74 912212-2 C.S.H. SCREW M5X12, 9045B 5
75 266213-5 H.S.H. SCREW M5X12,2012NB 1
75 266180-4 SCREW M5X12,5037NB-T2 1
76 265085-5 CSH SCREW M4X8, 5057KB 2
76 912107-9 C.S.H. SCREW M4X8, 5037NB 2
77 265995-6 TAPPING SCREW 4X18, 4323K 3
78 151565-6 DUST BOX L COMPLETE, 5057KB 1
78 151565-6 DUST BOX L COMPLETE, 5057KB 1
79 344761-5 EARTH PLATE, 5057KB 1
80 151978-1 DUST CAP COMPLETE,5057KB 1
81 421362-7 CAP, 5044KB 1
82 183105-2 DUST BOX R SET, 5057KB 1
82 183105-2 DUST BOX R SET, 5057KB 1
83 911263-2 P.H. SCREW M5X40, 2711 2
84 819003-1 MAKITA LABEL, 5057KB 1
85 213621-1 O RING 46, 5007NLK 1
1,001 164095-8 GUIDE RULE, 4200H 1
1,002 782016-4 OFFSET WRENCH 13, 5177B 1
1,003 A-90451 7-1/4 CT BLADE,5057KB FIBER BOARD 1
5,001 810177-1 N/A 1
Page 3 of 3 2/8/2008
