Makita DUH481 User manual

DUH481
DUH483
DUH521
DUH523
EN Cordless Hedge Trimmer INSTRUCTION MANUAL 6
UK Акумуляторна пила для
підрізання живоплоту ІНСТРУКЦІЯ З ЕКСПЛУАТАЦІЇ 13
PL Akumulatorowe nożyce do
żywopłotu INSTRUKCJA OBSŁUGI 21
RO Maşină de tuns gardul viu
fără cablu MANUAL DE INSTRUCŢIUNI 28
DE Akku-Heckenschere BEDIENUNGSANLEITUNG 35
HU Vezeték nélküli sövényvágó HASZNÁLATI KÉZIKÖNYV 43
SK Akumulátorové nožnice na
živé ploty NÁVOD NA OBSLUHU 50
CS Akumulátorové nůžky na živé
ploty NÁVOD K OBSLUZE 57

1
2
3
1
1
2
12
3
1
(1)
(2)
1
2
3
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
2

1
1
2
3
4
1
1
2
2
33
1
2
1
2
Fig.9
Fig.10
Fig.11
Fig.12
Fig.13
Fig.14
Fig.15
Fig.16
3

1
1
2
3
1
2
3
4
1
1
1
1
2
3
1
1
2
Fig.17
Fig.18
Fig.19
Fig.20
Fig.21
Fig.22
Fig.23
Fig.24
4

1
Fig.26
Fig.25
5

6ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model DUH481 DUH483 DUH521 DUH523
Blade length 480 mm 520 mm
Strokes per minute (min-1)1,350
Rated voltage D.C. 14.4 V D.C. 18 V D.C. 14.4 V D.C. 18 V
Overall length
(Depending on the battery)
869 - 881 mm 873 - 888 mm 919 - 931 mm 923 - 938 mm
Net weight 3.0 - 3.2 kg 3.0 - 3.3 kg 3.0 - 3.2 kg 3.0 - 3.4 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
withoutnotice.
• Specicationsmaydifferfromcountrytocountry.
• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
Applicable battery cartridge and charger
Batterycartridge D.C.14.4 V Model BL1415N/BL1430/BL1430B/BL1440/BL1450/BL1460B
D.C.18 V Model BL1815N/BL1820/BL1820B/BL1830/BL1830B/BL1840/
BL1840B/BL1850/BL1850B/BL1860B
Charger DC18RC/DC18RD/DC18RE/DC18SD/DC18SE/DC18SF/
DC18SH
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionofresidence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
Symbols
Thefollowingsshowthesymbolsusedfortheequip-
ment.Besurethatyouunderstandtheirmeaningbefore
use.
Readinstructionmanual.
Do not expose to moisture.
Ni-MH
Li-ion
OnlyforEUcountries
Donotdisposeofelectricequipmentor
batterypacktogetherwithhouseholdwaste
material!
InobservanceoftheEuropeanDirectives,
onWasteElectricandElectronic
EquipmentandBatteriesandAccumulators
andWasteBatteriesandAccumulators
andtheirimplementationinaccordance
withnationallaws,electricequipmentand
batteriesandbatterypack(s)thathave
reachedtheendoftheirlifemustbecol-
lectedseparatelyandreturnedtoanenvi-
ronmentallycompatiblerecyclingfacility.
Intended use
Thetoolisintendedfortrimminghedges.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ingtoEN60745-2-15:
Model DUH481,DUH483,DUH521
Sound pressure level (LpA):75dB(A)
Uncertainty(K):2.5dB(A)
Model DUH523
Sound pressure level (LpA):77dB(A)
Uncertainty(K):2.5dB(A)
Thenoiselevelunderworkingmayexceed80dB(A).
NOTE:
Thedeclarednoiseemissionvalue(s)hasbeen
measuredinaccordancewithastandardtestmethod
andmaybeusedforcomparingonetoolwithanother.
NOTE: Thedeclarednoiseemissionvalue(s)may
alsobeusedinapreliminaryassessmentofexposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can differ from the declared val-
ue(s) depending on the ways in which the tool is used
especially what kind of workpiece is processed.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (tak-
ing account of all parts of the operating cycle such
as the times when the tool is switched off and when
it is running idle in addition to the trigger time).

7ENGLISH
Vibration
Thevibrationtotalvalue(tri-axialvectorsum)deter-
minedaccordingtoEN60745-2-15:
Vibration emission (ah):2.5m/s2or less
Uncertainty(K):1.5m/s2
NOTE:Thedeclaredvibrationtotalvalue(s)hasbeen
measuredinaccordancewithastandardtestmethod
andmaybeusedforcomparingonetoolwithanother.
NOTE:Thedeclaredvibrationtotalvalue(s)mayalso
beusedinapreliminaryassessmentofexposure.
WARNING: The vibration emission during
actual use of the power tool can differ from the
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
tothisinstructionmanual.
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions.Failuretofollowthewarningsandinstruc-
tionsmayresultinelectricshock,reand/orserious
injury.
Save all warnings and instructions for
future reference.
Cordless Hedge Trimmer Safety
Warnings
1. Keep all parts of the body away from the cut-
ter blade. Do not remove cut material or hold
material to be cut when blades are moving.
Make sure the switch is off when clearing
jammed material.Amomentofinattentionwhile
operating the hedge trimmer may result in serious
personalinjury.
2. Carry the hedge trimmer by the handle with
the cutter blade stopped. When transporting or
storing the hedge trimmer always t the cut-
ting device cover.Properhandlingofthehedge
trimmerwillreducepossiblepersonalinjuryfrom
thecutterblades.
3. Hold the power tool by insulated gripping
surfaces only, because the cutter blade may
contact hidden wiring.Cutterbladescontacting
a"live"wiremaymakeexposedmetalpartsofthe
powertool"live"andcouldgivetheoperatoran
electricshock.
4. DANGER - Keep hands away from blade.
Contactwithbladewillresultinseriouspersonal
injury.
5. Do not use the hedge trimmer in the rain or in
wet or very damp conditions.Theelectricmotor
isnotwaterproof.
6. First-time users should have an experienced
hedge trimmer user show them how to use the
trimmer.
7. The hedge trimmer must not be used by
children or young persons under 18 years of
age.Youngpersonsover16yearsofagemaybe
exemptedfromthisrestrictioniftheyareundergo-
ingtrainingunderthesupervisionofanexpert.
8. Use the hedge trimmer only if you are in good
physical condition.Ifyouaretired,yourattention
willbereduced.Beespeciallycarefulattheendof
aworkingday.Performallworkcalmlyandcare-
fully.Theuserisresponsibleforalldamagesto
third parties.
9. Never use the trimmer when under the inu-
ence of alcohol, drugs or medication.
10. Work gloves of stout leather are part of the
basic equipment of the hedge trimmer and
must always be worn when working with it.
Also wear sturdy shoes with anti-skid soles.
11. Before starting work check to make sure
that the trimmer is in good and safe working
order. Ensure guards are tted properly. The
hedge trimmer must not be used unless fully
assembled.
12. Make sure you have a secure footing before
starting operation.
13. Hold the tool rmly when using the tool.
14. Do not operate the tool at no-load
unnecessarily.
15. Immediately switch off the motor and remove
the battery cartridge if the cutter should come
into contact with a fence or other hard object.
Check the cutter for damage, and if damaged
repair immediately.
16. Before checking the cutter, taking care of
faults, or removing material caught in the cut-
ter, always switch off the trimmer and remove
the battery cartridge.
17. Switch off the trimmer and remove the battery
cartridge before doing any maintenance work.
18. When moving the hedge trimmer to another
location, including during work, always
remove the battery cartridge and put the blade
cover on the cutter blades. Never carry or
transport the trimmer with the cutter running.
Never grasp the cutter with your hands.
19. Clean the hedge trimmer and especially the
cutter after use, and before putting the trimmer
into storage for extended periods. Lightly oil
the cutter and put on the cover.Thecoversup-
pliedwiththeunitcanbehungonthewall,pro-
vidingasafeandpracticalwaytostorethehedge
trimmer.
20. Store the hedge trimmer with the cover on, in
a dry room. Keep it out of reach of children.
Never store the trimmer outdoors.

8ENGLISH
21. Never point the shear blades to yourself or
others.
22. If the blades stop moving due to the stuck of
foreign objects between the blades during
operation, switch off the tool and remove the
battery cartridge, and then remove the foreign
objects using tools such as pliers. Removing
theforeignobjectsbyhandmaycauseaninjury
forthereasonthatthebladesmaymoveinreac-
tiontoremovingtheforeignobjects.
23. Avoid dangerous environment. Don't use the
tool in damp or wet locations or expose it to
rain. Water entering the tool will increase the
risk of electric shock.
24. Do not dispose of the battery(ies) in a re. The
cell may explode. Check with local codes for
possible special disposal instructions.
25. Do not open or mutilate the battery(ies).
Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be
toxic if swallowed.
26. Do not charge battery in rain, or in wet
locations.
27. Check the hedges and bushes for foreign
objects, such as wire fences or hidden wiring
before operating the tool.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwardingagents,specialrequirementonpack-
aging and labeling must be observed.
Forpreparationoftheitembeingshipped,consult-
inganexpertforhazardousmaterialisrequired.
Pleasealsoobservepossiblymoredetailed
national regulations.
Tapeormaskoffopencontactsandpackupthe
batteryinsuchamannerthatitcannotmove
aroundinthepackaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Useofnon-genuineMakitabatteries,orbatteriesthat
have been altered, may result in the battery bursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).

9ENGLISH
FUNCTIONAL DESCRIPTION
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
thebatterycartridgeisremovedbeforeadjust-
ingorcheckingfunctiononthetool.
Installing or removing battery
cartridge
►Fig.1: 1.Redindicator2. Button 3.Batterycartridge
CAUTION:
• Alwaysswitchoffthetoolbeforeinstallingor
removingofthebatterycartridge.
• Hold the tool and the battery cartridge rmly
when installing or removing battery car-
tridge.Failuretoholdthetoolandthebattery
cartridgermlymaycausethemtoslipoffyour
hands and result in damage to the tool and
batterycartridgeandapersonalinjury.
Toremovethebatterycartridge,slideitfromthetool
whileslidingthebuttononthefrontofthecartridge.
Toinstallthebatterycartridge,alignthetongueonthe
batterycartridgewiththegrooveinthehousingandslip
itintoplace.Insertitallthewayuntilitlocksinplace
withalittleclick.Ifyoucanseetheredindicatoronthe
uppersideofthebutton,itisnotlockedcompletely.
CAUTION:
• Alwaysinstallthebatterycartridgefullyuntilthe
redindicatorcannotbeseen.Ifnot,itmayacci-
dentallyfalloutofthetool,causinginjurytoyou
or someone around you.
• Donotinstallthebatterycartridgeforcibly.Ifthe
cartridgedoesnotslideineasily,itisnotbeing
insertedcorrectly.
Battery protection system (Lithium-
ion battery with star marking)
►Fig.2: 1. Star marking
Lithium-ionbatterieswithastarmarkingareequipped
withaprotectionsystem.Thissystemautomatically
cutsoffpowertothetooltoextendbatterylife.
Thetoolwillautomaticallystopduringoperationifthe
tooland/orbatteryareplacedunderoneofthefollowing
conditions:
• Overloaded:
Thetoolisoperatedinamannerthatcauses
ittodrawanabnormallyhighcurrent.
Inthissituation,releasetheswitchtriggeron
thetoolandstoptheapplicationthatcaused
thetooltobecomeoverloaded.Thenpullthe
switchtriggeragaintorestart.
Ifthetooldoesnotstart,thebatteryisover-
heated.Inthissituation,letthebatterycool
beforepullingtheswitchtriggeragain.
• Lowbatteryvoltage:
Theremainingbatterycapacityistoolow
and the tool will not operate. In this situation,
removeandrechargethebattery.
Indicating the remaining battery
capacity
(Onlyforbatterycartridgeswith"B"attheendofthe
model number.)
►Fig.3: 1.Indicatorlamps2.CHECKbutton
Pressthecheckbuttononthebatterycartridgetoindi-
catetheremainingbatterycapacity.Theindicatorlamps
lightupforfewseconds.
Off BlinkingLighted
Indicator lamps
Charge the
battery.
0% to 25%
25% to 50%
50% to 75%
75% to 100%
Remaining
capacity
The battery
may have
malfunctioned.
NOTE:
• Dependingontheconditionsofuseandthe
ambienttemperature,theindicationmaydiffer
slightlyfromtheactualcapacity.
Switch action
CAUTION:
• Beforeinsertingthebatterycartridgeintothe
tool,alwayschecktoseethattheswitchtrigger
actuatesproperlyandreturnstothe"OFF"
position when released.
►Fig.4: 1.SwitchtriggerA2.SwitchtriggerB
3.Lock-offbutton
Foryoursafety,thistoolisequippedwithadualswitch-
ingsystem.Toturnonthetool,pressthelock-offbutton
andtriggersAandB.Releaseeitheroneofthetwo
pressedtriggerstoturnoff.Thesequenceofswitch-
ing is unimportant as the tool only starts when both
switchesareactivated.

10 ENGLISH
Indication lamp
►Fig.5: 1.Indicationlamp
Runningthetoolallowstheindicationlamptoshowthebatterycartridgecapacitystatus.
When the tool is also overloaded and has stopped during operation, the lamp lights up in red.
Refertothefollowingtableforthestatusandactiontobetakenfortheindicationlamp.
Note 1: The time at which the indication lamp lights up varies by the temperature
around the work area and the battery cartridge conditions.
Indication lamp
The lamp blinks in red.
The lamp lights up in red.
(Note 1)
The lamp lights up in red.
(Note 1)
Status
This indicates the appropriate
time to replace the battery
cartridge when the battery
power becomes low.
This function works when the
battery power is almost used
up. At this time, tool stops
immediately.
Autostop due to overload.
Action to be taken
Recharge the battery cartridge
as soon as possible.
Recharge the battery cartridge.
Turn off the tool.
OPERATION
CAUTION:
• Becarefulnottoaccidentallycontactametal
fenceorotherhardobjectswhiletrimming.The
bladewillbreakandmaycauseseriousinjury.
• Overreachingwithahedgetrimmer,particularly
fromaladder,isextremelydangerous.Donot
workfromanythingwobblyorinrm.
NOTICE: Do not attempt to cut branches thicker
than 10 mm in diameter with the tool.Cutbranches
to10cmlowerthanthecuttingheightusingbranch
cuttersbeforeusingthetool.
►Fig.6: (1) Cutting height (2)10cm
CAUTION:
• Donotcutoffdeadtreesorsimilarhardobjects.
Failuretodosomaydamagethetool.
►Fig.7
Holdthetrimmerwithbothhandsandpulltheswitch
triggerAorBandthenmoveitinfrontofyourbody.
►Fig.8: 1.Trimmingdirection2.Hedgesurfacetobe
trimmed 3.Tilttheblades
Asabasicoperation,tiltthebladestowardsthetrim-
mingdirectionandmoveitcalmlyandslowlyatthe
speedrateof3-4secondspermeter.
►Fig.9: 1. String
Tocutahedgetopevenly,ithelpstotieastringatthe
desired hedge height and to trim along it, using it as a
referenceline.
►Fig.10
Attachingthechipreceiver(optionalaccessory)onthe
toolwhentrimmingthehedgestraightcanavoidcutoff
leaves’ being thrown away.
►Fig.11
Tocutahedgesideevenly,ithelpstocutfromthe
bottom upwards.
►Fig.12
Trimboxwoodorrhododendronfromthebasetoward
thetopforaniceappearanceandgoodjob.
Installing or removing chip receiver
(optional accessory)
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
unpluggedbeforeinstallingorremovingchip
receiver.
NOTE:
• Whenreplacingthechipreceiver,alwayswear
glovessothathandsandfacedoesnotdirectly
contacttheblade.Failuretodosomaycause
personalinjury.
• Alwaysbesuretoremovethebladecover
beforeinstallingthechipreceiver.
• Thechipreceiverreceivescut-offleavesand
alleviatescollectingthrown-awayleaves.This
canbeinstalledoneithersideofthetool.
►Fig.13: 1.Press2.Chipreceiver3. Nut 4. Shear
blade
Pressthechipreceiverontheshearbladessothatits
slits overlap with the nuts on the shear blades.
