Makita DUX60 User manual

INSTRUCTION MANUAL
Cordless Multi Function Power
Head
DUX60
ENGLISH: Original instructions
Read before use.

2ENGLISH
SPECIFICATIONS
Model: DUX60
No load speed
(without attachment)
Low 0 - 5,700 min-1
Medium 0 - 8,200 min-1
High 0 - 9,700 min-1
Overall length 1,011 mm
Rated voltage D.C. 36 V
Net weight 4.1 kg - 8.7 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
Applicable battery cartridge
BL1815N/BL1820/BL1820B/BL1830/BL1830B/BL1840/BL1840B/BL1850/BL1850B/BL1860B
• Someofthebatterycartridgeslistedabovemaynotbeavailabledependingonyourregionofresidence.
WARNING: Only use the battery cartridges listed above.Useofanyotherbatterycartridgesmaycause
injuryand/orre.
No load speed with attachment
Model Rotation speed
Low Medium High
EM401MP 0 - 4,200 min-1 0 - 6,000 min-1 0 - 7,100 min-1
EM404MP, EM406MP 0 - 3,500 min-1 0 - 5,000 min-1 0 - 6,000 min-1
EN401MP, EN410MP, EN420MP 0 - 2,400 spm 0 - 3,400 spm 0 - 4,000 spm
EY401MP (chain speed) 0-12m/s 0-17m/s 0-20m/s
KR400MP 0 - 160 min-1 0 - 230 min-1 0 - 280 min-1
EE400MP 0 - 2,800 min-1 0 - 4,000 min-1 0 - 4,700 min-1
EJ400MP 0 - 1,600 min-1 0 - 2,300 min-1 0 - 2,800 min-1
Approved attachment
Type Model
Brushcutter attachment EM401MP, EM404MP
Stringtrimmerattachment EM406MP
Hedge trimmer attachment EN401MP, EN410MP
Ground trimmer attachment EN420MP
Pole saw attachment EY401MP
Cultivator attachment KR400MP
Edger attachment EE400MP
Coffee harvester attachment EJ400MP
Shaftextensionattachment LE400MP

3ENGLISH
Symbols
Thefollowingshowthesymbolsusedfortheequip-
ment.Besurethatyouunderstandtheirmeaningbefore
use.
Read instruction manual.
Takeparticularcareandattention.
Donotexposetomoisture.
Ni-MH
Li-ion
OnlyforEUcountries
Donotdisposeofelectricequipmentor
batterypacktogetherwithhousehold
waste material! In observance of the
European Directives, on Waste Electric
andElectronicEquipmentandBatteries
andAccumulatorsandWasteBatteriesand
Accumulatorsandtheirimplementation
in accordance with national laws, electric
equipmentandbatteriesandbattery
pack(s) that have reached the end of
theirlifemustbecollectedseparatelyand
returnedtoanenvironmentallycompatible
recyclingfacility.
Intended use
Thiscordlessmultifunctionpowerheadisintendedfor
driving an approved attachment listed in the section
"SPECIFICATIONS"ofthisinstructionmanual.Never
use the unit for the other purpose.
WARNING: Read the instruction manual of
the attachment as well as this instruction manual
before using.Failuretofollowthewarningsand
instructionsmayresultseriousinjury.
Noise
Attachment Sound pressure level
average
Sound power level
average
Applicable
standard
LPA (dB (A))
Uncertainty
K (dB (A))
LWA (dB (A))
Uncertainty
K (dB (A))
EM401MP (as a brushcutter) 78.5 1.0 90.2 1.5 EN11806
EM401MP (as a string trimmer) Nyloncuttinghead 84.3 0.6 93.3 1.6 EN50636
Plastic blade 77.0 1.7 88.5 1.8 EN50636
EM404MP (as a brushcutter) 82.5 2.2 93.3 2.9 EN11806
EM404MP (as a string trimmer) Nyloncuttinghead 84.7 2.3 92.8 1.6 EN50636
Plastic blade 76.0 1.8 87.7 1.5 EN50636
EM406MP Nyloncuttinghead 84.7 2.5 93.5 2.2 EN50636
Plastic blade 77.0 1.9 85.6 2.0 EN50636
EN401MP 83.7 1.2 92.6 0.7 ISO10517
EN401MP + LE400MP 83.7 1.3 92.8 1.1 ISO10517
EN410MP 80.2 1.9 88.2 2.2 ISO10517
EN410MP + LE400MP 78.9 1.7 88.3 2.7 ISO10517
EN420MP 84.0 0.8 94.0 0.7 ISO10517
EY401MP 92.5 1.4 101.9 1.4 ISO11680
EY401MP + LE400MP 86.6 1.0 101.2 1.0 ISO11680
KR400MP 76.7 2.2 84.2 1.0 EN709
EE400MP 74.8 1.5 88.2 2.6 ISO11789
EJ400MP 87.4 1.4 94.5 1.3 ISO10517
EJ400MP + LE400MP 85.6 1.0 95.5 1.3 ISO10517
• Evenifthesoundpressurelevellistedaboveis80dB(A)orless,thelevelunderworkingmayexceed80dB
(A).Wearearprotection.

4ENGLISH
Vibration
Attachment Left handle (Front grip) Right handle (Rear grip) Applicable
standard
ah (m/s2)
Uncertainty
K (m/s2)
ah (m/s2)
Uncertainty
K (m/s2)
EM401MP (as a brushcutter) 3.0 1.5 2.5 1.5 EN11806
EM401MP (as a string trimmer) Nyloncuttinghead 5.0 1.5 2.5 1.5 EN50636
Plastic blade 2.5 1.5 2.5 1.5 EN50636
EM404MP (as a brushcutter) 3.0 1.5 2.5 1.5 EN11806
EM404MP (as a string trimmer) Nyloncuttinghead 3.0 1.5 2.5 1.5 EN50636
Plastic blade 2.5 1.5 2.5 1.5 EN50636
EM406MP Nyloncuttinghead 2.5 1.5 2.5 1.5 EN50636
Plastic blade 4.0 1.5 2.5 1.5 EN50636
EN401MP 5.5 1.5 3.5 1.5 ISO10517,
EN60745
EN401MP + LE400MP 5.5 1.5 4.0 1.5 ISO10517,
EN60745
EN410MP 4.0 1.5 2.5 1.5 ISO10517,
EN60745
EN410MP + LE400MP 4.5 1.5 2.5 1.5 ISO10517,
EN60745
EN420MP 6.5 1.5 4.0 1.5 ISO10517
EY401MP 2.5 1.5 2.5 1.5 ISO11680
EY401MP + LE400MP 5.5 1.5 2.5 1.5 ISO11680
KR400MP 2.5 1.5 2.5 1.5 EN709
EE400MP 2.5 1.5 2.5 1.5 ISO11789
EJ400MP 4.0 1.5 3.0 1.5 ISO10517
EJ400MP + LE400MP 4.5 1.5 3.0 1.5 ISO10517
NOTE:Thedeclaredvibrationemissionvaluehasbeenmeasuredinaccordancewiththestandardtestmethod
andmaybeusedforcomparingonetoolwithanother.
NOTE:Thedeclaredvibrationemissionvaluemayalsobeusedinapreliminaryassessmentofexposure.
WARNING:Thevibrationemissionduringactualuseofthepowertoolcandifferfromthedeclaredemission
valuedependingonthewaysinwhichthetoolisused.
WARNING:Besuretoidentifysafetymeasurestoprotecttheoperatorthatarebasedonanestimationof
exposureintheactualconditionsofuse(takingaccountofallpartsoftheoperatingcyclesuchasthetimeswhen
the tool is switched off and when it is running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
to this instruction manual.

5ENGLISH
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool.Failuretofollowallinstructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
whichmayignitethedustorfumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
youtolosecontrol.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.Thereisanincreasedriskofelec-
tricshockifyourbodyisearthedorgrounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However, users of pacemakers and other similar
medical devices should contact the maker of their
deviceand/ordoctorforadvicebeforeoperating
this power tool.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication.Amomentofinattentionwhileoperating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection.Protectiveequipmentsuch
asadustmask,non-skidsafetyshoes,hardhator
hearing protection used for appropriate conditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool.Carryingpowertoolswith
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on.Awrenchorakeyleft
attachedtoarotatingpartofthepowertoolmay
resultinpersonalinjury.
5. Do not overreach. Keep proper footing and
balance at all times.Thisenablesbettercontrol
ofthepowertoolinunexpectedsituations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.Acarelessaction
cancausesevereinjurywithinafractionofa
second.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.

6ENGLISH
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application.Thecorrect
powertoolwilldothejobbetterandsaferatthe
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and off.Anypowertoolthatcannot
be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools.Suchpreventivesafetymeasuresreduce
theriskofstartingthepowertoolaccidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool. Power tools are dangerous in the
hands of untrained users.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Manyaccidentsarecausedbypoorlymaintained
power tools.
6. Keep cutting tools sharp and clean.Properly
maintained cutting tools with sharp cutting edges
arelesslikelytobindandareeasiertocontrol.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
8. Keep handles and grasping surfaces dry,
clean and free from oil and grease.Slippery
handles and grasping surfaces do not allow for
safehandlingandcontrolofthetoolinunexpected
situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled.Theentangle-
mentofclothworkglovesinthemovingpartsmay
resultinpersonalinjury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer.Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskofre
whenusedwithanotherbatterypack.
2. Use power tools only with specically desig-
nated battery packs.Useofanyotherbattery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another.Shortingthebatterytermi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
mayexhibitunpredictablebehaviourresultingin
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
peratureabove130°Cmaycauseexplosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions.Chargingimproperlyorattemperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts.Thiswillensurethatthesafetyofthepower
tool is maintained.
2. Never service damaged battery packs.Service
ofbatterypacksshouldonlybeperformedbythe
manufacturer or authorized service providers.
3. Follow instruction for lubricating and chang-
ing accessories.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.

7ENGLISH
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwardingagents,specialrequirementonpack-
aging and labeling must be observed.
Forpreparationoftheitembeingshipped,consult-
inganexpertforhazardousmaterialisrequired.
Pleasealsoobservepossiblymoredetailed
national regulations.
Tapeormaskoffopencontactsandpackupthe
batteryinsuchamannerthatitcannotmove
around in the packaging.
11. Follow your local regulations relating to dis-
posal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
havebeenaltered,mayresultinthebatterybursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).
PARTS DESCRIPTION
2
1
89
10 11
3
4
5
6
7
12
1Batterycartridge 2Lock-off lever 3Switchtrigger 4Hanger
5Handle 6Release button 7Barrier(countryspecic) 8Speedindicator
9Power lamp 10 Main power button 11 Reverse button 12 Shoulderharness

8ENGLISH
FUNCTIONAL
DESCRIPTION
WARNING: Always be sure that the tool is
switched off and the battery cartridge is removed
before adjusting or checking function on the tool.
Failuretoswitchoffandremovethebatterycartridge
mayresultinseriouspersonalinjuryfromaccidental
start-up.
Installing or removing battery
cartridge
CAUTION: Always switch off the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge.Failuretoholdthetoolandthebattery
cartridgermlymaycausethemtoslipoffyourhands
andresultindamagetothetoolandbatterycartridge
andapersonalinjury.
2
1
3
►1. Red indicator 2. Button 3.Batterycartridge
Toremovethebatterycartridge,slideitfromthetool
while sliding the button on the front of the cartridge.
Toinstallthebatterycartridge,alignthetongueonthe
batterycartridgewiththegrooveinthehousingandslip
itintoplace.Insertitallthewayuntilitlocksinplace
withalittleclick.Ifyoucanseetheredindicatoronthe
uppersideofthebutton,itisnotlockedcompletely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
itmayaccidentallyfalloutofthetool,causinginjuryto
youorsomeonearoundyou.
CAUTION: Do not install the battery cartridge
forcibly.Ifthecartridgedoesnotslideineasily,itis
notbeinginsertedcorrectly.
Tool / battery protection system
Thetoolisequippedwithatool/batteryprotectionsys-
tem.Thissystemautomaticallycutsoffpowertothe
motortoextendtoolandbatterylife.Thetoolwillauto-
maticallystopduringoperationifthetoolorbatteryis
placed under one of the following conditions:
Status Indicator lamps
On Off Blinking
Overload
Overheat
Over
discharge
Overload protection
Ifthetoolisoverloadedbyentangledweedsorother
debris, and the middle indicators start blinking and
thetoolautomaticallystops.
In this situation, turn the tool off and stop the application
thatcausedthetooltobecomeoverloaded.Thenturn
the tool on to restart.
Overheat protection for tool or
battery
When a over heating occurs, all speed indicators blink.
Iftheoverheatingoccurs,thetoolstopsautomatically.
Letthetooland/orbatterycooldownbeforeturningthe
tool on again.
Overdischarge protection
Whenthebatterycapacitybecomeslow,thetoolstops
automaticallyand indicator blinks.
If the tool does not operate even when the switches are
operated, remove the batteries from the tool and charge
the batteries.

9ENGLISH
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
1
2
►1. Indicator lamps 2. Check button
Pressthecheckbuttononthebatterycartridgetoindi-
catetheremainingbatterycapacity.Theindicatorlamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted Off Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
mayhave
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydifferslightly
fromtheactualcapacity.
Main power switch
WARNING: Always turn off the main power
switch when not in use.
Tostandbythetool,pressthemainpowerbuttonuntil
themainpowerlamplightsup.Toturnoff,pressthe
main power button again.
1
►1. Main power button
NOTE:Themainpowerlampbrinksiftheswitch
triggerispulledunderunoperatableconditions.The
lampblinksifyouturnonthemainpowerswitchwhile
holding down the lock-off lever and the switch trigger
NOTE:Thistoolemploystheautopower-offfunction.
Toavoidunintentionalstartup,themainpowerswitch
willautomaticallyshutdownwhentheswitchtrigger
is not pulled for a certain period after the main power
switch is turned on.
Switch action
WARNING: For your safety, this tool is
equipped with lock-off lever which prevents the
tool from unintended starting. NEVER use the tool
if it runs when you simply pull the switch trigger
without pressing the lock-off lever. Return the
tool to our authorized service center for proper
repairs BEFORE further usage.
WARNING: NEVER tape down or defeat pur-
pose and function of lock-off lever.
CAUTION: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the "OFF" position when released.
NOTICE: Do not pull the switch trigger hard with-
out pressing the lock-off lever. This can cause
switch breakage.
Topreventtheswitchtriggerfrombeingaccidentally
pulled, a lock-off lever is provided.

10 ENGLISH
2
1
►1. Lock-off lever 2.Switchtrigger
Tostartthetool,turnonthemainpowerswitchand
graspthehandle(thelock-offleverisreleasedbythe
grasp)andthenpulltheswitchtrigger.Toolspeedis
increasedbyincreasingthepressureontheswitch
trigger.Tostopthetool,releasetheswitchtrigger.
Speed adjusting
Youcanadjustthetoolspeedbytappingthemain
power button.
Eachtimeyoutapthemainpowerbutton,thelevelof
speed will change.
1
►1. Main power button
Indicator Mode
High
Medium
Low
Reverse button for debris removal
WARNING: Switch off the tool and remove
the battery cartridge before you remove entan-
gled weeds or debris which the reverse rotation
function can not remove.Failuretoswitchoffand
removethebatterycartridgemayresultinserious
personalinjuryfromaccidentalstart-up.
Thistoolhasareversebuttontochangethedirectionof
rotation.Itisonlyforremovingweedsanddebrisentan-
gled in the tool.
Toreversetherotation,tapthereversebuttonandpull
thetriggerwhenthetool’sheadisstopped.Thepower
lamp starts blinking, and the tool's head rotates in
reversedirectionwhenyoupulltheswitchtrigger.
Toreturntoregularrotation,releasethetriggerandwait
until the tool's head stops.
1
►1. Reverse button
NOTE: During the reverse rotation, the tool operates
onlyforashortperiodoftimeandthenautomatically
stops.
NOTE: Once the tool is stopped, the rotation returns
toregulardirectionwhenyoustartthetoolagain.
NOTE:Ifyoutapthereversebuttonwhilethetool's
head is still rotating, the tool comes to stop and to be
readyforreverserotation.
Electronic torque control function
Thetoolelectronicallydetectsasuddendropinthe
rotationspeedwhichmaycauseakickback.Inthis
situation,thetoolautomaticallystopstopreventfurther
rotationofcuttingtool.Torestartthetool,releasethe
switch trigger. Clear the cause of sudden drop in the
rotation speed and then turn the tool on.
NOTE:Thisfunctionisnotapreventivemeasurefor
kickbacks.

11 ENGLISH
ASSEMBLY
WARNING: Always be sure that the tool is
switched off and battery cartridge is removed
before carrying out any work on the tool.Failureto
switchoffandremovethebatterycartridgemayresult
inseriouspersonalinjuryfromaccidentalstart-up.
WARNING: Never start the tool unless it is
completely assembled. Operation of the tool in a
partiallyassembledstatemayresultinseriousper-
sonalinjuryfromaccidentalstart-up.
Mounting the handle
Attachthehandlewithsuppliedclampsandbolts.Make
sure that the handle is located between the spacer and
the arrow mark. Do not remove or shrink the spacer.
4
2
3
1
3
5
►1. Handle 2.Hexsocketbolt3. Clamp 4.Spacer
5.Arrowmark
Attachthebarrier(countryspecic)tothehandleusing
the screw on the barrier. Once assembled, do not
remove the barrier.
1
2
►1. Barrier 2.Screw
Mounting the attachment pipe
Mount the attachment pipe to the power unit.
1. Turnthelevertowardthecuttingattachment.
1
►1. Lever
2. Alignthepinwiththearrowmarkandinsertthe
attachment pipe until the release button pops up.
1
2
3
►1. Release button 2.Arrowmark3. Pin
3. Turnthelevertowardthepowerunit.
1
►1. Lever
Make sure that the surface of the lever is parallel to the
pipe.
Toremovethepipe,turnthelevertowardthecutting
attachment and pull the pipe out while pressing down
the release button.

12 ENGLISH
Fig.12
3
1
2
►1. Release button 2. Lever 3. Pipe
Adjusting the handle/hanger
position
Adjustthehandleandhangerpositiontoobtainconfort-
able handling of the tool.
Loosenthehexsocketheadboltonthehandle.Move
the handle to a comfortable working position and then
tighten the bolt.
1
2
►1. Handle 2.Hexsocketheadbolt
Loosenthehexsocketheadboltonthehanger.Move
the hanger to a comfortable working position and then
tighten the bolt.
21
►1.Hexsocketheadbolt2. Hanger
Attaching shoulder harness
WARNING: Be extremely careful to maintain
control of the tool at all times. Do not allow the
tool to be deected toward you or anyone in the
work vicinity.Failuretokeepcontrolofthetool
couldresultinseriousinjurytothebystanderandthe
operator.
CAUTION: Always use the shoulder harness
attached. Before operation, adjust the shoulder
harness according to the user size to prevent
fatigue.
Puttheshoulderharnessonyourleftshoulderbyput-
tingyourheadandrightarmthroughit.Keepthetoolon
yourrightside.
Afterputtingtheshoulderharness,attachittothetool
byconnectingthebucklesprovidedonboththetool
hook and the harness. Be sure that the buckles click
andlockcompletelyinplace.
Adjustthestraptothesuitablelengthforyouroperation.
1
2
►1. Hanger 2. Hook
Thebuckleisprovidedwithameansofquickrelease
whichcanbeaccomplishedbysimplysqueezingthe
sides and the buckle.
1
►1. Buckle

13 ENGLISH
Hex wrench storage
CAUTION: Be careful not to leave the hex
wrench inserted in the tool head. Itmaycause
injuryand/ordamagetothetool.
Whennotinuse,storethehexwrenchasillustratedto
keep it from being lost.
1
2
►1. Handle 2.Hexwrench
MAINTENANCE
WARNING: Always be sure that the tool is
switched off and battery cartridge is removed
before attempting to perform inspection or main-
tenance on the tool.Failuretoswitchoffandremove
thebatterycartridgemayresultinseriouspersonal
injuryfromaccidentalstart-up.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Battery guard
WARNING: Do not remove the battery
guard. Do not use the tool with the battery guard
removed or damaged.Directimpacttothebattery
cartridgemaycausebatterymalfunctionandresult
ininjuryand/orre.Ifthebatteryguardisdeformed
ordamaged,contactyourauthorizedservicecenter
for repairs.
1
►1.Batteryguard
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
TROUBLESHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
donotattempttodismantlethetool.Instead,askMakitaAuthorizedServiceCenters,alwaysusingMakitareplace-
ment parts for repairs.
State of abnormality Probable cause (malfunction) Remedy
Motor does not run. Batterycartridgeisnotinstalled. Installthebatterycartridge.
Batteryproblem(undervoltage) Rechargethebattery.Ifrechargingisnoteffective,
replacebattery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Motor stops running after a little use. Rotation is in reverse. Change the direction of rotation with the reversing
switch.
Battery'schargelevelislow. Rechargethebattery.Ifrechargingisnoteffective,
replacebattery.
Overheating. Stopusingoftooltoallowittocooldown.
ItdoesnotreachmaximumRPM. Batteryisinstalledimproperly. Installthebatterycartridgeasdescribedinthis
manual.
Batterypowerisdropping. Rechargethebattery.Ifrechargingisnoteffective,
replacebattery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.

14
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
Referto"Approvedattachment"sectionfortheapplica-
ble models for this tool.
• Edgerattachment
• Brushcutterattachment
• Stringtrimmerattachment
• Hedgetrimmerattachment
• Groundtrimmerattachment
• Polesawattachment
• Coffeeharvesterattachment
• Cultivatorattachment
• Shaftextensionattachment
• Makitagenuinebatteryandcharger
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
differfromcountrytocountry.
ENGLISH

15

www.makita.com
Makita Europe N.V.
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi 446-8502 Japa
n
Jan-Baptist Vinkstraat 2,
3070 Kortenberg, Belgium
885603-225
EN
20170824
Other manuals for DUX60
10
Table of contents
Other Makita Trimmer manuals

Makita
Makita UH014G User manual

Makita
Makita 3709 User manual

Makita
Makita UR3000 User manual

Makita
Makita UR007G User manual

Makita
Makita BUR142U User manual

Makita
Makita UR014G User manual

Makita
Makita DUR193 User manual

Makita
Makita BUH550 User manual

Makita
Makita DUH506 User manual

Makita
Makita UR013G User manual

Makita
Makita XNU01 User manual

Makita
Makita UM600D User manual

Makita
Makita XHU02M1 User manual

Makita
Makita EN5950SH User guide

Makita
Makita XRU09PT User manual

Makita
Makita DUR190U User manual

Makita
Makita DRT50 User manual

Makita
Makita DUR194 User manual

Makita
Makita DUR365U User manual

Makita
Makita DRT50ZX06 User manual
