Malone BigFoot User manual
IMPORTANT WARNING: All vehicular transports are potentially hazardous. Any person(s) using Malone products are personally responsible for
following the given directions for use and/or installation and accepts full responsibility for any and all damages or injury of any kind including death,
which may result from their use and/or installation.
It is critical that all Malone racks and accessories be properly and securely attached to your vehicle. Improper attachment could result in a serious
accident, and could cause serious bodily injury or death to you or to others. You are responsible for securing the racks and accessories to your car,
checking the attachment’s prior to use, and periodically inspecting the products for adjustment, wear, and damage.
You must read and understand all of the instructions and cautions supplied with your Malone products(s) prior to installation or use. If you do not
understand all of the instructions and cautions, or, if you have no mechanical experience and are not thoroughly familiar with the installation
procedures, you should have the product installed by a professional installer.
MISE EN GARDE IMPORTANTE: Tout transport d’un chargement sur le toit d’un véhicule est potentiellement dangereux. Une personne qui
utilise les produits Malone doit suivre sans faute les instructions d’installation et d’utilisation fournies et assume l’entière responsabilité pour tout
dommage ou toute blessure, y compris un décès, pouvant résulter d’une telle installation ou utilisation.
Il est essentiel de xer correctement et solidement les supports et les accessoires à votre véhicule. Une mauvaise installation ou attache pourrait
provoquer un accident, entraîner des blessures corporelles graves à vous et aux autres et même causer la mort. Vous avez la responsabilité de
xer solidement les supports et les accessoires à votre véhicule, de vérier l’installation avant l’utilisation et d’inspecter périodiquement le produit
pour déceler tout signe d’usure ou de dommage ou tout problème d’ajustement.
Vous devez lire et comprendre les instructions et les mises en garde fournies avec les produits Malone avant l’installation et l’utilisation. Si vous
ne comprenez pas les instructions et les mises en garde ou si vous ne possédez pas d’expérience en mécanique et ne connaissez pas à fond les
procédures à suivre d’installation, vous devriez faire monter et poser le produit par un installateur professionnel.
MALONE
R
DownLoaderDownLoaderTM
J-STYLE FOLDING KAYAK CARRIER
12’ Safety LinesJawz Universal Adapters Mounting BoltsKayak Carriers Load Straps T-Knobs
60mm
70mm
Installation & Loading Instructions - Please Read Before Beginning
Veuillez lire les instructions avant d’entreprendre l’installation et le chargement
1
3
2
. Insert Mounting Bolt through one hole of a Jawz adapter.
Insert washer and loosely apply a T-knob. See image 2.
. Faites passer le boulon de fixation dans l’un des trous
d’un adaptateur Jawz puis vissez légèrement un bouton
en ‘‘T’’ à la base du boulon. (Figure 2)
. Prior to installation, insert a bolt into the mounting holes in
the bottom of the carriers. Push upward to open the two
mounting hole covers located in the Base pads.
. Insert a Mounting Bolt into one mounting hole from the top
side. Rotate and close the mounting hole cover.
See image 1.
. Insérez un boulon de fixation dans l’un des trous hexagonaux
situés sur le côté supérieur du support.
(Figure 1)
. Place the carrier onto the front cross bar with the boarding
ramp facing out. Swing the Jawz under the cross bar as
shown. See image 3.
. Placez le support sur la barre transversale avant, la rampe
de chargement vers l’extérieur. Faites passer l’adaptateur
Jawz sous la barre transversale, tel qu’indiqué. (Figure 3)
1
Mounting Bolt Washers
Base Pad
Covers
MALONE
R
MALONE
R
MPG1012MPG1012
T-Slot Integration Hardware Kit
12’ Safety Tie-Downs (2) 50mm + 60mm Mounting Bolts (16)
Gunwale Brackets (4)
Jawz Universal Adapters (8)
TM
MALONE
R
Installation & Loading Instructions - Please Read Before Beginning
Veuillez lire les instructions avant d’entreprendre l’installation et le chargement
2
1
3
. Place the carrier onto the front cross bar with the
forward section (with foam pads) facing inward.
See image 2.
. Insert a mounting bolt (50 mm or 60 mm) into the right side
hex hole. Install a Jawz mounting adapter and washer.
Loosely apply a T-knob.
See image 1.
.Insert the second mounting bolt (50 mm or 60 mm) into the
left side carrier hex hole. Fit the Jawz mounting adapter
and apply the washer. Loosely apply a T-knob.
See image 3.
15’ Load Straps
(2)
GUNWALE STYLE CANOE CARRIER
BF
OI G O T
Important Note
Product Warranty & Registration Form
MALONE
R
MALONE AUTO RACKS 81 County Rd. Ste 1, Westbrook, ME 04092
P: 207.774.9100 F: 207.615.0551
E: support@maloneautoracks.com W: www.maloneautoracks.com
Dear Customer,
Thank you for your purchase of a Malone Product.
In order to be eligible for the Malone Warranty program, we ask that you contact us online at the link provided
below: With-in 30 days of purchase. You can also mail this letter back to the address at the bottom.
• Online: https://maloneautoracks.com/product-registration.php
We will require the information below.
Here is the information collected:
First Name:
Last Name:
Address:
Address2:
City:
State:
Zip:
Country:
Email:
Phone:
Product Description/Name:
Product MPG#
Date Purchased:
Store Where Purchased:
Purchase Price:
Thank you for choosing Malone!
MALONE
R
(4)
MPG1012MPG1012
T-ST-Slotlot IIntegrationntegration HHardwareardware KKitit
60 (8)
S T-D S
This Package Also Contains The Standard Mounting Kit For
Traditional Mounting On A Vehicles Cross Bars
See back section of instructions for mounting procedure
J T-K 50 (8)
This Kit Can Be Used With Both Aero Style Roof Racks & Truck Rack Systems
TThishis KKit Fits Malone Kayak Carrier Models: MPG112it Fits Malone Kayak Carrier Models: MPG112
1
H K
S (8)
S S (8)
S (8)
(8)
S W (8)
A W (1)
MALONE
R
MPG1012MPG1012
T-ST-Slotlot IIntegrationntegration HHardwareardware KKitit
23
MALONE
R
MPG1012MPG1012
60 (8)J T-K 50 (8)
UUtilizingtilizing TThehe SStandardtandard MMountingounting KKitit FForor
TTraditionalraditional MMountingounting OOnnA VA Vehiclesehicles CCrossross BBarsars
12’ Safety Tie-Downs (2) 50mm + 60mm Mounting Bolts (16)
Gunwale Brackets (4)
Jawz Universal Adapters (8)
TM
MALONE
R
Installation & Loading Instructions - Please Read Before Beginning
Veuillez lire les instructions avant d’entreprendre l’installation et le chargement
2
1
3
. Place the carrier onto the front cross bar with the
forward section (with foam pads) facing inward.
See image 2.
. Insert a mounting bolt (50 mm or 60 mm) into the right side
hex hole. Install a Jawz mounting adapter and washer.
Loosely apply a T-knob.
See image 1.
.Insert the second mounting bolt (50 mm or 60 mm) into the
left side carrier hex hole. Fit the Jawz mounting adapter
and apply the washer. Loosely apply a T-knob.
See image 3.
15’ Load Straps
(2)
GUNWALE STYLE CANOE CARRIER
BF
OI G O T
1
3
2
Green Load Straps
Insert a mounting bolt (50mm or 60mm) into the right side
hex hole. Install a Jawz mounting adapter and loosely apply
a T-knob. See image 1.
Insert the second mounting bolt (50mm or 60mm) into the
left side hex hole. Fit the Jawz mounting adapter and apply a
T-knob. See image 3.
(4)
Note: The base of the carrier has a rectangular “cutout” that has
been included for square cross bar t. This “cutout” does not effect
the t or function of the carriers when installed to round or oval
shaped cross bars.
Jawz Brackets (4)
MALONE
R
MPG1012MPG1012
UUtilizingtilizing TThehe SStandardtandard MMountingounting KKitit FForor
TTraditionalraditional MMountingounting OOnnA VA Vehiclesehicles CCrossross BBarsars
MALONE
R
Installation & Loading Instructions - MPG112MD BigFoot
Instructions - Installation et chargement
TM
. Pull the free end of the strap loop down until the buckle
is approximately half-way up the side of the canoe.
Dress the free end under the cross rail.
See image 7.
5
. Dress the free end of a strap under the cross rail. Pull the
free end up and out until an even loop is created. Place the
loop up and over the canoe. See image 6.
4
6
7
. Install the three remaining gunwale brackets according to
steps 1-3. Note: Do not tighten the T-knobs. The brackets
should be left loose so they can be centered in step 5.
See image 4.
. Place the canoe on the gunwale brackets. Adjust the
canoe and brackets until they are centered in the middle
of the roof and the canoe is evenly balanced. With the
brackets fitted against the canoe, firmly tighten the
T-knobs on all four brackets.
See image 5.
MALONE
R
MPG1012MPG1012
UUtilizingtilizing TThehe SStandardtandard MMountingounting KKitit FForor
TTraditionalraditional MMountingounting OOnnA VA Vehiclesehicles CCrossross BBarsars
MALONE
R
. Install the bow & stern safety lines per attached the
attached instructions.
See image 9.
. Dress the free end of the strap up and through the buckle.
Pull down to tighten. Repeat steps 6-8 for the second strap.
See image 8.
. The canoe should now be firmly attached to the vehicle with
both straps firmly secured and both safety tie-downs installed.
See image 10.
8
10
9
Always check mounting hardware, load straps and safety tie-down lines for proper
and secure attachment before transport. Use of this product for any other
application other than watersport transport voids warranty.
Assurez-vous que les pièces de montage, les courroies de fixation et les filins de sécurité soient fixés
correctement lorsque vous transportez un kayak. L’utilisation de ce produit pour un usage autre que le
transport d’un kayak en annule la garantie.
MALONE AUTO RACKS, 81 County Road, Westbrook, Maine 04092
Phone: 207-774-9100 Fax: 207-615-0551
Website: www.maloneautoracks.com Email: technical@maloneautoracks.com
Installation & Loading Instructions - MPG112MD BigFoot
Instructions - Installation et chargement
TM
Bow and Stern Safety tie-downs are required for all rooftop transport.
Failure to use these safety lines voids all warranty.
If your kit did not include safety tie-downs, we strongly recommend the use of the
Malone MPG316 Sentry Ratchet Tie-Down System or Malone MPG309 SpeedLine Mini Ratchet Tie-Down
MALONE
R
. Install the bow & stern safety lines per attached the
attached instructions.
See image 9.
. Dress the free end of the strap up and through the buckle.
Pull down to tighten. Repeat steps 6-8 for the second strap.
See image 8.
. The canoe should now be firmly attached to the vehicle with
both straps firmly secured and both safety tie-downs installed.
See image 10.
8
10
9
Always check mounting hardware, load straps and safety tie-down lines for proper
and secure attachment before transport. Use of this product for any other
application other than watersport transport voids warranty.
Assurez-vous que les pièces de montage, les courroies de fixation et les filins de sécurité soient fixés
correctement lorsque vous transportez un kayak. L’utilisation de ce produit pour un usage autre que le
transport d’un kayak en annule la garantie.
MALONE AUTO RACKS, 81 County Road, Westbrook, Maine 04092
Phone: 207-774-9100 Fax: 207-615-0551
Website: www.maloneautoracks.com Email: technical@maloneautoracks.com
Installation & Loading Instructions - MPG112MD BigFoot
Instructions - Installation et chargement
TM
Visit www.maloneautoracks.com/Replacement-Parts
for all of your spare part needs
MPG370 BOW & STERN LINE KIT
MALONE
R
Thread free end
of cord through
hook.
Create a “left
over right”
knot & tighten.
Create a “right
over left”
knot & tighten.
Pull to test for
knot strength.
A B C D
Attach hook to rope (steps A-D)
Keeping the rope tight and
S-hook in place, thread the
free end up and through a
strong point on the kayak
F
Make a loop in the rope
12” to 14” away
from the kayak or canoe.
G
Attach and dress rope to vehicle and boat (steps E-O)
Attach S-hook to vehicle
tow ring or other sturdy
body part.
E
Bend the loop over leaving
a large opening as shown.
H
Opening
Pass the loop through the
opening.
I
Pull to create a tight knot.
JK
Thread the free end of
the rope
through the loop.
L
Pull the free end up until
the rope
is sufficiently tight.
M
Hold the rope secure with
one hand.
Form a knot with the free
end and tighten. Form
a second knot for
safety purposes.
N
The line should be tight
and secure. Repeat for
second tie-down.
O
MALONE AUTO RACKS, 81 County Road, Westbrook, Maine 04092
Phone: 207-774-9100 Fax: 207-615-0551
Website: www.maloneautoracks.com Email: technical@maloneautoracks.com
MPG306 BOW & STERN LINE KIT
NOTE: NOT REQUIRED ON TRAILER PACKAGES
MALONE AUTO RACKS 81 County Rd. Ste 1, Westbrook, ME 04092
P: 207.774.9100 F: 207.615.0551
E: support@maloneautoracks.com W: www.maloneautoracks.com
MALONE
R
Enfiler l’extrémité
libre de la corde dans le
crochet.
Faire un nœud «
gauche sur droit »
et serrer.
Faire un nœud «
droit sur gauche »
et serrer.
Tirer pour vérifier
la solidité du nœud.
A B C D
ENSEMBLE D’ATTACHES AVANT ET ARRIÈRE MPG306
En maintenant la corde serrée
et le crochet en place, faire
passe l’extrémité libre dans
un point d’attache sur le kayak.
F
Faire une boucle dans
la corde à une distance
de 30 cm à 35 cm du
kayak ou du canot.
G
Attacher la corde au véhicule et à l’embarcation (étapes E à O)
Fixer le crochet en S à
l’anneau de remorquage
ou à une autre
partie solide du véhicule.
E
Replier la boucle en faisant
une large ouverture,
tel qu’indiqué.
H
Ouverture
Introduire la boucle dans
l’ouverture.
I
Serrer pour faire un
nœud solide.
JK
Faire passer l’extrémité
libre de la corde dans
la boucle.
L
Tirer sur l’extrémité
libre jusqu’à ce que la
corde soit bien serrée.
M
Maintenir la corde serrée
d’une main.
Faire un nœud avec
l’extrémité libre et serrer.
Faire un deuxième nœud
en guise de sécurité.
N
La corde doit être bien
tendue et solide. Répéter
la procédure pour la
deuxième corde d’attache.
O
MALONE, 81 County Road, Westbrook, Maine USA 04092
Courriel : sales@maloneautoracks.com
Web: www.maloneautoracks.com
NOTE: PAS NÉCESSAIRE SUR LES COLIS TRAILER
MALONE AUTO RACKS 81 County Rd. Ste 1, Westbrook, ME 04092
P: 207.774.9100 F: 207.615.0551
E: support@maloneautoracks.com W: www.maloneautoracks.com
MALONE AUTO RACKS 81 County Rd. Ste 1, Westbrook, ME 04092
P: 207.774.9100 F: 207.615.0551
E: support@maloneautoracks.com W: www.maloneautoracks.com
Limited Lifetime Warranty
Disclaimer of Liability
MALONE
R
Other manuals for BigFoot
1
Table of contents
Other Malone Automobile Accessories manuals
Malone
Malone MPG902 User manual
Malone
Malone SaddleUp PRO User manual
Malone
Malone MPG186 User manual
Malone
Malone MPG502 User manual
Malone
Malone AutoLoader MPG106M User manual
Malone
Malone MPG201 User manual
Malone
Malone BigFoot MPG112 User manual
Malone
Malone SaddleUp PRO Series User manual
Malone
Malone DownLoader MPG114 User manual
Malone
Malone BigFoot User manual
