MAMAC SYSTEMS PR-274 Manual

ModelPR-274/275
TechnicalInformation
TI.274/275-01
LowPressureTransducer
Accuracy*:±1%FS
Overpressure:10 PSID
SupplyVoltage:12-40 VDC
12-35 VAC(VDC output
unitsonly)
SupplyCurrent: VDC Units-10 mAmax.
mAUnits-20 mAmax.
Enclosure:18 GaC.R.SteelNEMA4(IP-65)orPanelMountChassis
Finish:Baked on enamel-PMS2GR88B
CompensatedTempRange:25ºF-150ºF(-4ºC-65ºC)
T.C.Error:±0.0125%/ºF(.02%/ºC)
Operating TempRange:0ºF-175ºF(-18ºC-80ºC)
MediaCompatibility:Clean dryairoranyinertgas
Environmental:10-90%RH Non-Condensing
Termination:Unpluggablescrewterminalblock
WireSize:12 Gamax.
LoadImpedance:1.6Kohmsmax.at40 VDC (mAoutputunits)
1Kohmsmin.(VDC outputunits)
Weight: Enclosure1.0lbs.(.45 kg)
PanelMount: 0.5lbs.(.25 kg)
*Includesnon-linearity,hysteresisand non-repeatability
FORADDITIONALINFORMATION
SEE PR-274/275 DATASHEET
SPECIFICATIONS
274 (enclosure)R1("wc)0TO0.10 /-0.05TO+0.05 mA(4-20 mA2wire)
275 (panelmount)R2("wc)0TO1.0/0TO0.5/0TO0.25/VDC (0-5VDC or
-0.5TO+0.5/-0.25 TO+0.25/0-10 VDC fieldselectable)
-0.125 TO+0.125
R3("wc)0TO5.0/0TO2.5/0TO1.25/
-2.5TO+2.5/-1.25 TO+1.25/
-0.625 TO+0.625
R4("wc)0TO30 /0TO15 /0TO7.5/
-15.0TO+15.0/-7.5TO+7.5/
-3.75 TO+3.75
R5(pa)0TO25 /-12.5TO+12.5
R6(pa)0TO250 /0TO125 /0TO62.5/
-125TO+125 /-62.5TO+62.5/
-31.25 TO+31.25
R7(pa)0TO1250 /0TO625 /0TO312.5/
-625TO+625 /-312.5TO+312.5/
-156.25TO+156.25
R8(pa)0TO7500 /0TO3750 /0TO1875/
-3750TO+3750 /-1875 TO+1875/
-937.5TO+937.5
PACKAGINGRANGEOUTPUT
INSTALLATION
Inspection Inspectthe package fordamage.If damaged,notifythe
appropriatecarrierimmediately.If undamaged,open
the package and inspectthe deviceforobviousdamage
.
Returndamaged products.
Requirements •Tools(notprovided)
-DigitalVolt-ohmMeter(DVM)
-Appropriatescrewdriverformounting screws
-Appropriatedrill and drill bitformounting screws
•Appropriateaccessories
•Two#8 self-tapping mounting screws(notprovided)
•Training:Installermustbe aqualified,experienced
technician
Warning:
•Disconnectpowersupplybeforeinstallation toprevent
electricalshock and equipmentdamage.
•Makeall connectionsinaccordancewiththe job wiring
diagram,and inaccordancewithnationaland local
electricalcodes.Usecopperconductorsonly.
Caution:
•Useelectrostaticdischarge precautions(e.g., useof
wriststraps)during installation and wiring toprevent
equipmentdamage.
•Avoidlocationswheresevereshock orvibration,
excessivemoistureorcorrosivefumesarepresent.
NEMAType 4housingsareintended foroutdooruse
primarilytoprovide adegree ofprotection against
wind-blowndust, rain,and hose-directed water.
•Donotexceed ratingsofthe device.
Mounting The PR-274/275 mustbe mounted asindicated bythe arrows
on the enclosure.RefertoFigure-7formounting dimensions.
1.Removethe transducercoverusing aPhillipshead
screwdriver.
2.Selectthe mounting location.
3.Mounttransduceron averticalsurfacewithtwo#8 self-
tapping screws(notprovided).
4.Pull wiresthrough bottomofenclosureand makenecessary
connections.
5.Replacecoverand makepneumaticconnections.
Wiring Usemaximum12 AWGwireforwiring terminals.Useflexible
1/4”O.D., 5/32”I.D.tubing forthe high and lowpressure
connections.RefertoFigures1,2,3,&4forwiring information
and Figures5&6forjumperdesignations.
Wiring PR-274/275 UnitswithmAOutput
PR-274/275 pressuretransducersare4-20 mAoutputunits
powered witha12-40 VDC supply.
The following describesthe properwiring ofthesepressure
transducerswithmAoutput:
1.Removethe blue terminalblock bycarefullypulling itoff
the circuitboard.
2.Locatethe [+]and [-]terminalmarkingson the board.
3.Attachthe supplyvoltage tothe [+]lead.
4.Connectthe 4-20 mAoutput([-]terminal)tothe controller’s
inputterminal.
5.Ensurethatthe powersupplycommon isattached tothe
common busofthe controller.
6.Re-insertthe terminalblock tothe circuitboardand apply
powertothe unit.
7.Check forthe appropriateoutputsignalusing aDVMset
on DC milliampsconnected inserieswiththe [-]terminal.
!
EnclosureMount

ModelPR-274/27
5
TechnicalInformatio
n
TI.274/275-0
1
LowPressureTransducer
+–ZS
High Low
+–ZS
High Low
Legend
S=Span Adjust
Z=ZeroAdjust
+=SupplyVoltage
-=Output
Caution:If you areusing grounded AC,the hotwiremustbe on
the (+)terminal.Also,ifyou areusing acontrollerwithoutbuilt-in
isolation,usean isolation transformertosupplythe PR-274/275
transducer.
PR-274
(mAoutput)PR-275
(mAoutput)
Wiring PR-274/275 UnitswithVDC Output
PR-274/275 pressuretransducerswithVdcoutputarefieldselectable
0-5VDC or0-10 VDC outputand can be powered witheither12-40
VDC or12-35 VAC.The following describesthe properwiring ofthese
pressuretransducerswithVDC output:
1.Removethe blue terminalblock bycarefullypulling itoff the circuit
board.
2.Locatethe (+),(-),and (0)terminalmarkingson the board.
3.Attachthe powerwirestothe (+)and (-) terminals.The (-) terminal
isalsothe negativeoutputterminal.
4.Connectthe (0)terminal,whichisthe positiveVDC outputterminal,
tothe controller’sinput.
5.Re-insertthe terminalblock tothe circuitboardand applypowerto
the unit.
6.Check the appropriateVDC outputusing avoltmeterseton DC volts
across the (0)and (-) terminals.
TYPICALAPPLICATIONS(wiring diagrams)
Caution:Thisproductcontainsahalf-waverectifierpowersupply
and mustnotbe powered off transformersused topowerother
devicesutilizing non-isolated full-waverectifierpowersupplies.
Caution:When multiplePR-274/275 unitsarepowered fromthe
sametransformer,damage will resultunless all 24Gpowerleads
areconnected tothe samepowerleadon all devices.It ismandatory
thatcorrectphasing be maintained when powering morethan one
devicefromasingletransformer.
PR-274/275 PressureTransducerswithmAOutput
Page 2of5
Figure-1and Figure-2
Illustratetypicalwiring diagramsforthe PR-274/275,4-20 mA,
two-wirelowpressuretransducers.
+
–+ –
+
–
mAOutput
TransducerOnly12-40 VDC
PowrSupply
Controller/
Meter/
Recorder
Shield/
Ground
InputSignal
Common
Figure-1Wiring formALowPressure
TransducerswithExternalDC
PowerSupply
+
–
mAOutput
TranducerOnly+
–
Controller/
Meter/
Recorder
Shield/
Ground
InputSignal
Common
Figure-2Wiring formALowPressureTransducers
WhereControllerorMeterhasInternalDC
PowerSupply
+-0
S Z
Legend
S=Span Adjust+=SupplyVoltage (Hot)
Z=ZeroAdjust-=Common (Neutral)
0=Input
PR-274/275 PressureTransducerswithVDC Output
PR-274
(VDC output)
PR-275
(VDC output)
High Low
+-0ZS
High Low

+
–
Controller/
Meter/
Recorder
Shield/
Ground
Input
Signal
Common
12-40 VDC
PowerSupply
+
–
VDC Output
TransducerOnly
Common
+
–
Supply
Signal0
Figure-4Wiring forVDC LowPressureTransducers
When Applied withExternalDC Supply.
ADJUSTMENTS
JumperJumperselectionsvaryaccording tothe low
pressuretransducer(mAorVDC).
Selection The following describesthe possibleselectionsfor
eachmodel.
JumperSelectionsforPR-274/275 LowPressure
TransducerswithmAOutputs
The possiblerange configurationsand jumper
selectionsforpressuretransducerswithmAoutputs
areshowninTable-1and Figure-5,respectively.
+–ZS
Range:A
+–ZS
Range:B
+–ZS
Range:C
+–ZS
Range:D
+–ZS
Range:E
+–ZS
Range:F
+–ZS
Range:G
+–ZS
Range:H
Figure-5JumperSelectionsforLowPressureTransducers
withmAOutputs.
JumperSelectionsforPR-274/275 LowPressure
TransducerswithVDC Outputs
The possiblerange configurationsand jumper
selectionsforlowpressuretransducerswithVDC
outputsareshowninTable-2and Figure-6,
respectively.
Figure-3and Figure-4
Illustratetypicalwiring diagramsforthe PR-274/275,0-5/0-10
VDC outputLowPressureTransducers.
+
–
Controller/
Meter/
Recorder
Shield/
Ground
InputSignal
Common
12-35 VAC
Transformer
Hot
Neutral
+
–
VDC Output
TransducerOnly
Common
+
–
Supply
Signal0
Figure-3Wiring forVDC LowPressureTransducers
When Applied withExternalACSupply.
ModelPR-274/275
TechnicalInformation
TI.274/275-01
LowPressureTransducer
Page 3of5
A
Range BCDEFGH
Range Configurations(inchesw.c.)
R1
R2
R3
R4
0to.10 -0.05 -+0.05 0to1.0
0to5.0
0to30
0to0.5
0to2.5
0to15
0to0.25
0to1.25
0to7.5
-0.5to+0.5
-2.5to+2.5-
15.0-+15.0
-0.25 to+0.25
-1.25 to+1.25
-7.5to+7.5
-0.125 to+0.125
-0.625 to+0.625
-3.75 to+3.75
A
Range BCDEFGH
Range Configurations(pa)
R5
R6
R7
R8
0to25 -12.5to+12.50to250
0to1250
0to7500
0to125
0to625
0to3750
0to62.5
0to312.5
0to1875
-125 to+125
-625 to+625
-3750to+3750
-62.5to+62.5
-312.5to+312.5
-1875 to+1875
-31.25 to+31.25
-156.25to+156.25
-937.5to+937.5
Table-1Range configurationsforLowPressureTransducers
withmAoutput

CALIBRATIONAll unitsarefactorycalibrated tomeetorexceed
published specifications.If fieldadjustmentisnecessar
y
followthe instructionsbelow.
Calibration ofPR-274/275 mAUnits
1.Connectterminals(+)and (-) tothe appropriate
powersource.
2.Connectthe DVMinserieson the (-) terminal.
3.Applylowpressuretothe unitand carefullyadjus
t
the zerotrimmer(Z)toobtaindesired lowoutput.
4.Applyhigh pressuretothe unitand adjustspan
trimmer(S)toobtainthe desired high output
pressure.
5.Repeatsteps3and 4until desired calibration is
achieved.
Range:ARange:B
Range:C Range:D
Range:ERange:F
Range:GRange:H
Figure-6JumperSelectionsforLowPressureTransducers
withVDC Outputs.
+–0ZS+–0ZS
+–0ZS+–0ZS
+–0ZS+–0ZS
+–0ZS+–0ZS
RANGECONFIGURATIONS
MAINTENANCERegularmaintenanceofthe totalsystemis
recommended toassuresustained optimum
performance.
FIELDREPAIRNone.Replacewithafunctionalunit.
WARRANTYSee DataSheetforadditionalinformation.
ModelPR-274/27
5
TechnicalInformation
TI.274/275-0
1
LowPressureTransducer
Page 4of5
Calibration ofPR-274/275 VDC Units
1.Connectterminals(+)and (-) tothe appropriate
powersource.The (-) terminalisalsothe negative
outputterminal.
2.Connectthe DVMon DC voltsacross (0)and (-)
terminal.
3.Applylowpressuretothe unitand carefullyadjust
the zerotrimmer(Z)toobtaindesired lowoutput.
4.Applyhigh pressuretothe unitand adjustspan
trimmer(S)toobtainthe desired high output
pressure.
5.Repeatsteps3and 4until desired calibration is
achieved.
CHECKOUT1.Verifythatthe unitismounted inthe correctposition
.
2.Verifyappropriateinputsignaland supplyvoltage
.
Caution:Neverconnect120 VACtothese
transducers.NeverconnectACvoltage toaunit
intended forDC supply.
3.Verifyappropriateconfiguration range.
TransducerThisisarough functionalcheck only.
Operation 1.Adjustthe pressuretoobtainmaximumoutputsigna
l
forappropriaterange.
2.Outputshouldbe 20 mAor5or10 VDC.
3.Adjustthe pressuretoobtainminimumoutputsigna
l
4.Outputshouldbe 4mAor0VDC.
Note:The PR-274/275 isahighlyaccuratedevice.
Forapplicationsrequiring ahigh degree ofaccuracy
,
the useoflaboratoryqualitymetersand gaugesare
recommended.
0TO5VDC
+–0ZS
0to10 VDC
+–0ZS
OUTPUT
CONFIGURATIONS
Table-2Range ConfigurationsforLowPressureTransducers
withVDC Outputs.
A
Range
BC D EFGH
Range Configurations(inchesw.c.)
R2
R3
R4
0to.10 -0.05to
+0.05
0to1.0
0to5.0
0to30
0to0.5
0to2.5
0to15
0to0.25
0to1.25
0to7.5
-0.5to+0.5
-2.5to+2.5
-15.0to+15.0
-0.25to+0.25
-1.25to+1.25
-7.5to+7.5
-0.125to+0.125
-0.625to+0.625
-3.75to+3.75
A B CDEFGH
Range Configurations(pa)
0to25 -12.5to
+12.5
0to250
0to1250
0to7500
0to125
0to625
0to3750
0to62.5
0to312.5
0to1875
-125to+125
-625to+625
-3750to+3750
-62.5to+62.5
-312.5to+312.5
-1875to+1875
-31.25to+31.25
-156.25to+156.25
-937.5to+937.5
R1
Output
Configurations
0to
5VDC
0to
10 VDC
R
ange
R6
R7
R8
R5
Output
Configurations
0to
5VDC
0to
10 VDC

Figure-7PR-274/275LowPressureTransducerDimensionsshownininches
andmillimeters(mm).
ForTechnical/Application Assistance contactyournearestoffice.
MAMACSystemsInc.reservesthe righttochange anyspecifications
withoutnoticetoimproveperformance,reliability,orfunction ofour
products.TI.274/275-01
1.56”
(39.78)2.125”
(54.19)
4.50”(114.75)5.50”(140.25)
2.20”
(56.1)
5.00”(127.5)
4.00”
(102)
2.658”
(67.78)
3.250”
(82.88)
2.75”(70.12)2.75”(70.12)5.00”(127.5)
2.25”
(57.38)
1.125”
(28.69)
1.125”
(28.69)
PanelMountEnclosure
ModelPR-274/275
TechnicalInformation
TI.274/275-01
LowPressureTransducer
DimensionalData
Page 5of5

Model PR-274/275
Installation Instructions
IS.274/275-02
Low PressureTransducer - mA Output

Model PR-274/275
Installation Instructions
IS.274/275-02
Low PressureTransducer - VDC Output
