Manitowoc K00384 User manual

Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 000002675
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 1 of 3
Web Site - www.manitowocice.com 07/23/07
WARNING
The stand must be secured to the wall with the bracket and fasteners provided in this kit.
The security bracket must be attached to two studs.
The ice machine must be secured to the stand top cover with the supplied bolts (4) and washers (4).
The stand top cover must be secured to the stand with the screws (2) provided.
K00384 Ice Machine Stand
Installation Instructions
Material List
Cabinet Assembly
TOP
PANEL REAR
PANEL FRONT
PANEL BRACE
PANEL
(2)
SIDE
PANEL
(2)
CAP
PLUG
(4)
TOP
COVER
SCREWS
(2)
SUPPORT
ANGLE
(2)
LEG
(4) BASE TOP COVER BOLT (4)
WASHER (4)
SECURITY
BRACKET
BOLT (2)
WASHER (2)
NUT (2)
Step 1 - Slide side panels onto
base.
Step 2 - Place support angles
under the side panels.
Step 3 - Screw legs into the base
(through support angles & side panels).

Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 000002675
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 2 of 3
Web Site - www.manitowocice.com 07/23/07
Step 7 - Install top cover onto stand.
Step 8 - Install rear panel.
Step 9 - Move into position and level front to back and side to side.
Step 10 - Locate studs in wall and mark bracket screw locations (2 studs must be used).
Step 11 – Provide screws suitable for your building material and mount second ½ of bracket to wall.
WARNING
This stand must be secured to a wall to prevent tipping.
Step 4- Place brace panels on the
inside of the frame, engaging the hook
flanges of the brace to the rectangular
slots on the side panels.
Step 5- Place the top panel with the
rubber grommets along open sides.
Step 6- Install ½ of the security
bracket to stand.

Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 000002675
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 2 of 3
Web Site - www.manitowocice.com 07/23/07
Step 12- Move stand into position Step 13- Secure stand top to stand with provided screws
and secure 2 bracket halves with through the rear of the stand.
provided bolts, washers and nuts.
Step 14- Place ice machine on stand.
Step 15- Secure the ice machine to the stand with provided bolts and washers (access thru front door to align holes).
Step 16- Refer to Installation Use and Care Manual and install ice machine. Water, drain and electrical connections
can be made out the back or through the bottom of the ice machine.
Step 17 - Install removable front panel.
Secure With Screws
