Marantz DV110 User manual

vii
Model DV110 User Guide
DVD
/ Tuner
R
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
I.H.T. IEC 825

i
ENGLISH
WARRANTY
For warranty information, contact your local Marantz distributor.
RETAIN YOUR PURCHASE RECEIPT
Your purchase receipt is your permanent record of a valuable purchase. It
should be kept in a safe place to be referred to as necessary for insurance
purposes or when corresponding with Marantz.
IMPORTANT
When seeking warranty service, it is the responsibility of the consumer to
establish proof and date of purchase. Your purchase receipt or invoice is
adequate for such proof.
FOR U.K. ONLY
This undertaking is in addition to a consumer's statutory rights and does not
affect those rights in any way.
FRANÇAIS
GARANTIE
Pour des informations sur la garantie, contacter le distributeur local Marantz.
CONSERVER L'ATTESTATION D'ACHAT
L'attestation d'achat est la preuve permanente d'un achat de valeur. La
conserver en lieu sur pour s'y reporter aux fins d'obtention d'une couverture
d'assurance ou dans le cadre de correspondances avec Marantz.
IMPORTANT
Pour l'obtention d'un service couvert par la garantie, il incombe au client
d'établir la preuve de l'achat et d'en corroborer la date. Le reçu ou la facture
constituent des preuves suffisantes.
DEUTSCH
GARANTIE
Bei Garantiefragen wenden Sie sich bitte an Ihren Marantz-Händler.
HEBEN SIE IHRE QUITTING GUT AUF
Die Quittung dient Ihnen als bleibende Unterlage für Ihren wertvollen Einkauf
Das Aufbewahren der Quittung ist wichtig, da die darin enthaltenen Angaben
für Versicherungswecke oder bei Korrespondenz mit Marantz angeführt
werden müssen.
WICHTIG!
Bei Garantiefragen muß der Kunde eine Kaufunterlage mit Kaufdatum
vorlegen. Ihren Quittung oder Rechnung ist als Unterlage ausreichend.
NEDERLANDS
GARANTIE
Voor inlichtingen omtrent garantie dient u zich tot uw plaatselijke Marantz.
UW KWITANTIE, KASSABON E.D. BEWAREN
Uw kwitantie, kassabon e.d. vormen uw bewijs van aankoop van een
waardevol artikel en dienen op een veilige plaats bewaard te worden voor
evt, verwijzing bijv, in verbend met verzekering of bij correspondentie met
Marantz.
BELANGRIJK
Bij een evt, beroep op de garantie is het de verantwoordelijkheid van de
consument een gedateerd bewijs van aankoop te tonen. Uw kassabon of
factuurzijn voldoende bewijs.
ESPAÑOL
GARANTIA
Para obtener información acerca de la garantia póngase en contacto con su
distribuidor Marantz.
GUARDE SU RECIBO DE COMPRA
Su recibo de compra es su prueba permanente de haber adquirido un
aparato de valor, Este recibo deberá guardarlo en un lugar seguro y utilizarlo
como referencia cuando tenga que hacer uso del seguro o se ponga en
contacto con Marantz.
IMPORTANTE
Cuando solicite el servicio otorgado por la garantia el usuario tiene la
responsabilidad de demonstrar cuándo efectuó la compra. En este caso, su
recibo de compra será la prueba apropiada.
ITALIANO
GARANZIA
L’apparecchio è coperto da una garanzia di buon funzionamento della durata di
un anno, o del periodo previsto dalla legge, a partire dalla data di acquisto
comprovata da un documento attestante il nominativo del Rivenditore e la data
di vendita. La garanzia sarà prestata con la sostituzione o la riparazione gratuita
delle parti difettose.
Non sono coperti da garanzia difetti derivanti da uso improprio, errata
installazione, manutenzione effettuata da personale non autorizzato o,
comunque, da circostanze che non possano riferirsi a difetti di funzionamento
dell’apparecchio. Sono inoltre esclusi dalla garanzia gli interventi inerenti
l’installazione e l’allacciamento agli impianti di alimentazione.
Gli apparecchi verranno riparati presso i nostri Centri di Assistenza Autorizzati.
Le spese ed i rischi di trasporto sono a carico del cliente.
La casa costruttrice declina ogni responsabilità per danni diretti o indiretti
provocati dalla inosservanza delle prescrizioni di installazione, uso e
manutenzione dettagliate nel presente manuale o per guasti dovuti ad uso
continuato a fini professionali.
PORTUGUÊS
GARANTIA
Para informações sobre a garantia, contactar o distribuidor Marantz local.
GUARDAR O RECIBO DE COMPRA
O recibo é o registo permanente da compra que fez. Deve ser guardado num
local seguro, para ser apresentado em questões relacionadas com o seguro
ou para quando tiver de contactar a Marantz.
IMPORTANTE
Quando procurar assisténcia técnica ao abrigo da garantia, é da
responsabilidade do consumidor estabelecer a prova e data de compra. O
recibe é prova adequada.
SVENSKA
GARANTI
För information om garantin, kontakta Marantz lokalagent.
SPAR KVITTOT
Kvittot är ett inköpsbevis på en värdefull vara. Det skall förvaras säkert och
hänvisas till vid försäkringsfall eller vidkorrespondens mod Marantz.
VIKTIGT
Fö att garantin skall gälla är det kundens sak att framställa bevis och datum
om köpet. Kvitto eller faktura är tillräokligt bevis fö detta.
DANSK
GARANTI
Henvend dem til Deres MARANTZ-forhandler angående inrformation om
garantien.
GEM DERES KVITTERING
Deres købskvittering er Deres varige bevis på et dyrt køb. Den bør gemmes
godt og anvendes som bevis, hvis De vil tegne en forsikring, eller hvis De
kommunikerer med Marantz.
VIGTIGT
Det påhviler forbrugeren at skaffe bevis for købet og købsdatoen, hvis han
eller hun ønsker garantiservice. Deres købskvittering eller faktura er et
fuldgyldigt bevis herpå.

ii
CE MARKING
English
The DV110 is in conformity with the EMC directive and low-voltage directive.
Français
Le DV110 est conforme àla directive EMC et àla directive sur les basses tensions.
Deutsch
Das Modell DV110 entspricht den EMC-Richtlinien und den Richtlinien für Niederspannungsgeräte.
Nederlands
De DV110 voldoet aan de EMC eisen en de vereisten voor laag-voltage.
Español
El DV110 estáde acuerdo con las normas EMC y las relacionadas con baja tensión.
Italiano
Il DV110 èconforme alle direttive CEE ed a quelle per i bassi voltaggi.
Português
O DV110 conforma com as diretrizes EMC e de baixa voltagem.
Svenska
DV110 är tillverkad i enlighet med EMC direktiven och direktiven för lågvoltsutrusning.
Dansk
Model DV110 er i overensstemmelse med EMC-direktiveet og direktivet om lavspænding.
WARNINGS FOR LASER RADIATION
CAUTION : INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM.
DANGER : INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM.
VARO! : AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINANAKYMÄTTÖMÄALLE
LASERSÄTEILYLLE. ÄLÄKATSO SÄTEESEEN.
VARNING! : OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR
URKOPPLAD. BETRAKTA EJ STRALEN.
ENGLISH:
CAUTION –USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIA-
TION EXPOSURE.
FINNISH:
VAROITUS! Laitteen käyttäminen muulla kuin tässäkäyttöohjeessa mainitulla tavalla saattaa
altistaa käyttäjän turvallisuusluokan 1 ylittävuälle näkymättömälle lasersäteilylle.
SWEDISH:
VARNING! Om apparaten används påannat sätt än vad som beskrivs 1 denna bruksanvisning kan
användaren utsättas för osynlig laserstrålning som overskrider gränsen för laserklass 1 .

iii
English
To ventilate the unit, do not install the unit in a rack or bookshelf,
and note the followings.
- Do not touch the top of the enclosure during operation.
- Do not block the openings in the enclosure during operation.
- Do not insert objects beneath the unit.
- Do not block the ventilation slots at the top of the unit.
Do not place anything about 1 meter above the top panel.
- Make a space of about 0.2 meter around the unit.
Français
Pour que l'appareil puisse être correctement ventilé, ne pas
l'installer dans un meuble ou une bibliothèque et respecter
ce qui suit.
- Ne pas toucher le dessus du coffret.
- Ne pas obstruer les ouïes de ventilation du coffret pendant le
fonctionnement.
- Ne placer aucun objet sous l'appareil.
- Ne pas obstruer les ouães de ventilation du panneau supérieur. Ne placer
aucun objet à moins d'un mètre environ du panneau supérieur.
- Veiller à ce qu'aucun objet ne soit à moins de 0,2 mètre des côtés de
l'appareil.
Deutsch
Um eine einwandfreie Belüftung des Geräts zu gewährleisten,
darf das Gerät nicht in einem Gestell oder Bücherregal
aufgestellt werden; die folgenden Punkte sind besonders zu
beachten:
- Während des Betriebs das Oberteil des Gehäuses nicht berühren.
- Während des Betriebs die Öffnungen im Gehäuse nicht blockieren.
- Keine Gegenstände in das Gerät einführen.
- Die Belüftungsschlitze an der Oberseite des Geräts dürfen nicht blockiert
werden. Darauf achten, daß über dem Gerät ein Freiraum von mindestens
1 meter vorhanden ist.
- Auf allen Geräteseiten muß ein Zwischenraum von ungefähr 0,2 meter
vorhanden sein.
Nederlands
Installeer het toestel niet in een rek of boekenkast waar de
ventilatie mogelijk wordt gehinderd. Let tevens op de volgende
punten:
- Raak de bovenkant van het toestel niet aan als het in gebruik is.
- Blokkeer de openingen van het toestel niet als het in gebruik is.
- Plaats geen onderwerpen onder het toestel.
- Blokkeer de ventilatie-openingen aan de bovenkant van het toestel niet.
Zorg dat er tenminste 1 meter vrije ruimte boven het toestel is.
- Zorg dat er 0,2 meter vrije ruimte rond het toestel is.
Español
Para ventilar la unidad no la instale en una estantería ni
estante para libros, y tenga en cuenta lo siguiente:
- No toque la parte superior de la caja durante el funcionamiento.
- No tape las ranuras en la caja durante el funcionamiento
- No ponga objetos debajo de la unidad.
- No tape las ranuras de ventilación de la parte superior de la unidad. No
ponga nada a menos de 1 metro por encima del panel superior.
- Deje un espacio de unos 0,2 metro alrededor de la unidad.
Italiano
Perch é l'unità possa essere sempre ben ventilata, non
installarla in scaffali o librerie e tenere presente quanto segue.
- Non toccare la parte superiore del rivestimento durante il funzionamento.
- Non bloccare le aperture sul rivestimento durante il funzionamento.
- Non inserire oggetti al di sotto dell'unità.
- Non bloccare le fessure di ventilazione sopra l'unità.
Non posare nulla per circa un metro sopra il pannello superiore.
- Lasciare 0,2 metro liberi tutto intorno l'unità.
Português
Para ventilar o aparelho, não instalá-lo dentro duma estante
ou algo similar, e observar as seguintes recomendações:
- Não tocar a parte superior do aparelho durante a operação.
- Não bloquear as aberturas do aparelho durante a operação.
- Não insertar objectos debaixo do aparelho.
- Não bloquear as aberturas de ventilação na parte de cima do aparelho.
Deixar um espaço completamente livre de cerca de 1 metro acima do painel
superior.
- Deixar um espaço de cerca de 0,2 metro ao redor do aparelho.
Svenska
För att ventilera enheten, ställ den inte i ett ställ eller bokhylla
och tänk på följande.
- Vidrör inte ytterhöljets ovansida under pågående drift.
- Blockera inte öppningarna i ytterhöljet under pågående drift.
- Stick inte in föremål under enheten.
- Blockera inte ventialtionshålen ovanpå enheten.
Placera inte någonting närmare än 1 meter ovanför apparaten eller
enheten.
- Se till att det finns omkring 0,2 meter fri plats runt omkring enheten.
Dansk
Anbring ikke apparatet i et rack eller en boghylde, da dette kan
bloke luftcirkulationen omkring apparatet. Iagttag ligeledes
følgende:
- Berør ikke oversiden af kabinettet under anvendelsen.
- Bloker ikke åbningerne i kabinettet under anvendelsen.
- Stik ikke genstande ind under apparatet.
- Bloker ikke ventilationsåbningerne ovenpå apparatet.
Anbring ikke noget nærmere end 1 m over apparatets overside,
- Sørg for, at der er et frit område på omkring 0,2 m omkring apparatet.
This product incorporates copyright protection technology that
is protected by method claims of certain U. S. patents and
other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be Authorized by Macrovision
Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision
corporation. Reverse engineering or disassembly is prohibited.
Dolby Digital
The maximum 5.1 channels of audio used in the surround
system (Surround Digital) for movie theaters is digital data
compressed by the third generation algorithm encoder.
1
In order to enjoy Dolby Digital discs, this unit’s digital output
jack (either coaxial or optical) must be connected to the
digital input jack of an AV amplifier or Dolby Digital decoder
to enjoy the sound of Dolby Digital soundtracks.
DTS
DTS stands for Digital Theater System. DTS is a surround
system different from Dolby Digital that has become a
popular surround sound format for movies. In order to enjoy
the benefits of DTS encoded discs, the digital output jack
(either coaxial or optical) of this player needs to be connected
to an AV amplifier or receiver or to a DTS decoder to be able
to enjoy the surround sound of DTS audio. DTS audio is not
output from the analog audio outputs.
Manufactured under license from Dolby Laboratories. “Dolby”
and the double-D symbol are trademarks of Dolby Laboratories.
“DTS” and “DTS Digital Out” are trademarks of Digital Theater
Systems, Inc.

iv
DV110
STANDBY OPEN
STANDBY OPEN
/MODE
/MEMO
MENU TUNER
ENTER
MULTI JOG
PUSH ENTER
MEMO SLOW
PROGRESSIVE
CLEAR PROGRAM
TUNER
RC110DV
REMOTE CONTROLLER
SETUP
ENTER
RETURN ZOOM
TIMER NEWS/TA PTY
MODE
REPEAT A-B
RANDOM
DISPLAY
S.TITLE ANGLE
AUDIO
MENU
MENU
TOP
0
9
6
3
8
2
5
7
4
1
AMS
1 2 4 5
3
6 7 8 9 10 11 12 13 14 15
A B C D E F G H
I J K
1
18
20
21
22
24
25
26
28
29
2
4
6
7
8
9
11
12
13
14
15
3
5
10
16
17
19
23
27

1
ENGLISH
TABLE OF CONTENTS
FOREWORD ........................................................ 2
EQUIPMENT MAINS WORKING SETTING ........................ 2
COPYRIGHT ........................................................................ 2
FEATURES .......................................................... 2
ABOUT DISCS .................................................... 3
PLAYABLE DISCS ............................................................... 3
NOT PLAYABLE DISCS ....................................................... 3
VIDEO FORMAT .................................................................. 3
ABOUT DVD DISCS ............................................................ 3
ABOUT VIDEO CDS ............................................................ 4
ABOUT AUDIO CD .............................................................. 4
ABOUT MP3 ........................................................................ 4
COMPACT DISCS ............................................... 4
REMOTE CONTROL UNIT .................................. 5
OPERATION OF REMOTE CONTROL UNIT ...................... 6
MAIN UNIT........................................................... 7
FRONT PANEL .................................................................... 7
REAR PANEL ....................................................................... 8
CONNECTIONS................................................... 9
PRECAUTIONS CONCERNING CONNECTIONS .............. 9
CONNECTING THE MARANTZ EQUIPMENT
(PS110, DR110, MD110) ...................................................... 9
CONNECTING OTHER AUDIO EQUIPMENT ................... 10
BASIC OPERATIONS ....................................... 11
PREPARATION .................................................................. 11
PLAYING A DISC ............................................................... 11
TO PAUSE PLAYING ......................................................... 12
TO STOP PLAYING ........................................................... 12
DIRECT SEARCH .............................................................. 13
SKIP PLAY ......................................................................... 13
SEARCH PLAYING ............................................................ 13
DVD MENU ........................................................................ 13
PLAYING VCD DISCS WITH PBC FUNCTION ................. 13
PLAYING MP3 ................................................................... 14
SWITCHING INFORMATION ON FL DISPLAY ................. 14
VARIOUS PLAYING FUNCTIONS .................... 15
SLOW PLAY ....................................................................... 15
FRAME-BY-FRAME PLAY ................................................. 15
REPEAT PLAY ................................................................... 15
A-B REPEAT PLAY ............................................................ 16
RANDOM PLAY ................................................................. 16
AMS (AUTO MUSIC SCAN) PLAYING .............................. 17
PROGRAM PLAY ............................................................... 17
CHANGING ANGLES ........................................................ 18
ZOOM FUNCTION ............................................................. 18
CHANGING AUDIO TRACKS ............................................ 18
SWITCHING AUDIO CHANNELS ...................................... 18
CHANGING SUBTITLE LANGUAGES .............................. 18
TUNER OPERATION ......................................... 19
TO LISTEN TO THE RADIO .............................................. 19
PRESET MEMORY OPERATION ...................................... 19
SELECTING PRESET CHANNEL ..................................... 20
SWITCHING RECEIVING MODE ...................................... 20
RECEPTION OF RDS BROADCASTING .......................... 21
SETUP MENU OPERATION ............................. 23
CONTENTS OF SETUP MENU ......................................... 23
LANGUAGE SETUP .......................................................... 23
VIDEO SETUP ................................................................... 25
AUDIO SETUP ................................................................... 27
RATINGS SETUP .............................................................. 28
OTHERS SETUP ............................................................... 29
LANGUAGE CODE LIST ................................................... 30
USING THE TIMER FUNCTIONS ...................... 31
SETTING TIME .................................................................. 31
TIMER PLAYBACK ............................................................ 31
SETTING AND CLEARING TIMER PLAYBACK ................ 32
INITIALIZE (RESET ALL).................................. 32
TROUBLE SHOOTING ...................................... 33
MAINTENANCE................................................. 33

2
ENGLISH
FOREWORD
This section must be read before any connection is made to the
mains supply.
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
Do not insert anything into the equipment through the
ventilation holes.
Do not handle the mains lead with wet hands.
Do not cover the ventilation with any items such as
tablecloths, newspapers, curtains, etc.
No naked flame sources, such as lighted candles, should
be placed on the equipment.
When disposing of used batteries, please comply with
governmental regulations or environmental public
instruction's rules that apply in your country or area.
EQUIPMENT MAINS WORKING SETTING
Your Marantz product has been prepared to comply with the
household power and safety requirements that exist in your
area.
DV110 can be powered by 230 V AC only.
COPYRIGHT
Recording and playback of any material may require consent.
For further information refer to the following:
- Copyright Act 1956
- Dramatic and Musical Performers Act 1958
- Performers Protection Acts 1963 and 1972
- any subsequent statutory enactments and orders
FEATURES
• DVD Player with FM/AM Tuner
• RDS Function
• Preset channel 30
• Play back DVD/VCD/CDDA/CD-R/CD-RW/MP3
• 10 bit/27 MHz Video DAC
• 24 bit/192 KHz Audio DAC
• Timer (Daily)

3
ENGLISH
ABOUT DVD DISCS
Marks on packages
The marks listed below indicate contents in a disc.
Indicates the number of recorded audio tracks.
Indicates the number of recorded subtitle languages.
Indicates the number of recorded angles.
Indicates the selectable aspect ratios.
Indicates the region number of the disc.
Regional restriction codes (region number)
Regional restriction codes are built in to DV110 player and DVD
discs for each sales region. If the regional code of the DV110
player does not match one of the regional codes of the DVD
disc, playback is not possible.
The region number can be found on the rear panel of the
DV110 player. The illustration below shows the regions and
corresponding region numbers.
Structure of DVD discs
Depending on the material on the disc (a movie, video clips, a
drama series, etc.), these discs may have one or more Titles,
and each Title may have one or more Chapters. To make
access easy and convenient, your player lets you move
between Titles and between Chapters.
ABOUT DISCS
PLAYABLE DISCS
DVD
DVD-R
Finalized DVD disc recorded in the DVD
video format.
Video CD (VCD)
Audio CD (CD-DA)
CD-R/CD-RW
Finalized CD-R and CD-RW discs recorded
in the CD-DA format, MP3 format (☞p4) or
Video-CD format can be played with the unit.
Nevertheless, some discs may not be able to
be played depending on condition of the
discs.
* Finalize is the process to make a DVD-R or CD-R/CD-RW
playable for players (not recorders)
NOT PLAYABLE DISCS
• DVD discs whose region number is not “2” nor “ALL”.
• DVD-RW
• DVD-ROM
• DVD-RAM
• DVD-Audio
• DVD+RW
• CD-ROM
• CDV
• CD-G
• CVD
• Super Audio CD
• CD Photo, etc.
VIDEO FORMAT
This player can handle with MULTI, NTSC or PAL format.
Caution
This player cannot handle with NTSC4.43 and SECAM
formats.
Setting picture format
1. Press the PROGRESSIVE(MEMO) button @7 on the remote
for 3 seconds while in the stop mode.
• Every time the PROGRESSIVE button @7 is pressed,
picture format changes in the following order.
MULTI NTSC PAL
Caution
• If wrong color or disordered picture appears in the MULTI
mode, switch the mode to NTSC or PAL.
• If a disc recorded in PAL(NTSC) is played in the NTSC(PAL)
mode, picture may be disordered.
• This player does not support the progressive video output.
2
2
4
16 : 9 LB
2
ALL

4
ENGLISH
ABOUT VIDEO CDS
Variations of Video CD
•Video-CD Version 2.0
The Video-CD with PBC (Play Back Control : Menu playback
function) function. You can choose or search a section to play
with a menu displayed on the TV screen. Also still pictures
can be displayed in higher quality.
•Video-CD Version 1.1
The video-CD without PBC function. It can play video and
audio by operation much like to the ordinal audio-CD.
Structure of Video-CD discs
Depending on the material on the disc (a movie, video clips, a
drama series, etc.), these discs may have one or more tracks,
and tracks may have one or more indexes, as indicated on the
disc case. To make access easy and convenient, your player
lets you move between tracks and between indexes.
ABOUT AUDIO CD
Structure of Audio CD
Audio CDs contain music tracks only.
You can play them in conventional style through a stereo
system, using the keys on the remote control and/or front panel.
ABOUT MP3
MP3 is the compressed music file in MPEG1, Audio Layer 3
format.
MP3 playback
•This player can play MP3 discs recorded in ISO9660 format.
•The player plays the files with '.mp3' extension only.
•The maximum file number in a disc is 999. (Including the
number of folders.)
•The maximum folder layer number is 8.
•When playing a MP3 disc, it may take more than 30 seconds
depending on the number of files and folder layer structure.
•When playing MP3 files, the 5buttons on the player and on
the remote do not work.
COMPACT DISCS
The glossy side shining like a rainbow is the front side of the
disc, and the side on which the label is printed is the back.
Unlike conventional turntables for playing analog discs, the
DV110 reads the information recorded on the disc from
underneath without contacting it using a beam of laser light.
Therefore, the performance of a compact disc will not degrade
like conventional analog records.
Handle discs carefully so as not to damage or scratch the
front side.
To protect the disc, avoid placing it in the following locations:
•In direct sunlight or near a source of heat like a heater.
•In a place which is damp or dirty.
•In a place which could be exposed to rain, such as near a
window.
Always keep the disc surface clean.
Up to six billion data units are recorded on the front side of the
disc. When cleaning the disc surface, always be sure to use a
special compact disc cleaner and wipe as shown below.
•Do not use conventional record cleaner for analog records,
as this will adversely affect the disc surface.
Store discs properly by placing them in their disc cases.
•Do not attach a piece of paper or sticker on the label side of
disc. When a disc has a piece of plastic tape or rental DVD/
CD label with paste protruded from the edge or when a disc
has a trace of such a sticky object, do not attempt to play the
disc. If such a disc is played on the DVD player, impossibility
of taking out the disc or other malfunction may result.
•Do not use a disc with a special shape.
Do not attempt to play a disc with a special shape such as a
heart-shaped disc or octagonal disc. Otherwise the
equipment malfunction may result.

5
ENGLISH
REMOTE CONTROL UNIT
qSTANDBY button
•Press to switch the power ON, and press again to switch it
OFF.
•If the PS110 is connected to the REMOTE CONTROL jacks
on the rear panel and its power is ON, the unit will not be set
to the standby mode even when this button is pressed.
wTUNER button
•Press to mode change from DVD mode to TUNER mode.
•Press two times to change tuner band (FM/AM).
eREPEAT button
•Press for repeat play. Each time the button is pressed, the
mode changes in the following sequence:
1-chapter(track) repeat Title(all track) repeat
clear
rAMS button
•Press to play the first 10 seconds of all the tracks on the disc
in sequence starting with the first track.
tAUDIO button
•Press this button to switch audio track (language) to another
track (language) in the DVD mode.
•The function of this button changes depending on the loaded
disc.
•This button cannot be used with MP3 discs.
yANGLE button
•If the playing DVD disc contains multi-angle video, press this
button to select another angle.
uNumeric (ten keypad) buttons
• You can select a chapter number directly by pressing a
numeric button after pressing DISPLAY button !9 while in play
or stop DVD.
•For VCD or CD discs, press to specify track number directly
in the disc play or stop mode.
• Press to specify preset channels directly in the TUNER mode.
•These buttons cannot be used with MP3 discs.
iTOP MENU button
•Press this button to display the title screen in a DVD disc.
This button is to show the title menu screen of DVD discs that
contain multiple titles.
o9(Stop) button
•Press to stop playback.
• In the tuner mode, press this button to turn into the DVD mode.
!0 SETUP button
•Press this button to display the setup menu.
!1 Cursor (3,4,1, 2) buttons
• Press this button to select an item on the menu or title screen.
!2 ZOOM button
•Press this button to enlarge picture. (This function may be
disabled depending on discs.)
!3 ,/ .(Slow) buttons
• Press this button for slow forward/backward playback chapter.
!4 5/ 6button
•Press this button for fast forward/rewind playback of the
currently playing chapter(DVD) or track(Video-CD/CD).
•When in TUNER mode, this button is to select the received
frequency.
Note:
5button is unavailable for MP3.
!5 PTY, CLEAR button
• Press this button to select a program type of RDS (Tuner-FM).
•Press this button to cancel a programmed track (CD).
Note:
To select PTY and NEWS/TA, press 4 / ¢ buttons @8. To
decide the selection, press MEMO button @7. Cursor buttons
!1/.and ENTER button @4/,does not work.
!6 NEWS/TA , PROGRAM button
•This button is used to select the TA (Traffic Announcement)
in RDS function or NEWS in the PTY (Program Type) of RDS
function when FM function is selected.
•Press this button to program tracks for program play.
Note:
To select PTY and NEWS/TA, press 4 / ¢ buttons @8. To
decide the selection, press MEMO button @7. Cursor buttons
!1/.and ENTER button @4/,does not work.
!7 A-B Repeat button
•Used to set the starting and stopping points of a passage for
repeated playback.
!8 RANDOM button
• Press for random play to play the tracks in a random sequence.
!9 DISPLAY button
•This button is used to change the disc information or present
time. A present time can be also displayed for 10 seconds in
standby mode.
•A present time can not be displayed if PS110 is connected
through the REMOTE CONTROL bus and set the system
switch to EXT (System connection activates).
@0 S.TITLE button
•Press this button to select another subtitle language.
•The function of this button changes depending on the loaded
disc.
@1 MENU button
•Press this button to display the menu in a DVD disc.
@2 2(Play) button
•Press to start playback.
• In the tuner mode, press this button to turn into the DVD mode.

6
ENGLISH
@3 ;(Pause) button
•Press to stop for play temporarily.
@4 ENTER button
•Press this button to decide an item selected with the cursor.
• In the tuner mode, press this button to turn into the DVD mode.
• Press this button to decide clock setting and timer play setting.
@5 RETURN button
•When PBC function is on and the menu in a VCD 2.0 disc is
displayed, press this button to return to the previous menu
item.
•Press this button to quit setup menu.
@6 MODE button
• This button is used to select for TUNER mode.
Normal frequency display Preset mode
RDS mode Receiving mode
•To select tuner mode or a preset channel, press 4/ ¢
buttons @8. To decide the selection, press MEMO button @7.
@7 MEMO/PROGRESSIVE button
•This button is used to set the preset memory.
•Press this button to decide TUNER mode.
•Press this button more than 3 seconds in DVD mode to
switch the picture format PAL/NTSC.
Note:
Progressive function cannot be used.
@8 4 / ¢ button
•Press this button to skip to next/previous chapter(DVD) or
track(Video-CD/CD).
•When in TUNER mode, this button is to select the preset
channel, receiving mode or RDS.
@9 TIMER button
•Press to set the timer and clock. (These settings can be
performed only when the unit is used on its own.)
OPERATION OF REMOTE CONTROL UNIT
1. REMOTE CONTROL
The distance between the transmitter of the remote control unit
and the IR SENSOR of the DV110 should be less than about 5
meters. If the transmitter is pointed to a direction other than the
IR SENSOR or if there is an obstacle between them, remote
control may not be possible.
Remote-controllable range
(Condition is door open.)
60
2. LOADING BATTERIES
The life of the batteries used with the remote control unit is about
6 months with normal use. Also be sure to replace batteries
earlier when you notice that they are getting weak.
1. Remove the back cover.
2. Insert the new batteries (AAA type) with correct (+) and (–)
polarity.
3. Close until it clicks.
Approx. 5 meters

7
ENGLISH
MAIN UNIT
FRONT PANEL
zSTANDBY button
•Press to switch the power ON, and press again to switch to
STANDBY mode.
•If the PS110 is connected to the REMOTE CONTROL jacks
on the rear panel and its power is ON, the unit will not be set
to the standby mode even when this button is pressed.
x9(Stop) button
•Press to stop playback.
• In the tuner mode, press this button to turn into the DVD mode.
cDisc tray
•Place a disc on the tray with its label surface facing up.
v2/ ;(Play/Pause) button
•Press to start for play or temporarily stop for play.
• In the tuner mode, press this button to turn into the DVD mode.
bOpen button
•Press to open the front door.
nTUNER button
•Press to mode change from DVD to TUNER.
•Press two times to change tuner band (FM/AM).
mMENU button
•This button is to recall the menu information in a DVD disc.
,ENTER button
•This button is to decide an item selected with the cursor.
• In the tuner mode, press this button to turn into the DVD mode.
.Cursor (3,4,1, 2) buttons
•This button is to select an item on the menu, etc.
⁄0 Display panel
•This panel displays the operating modes and statuses.
⁄1 6/ MODE button
•Press this button to fast forward the disc while playing.
•Also this button is to change the tuner mode.
Normal frequency display Preset mode
RDS mode Receiving mode
⁄2 5/ MEMO button
•Press this button to fast rewind the disc while playing.
•Also this button is used for preset memory.
Note:
5button is unavailable for MP3.
⁄3 Infrared sensor
•This sensor is for receiving signals transmitted from the
remote control unit.
⁄4 MULTI JOG
•When playing a disc, this dial is to skip to next or previous
chapter(track).
•When in tuner mode, this dial is to select the received
frequency.
•In the preset mode, you can select a preset channel with this
dial.
•In RDS, you can select PTY with this dial.
•You can select the receiving mode (AUTO/MONO) with this
dial.
•To decide your selection, press this dial.
⁄5 /(Open/Close) button
•When this button is pressed, the disc tray opens so place the
disc on the tray with its label surface facing up. When it is
pressed again the disc tray closes.

8
ENGLISH
REAR PANEL
AAM antenna terminal
•To connect the supplied AM loop antenna, use the terminals
marked "AM" and "GND". (☞p10)
•In areas where the AM loop antenna gives unsatisfactory
results, it is recommended that the receiver be connected to
an outdoor antenna. Use the terminal marked 'AM' for this. A
grounding lead can be connected to the terminal marked
'GND' to further reduce interference. In this case, it must be
connected together with the supplied loop antenna.
BAnalog output jacks
•Connect to the audio input jacks of an amplifier.
CVideo input jack
•Connect to the video signal output terminals of a video
equipment (TV-Tuner, VCR, etc.).
Note:
This video input jack is used only when the player is system-
connected with PS110. This jack cannot be used when the
player is used in stand-alone.
DSystem selector switch
•This switch selects the system operation mode.
• Set to EXT position when DV110 is being used in combination
with a AV amplifier (PS110), CDR (DR110) or MD (MD110).
•If your component is not capable of system connection, set
this switch to INT position.
ES-Video output jack
•Connect to the S-video input terminals of an AV amplifier,
VCR.
FDigital out COAX jacks
•The DVD , CD signals during playback are output digitally to
these jacks.
•Connect these jacks to a PS110 DVD (digital) input or other
recorder component with coaxial digital input jacks.
GScart connector (Euroconnector)
•Euroconnector for connection to a TV with euroconnector.
•The video signal formats output from the SCART terminal are
S-Video and Composite. RGB signal is not supported.
HPower cord cable
•Connect this to a household AC 230 V outlet.
IFM antenna terminal
•For connecting an external FM antenna with a circular plug,
or for connecting a cable network. (☞p10)
JRemote control jacks
•Connect to a component equipped with remote control jacks.
(☞p9)
KVideo output jack
•Connect to the video input terminals of an AV amplifier, VCR.

9
ENGLISH
CONNECTIONS
PRECAUTIONS CONCERNING CONNECTIONS
• Use only a 230V AC power source. Using any other power source could cause a fire or electric shock.
• Always grasp the power plug when unplugging or plugging in the power cord.
• Complete all connections before plugging in the power cord.
• Be sure to make a distinction between the left (white) and right (red) audio cable plugs when connecting them.
• When connecting this unit to other audio equipment, read the operation manual for that equipment carefully for details on how to
make the correct connections.
CONNECTING THE MARANTZ EQUIPMENT (PS110, DR110, MD110)
MODEL NO. PS110
R
L
TUNER TV/VCR IN
DVD
IN-CDR/MD-OUT
REMOTE
CONTROL
SELECTOR
SYSTEM INT.
SPEAKER
SYSTEM
(6-16 OHMS)
COAX. OPT. IN OUT PRE OUT
DIGITAL
IN
FRONT RL SURROUND RL CENTER
REMOTE
CONTROL SUB WOOFER
ANALOG
- INOUT-
REMOTE CONTROL DIGITAL IN
LEFT
RIGHT
IN
OUT
SELECTOR
EXT. INT.
OPT.
COAX.
MODEL NO. MD110
ANALOG
- INOUT-
REMOTE CONTROL
DIGITAL IN
LEFT
RIGHT
IN
OUT
SELECTOR
EXT. INT.
OPT.
COAX. MODEL NO. DR110
VIDEO
OUT
EUROCONNECTOR
IN
VIDEO
IN
VIDEO
IN
DV110
PS110
DR110
MD110
FM feeder antenna FM external antenna AM loop antenna VCR TV
IEC type converter plug (attached)
• When using the FM antenna attach to this
apparatus.
White
Black

10
ENGLISH
Connecting the supplied FM antenna
The supplied FM antenna is for indoor use only.
During use, extend the antenna and move it in various directions
until the clearest signal is received.
Fix it with push pin or similar implements in the position that will
cause the least amount of distortion.
Connecting the supplied AM loop antenna
The supplied AM loop antenna is for indoor use only.
Set it in the direction and position where you receive the clearest
sound. Put it as far away as possible from the unit, televisions,
speaker cables, and power cords.
1. Press and hold down the lever of the AM antenna terminal.
2. Insert the bared wire into the antenna terminal.
3. Release the lever.
1.
3. 4.
2.
CONNECTING OTHER AUDIO EQUIPMENT
Assembling the AM loop antenna
1. Release the vinyl tie and take out the connection line.
2. Bend in the reverse direction.
3. Inserting into the hole to attach the loop antenna to the
antenna stand.
4. With the antenna on top any stable surface.
LEFT
RIGHT
RIGHT
LEFT
ANALOG IN
LEFT
RIGHT
DIGITAL COAX. OUT DIGITAL OPT OUT
ANALOG
OUT IN
DIGITAL COAX. IN DIGITAL OPT IN
VIDEO
OUT
EUROCONNECTOR
IN
VIDEO
IN
VIDEO
IN
DV110
FM feeder antenna FM external antenna AM loop antenna VCR TV
IEC type converter plug (attached)
•When using the FM antenna attach to this
apparatus.
Amplifier
CD-Recorder
White
Black

11
ENGLISH
BASIC OPERATIONS
For operations for specific disc types, the disc type marks (
DVD VCD CD MP3
) are shown beside the operations.
If no mark is shown, the operation is for all disc types.
Note:
If the player is in the tuner mode, press 9, 2or ENTER button
@4/,to turn into the DVD mode.
PREPARATION
DVD VCD
1. Turn on power of TV.
2. Set the input source of the TV to the player.
PLAYING A DISC
1. Press the STANDBY button q/zto turn the power ON.
•The display will be like below.
↓
2. Press OPEN button bto open the Front door.
3. Press /button ⁄5 on the main unit to open the disc tray.
4. Insert a disc in the tray, label side up.
5. Press /button ⁄5 on the main unit to close the tray.
6. Press the 2button @2/vto start the play.
DVD
For DVD playback, FL Display will be like below. If DVD
menu is displayed on the TV screen, see “DVD menu”
page (☞p13).
VCD
For VCD playback without PBC function FL Display will
be like below. For VCD playback with PBC function, see
“Playing VCD discs with PBC function”page (☞p13).
CD
For Audio CD playback, FL Display will be like below.
MP3
For MP3 playback, FL Display will be like below. See
“Playing MP3”page (☞p14).
•If there is no MP3 file(track) in a folder, the level goes
one step under for MP3 discs.

12
ENGLISH
TO PAUSE PLAYING
1. Press the ;button @3/v.
To resume playing, press the 2button @2/v.
TO STOP PLAYING
1. Press the 9button o/x.
Resume Function
DVD VCD
The player can memorize the position where the playback is
stopped for DVD and VCD discs. With this function, playback
can be started from the position where the playback was
stopped.
•When 9button o/xis pressed, FL Display will be like
below.
•When 2button @2/vis pressed, playback is resumed at
the stopped position.
Deactivate Resume Function
DVD
VCD
•After stopping playback (Resume status displayed),
press 9button o/xagain to deactivate the resume
function.
• Press 2button @2/vto start playback from the beginning.
CD
For Audio CD discs, FL Display is like below in stop mode.
MP3
For Audio MP3 discs, FL Display is like below in stop
mode.
For MP3 discs, press 9button o/xagain to go one
level higher.

13
ENGLISH
DIRECT SEARCH
Using the numeric buttons
In playback and stop modes, you can choose a chapter(track)
directly by pressing a numeric button on the remote.
1. In DVD mode, you can select a chapter number directly by
pressing a numeric buttons u(0 to 9) on the remote control
after pressing the DISPLAY button !9.
Specify the track number using the numeric buttons u(0 to
9) on the remote control in the VCD or CD mode.
Chapter 3 : Press numeric button "3".
Track 12 : Press numeric button "1" and then numeric
button "2" within two seconds.
2. After selecting a chapter(track), press the ENTER button @4/
,to play the chapter(track).
Note :
This operation does not work with MP3 discs.
Using the MULTI JOG dial
In playback and stop modes, you can choose a chapter(track)
directly by rotating the MULTI JOG dial on the main unit.
1. Select the chapter(track) number by turning the MULTI
JOG dial ⁄4.
Once a chapter(track) number has been selected, that it
begins playing automatically.
•To move to a later chapter(track), turn the MULTI JOG
dial ⁄4 to the right.
•To go back to the beginning of the current chapter(track)
or to select an earlier chapter(track), turn the MULTI
JOG dial ⁄4 to the left.
SKIP PLAY
1. While playing, press 4button or ¢button @8 on the remote
to skip to the previous or next chapter (track).
•Every time ¢ button @8 is pressed, the player skips to
the next chapter (track).
•If 4 button @8 is pressed once, the player skips to the
beginning of the current chapter(track). If the button is
pressed more than 2 times, the player skips to the
previous chapter(track) every time the button is pressed.
SEARCH PLAYING
1. While playing, press 5⁄2 button or 6⁄1 button !4 for fast
rewind or fast forward play.
•Every time 5⁄2 button or 6⁄1 button !4 is pressed,
playing speed changes as shown below.
Note:
5button !4/⁄2 is unavailable for MP3.
Normal play 2X 4X 8X
16X32X64X
Normal play 2X 4X 6X
DVD
Normal play 2X 4X 6X
8X
MP3
VCD
CD
2. Press 2button @2/vto return to normal play.
DVD MENU
DVD
Most of DVD discs have their own menu screen (DVD menu). In
this menu, you can choose a chapter, audio language, subtitle,
etc.
1. Insert a DVD disc. The menu will be displayed on TV. If
menu is not displayed, press MENU button @1/mon the
remote.
2. Press Cursor button !1/.to select a chapter (menu item).
3. Press ENTER button @4/,to confirm the item.
• If a chapter is selected, the chapter is played automatically.
•If an audio language or subtitle is selected, press 2
button @2/vto start playback from the beginning.
• Press MENU button @1/mto return to the previous menu.
PLAYING VCD DISCS WITH PBC FUNCTION
VCD
VCD discs with PBC function will not be played by pressing 2
button @2/v.
When a disc is loaded, the menu is displayed automatically.
1. Specify the menu number using the numeric buttons u(0
to 9) on the remote control.
2. After selecting a chapter(track), press the ENTER button @4/
,to play the chapter(track).
Display Menu
• While playing, press RETURN button @5 to display menu screen.
•In Stop mode, press 2button @2/vto display menu screen.
Disable PBC function
You can disable PBC function to play VCD discs without
displaying menu, like an Audio CD. To disable PBC function, go
to the setup menu of the player.
See “Setup menu operation”page (☞p23).
1. After disabling PBC function, press a number button on the
remote to select a track. The track will be played.

14
ENGLISH
PLAYING MP3
MP3
If discs in MP3 format is loaded, menu screen is displayed on
TV automatically. This menu shows folder and file (track)
names that are given with a PC, etc.
•Folder and file names are shown up to 10 characters. ID3
tag information is not shown.
•Characters except “A-Z”, ”0-9”, ”_”are not displayed
correctly.
•The order shown in the menu may not be the same to the
order shown in a PC.
001
004.mp3
005.mp3
006.mp3
003
011.mp3
012.mp3
013.mp3
002
007.mp3
008.mp3
009.mp3
010.mp3
XXX.mp3
1. When a disc is loaded, menu screen is displayed on TV. If
menu is not displayed, press MENU button @1/mon the
remote.
2. Choose a track by pressing a Cursor button !1/..
3. Press ENTER button @4/,to confirm the selected track.
•If the track is confirmed, it is played automatically.
•To select a track while playing MP3, press 4 or ¢
button @8 on the remote.
Cautions on Discs in MP3 Format.
•This player can handle with the multi-session.
If there are many sessions, it may take much time to start
playing. To record MP3 discs, make the number of sessions
as few as possible.
•This player cannot play MP3 files recorded in 32kHz
sampling frequency. Record MP3 files in 44.1kHz sampling
frequency, 128kbps bit rate.
: Folder
: File (track)
SWITCHING INFORMATION ON FL DISPLAY
Information on the FL Display, such as time clock or remaining
time, can be changed by pressing DISPLAY button !9 on the
remote.
Caution
Time clock is not displayed when the player is in the System
Connection.
1. Every time DISPLAY button !9 on the remote is pressed,
information displayed is changed in the following order.
Title Playing Time
Clock
Title Playing Time
Title remain
Chapter playingChapter remain
Playing Time Track remain
Clock Total remain
Playing Time Track remain
Clock
Playing Time Track remain
Clock
DVD
VCD
CD
MP3

15
ENGLISH
VARIOUS PLAYING FUNCTIONS
SLOW PLAY
DVD
1. While playing, Press ,button or .button !3 on the remote
for slow backward play or slow forward play.
• Press .button !3 for slow forward.
• Press ,button !3 for slow backward.
•
Every time ,/ .button !3 is pressed, slow speed changes
in 4 steps.
Normal play 1/2 1/4 1/8
Caution
• In slow play, there is no audio
2. To return to normal play, press 2button @2/v.
FRAME-BY-FRAME PLAY
DVD
1. While playing, press ;button @3/vto still the picture.
2. Press 5⁄2 button or 6⁄1 button !4 to step the frame backward
or forward.
• Press 6button !4/⁄1 to step the frame forward.
• Press 5button !4/⁄2 to step the frame backward.
Caution
• In frame-by-frame play, there is no audio
REPEAT PLAY
Each time REPEAT button eis pressed, repeat mode is changed
in the following order.
1-chapter(track) repeat Title(all track) repeat
clear
Caution
For repeat play on VCD discs with PBC function, disable
PBC function first.
1. Play the title or chapter(track) you want to repeat.
2. Press REPEAT button eon the remote once.
• For DVD discs, currently played chapter is repeated.
DVD
• For VCD, Audio CD and MP3 discs, currently played
track is repeated.
VCD
CD
MP3
3. Press REPEAT button eon the remote once again.
• For DVD discs, currently played title is repeated.
DVD
• For VCD and Audio CD discs, the entire disc is repeated.
VCD
CD
• For MP3 discs, the folder is repeated.
MP3
4. Press REPEAT button eon the remote again to clear the
repeat.
