Mark Fitness XM-7618 User manual

Owner’s Manual
XM-7618
LAT MACHINE

Table of Contents
3
4
5-12
13
14
Important Safety Information
Before You Start
Assembly
Parts List
Exploded View
2

NOTE: Hand tighten bolts and nylon nuts until machine is fully
assembled.
SAFETY PRECAUTIONS
SAFETY INFORMATION WARNING!
Prior to assembly, remove components from the box and verify that all the listed parts
were supplied.
Before using this unit or starting any exercise program, consult your physician.
This is especially important for persons over the age of 35 and/or persons with pre-
existing health problems. XMARK Fitness assumes no responsibility for personal
injury or property damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit have read the
Owner’s Manual and are familiar with safety information and precautions.
•This unit should only be used on a level surface and is intended for indoor use
only. XMARK Fitness recommends an equipment mat be placed under the unit to
protect the floor or carpet and for easier cleaning.
•Wear comfortable, good-quality walking or running shoes and appropriate cloth-
ing. Do not use this unit with bare feet, sandals, socks or stockings!
•Always examine your unit before using to ensure all parts are in working order.
•Do not leave children unsupervised near or on the unit.
•Service to your unit should only be performed by an authorized service represen-
tative, unless authorized and/or instructed by a XMARK Fitness technician. Failure
to follow these instructions will void the warranty.
Important Safety Information
3

MODEL: XM-7618
When calling please have the following product information available:
Model Name :
Date Mfg.:
Serial #
Model Name Decal Location
Before You Start
QUESTIONS?
CALL 1-800-719-4605
Monday-Friday
8:30 a.m.-5:00 p.m.
(Central Standard Time)
4
THANK YOU for making this unit a part of your exercise
program.
XMARK Fitness assures the very best in value,
appearance, durability and biomechanics.
XMARK FITNESS SERIES
This manual will guide you through the assembly process. If at any time you
are having trouble with the assembly or use of this product, then please contact
us at our
XMARK Fitness help line. We have trained service technicians on site to
take care of you, our valued customer.
Visit www.xmarkfitness.com for warranty information

Assembly
5

Assembly
NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.
Step 1
Connect Main Base (#1) to the Rear Base (#2) using:
•two M10*80 Button Head Cap Screw (#34)
•four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37)
Attach two Guide Rods (#9) to the Rear Base (#2) using:
•two M10*25 Button Head Cap Screw (#36)
•two Φ11*Φ20*2 Flat Washer (#31)
6

Assembly
NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.
Step 2
Slide Weight Bumppers (#24) and Slide Weight Support (#12) onto guide rods (#9) as shown.
Connect Upright (#3) to the Main Base (#1) using:
•two M10*75 Button Head Cap Screw (#33)
•four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37)
Attach Seat Support (#6) to Main Base (#1) using:
•two M10*75 Button Head Cap Screw (#33)
•four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37)
7

Step 3
Slide Top Cross Frame (#5) on top of Guide Rod (#9) and secure using:
•two M10*25 Button Head Cap Screw (#36) •two Φ11*Φ20*2 Flat Washer (#31)
Attach Top Frame (#4) to the Upright (#3) using:
•two M10*75 Button Head Cap Screw (#33) •four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37)
Attach Top Frame (#4) to the Top Cross Frame (#5) using:
•two M10*80 Button Head Cap Screw (#34) •four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37)
Attach Lat Bar Hook GYM (#8) to Top Frame (#4) using:
•one M10*65 Button Head Cap Screw (#32) •two Φ11*Φ20*2 Flat Washer (#31)
•one M10 Nylon Locknut (#37)
8
Assembly
NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.

Assembly
NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.
Step 4
Start by attaching the High Pully Cable (#15) to Slide Weight Support (#12) using:
•one 1/2"-12 Jam Nut (#44)
Attach one Big Pulley (#21) to the Top Frame (#4) using:
•one M10*50 Button Head Cap Screw (#38) •two Φ11*Φ20*2 Flat Washer (#31)
•one M10 Nylon Locknut (#37)
Attach one Big Pulley (#21) to Pulley Plates (#28) using:
•one M10*50 Button Head Cap Screw (#38) •two Φ11*Φ20*2 Flat Washer (#31)
•one M10 Nylon Locknut (#37)
Attach two Big Pulley (#21) to the Top Frame (#4) using:
•two M10*75 Button Head Cap Screw (#33) •four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37) •four Φ11*Φ16*15 Pulley Spacer (#29)
Start by attaching Low Pully Cable (#17) to Main Base (#1) using:
•one 1/2"-12 Jam Nut (#44)
Attach one Big Pulley (#21) to Pulley Plates (#28) using:
•one M10*50 Button Head Cap Screw (#38) •two Φ11*Φ20*2 Flat Washer (#31)
•one M10 Nylon Locknut (#37)
Attach two Big Pulley (#21) to Upright (#3) & Seat Support (#6) using:
•two M10*75 Button Head Cap Screw (#33) •four Φ11*Φ20*2 Flat Washer (#31)
•two M10 Nylon Locknut (#37) •four Φ11*Φ16*15 Pulley Spacer (#29)
Attach the Short Bar (#13) to the Low Pully Cable (#17) using:
•two Gear Hook (#40) •one Long Chain 12 (#18)
Attach the Long Bar (#19) to the High Pully Cable (#15) using:
•two Gear Hook (#40) •one Short Chain 4 (#16)
9

Assembly
Step 4
10

Assembly
NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.
Step 5
Complete leg hold down assembly using:
•one Roller Pad Frame (#10) •two Foam Padding (#30)
•two Plastic Washer (#42) •two Metal End Cap (#43)
Complete Seat Pad (#20) assembly using:
•two Seat Pad Tube (#7) •one M10*115 Button Head Cap Screw (#35)
•four M10*75 Button Head Cap Screw (#33) •six Φ11*Φ20*2 Flat WasFher (#31)
•one M10 Nylon Locknut (#37)
Slide "L" Pin (#22) through holes in Foot Plate (#11) and Main Base (#1).
11

Assembly
NOTE: Wrench Tighten above all bolts and Nylon Locknuts.
Step 6
Silde two Adapters (#50) to the Slide Weight Support (#12) and secure using:
•two M8*6 Screw (#49)
For standard plate do not slide the Adapters (#50) on, just using two Spring Clip (#56) hold the plate off
from the Slide Weight Support (#12).
12

XM-7618 Parts List
Ref # Part # Description Qty
Parts List
13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
P00279
P00280
P00449
P00450
P00451
P00452
P00453
P00676
P00454
P00455
P00281
P00005
P00655
P00664
P00456
P00151
P00457
P00526
P00686
P00085
P00654
P00150
P00249
P00585
P00578
P00182
P00567
P00675
P00646
P00061
P00134
P00608
P00612
P00613
P00592
P00597
P00561
P00604
P00184
P00149
P00014
P00140
P00062
P00429
P00153
P00154
P00636
P00037
P00121
P00644
P00566
P00559
P00560
P00022
P00679
P00570
P00653
H00021
M00026
Main Base
Rear Base
Upright
Top Frame
Top Cross Frame
Seat Support
Seat Pad Tube
Lat Bar Hook GYM
Guide Rod
Roller Pad Frame
Foot Plate
Slide Weight Support
Short Bar
Pop Pin XM Series
High Pully Cable
Short Chain 4
Low Pully Cable
Long Chain 12
Long Bar
Seat Pad
Big Pulley 4.5"
"L" Pin
Plug 50.8*76.2
Weight Bumpper
Plug 25*50
Plug 44.5
Plastic Sleeve 44.5*25
Pulley Plate
Pulley Spacer Φ11*Φ16*15
Foam Padding Φ110*Φ22*180 XM SERIES
Flat Washer Φ11*Φ20*2
Button Head Cap Screw M10*65
Button Head Cap Screw M10*75
Button Head Cap Screw M10*80
Button Head Cap Screw M10*115
Button Head Cap Screw M10*25
Nylon Locknut M10
Button Head Cap Screw M10*50
Base Pad
Gear Hook
Grip Φ24*154
Plastic Washer
Metal End Cap
Jam Nut 1/2"-12
Foot Cap, Right 50.8 XM Series
Foot Cap, Left 50.8 XM Series
Button Head Cap Screw M8*25
Flat Washer Φ9*Φ22*2
Screw M8*12
Adapter
Plug 48
Hex Key S=4
Hex Key S=6
Wrench 17-19
Lubricant
Spring Clip
Spring Collar Plastic Grip
Bolt Pack, XM-7618
Owner's Manual XM-7618
1
1
1
1
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
1
7
1
2
2
4
2
4
2
8
2
46
1
14
4
1
4
19
3
1
4
4
2
2
2
2
2
4
4
2
2
2
1
1
1
1
2
4
1
1

Exploded View
21
21
21
21
21
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
18
18
19
20
22
23
24
25
26
26
27
27
28
29
29
29
30
31
31
31
31
31
31
31 31
31
31
32
33
33
33
33
34
34
34
34
33 33
33
33
31
34
36
36
37
37 37 37
37 37
37
37
37
38
38
38
38
39
40
41
41
43
44
45
46
47
48
48
80
31
77
33
49
50
51
49
50
51
42
56
57 57
14

Customer Service: 1-800-719-4605
