Marmitek BoomBoom 230 User manual

BOOM
BOOM 230
20450/20121011 • BOOMBOOM 230
ALL RIGHTS RESERVED MARMITEK ©
USER MANUAL 3
GEBRAUCHSANLEITUNG 9
GUIDE UTILISATEUR 15
MODO DE EMPLEO 21
MANUALE D’ISTRUZIONI 27
GEBRUIKSAANWIJZING 33
BoomBoom 230

© MARMITEK2

BoomBoom 230 3
ENGLISH
SAFETY WARNINGS
xTo prevent short circuits, this product should only be used inside and only
in dry spaces. Do not expose the components to rain or moisture. Do not
use the product close to a bath, swimming pool etc.
xDo not expose the components of your systems to extremely high
temperatures or bright light sources.
xIn case of improper usage or if you have altered and repaired the product
yourself, all guarantees expire. Marmitek does not accept responsibility in
the case of improper usage of the product or when the product is used
for purposes other than specified. Marmitek does not accept
responsibility for additional damage other than covered by the legal
product responsibility.
xThis product is not a toy. Keep out of reach of children.
xDo not open the product: the device may contain live parts. The product
should only be repaired or serviced by a qualified expert.
xOnly connect the adapter to the mains after checking whether the mains
voltage is the same as the values on the identification tags. Never connect
an adapter or power cord when it is damaged. In that case, contact your
supplier.
TABLE OF CONTENTS
SAFETY WARNINGS .................................................................................................3
TABLE OF CONTENTS...............................................................................................3
INTRODUCTION........................................................................................................4
SET CONTENTS .........................................................................................................4
OVERVIEW................................................................................................................4
PAIRING BLUETOOTH DEVICES (ONE-OFF).............................................................5
VOLUME CONTROL..................................................................................................5
TURNING OFF...........................................................................................................5
CONNECTING DEVICES THAT HAVE ALREADY BEEN PAIRED ...............................6
SWITCHING BETWEEN THE LAST 2 BLUETOOTH DEVICES ....................................6
CONNECTING WITH AN AUDIO CABLE...................................................................6
FREQUENTLY ASKED QUESTIONS...........................................................................7
COPYRIGHTS ............................................................................................................7

INTRODUCTION
Congratulations on your purchase of the Marmitek BoomBoom 230. This
Bluetooth speaker allows you to play music from a sound source that is
equipped with Bluetooth technology without having to connect the source
using cables. This could involve a PC or a laptop that has a Bluetooth USB
dongle, a mobile telephone that supports Bluetooth, an Android telephone,
an Android Tablet, an iPhone an iPad or a Mac.
The BoomBoom 230 has a range of about 10 metres, allowing you to organise
your music in the same or in an adjoining room.
SET CONTENTS
1 x BoomBoom 230, universal Bluetooth wireless stereo speaker
1x Power adapter
1 x Mini Jack to Mini Jack converter cable
1 x set of instructions in English, German, French, Spanish, Italian, Dutch.
OVERVIEW
1 3
6
1. Pause (short Press is pause, again Press is play)
2. Volume Up/Down
3. CONNECT Button/LED status indicator
LED status Speaker Status
Lit steady Idle (Powered ON, not connected to
Bluetooth device)
LED rapid blinking Pairing mode
LED blinks every 2 seconds Connected to Bluetooth device
4. Power ON/OFF switch
5. DC in
6. AUX IN
© MARMITEK4

BoomBoom 230 5
ENGLISH
PAIRING BLUETOOTH DEVICES (ONE-OFF)
The BoomBoom 230 is able to remember up to 8 paired devices. As a result it is
not necessary to pair a device every time you connect it. If a 9th device is paired
with the BoomBoom 230, the device which has been originally paired with the
BoomBoom 230 will be deleted from its memory.
1. Connect the AC Power Adaptor plug to the DC INPUT [5] located on the
rear panel of the BoomBoom 230.
2. Connect the AC Power Supply Unit into a suitable wall outlet.
3. Set the ON/OFF switch [4] to the ON position.
4. The LED status [3] will light up and stay on, indicating that the
BoomBoom 230 is switched on.
5. Press and hold the CONNECT [3] button for 3 seconds to put the
BoomBoom 230 into connection mode. Release the CONNECT button
once you hear 2 short beeps. The LED status will now blink rapidly.
6. Turn on a device that supports Bluetooth, such as an iPod, iPhone,
Android or mp3 player and go to: Settings > General > Bluetooth. Click
ON ‘Bluetooth’ and the BoomBoom 230 will appear on the device. Click
ON ‘BoomBoom 230’. The device is now connected and paired with the
speaker. If the device prompts for a pairing code, enter:”0000”
7.
VOLUME CONTROL
1. Tap VOLUME+ to increase the volume. When maximum volume has been
reached, a tone indicator will sound.
2. Tap VOLUME- to decrease the volume. When minimal volume has been
reached, a tone indicator will sound.
3.
TURNING OFF
Set the ON/OFF button to the OFF position in order to turn the BoomBoom
230 off.
To be completely disconnected from the power input, the main plug of the
AC/DC adapter shall be disconnected from the main.

© MARMITEK6
CONNECTING DEVICES THAT HAVE ALREADY BEEN
PAIRED
Set the ON/OFF switch to the ON position.
The LED status will now light up and stay on, indicating that the BoomBoom
230 is switched on but not yet paired with any Bluetooth device.
Once a Bluetooth device has been paired with the BoomBoom 230, it can be
reconnected to the BoomBoom 230 in two different ways.
1. Switch the Bluetooth device on and select the BoomBoom 230 to make a
new connection. The device is now connected to the speaker.
2. Press the Connect button on the BoomBoom 230 briefly. The BoomBoom
230 will now reconnect with the most recently paired Bluetooth device.
When connected, the blue LED lights will start to flash at a slow rate. Only one
device can be connected at the same time to the BoomBoom 230.
SWITCHING BETWEEN THE LAST 2 BLUETOOTH
DEVICES
You can switch between the 2 most recently paired Bluetooth devices by
pressing the CONNECT button briefly.
! Ensure that the device is switched on and that it accepts Bluetooth
connections.
CONNECTING WITH AN AUDIO CABLE
The Bluetooth connection can be switched to a wired connection by plugging
the cable into the 3.5mm audio jack. The volume and pause key function will
be disabled in the wired connection mode. Simply unplug the 3.5mm audio
jack and press the CONNECT button to revert back to the Bluetooth
connection.

ENGLISH
FREQUENTLY ASKED QUESTIONS
I can’t connect my BoomBoom 230.
Check the following:
xEnsure that the power adapter is connected.
xEnsure that the Bluetooth function on your mobile telephone is on (check
your phone's manual for reference).
xEnsure that the distance between your mobile phone and the BoomBoom
230 is no greater than 10 metres and that there are no large obstacles in
the way.
Can I pair numerous devices to my BoomBoom 230?
xYou can pair up to 8 devices to your BoomBoom 230. If the BoomBoom
230 is switched on, it will automatically connect to the last paired device
once the CONNECT button has been pressed.
Do you have other questions that have not been resolved by the above
information? Please go to www.marmitek.com
Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this
symbol on the product and/or its packaging must not be disposed of with
unsorted municipal waste. The symbol indicates that this product should be
disposed of separately from regular household waste streams. It is your
responsibility to dispose of this and other electric and electronic equipment
via designated collection facilities appointed by the government or local authorities.
Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. For more detailed information about the disposal of
your old equipment, please contact your local authorities, waste disposal service, or the
shop where you purchased the product.
COPYRIGHTS
Marmitek is a trademark of Pattitude B.V.
BoomBoom 230™ is a trademark of Marmitek B.V. All rights reserved.
Every effort has been made to ensure that the information in this manual is accurate.
Marmitek is not responsible for printing or clerical errors.
Copyright and all other proprietary rights in the content (including but not limited to
model numbers, software, audio, video, text and photographs) rests with Marmitek B.V.
Any use of the Content, but without limitation, distribution, reproduction, modification,
display or transmission without the prior written consent of Marmitek is strictly
prohibited. All copyright and other proprietary notices shall be retained on all
reproductions.
Other company and product names mentioned herein may be trademarks of their
respective companies. Mention of third-party products is for informational purposes only
and constitutes neither an endorsement nor a recommendation. Marmitek assumes no
responsibility with regard to the performance or use of these products.
BoomBoom 230 7

© MARMITEK8
TECHNICAL DATA
Supply voltage: 100-240VAC
5V 1000mA
Bluetooth Frequency: 2.402-2.480GHz
Bluetooth version: V2.1+EDR
Bluetooth power Class: Class 2.
Supported Bluetooth profiles: A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
Supported Codec: SBC (subband codec)
Support multiple pair: up to 8 devices
Range: Up to 30 metres with Class 2 source.
Up to 50 metres with Class 1 source.
Output power: 2 x 3W RMS
Output power: 2 x 18W PMPO
Signal To Noise Ratio: ≥ 70dB
Frequency Response: 150Hz-20kHz
Distortion: <10%
audio input: DC3.5 female
Input impedance: ≥ 10 Kohm
Driver Unit: 80mm, 4 Ohm ,3W
Power Indicator Light: Blue lights
Product weight: 1 kg
Product dimension: 280 x 95 x 100 mm
Operation temperature: -10°C ~ +55°C
Storage temperature: -20°C ~ +60°C
In order to continue improving the product, Marmitek reserves the right to change
specifications and/or designs without prior notice.

BoomBoom 230 9
DEUTSCH
SICHERHEITSHINWEISE
xUm Kurzschluss vorzubeugen, dieses Produkt bitte ausschließlich
innerhalb des Hauses und nur in trockenen Räumen nutzen. Setzen Sie
die Komponenten nicht Regen oder Feuchtigkeit aus. Nicht neben oder
nahe eines Bades, Schwimmbades usw. verwenden.
xSetzen Sie die Komponente Ihres Systems nicht extrem hohen
Temperaturen oder starken Lichtquellen aus.
xBei einer zweckwidrigen Verwendung, selbst angebrachten
Veränderungen oder selbst ausgeführten Reparaturen verfallen alle
Garantiebestimmungen. Marmitek übernimmt bei einer falschen
Verwendung des Produkts oder bei einer anderen Verwendung des
Produktes als für den vorgesehenen Zweck keinerlei Produkthaftung.
Marmitek übernimmt für Folgeschäden keine andere Haftung als die
gesetzliche Produkthaftung.
xDieses Produkt ist kein Spielzeug. Außer Reichweite von Kindern halten.
xDas Produkt niemals öffnen: Das Gerät kann Teile enthalten, worauf
lebensgefährliche Stromspannung steht. Überlassen Sie Reparaturen oder
Wartung nur Fachleuten.
xSchließen Sie den Netzadapter erst dann an das Stromnetz an, nachdem
Sie überprüft haben, ob die Netzspannung mit dem auf dem Typenschild
angegeben Wert übereinstimmt. Schließen Sie niemals einen Netzadapter
oder ein Netzkabel an, wenn diese beschädigt sind. In diesem Fall
nehmen Sie Kontakt mit Ihrem Lieferanten auf.
INHALTSVERZEICHNIS
SICHERHEITSHINWEISE ............................................................................................9
INHALTSVERZEICHNIS..............................................................................................9
EINFÜHRUNG .........................................................................................................10
VERPACKUNGSINHALT..........................................................................................10
ÜBERSICHT .............................................................................................................10
EINMALIGES KOPPELN VON BLUETOOTH GERÄTEN...........................................11
LAUTSTÄRKEREGELUNG........................................................................................11
AUSSCHALTEN .......................................................................................................11
VERBINDEN BEREITS GEKOPPELTER GERÄTE.......................................................12
ZWISCHEN DEN LETZTEN 2 BLUETOOTH GERÄTEN HIN- UND HERSCHALTEN ..12
VERBINDEN ÜBER EIN AUDIOKABEL ....................................................................12
HÄUFIG GESTELLTE FRAGEN.................................................................................13
COPYRIGHT ............................................................................................................13
TECHNISCHE DATEN ..............................................................................................14

EINFÜHRUNG
Herzlichen Glückwunsch zum Erwerb des Marmitek BoomBoom 230! Mit
diesem Bluetooth Lautsprecher können Sie über eine Bluetooth fähige
Tonquelle Musik abspielen, ohne die Quelle mit Kabeln verbinden zu müssen.
Das kann beispielsweise ein mit einem Bluetooth USB Dongle versehener PC
oder Laptop sein, ein Bluetooth fähiges Mobiltelefon, Android Telefon,
Android Tablet, iPhone, iPad oder Mac.
Die Reichweite des BoomBoom 230 beträgt zirka 10 Meter, sodass Sie Ihre
Musik im gleichen oder angrenzenden Raum regeln können.
VERPACKUNGSINHALT
1 x BoomBoom 230, Universal Bluetooth drahtloser Stereolautsprecher
1x Speisungsadapter
1 x Mini Jack-to-Mini Jack Converter Kabel
1 x Gebrauchsanleitungssatz Englisch, Deutsch, Französisch, Spanisch,
Italienisch, Niederländisch.
ÜBERSICHT
1 3
6
1. Pause (kurz drücken ist Pause, wieder drücken ist Abspielen.
2. Volumen lauter/leiser
3. CONNECT Taste / LED Statusanzeige.
LED Anzeige Lautsprecherstatus
Fortwährend eingeschaltet Ruhestellung (eingeschaltet, nicht mit einem
Bluetooth Gerät verbunden)
Blinkt schnell Pairing Modus
Blinkt alle 2 Sekunden Verbunden mit Bluetooth Gerät
4. EIN/AUS Schalter
5. DC INPUT
6. AUX INPUT
© MARMITEK10

BoomBoom 230 11
DEUTSCH
EINMALIGES KOPPELN VON BLUETOOTH GERÄTEN
Der BoomBoom 230 kann sich bis zu 8 gekoppelte Geräte im Datenspeicher
speichern. Somit ist es nicht mehr nötig, bei jeder Kopplung erneut zu
verbinden. Wird ein 9. Gerät mit dem BoomBoom 230 gekoppelt, dann wird
das zuerst mit dem BoomBoom230 verbundene Gerät aus dem Speicher
gelöscht werden.
1. Verbinden Sie den Adapter der AC Einheit mit dem DC INPUT [5]
Anschluss an der Hinterseite des BoomBoom 230.
2. Verbinden Sie das AC Netzteil mit einer geeigneten Steckdose.
3. Schalten Sie den EIN/AUS Schalter [4] EIN.
4. Die LED Anzeige [3] wird nun unaufhörlich leuchten und anzeigen, dass
der BoomBoom 230 eingeschaltet ist.
5. Halten Sie die CONNECT [3] Taste 3 Sekunden lang fest, um den
BoomBoom 230 in die Verbindungsstellung zu schalten. Lassen Sie die
CONNECT Taste los, wenn Sie 2 kurze Pieptöne hören. Die LED Anzeige
wird nun schnell blinken.
6. Schalten Sie ein Gerät das Bluetooth unterstützt ein, wie iPod, iPhone,
Android oder MP3-Gerät und gehen Sie zu den: Einstellungen >
Allgemein > Bluetooth. Klicken Sie Bluetooth EIN. BoomBoom 230
erscheint nun auf dem Gerät. Klicken Sie Bluetooth 230 EIN. Das Gerät ist
nun verbunden und an Ihren BoomBoom 230 Lautsprecher gekoppelt.
Geben Sie ”0000” ein, wenn das Gerät einen Pairing Code benötigt.
LAUTSTÄRKEREGELUNG
1. Tippen Sie auf VOLUME+ , um die Lautstärke zu erhöhen. Nach Erreichen
der maximalen Lautstärke erklingt ein Tonsignal.
2. Tippen Sie auf VOLUME- , um die Lautstärke zu verringern. Nach
Erreichen der Mindestlautstärke erklingt ein Tonsignal.
AUSSCHALTEN
Schalten Sie die EIN/AUS Taste auf AUS, um den BoomBoom 230
auszuschalten.
Möchten Sie das Gerät vollständig ausschalten, müssen Sie das Netzkabel aus
der Steckdose ziehen.

© MARMITEK12
VERBINDEN BEREITS GEKOPPELTER GERÄTE
Schalten Sie den EIN/AUS Schalter EIN.
Die LED Anzeige wird nun kontinuierlich leuchten und anzeigen, dass der
BoomBoom230 eingeschaltet, aber noch nicht mit dem Bluetooth Gerät
verbunden ist.
Wenn ein Bluetooth Gerät einmal mit dem BoomBoom 230 verknüpft ist, kann
dieses auf zweierlei Art und Weise erneut mit dem BoomBoom 230 verbunden
werden.
1. Schalten sie das Bluetooth Gerät ein und wählen Sie den BoomBoom 230,
um erneut Verbindung herzustellen. Das Gerät ist nun mit dem
Lautsprecher verbunden.
2. Drücken Sie einmal kurz auf die Connect Taste des BoomBoom 230. Der
BoomBoom230 stellt nun eine Verbindung mit dem zuletzt verbundenen
Bluetooth Gerät her.
Sobald diese Verbindung hergestellt ist, wird die blaue LED langsam blinken.
Sie können nur 1 Gerät zugleich mit dem BoomBoom 230 verbinden.
ZWISCHEN DEN LETZTEN 2 BLUETOOTH GERÄTEN
HIN- UND HERSCHALTEN
Sie können zwischen den letzten 2 verknüpften Bluetooth Geräten hin- und
herschalten, indem Sie kurz die CONNECT Taste drücken.
! Achten Sie jedoch darauf, dass das Gerät eingeschaltet ist und Bluetooth
Verbindungen akzeptiert.
VERBINDEN ÜBER EIN AUDIOKABEL
Anstelle einer Bluetooth Verbindung kann über einen Anschluss an den 3,5mm
Audioanschluss eine Kabelverbindung hergestellt werden. Die Lautstärke- und
Pause Tastenfunktion wird im verkabelten Verbindungsmodus ausgeschaltet.
Entkoppeln Sie einfach den 3,5mm Audioanschluss und drücken Sie die
CONNECT Taste, um zur Bluetooth Verbindung zurückzukehren.

HÄUFIG GESTELLTE FRAGEN
Ich kann meinen BoomBoom 230 nicht verbinden.
Achten Sie auf Nachfolgendes:
xÜberprüfen Sie, ob das Netzteil angeschlossen ist.
xÜberprüfen Sie, ob die Bluetooth Funktion auf Ihrem Mobiltelefon
eingeschaltet ist. (ziehen Sie die Gebrauchsanleitung Ihres Mobiltelefons
zurate).
DEUTSCH
xHalten Sie einen Abstand von weniger als 10 Metern zwischen
Mobiltelefon und BoomBoom 230 ohne große, im Weg stehende
Hindernisse ein.
Kann ich mehrere Geräte mit meinem BoomBoom 230 verbinden?
xEs können bis zu 8 Geräte mit Ihrem BoomBoom 230 verbunden werden.
Wenn der BoomBoom 230 eingeschaltet wird, wird er nach dem Drücken
der CONNECT Taste automatisch die zuletzt verwendete Gegenstelle
verbinden.
Sie haben noch Fragen, die im Obigen nicht beantwortet wurden?
Schauen Sie dann auf www.marmitek.com
Umweltinformation für Kunden innerhalb der Europäischen Union
Die Europäische Richtlinie 2002/96/EC verlangt, dass technische Ausrüstung, die
direkt am Gerät und/oder an der Verpackung mit diesem Symbol versehen ist nicht
zusammen mit unsortiertem Gemeindeabfall entsorgt werden darf. Das Symbol
weist darauf hin, dass das Produkt von regulärem Haushaltmüll getrennt entsorgt
werden sollte. Es liegt in Ihrer Verantwortung, dieses Gerät und andere elektrische
und elektronische Geräte über die dafür zuständigen und von der Regierung oder örtlichen
Behörden dazu bestimmten Sammelstellen zu entsorgen. Ordnungsgemäßes Entsorgen und
Recyceln trägt dazu bei, potentielle negative Folgen für Umwelt und die menschliche
Gesundheit zu vermeiden. Wenn Sie weitere Informationen zur Entsorgung Ihrer Altgeräte
benötigen, wenden Sie sich bitte an die örtlichen Behörden oder städtischen
Entsorgungsdienste oder an den Händler, bei dem Sie das Produkt erworben haben.
COPYRIGHT
Marmitek BV ist ein Warenzeichen von Pattitude
BoomBoom 230™ ist ein Warenzeichen von Marmitek BV Alle Rechte vorbehalten.
Weitergehende Ansprüche sind ausgeschlossen, insbesondere übernimmt Marmitek BV
keine Gewähr für die Richtigkeit des Inhalts dieses Handbuchs.
Urheber- und andere Eigentumsrechte am Inhalt (einschließlich aber nicht beschränkt
auf, Modellnummern, Software, Audio, Video, Text und Fotos begrenzt) liegt bei
Marmitek BV. Jegliche Nutzung von Inhalten, aber ohne Begrenzung, Verteilung,
Vervielfältigung, Änderung, Anzeige oder Übermittlung ohne die vorherige schriftliche
Erlaubnis von Marmitek ist strengstens untersagt. Alle Urheber- und andere
Eigentumsrechte muss auf allen Reproduktionen beibehalten werden.
Die Rechte an anderen in diesem Handbuch erwähnten Markenund Produktnamen
können bei ihren Inhabern liegen und werden hiermit anerkannt. Die Nennung von
Produkten, die nicht von Marmitek sind, dient ausschließlich Informationszwecken und
stellt keine Werbung dar. Marmitek übernimmt hinsichtlich der Auswahl, Leistung oder
Verwendbarkeit dieser Produkte keine Gewähr.
BoomBoom 230 13

© MARMITEK14
TECHNISCHE DATEN
Speisung: 100-240VAC
5V 1000mA
Bluetooth Frequenz: 2.402-2.480GHz
Bluetooth Version: V2.1+EDR
Bluetooth Leistungsklasse: Klasse 2
Unterstützte Bluetooth-Profile: A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
Unterstützte Codecs: SBC (subband codec)
Unterstützung Multiple Pair: bis zu 8 Geräte
Reichweite: Bis 30 Meter mit Klasse 2 Quelle.
Bis 50 Meter mit Klasse 1 Quelle.
Ausgangsleistung: 2 x 3W RMS
Ausgangsleistung: 2 x 18W PMPO
Signal / Rauschverhältnis: ≥ 70dB
Frequenzresonanz: 150Hz-20kHz
Verzerrung: <10%
Audioeingang: DC3.5 Buchse
Eingangsimpedanz: ≥ 10 Kohm
Driver Unit: 80mm, 4 Ohm ,3W
Ein-/Aus Indikatorleuchte: Blaue Beleuchtung
Produktgewicht: 1 kg
Produktmaße: 280 x 95 x 100 mm
Betriebstemperatur: -10°C ~ +55°C
Lagerung: -20°C ~ +60°C
Hinsichtlich weiterer Produktverbesserungen behält sich Marmitek das Recht vor,
Spezifikationen und/oder Entwürfe ohne vorherige Ankündigung zu ändern.

BoomBoom 230 15
FRANÇAIS
CONSIGNES DE SÉCURITÉ
xAfin d'éviter un court-circuit, ce produit ne doit être utilisé qu'à
l'intérieur, et uniquement dans des endroits secs. Ne pas exposer les
composants à la pluie ou à l'humidité. Ne pas utiliser à côté de ou près
d'une baignoire, une piscine, etc.
xNe pas exposer les composants de votre système à des températures
extrêmement élevées ou à des sources de lumières trop fortes.
xLa garantie n'est plus valable en cas d'usage inapproprié, de
modifications ou de réparations effectuées par des personnes non
agréées. Marmitek se dégage de toute responsabilité du fait des produits
en cas d'usage inapproprié du produit ou d'utilisation non conforme à
l'usage auquel le produit est destiné. Marmitek se dégage de toute
responsabilité en cas de dommage conséquent, autre que la
responsabilité civile du fait des produits.
xCe produit n'est pas un jouet. Tenir hors de portée des enfants.
xNe jamais ouvrir le produit : l'appareil peut contenir des éléments qui
sont sous tension très dangereux. Confier les réparations et l'entretien
exclusivement à un personnel qualifié.
xNe brancher l’adaptateur secteur sur le réseau électrique qu’après avoir
vérifié que la tension d’alimentation correspond à la valeur indiquée sur
les plaques d’identification. Ne jamais brancher un adaptateur secteur ou
un câble d’alimentation lorsque celui-ci est endommagé. Dans ce cas,
veuillez contacter votre revendeur.
TABLE DES MATIÈRES
CONSIGNES DE SÉCURITÉ ......................................................................................15
TABLE DES MATIÈRES............................................................................................15
INTRODUCTION......................................................................................................16
CONTENU DE L'EMBALLAGE.................................................................................16
DESCRIPTION..........................................................................................................16
UNE SEULE OPÉRATION DE CONFIGURATION DES APPAREILS BLUETOOTH.....17
RÉGLAGE DU VOLUME DU SON............................................................................17
ARRÊT.....................................................................................................................17
CONNECTION DES APPAREILS DÉJÀ CONNECTÉS................................................18
COMMUTATION ENTRE LES 2 DERNIERS APPAREILS BLUETOOTH.....................18
CONNEXION PAR LE BIAIS D'UN CÂBLE AUDIO ..................................................18
FOIRE AUX QUESTIONS .........................................................................................19
DROITS D'AUTEUR.................................................................................................19
CARACTÉRISTIQUES TECHNIQUES ........................................................................20

INTRODUCTION
Félicitations pour l'achat du Marmitek BoomBoom 230. Ce haut-parleur
Bluetooth vous permet d'écouter de la musique en provenance d'une source
audio dotée de la technologie Bluetooth, sans avoir besoin de relier cette
source avec un câble. Cela peut être par exemple un PC ou un ordinateur
portable dotés d'un dongle USB Bluetooth, un téléphone mobile compatible
Bluetooth, un téléphone Android, une tablette Android, un iPhone, un iPad
ou un Mac.
Le BoomBoom 230 a une portée d'environ 10 mètres ; vous pouvez ainsi régler
votre musique dans la même pièce ou dans une pièce adjacente.
CONTENU DE L'EMBALLAGE
1 x BoomBoom 230, haut-parleur universel stéréo Bluetooth sans fil
1x Adaptateur secteur
1 x câble adaptateur Mini-Jack vers Mini-Jack
1 x manuel d'utilisation en anglais, allemand, français, espagnol, italien et
néerlandais
DESCRIPTION
1 3
6
1. Pause (appuyer brièvement pour mettre en pause, appuyer encore
pour mettre en marche).
2. Volume haut/bas
3. Touche CONNECT / indicateur de statut de la LED
Statut de la LED Statut du haut-parleur
Allumée en continu Position de repos (activé, n'est pas connecté
à un appareil Bluetooth)
Clignote rapidement Mode d'appairage
Clignote toutes les 2 secondes Connecté avec un appareil Bluetooth
4. Interrupteur MARCHE/ARRÊT
5. DC in
6. AUX IN
© MARMITEK16

BoomBoom 230 17
FRANÇAIS
UNE SEULE OPÉRATION DE CONFIGURATION DES
APPAREILS BLUETOOTH
Le BoomBoom 230 peut mémoriser jusqu'à 8 appareils connectés. Par
conséquent il n'est pas nécessaire de reconfigurer à chaque connexion. Si un
9ème appareil est connecté au BoomBoom 230, le premier appareil qui avait
été connecté au BoomBoom 230 sera effacé de la mémoire.
1. Raccordez la prise de l’unité de distribution d’électricité AC à l’entrée DC
[5] se trouvant dans le panneau arrière BoomBoom 230.
2. Raccordez l’unité d’alimentation AC dans la sortie murale adéquate.
3. Mettez l'interrupteur MARCHE/ARRÊT [4] sur la position MARCHE.
4. La LED [3] restera maintenant allumée et indiquera que le BoomBoom
230 est activé.
5. Maintenez la touche CONNECT [3] enfoncée pendant 3 secondes pour
mettre le BoomBoom 230 en position de connexion. Lâchez la touche
CONNECT lorsque vous entendez 2 bips brefs. La LED clignotera
maintenant rapidement.
6. Connectez un appareil compatible Bluetooth tel qu'un iPod, un iPhone,
un Android ou un lecteur mp3 et allez sur : Configuration > Général >
Bluetooth. Cliquez sur Bluetooth ACTIVÉ. Le BoomBoom 230 est
maintenant affiché sur l'appareil. Cliquez sur BoomBoom 230 ACTIVÉ.
L'appareil est maintenant connecté et relié avec le haut-parleur. Saisissez
”0000” si l'appareil demande un code d'appairage.
RÉGLAGE DU VOLUME DU SON
1. Tapez sur VOLUME+ pour augmenter le volume du son. Lorsque le
volume maximum est atteint, un signal sonore retentit.
2. Tapez sur VOLUME- pour diminuer le volume du son. Lorsque le volume
minimum est atteint, un signal sonore retentit.
ARRÊT
Mettez la touche MARCHE/ARRÊT sur la position ARRÊT pour éteindre le
BoomBoom 230.
Pour que l’appareil soit complètement déconnecté de l’alimentation
électrique, il faut débrancher la prise de l’adaptateur CA/CC.

© MARMITEK18
CONNECTION DES APPAREILS DÉJÀ CONNECTÉS
Mettez l'interrupteur MARCHE/ARRÊT sur la position MARCHE.
La LED restera maintenant allumée et indiquera que le BoomBoom 230 est
activé, mais qu'il n'est pas encore connecté avec un appareil Bluetooth.
Lorsque un appareil Bluetooth a déjà été connecté au BoomBoom 230, celui-ci
peut être à nouveau connecté de 2 manières.
1. Branchez l'appareil Bluetooth et sélectionnez le BoomBoom 230 pour
établir à nouveau la connexion. L'appareil est maintenant connecté au
haut-parleur.
2. Appuyez 1 fois brièvement sur la touche Connect du BoomBoom 230. Le
BoomBoom 230 se connecte maintenant avec le dernier appareil
Bluetooth qui était connecté.
Dès que la connexion est établie, le témoin LED bleu se met à clignoter
lentement. Vous ne pouvez connecter qu'un seul appareil à la fois au
BoomBoom 230.
COMMUTATION ENTRE LES 2 DERNIERS APPAREILS
BLUETOOTH
Vous pouvez commuter entre les 2 derniers appareils Bluetooth connectés en
appuyant brièvement sur la touche CONNECT.
! Assurez-vous que cet appareil soit connecté et qu'il accepte une connexion
Bluetooth.
CONNEXION PAR LE BIAIS D'UN CÂBLE AUDIO
Au lieu d'une connexion Bluetooth il est possible de faire une connexion filaire
en connectant sur le connecteur audio 3,5 mm. En pause, la touche fonction
volume est désactivée en mode de connexion filaire. Il suffit de débrancher le
connecteur audio 3,5 mm et d'appuyer sur la touche CONNECT pour revenir à
la connexion Bluetooth.

FOIRE AUX QUESTIONS
Je ne peux pas connecter mon BoomBoom 230.
Contrôlez les points suivants :
xAssurez-vous que l'adaptateur secteur soit branché et/ou que la batterie
soit chargée.
xAssurez-vous que la fonction Bluetooth de votre téléphone mobile soit
activée. (Consultez le mode d'emploi de votre téléphone mobile pour
référence).
xAssurez-vous que la distance entre votre téléphone mobile et le
BoomBoom150 ne soit pas supérieure à 10 mètres et qu'il n'y ait pas
d'obstacles majeurs entre eux.
Puis-je connecter plusieurs appareils à mon BoomBoom 230?
Vous pouvez connecter à votre BoomBoom150 jusqu'à 8 appareils. Lorsqu'on
branche le BoomBoom 230, celui-ci se connecte après avoir appuyé sur la
touche CONNECT automatiquement au dernier appareil auquel il était
connecté.
FRANÇAIS
Les informations ci-dessus n'ont pas répondu à vos questions ?
Veuillez consulter le site internet www.marmitek.com.
Informations environnementales pour les clients de l’Union européenne
La directive européenne 2002/96/CE exige que l’équipement sur lequel est apposé ce
symbole sur le produit et/ou son emballage ne soit pas jeté avec les autres ordures
ménagères. Ce symbole indique que le produit doit être éliminé dans un circuit
distinct de celui pour les déchets des ménages. Il est de votre responsabilité de jeter ce
matériel ainsi que tout autre matériel électrique ou électronique par les moyens de
collecte indiqués par le gouvernement et les pouvoirs publics des collectivités territoriales.
L’élimination et le recyclage en bonne et due forme ont pour but de lutter contre l’impact néfaste
potentiel de ce type de produits sur l’environnement et la santé publique. Pour plus d’informations
sur le mode d’élimination de votre ancien équipement, veuillez prendre contact avec les pouvoirs
publics locaux, le service de traitement des déchets, ou l’endroit où vous avez acheté le produit.
DROITS D'AUTEUR
Marmitek est une marque déposée de Pattitude BV
BoomBoom 230™ est une marque déposée de Marmitek BV. Tous droits réservés.
Tout a été mis en oeuvre pour que les informations présentées dans ce manuel soient
exactes. Marmitek n’est pas responsable des erreurs de reproduction ou d’impression.
Les droits d'auteur et tout autres droits de propriété concernant le contenu (comprenant
mais pas limités aux numéros de modèle, logiciels, audio, vidéo, textes et photos)
appartiennent à Marmitek B.V. Toute utilisation du contenu, mais sans restriction,
concernant la distribution, la reproduction, toute modification, la publication ou la
diffusion est strictement interdite sans l'autorisation préalable par écrit de Marmitek.
Tous les droits d'auteur et autres droits de propriété doivent être respectés pour toutes
reproductions.
Les autres noms de produits et de sociétés peuvent être des marques de leurs détenteurs
respectifs. Les produits commercialisés par des entreprises tierces ne sont mentionnés que
pour information, sans aucune intention de préconisation ni
de recommandation. Marmitek décline toute responsabilité quant à l’utilisation et au
fonctionnement de ces produits.
BoomBoom 230 19

© MARMITEK20
CARACTÉRISTIQUES TECHNIQUES
Alimentation : 100-240VAC
5V 1000mA
Fréquence Bluetooth: 2.402-2.480GHz
Version Bluetooth: V2.1+EDR
Classe d'alimentation Bluetooth: Classe 2
Profils Bluetooth pris en charge: A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
Codec pris en charge: SBC (subband codec)
Appairage multiple: jusqu'à 8 appareils
Portée: Jusqu'à 30 mètres avec une source Classe 2.
Jusqu'à 50 mètres avec une source Classe 1.
Puissance de sortie: 2 x 3W RMS
Puissance de sortie: 2 x 18W PMPO
Signal/rapport signal sur bruit: ≥ 70dB
Réponse en fréquence: 150Hz-20kHz
Déformation: <10%
Entrée audio: DC3.5 femelle
impédance d'entrée: ≥ 10 Kohm
Unité Driver: 80mm, 4 Ohm ,3W
Témoin Marche/Arrêt: Eclairage bleu
Poids du produit: 1 kg
Dimensions du produit: 280 x 95 x 100 mm
Température de fonctionnement: -10°C ~ +55°C
Température de stockage: -20°C ~ +60°C
En vue d'améliorer encore plus le produit, Marmitek se réserve le droit de modifier sans
préavis les spécifications et/ou la conception.
Other manuals for BoomBoom 230
1
Table of contents
Languages:
Other Marmitek Portable Speakers manuals
