Marson MT1 User manual

MT1 User’s Manual V1.0
___________________________________________________________________________________
1
MT1
Scan Engine
User’s Manual
Version 1.0 DATE: 2022/09/15

MT1 User’s Manual V1.0
___________________________________________________________________________________
2
Table of Content
1. Introduction ...................................................................................................... 12
1.1 Manual Description .................................................................................................... 12
1.2 Product Requirements............................................................................................... 12
1.3 Barcode Configurability ............................................................................................. 12
1.4 Factory Default ........................................................................................................... 13
1.5 Custom Default........................................................................................................... 13
1.6 Check Version ............................................................................................................ 13
2. Interface............................................................................................................ 14
2.1 UART ........................................................................................................................... 14
2.1.1 Baud Rate ............................................................................................................ 14
2.1.2 Parity..................................................................................................................... 15
2.2 USB HID ...................................................................................................................... 16
2.2.1 Intercharacter Delay ........................................................................................... 16
2.2.2 Polling Rate ......................................................................................................... 16
2.2.3 Keyboard Layout................................................................................................. 17
2.2.4 Alt Code................................................................................................................ 20
2.2.5 Control Mode ....................................................................................................... 21
2.2.6 Capslock Mode ................................................................................................... 22
2.2.7 End of Data Symbol ........................................................................................... 22
2.2.8 GS Replacement................................................................................................. 22
2.2.9 CRLF Replacement............................................................................................ 23
2.3 USB VCP..................................................................................................................... 23
2.4 HID POS...................................................................................................................... 24
3. Reading Mode .................................................................................................. 25
3.1 Batch Mode................................................................................................................. 25

MT1 User’s Manual V1.0
___________________________________________________________________________________
3
3.2 Trigger Mode............................................................................................................... 25
3.2.1 Trigger Condition ................................................................................................ 25
3.2.2 LED Timeout........................................................................................................ 26
3.2.3 Sleep Mode.......................................................................................................... 26
3.2.4 Sleep Timeout ..................................................................................................... 26
3.2.5 Identical Read Interval ....................................................................................... 27
3.3 Auto-sensing Mode.................................................................................................... 28
3.3.1 LED Timeout........................................................................................................ 28
3.3.2 Identical Read Interval ....................................................................................... 29
3.3.3 Image Stabilization Timeout.............................................................................. 30
3.3.4 Auto-sensing Sensitivity..................................................................................... 30
3.3.5 Stop Mode............................................................................................................ 31
3.4 Continuous Mode ....................................................................................................... 31
3.4.1 LED Timeout........................................................................................................ 32
3.4.2 Scan Interval........................................................................................................ 32
3.4.3 Identical Read Interval ....................................................................................... 33
4. Illumination and Aimer .................................................................................... 35
4.1 Illumination .................................................................................................................. 35
4.2 Aimer............................................................................................................................ 35
5. Indicator............................................................................................................ 37
5.1 General Settings......................................................................................................... 37
5.2 Power Up Beep .......................................................................................................... 37
5.3 Good Read Beep ....................................................................................................... 37
5.3.1 Indicator Beep Type........................................................................................... 38
5.3.2 Beep Volume ....................................................................................................... 38
5.4 Configuration Barcode Beep .................................................................................... 38

MT1 User’s Manual V1.0
___________________________________________________________________________________
4
5.5 Good Read LED and Duration ................................................................................. 39
5.6 Good Read LED Mode.............................................................................................. 39
5.7 Not Good Read (NGR) Message............................................................................. 40
6. Data Format...................................................................................................... 41
6.1 General Settings......................................................................................................... 41
6.2 Data Length................................................................................................................. 41
6.3 STX (0x02) .................................................................................................................. 42
6.4 Preamble + Code ID .................................................................................................. 42
6.5 Preamble ..................................................................................................................... 42
6.5.1 Enable/Disable Preamble.................................................................................. 42
6.5.2 Set Preamble....................................................................................................... 43
6.5.3 Set Preamble of a Symbology .......................................................................... 43
6.5.4 Clear Preamble ................................................................................................... 44
6.6 Code ID........................................................................................................................ 44
6.6.1 Enable/Disable/Reset Code ID......................................................................... 44
6.6.2 Set Code ID ......................................................................................................... 44
6.7 Postamble ................................................................................................................... 47
6.7.1 Enable/Disable Postamble................................................................................ 47
6.7.2 Set Postamble ..................................................................................................... 47
6.7.3 Set Postamble of a Symbology ........................................................................ 48
6.7.4 Clear Postamble ................................................................................................. 49
6.8 Terminator ................................................................................................................... 49
6.8.1 Enable/Disable Terminator................................................................................ 49
6.8.2 Set Terminator..................................................................................................... 49
6.8.3 Quick Terminator Options.................................................................................. 50
6.9 Data Editing................................................................................................................. 50

MT1 User’s Manual V1.0
___________________________________________________________________________________
5
6.9.1 Data Output ......................................................................................................... 50
6.9.2 Set Data Length .................................................................................................. 51
6.9.3 Hide Start/Center/End........................................................................................ 51
6.9.4 Set Data Length of a Symbology...................................................................... 52
6.9.5 Clear Data Length............................................................................................... 54
6.10 Encoding Format...................................................................................................... 54
6.10.1 Input Encoding Format .................................................................................... 54
6.10.2 Output Encoding Format ................................................................................. 55
6.11 ECI Mode .................................................................................................................. 55
6.12 QR Code with URL .................................................................................................. 56
7. Symbologies..................................................................................................... 57
7.1 General Settings......................................................................................................... 57
7.1.1 All Symbologies................................................................................................... 57
7.1.2 1D Symbologies.................................................................................................. 57
7.1.3 2D Symbologies.................................................................................................. 57
7.2 Surround GS1 Application Identifiers (AI’s) with Parentheses............................ 57
7.3 Inverse Barcode ......................................................................................................... 58
7.3.1 All Inverse Barcode ............................................................................................ 58
7.3.2 1D Inverse Barcode............................................................................................ 58
7.3.3 2D Inverse Barcode............................................................................................ 58
7.4 Code128 ...................................................................................................................... 60
7.4.1 Reset to Default .................................................................................................. 60
7.4.2 Enable/Disable Code128................................................................................... 60
7.4.3 Min/Max Length................................................................................................... 60
7.5 EAN-8........................................................................................................................... 61
7.5.1 Reset to Default .................................................................................................. 61

MT1 User’s Manual V1.0
___________________________________________________________________________________
6
7.5.2 Enable/Disable EAN-8 ....................................................................................... 61
7.5.3 Check Digit........................................................................................................... 62
7.5.4 Supplement.......................................................................................................... 62
7.5.5 Supplement Required ........................................................................................ 62
7.5.6 EAN-8 Expand to EAN-13 ................................................................................. 63
7.6 EAN-13 ........................................................................................................................ 63
7.6.1 Reset to Default .................................................................................................. 63
7.6.2 Enable/Disable EAN-13 ..................................................................................... 63
7.6.3 Check Digit........................................................................................................... 63
7.6.4 Supplement.......................................................................................................... 64
7.6.5 Supplement Required ........................................................................................ 64
7.6.6 EAN-13 Convert to ISBN ................................................................................... 64
7.6.7 EAN-13 Convert to ISSN ................................................................................... 65
7.7 UPC-E0........................................................................................................................ 65
7.7.1 Reset to Default .................................................................................................. 65
7.7.2 Enable/Disable UPC-E0 .................................................................................... 65
7.7.3 Check Digit........................................................................................................... 65
7.7.4 System Number .................................................................................................. 66
7.7.5 Supplement.......................................................................................................... 66
7.7.6 Supplement Required ........................................................................................ 66
7.7.7 UPC-E0 Expand to UPC-A................................................................................ 67
7.8 UPC-E1........................................................................................................................ 67
7.8.1 Reset to Default .................................................................................................. 67
7.8.2 Enable/Disable UPC-E1 .................................................................................... 67
7.8.3 Check Digit........................................................................................................... 67
7.8.4 System Number .................................................................................................. 68

MT1 User’s Manual V1.0
___________________________________________________________________________________
7
7.8.5 Supplement.......................................................................................................... 68
7.8.6 Supplement Required ........................................................................................ 68
7.8.7 UPC-E1 Expand to UPC-A................................................................................ 69
7.9 UPC-A.......................................................................................................................... 69
7.9.1 Reset to Default .................................................................................................. 69
7.9.2 Enable/Disable UPC-A....................................................................................... 69
7.9.3 UPC-A Expand to EAN-13 ................................................................................ 69
7.9.4 Check Digit........................................................................................................... 70
7.9.5 System Number .................................................................................................. 70
7.9.6 Supplement.......................................................................................................... 70
7.9.7 Supplement Required ........................................................................................ 71
7.10 Interleaved 2/5.......................................................................................................... 71
7.10.1 Reset to Default ................................................................................................ 71
7.10.2 Enable/Disable Interleaved 2/5 ...................................................................... 71
7.10.3 Min/Max Length ................................................................................................ 71
7.10.4 Verification ......................................................................................................... 72
7.11 Matrix 2/5................................................................................................................... 73
7.11.1 Reset to Default ................................................................................................ 73
7.11.2 Enable/Disable Matrix 2/5 ............................................................................... 73
7.11.3 Min/Max Length ................................................................................................ 73
7.11.4 Verification ......................................................................................................... 74
7.12 Industrial 2/5 ............................................................................................................. 74
7.12.1 Reset to Default ................................................................................................ 74
7.12.2 Enable/Disable Industrial 2/5.......................................................................... 75
7.12.3 Min/Max Length ................................................................................................ 75
7.12.4 Verification ......................................................................................................... 76

MT1 User’s Manual V1.0
___________________________________________________________________________________
8
7.13 IATA 2/5..................................................................................................................... 76
7.13.1 Reset to Default ................................................................................................ 76
7.13.2 Enable/Disable IATA 2/5 ................................................................................. 76
7.13.3 Min/Max Length ................................................................................................ 77
7.13.4 Verification ......................................................................................................... 77
7.14 Code39 ...................................................................................................................... 78
7.14.1 Reset to Default ................................................................................................ 78
7.14.2 Enable/Disable Code39................................................................................... 78
7.14.3 Send Start & Stop............................................................................................. 78
7.14.4 Min/Max Length ................................................................................................ 78
7.14.5 Verification ......................................................................................................... 79
7.14.6 Enable/Disable Code32................................................................................... 79
7.14.7 Code32 Preamble............................................................................................. 80
7.14.8 Code32 Check Digit ......................................................................................... 80
7.14.9 Full ASCII Code39............................................................................................ 80
7.15 Codabar..................................................................................................................... 80
7.15.1 Reset to Default ................................................................................................ 80
7.15.2 Enable/Disable Codabar.................................................................................. 81
7.15.3 Min/Max Length ................................................................................................ 81
7.15.4 Verification ......................................................................................................... 82
7.15.5 Send Start & Stop............................................................................................. 82
7.16 Code93 ...................................................................................................................... 83
7.16.1 Reset to Default ................................................................................................ 83
7.16.2 Enable/Disable Code93................................................................................... 83
7.16.3 Min/Max Length ................................................................................................ 83
7.17 Code11 ...................................................................................................................... 84

MT1 User’s Manual V1.0
___________________________________________________________________________________
9
7.17.1 Reset to Default ................................................................................................ 84
7.17.2 Enable/Disable Code11................................................................................... 84
7.17.3 Min/Max Length ................................................................................................ 85
7.17.4 Verification ......................................................................................................... 85
7.18 MSI Plessey.............................................................................................................. 86
7.18.1 Reset to Default ................................................................................................ 86
7.18.2 Enable/Disable MSI Plessey........................................................................... 86
7.18.3 Min/Max Length ................................................................................................ 87
7.18.4 Verification ......................................................................................................... 87
7.19 GS1 DataBar ............................................................................................................ 88
7.20 GS1 DataBar Limited .............................................................................................. 88
7.21 GS1 DataBar Expanded ......................................................................................... 89
7.22 Plessey ...................................................................................................................... 89
7.22.1 Reset to Default ................................................................................................ 89
7.22.2 Enable/Disable Plessey................................................................................... 89
7.22.3 Min/Max Length ................................................................................................ 90
7.22.4 Check Digit ........................................................................................................ 90
7.23 Febraban................................................................................................................... 90
7.23.1 Enable/Disable ITF25 Febraban .................................................................... 90
7.23.2 Enable/Disable Code128 Febraban .............................................................. 91
7.23.3 Verification ......................................................................................................... 91
7.24 Composite ................................................................................................................. 91
7.25 PDF417 ..................................................................................................................... 91
7.26 QR Code ................................................................................................................... 92
7.27 Micro QR Code......................................................................................................... 92
7.28 Data Matrix................................................................................................................ 92

MT1 User’s Manual V1.0
___________________________________________________________________________________
10
7.29 MicroPDF417............................................................................................................ 92
7.30 Aztec .......................................................................................................................... 93
7.31 MaxiCode .................................................................................................................. 93
7.32 HanXin ....................................................................................................................... 93
7.33 DotCode .................................................................................................................... 93
8. Configuration Barcode .................................................................................... 95
8.1 Data 0~F...................................................................................................................... 95
8.2 Save & Abort............................................................................................................... 96
Appendix.................................................................................................................. 97
Appendix A - Default Table ............................................................................................. 97
Appendix B - Code ID .................................................................................................... 104
Appendix C - ASCII Table ............................................................................................. 106
Appendix D - Configuration Method............................................................................. 110
LED Timeout................................................................................................................ 110
Sleep Timeout ............................................................................................................. 110
Image Stabilization Timeout...................................................................................... 110
Identical Read Interval ............................................................................................... 110
Auto-sensing Threshold............................................................................................. 110
Scan Interval................................................................................................................ 111
Preamble/Postamble.................................................................................................. 111
Terminator.................................................................................................................... 111
Code ID ........................................................................................................................ 111
NGR (Not Good Read) Message ............................................................................. 111
Min/Max Length........................................................................................................... 112
Intercharacter Delay ................................................................................................... 112
Good Read LED Duration ......................................................................................... 112

MT1 User’s Manual V1.0
___________________________________________________________________________________
11
Appendix E – Control Code Table................................................................................ 113
Appendix F – Symbology Index Table......................................................................... 114
Version History...................................................................................................... 116

MT1 User’s Manual V1.0
___________________________________________________________________________________
12
1. Introduction
1.1 Manual Description
This user’s manual mainly provides instruction on configuring MT1. By
scanning the configuration barcodes in this manual, you can change MT1’s
interface, reading mode, data format and so on. The appendix lists the default
configurations of MT1. In most cases, user can use MT1 without further
configuration.
1.2 Product Requirements
Model
Firmware Version
Interface
MT1
V2.4.0.29.13 or up
UART
USB HID
USB VCP
HID POS
1.3 Barcode Configurability
Scanning below configuration barcodes will allow/prohibit user to change
settings by scanning configuration barcodes in this manual.
Enable Barcode Configurability* Disable Barcode Configurability
Scanning below configuration barcodes will allow/prohibit configuration
barcode data output.
Enable Config Barcode Data Output Disable Config Barcode Data Output*

MT1 User’s Manual V1.0
___________________________________________________________________________________
13
1.4 Factory Default
Scanning below configuration barcode will reset all parameters to factory
default settings (the ones with *asterisk mark)
Factory Default
1.5 Custom Default
You can create your own custom default. Scan Save Custom Default
configuration barcode below and all the current settings of MT1 will be saved
to your custom default, overwriting, if any, the previous one. Scan Custom
Default to reset MT1 to the custom default settings.
Save Custom Default Custom Default
1.6 Check Version
To check firmware version, please scan below configuration barcode.
Check Version

MT1 User’s Manual V1.0
___________________________________________________________________________________
14
2. Interface
MT1 provides UART serial interface and multiple USB interfaces to
communicate with the host. Through communication interface, it is possible to
receive barcode data and send command to control MT1 at the same time.
2.1 UART
Scanning below configuration barcode will set MT1 to UART interface, which is
based on TTL level signals. For RS232 communication, a conversion circuit
must be added externally.
UART
Parameter Default
Serial communication type UART (TTL-232)
Baud Rate 9600
Parity None
Data Bits 8
Stop Bits 1
Hardware Flow Control None
2.1.1 Baud Rate
The unit of Baud Rate is bps (bits per second); below are available options:
1200 2400

MT1 User’s Manual V1.0
___________________________________________________________________________________
15
4800 9600*
14400 19200
38400 57600
115200
2.1.2 Parity
Three parity options are available:
None* Odd
Even

MT1 User’s Manual V1.0
___________________________________________________________________________________
16
2.2 USB HID
Scanning below configuration barcode will set MT1 to USB HID interface, in
which MT1 becomes an HID keyboard device.
USB HID*
2.2.1 Intercharacter Delay
Intercharacter delay is the time interval between the release of last key and the
pressing of the next key. The configurable range is from 0 to 75ms; default is
2ms. Please refer to Appendix D for configuration method of Set
Intercharacter Delay.
2ms* 0ms
5ms 10ms
Set Intercharacter Delay
2.2.2 Polling Rate
The smaller the value, the faster MT1 sends characters to the host. If the host
loses characters, please increase polling rate.

MT1 User’s Manual V1.0
___________________________________________________________________________________
17
1ms* 2ms
3ms 4ms
5ms 6ms
7ms 8ms
9ms 10ms
2.2.3 Keyboard Layout
English (USA)* French

MT1 User’s Manual V1.0
___________________________________________________________________________________
18
Italian German
Spanish Turkish Q
English (UK) Belgian
Portuguese (Portugal) Portuguese (Brazil)
Hungarian Turkish F
Greek Swedish
Finnish Danish

MT1 User’s Manual V1.0
___________________________________________________________________________________
19
Czech Austrian
Italian (142) Russian
Russian (Typewriter) Arabian
Irish Polish (214)
Polish (Programmers) Dutch
Japanese Thai
Croatian Romanian

MT1 User’s Manual V1.0
___________________________________________________________________________________
20
Bulgarian Slovak
North Korean Ukrainian
Swiss French Hebrew
Vietnamese
2.2.4 Alt Code
To ensure that all ASCII code (0x00~0xFF) can be transmitted correctly
regardless of keyboard layout, Alt Code can be enabled. When Alt Code is
enabled, transmission speed will be slower because all keyboard data is sent
by key combinations. Please select one of the following modes according to
your applications:
Mode 1: Send all ASCII code (0x20~0xFF), not supported by current keyboard
layout, by Alt Code.
Mode 2: Send all ASCII code (0x20~0xFF) by Alt Code.
Mode 3: Send all ASCII code (0x00~0xFF) by Alt Code.
Note: When Mode 3 and Control Mode are enabled at the same time, Control
Code (0x00~0x1F) will be sent by Ctrl key combinations.
