Marson MT500 User manual

MT500 User’s Manual V1.0
MT500
1D Wireless Ring Scanner
User’s Manual
Version 1.0 DATE: 2022/07/13

MT500 User’s Manual V1.0
2
Table of Content
CHAPTER 1 INTRODUCTION............................................................................................................................................. 7
SPECIFICATIONS ............................................................................................................................................................................ 7
BEEPER INDICATION....................................................................................................................................................................... 9
LED INDICATION ............................................................................................................................................................................ 9
CHAPTER 2 GENERAL SETTINGS.................................................................................................................................. 10
BARCODE CONFIGURABILITY ....................................................................................................................................................... 10
FACTORY DEFAULT ...................................................................................................................................................................... 10
CHECK VERSION .......................................................................................................................................................................... 10
BUTTON PREFERENCE................................................................................................................................................................. 11
GOOD READ INDICATOR .............................................................................................................................................................. 11
Beep Tone ............................................................................................................................................................................. 11
Beep Mode ............................................................................................................................................................................ 12
DATA FORMAT.............................................................................................................................................................................. 13
HT/CR/ESC Converts to TAB/ENTER/ESCAPE ............................................................................................................. 13
Function Code Conversion.................................................................................................................................................. 13
Numeric Key.......................................................................................................................................................................... 14
Capslock Mode ..................................................................................................................................................................... 14
Keyboard Layout................................................................................................................................................................... 15
Intercharacter Delay............................................................................................................................................................. 17
Interblock Delay .................................................................................................................................................................... 17
BCC (Binary Check Character) .......................................................................................................................................... 18
IMAGING SETTINGS ...................................................................................................................................................................... 18
Inverse Barcode.................................................................................................................................................................... 18
CHAPTER 3 INTERFACE.................................................................................................................................................. 19
BT HID......................................................................................................................................................................................... 19
Getting Connected................................................................................................................................................................ 19
Pincode Setup....................................................................................................................................................................... 20
BT SPP........................................................................................................................................................................................ 21
Getting Connected................................................................................................................................................................ 21
Set SPP Pincode .................................................................................................................................................................. 22
GENERAL BLUETOOTH SETTINGS................................................................................................................................................ 23
Power Off Timeout................................................................................................................................................................ 23
Shut Down ............................................................................................................................................................................. 23
iOS Touch Keyboard............................................................................................................................................................ 24
Secure Simple Pairing (SSP).............................................................................................................................................. 24
Set Bluetooth Device ID....................................................................................................................................................... 25
Check Bluetooth Firmware Version ................................................................................................................................... 25
Check Device MAC Address............................................................................................................................................... 26
Check Host MAC Address................................................................................................................................................... 26

MT500 User’s Manual V1.0
3
Check Battery Life ................................................................................................................................................................ 26
ScanLink ................................................................................................................................................................................ 27
MEMORY MODE ........................................................................................................................................................................... 28
Delete Last Record............................................................................................................................................................... 28
Clear All Record.................................................................................................................................................................... 28
Data Format........................................................................................................................................................................... 29
Field Separator...................................................................................................................................................................... 29
Date Format........................................................................................................................................................................... 30
Time Format .......................................................................................................................................................................... 30
Date & Time Setup ............................................................................................................................................................... 31
USB HID...................................................................................................................................................................................... 31
USB VCP .................................................................................................................................................................................... 31
CHAPTER 4 READING MODE.......................................................................................................................................... 32
TRIGGER MODE ........................................................................................................................................................................... 32
TOGGLE MODE............................................................................................................................................................................. 32
FLASH MODE................................................................................................................................................................................ 32
CONTINUOUS MODE .................................................................................................................................................................... 33
CONTINUOUS AUTO OFF MODE .................................................................................................................................................. 33
Flash / Continuous Mode – Trigger Control...................................................................................................................... 33
Trigger / Toggle Mode – LED Auto-Off Control................................................................................................................ 34
Trigger / Toggle / Flash / Continuous Auto Off Mode – LED Auto-Off Timeout .......................................................... 34
Flash / Continuous / Continuous Auto Off Mode – Identical Read Interval.................................................................. 35
ACCURACY ADJUSTMENT ............................................................................................................................................................ 35
CHAPTER 5 DATA FORMAT............................................................................................................................................ 36
CODE ID....................................................................................................................................................................................... 36
SET ID.......................................................................................................................................................................................... 36
DATA LENGTH .............................................................................................................................................................................. 38
PREAMBLE.................................................................................................................................................................................... 39
POSTAMBLE.................................................................................................................................................................................. 39
Clear Preamble/Postamble ................................................................................................................................................. 39
TERMINATOR ................................................................................................................................................................................ 40
CHAPTER 6 SYMBOLOGIES............................................................................................................................................ 41
GENERAL SETTINGS .................................................................................................................................................................... 41
UPC-A ......................................................................................................................................................................................... 41
Enable/Disable UPC-A......................................................................................................................................................... 41
Lead Digit............................................................................................................................................................................... 41
Check Digit ............................................................................................................................................................................ 42
UPC-A Expand to EAN-13 .................................................................................................................................................. 42
Add On Supplement............................................................................................................................................................. 42
UPC-E ......................................................................................................................................................................................... 43

MT500 User’s Manual V1.0
4
Enable/Disable UPC-E......................................................................................................................................................... 43
UPC-E System Number....................................................................................................................................................... 43
Lead Digit............................................................................................................................................................................... 44
Check Digit ............................................................................................................................................................................ 44
UPC-E Expand to UPC-A.................................................................................................................................................... 44
Add On Supplement............................................................................................................................................................. 44
EAN-8.......................................................................................................................................................................................... 46
Enable/Disable EAN-8 ......................................................................................................................................................... 46
Lead Digit............................................................................................................................................................................... 46
Check Digit ............................................................................................................................................................................ 46
EAN-8 Expand to EAN-13 (Zero Extension)..................................................................................................................... 46
Add On Supplement............................................................................................................................................................. 47
EAN-13........................................................................................................................................................................................ 48
Enable/Disable EAN-13 ....................................................................................................................................................... 48
Lead Digit............................................................................................................................................................................... 48
Check Digit ............................................................................................................................................................................ 48
Add On Supplement............................................................................................................................................................. 48
ISBN ....................................................................................................................................................................................... 49
ISSN ....................................................................................................................................................................................... 50
ISMN....................................................................................................................................................................................... 50
CODE 128 .................................................................................................................................................................................... 51
Enable/Disable Code 128.................................................................................................................................................... 51
Code 128 Min/Max Length .................................................................................................................................................. 51
GS1-128(UCC/EAN 128).......................................................................................................................................................... 52
Enable/Disable GS1-128 ..................................................................................................................................................... 52
GS1-128 AIM ID.................................................................................................................................................................... 52
FUNC 1 Character................................................................................................................................................................ 52
GS1-128 Min/Max Length ................................................................................................................................................... 53
CODE 39 ...................................................................................................................................................................................... 54
Enable/Disable Code 39...................................................................................................................................................... 54
Verification ............................................................................................................................................................................. 54
Start/Stop ............................................................................................................................................................................... 54
Full ASCII Code39................................................................................................................................................................ 55
Code39 Min/Max Length ..................................................................................................................................................... 55
CODE 32 ...................................................................................................................................................................................... 56
Enable/Disable Code 32...................................................................................................................................................... 56
Leading/Tailing...................................................................................................................................................................... 56
CODE 93 ...................................................................................................................................................................................... 57
Enable/Disable Code 93...................................................................................................................................................... 57
Code 93 Min/Max Length .................................................................................................................................................... 57
CODE 11 ...................................................................................................................................................................................... 58
Enable/Disable Code 11...................................................................................................................................................... 58

MT500 User’s Manual V1.0
5
Verification ............................................................................................................................................................................. 58
Check Digit ............................................................................................................................................................................ 58
Code 11 Min/Max Length .................................................................................................................................................... 59
CODABAR (NW-7)........................................................................................................................................................................ 60
Enable/Disable Codabar...................................................................................................................................................... 60
Start/Stop ............................................................................................................................................................................... 60
Verification ............................................................................................................................................................................. 61
Codabar Min/Max Length .................................................................................................................................................... 61
CLSI Format .......................................................................................................................................................................... 62
ABC-Codabar ........................................................................................................................................................................ 62
CX-Codabar........................................................................................................................................................................... 63
Codabar Coupling................................................................................................................................................................. 64
INTERLEAVED 2OF 5.................................................................................................................................................................... 65
Enable/Disable Interleaved 2 of 5 ...................................................................................................................................... 65
Verification ............................................................................................................................................................................. 65
First / Last Digit Suppressed............................................................................................................................................... 65
Interleaved 2 of 5 Min/Max Length..................................................................................................................................... 66
IATA (STANDARD 2OF 5)............................................................................................................................................................ 67
Enable/Disable IATA ............................................................................................................................................................ 67
Verification ............................................................................................................................................................................. 67
IATA Min/Max Length........................................................................................................................................................... 67
MATRIX 2OF 5............................................................................................................................................................................. 68
Enable/Disable Matrix 2 of 5 ............................................................................................................................................... 68
Verification ............................................................................................................................................................................. 68
Matrix 2 of 5 Min/Max Length.............................................................................................................................................. 69
INDUSTRIAL 2OF 5....................................................................................................................................................................... 70
Enable/Disable Industrial 2 of 5.......................................................................................................................................... 70
Verification ............................................................................................................................................................................. 70
Industrial 2 of 5 Min/Max Length ........................................................................................................................................ 70
CHINA POSTAL CODE (TOSHIBA CODE)...................................................................................................................................... 72
Enable/Disable China Postal Code.................................................................................................................................... 72
Verification ............................................................................................................................................................................. 72
China Postal Code Min/Max Length .................................................................................................................................. 72
MSI PLESSEY............................................................................................................................................................................... 73
Enable/Disable MSI Plessey............................................................................................................................................... 73
Verification ............................................................................................................................................................................. 73
Check Digit ............................................................................................................................................................................ 73
MSI Plessey Min/Max Length ............................................................................................................................................. 74
UK PLESSEY ................................................................................................................................................................................ 75
Enable/Disable UK Plessey ................................................................................................................................................ 75
Verification ............................................................................................................................................................................. 75
TELEPEN....................................................................................................................................................................................... 75

MT500 User’s Manual V1.0
6
Enable/Disable Telepen....................................................................................................................................................... 75
Output Format ....................................................................................................................................................................... 75
GS1 DATABAR (RSS-14) ........................................................................................................................................................... 76
Enable/Disable GS1 DataBar ............................................................................................................................................. 76
Enable/Disable GS1 DataBar Stacked / Omnidirectional ............................................................................................... 76
Prefix AI.................................................................................................................................................................................. 76
Check Digit ............................................................................................................................................................................ 76
GS1 DATABAR LIMITED (RSS-LIMITED)..................................................................................................................................... 77
Enable/Disable GS1 DataBar Limited ............................................................................................................................... 77
Prefix AI.................................................................................................................................................................................. 77
Check Digit ............................................................................................................................................................................ 77
GS1 DATABAR EXPANDED (RSS-EXPANDED)........................................................................................................................... 77
Enable/Disable GS1 DataBar Expanded .......................................................................................................................... 77
Enable/Disable GS1 DataBar Expanded Stacked........................................................................................................... 78
GS1 DataBar Expanded Min/Max Length......................................................................................................................... 78
CHAPTER 7 APPENDIX.................................................................................................................................................... 79
APPENDIX -NUMBERS ................................................................................................................................................................. 79
APPENDIX -UPPER CASE ALPHABETS ........................................................................................................................................ 80
APPENDIX -LOWER CASE ALPHABETS........................................................................................................................................ 82
APPENDIX –CONTROL CODES .................................................................................................................................................... 84
APPENDIX –SYMBOLS ................................................................................................................................................................. 86
APPENDIX –FUNCTION KEYS ...................................................................................................................................................... 89
APPENDIX –NAVIGATION KEYS ................................................................................................................................................... 90
APPENDIX –MODIFIER KEYS ....................................................................................................................................................... 91
APPENDIX -ABORT ...................................................................................................................................................................... 92
APPENDIX -DEFAULT TABLE ....................................................................................................................................................... 93
APPENDIX -FACTORY ID AND AIM ID TABLE ............................................................................................................................. 99
APPENDIX -ASCII TABLE .......................................................................................................................................................... 101
VERSION HISTORY ......................................................................................................................................................... 105

MT500 User’s Manual V1.0
7
Chapter 1 Introduction
This user’s manual is dedicated to MT500, a wearable 1D wireless ring scanner that enables
hands-free scanning for mobile operators who work with smartphones or other mobile devices of
iOS and Android platform. With built-in Bluetooth 5.0 technology, MT500 provides 20-meter
wireless freedom to mobile operator.
Specifications
Optic & Performance
Light Source
625nm visible red LED
Sensor
Linear Image Sensor
Scan Rate
650 Scans/Sec
Resolution
4mil/ 0.1mm
Scan Angle
41°
Pitch Angle
±30°
Skew Angle
±40°
Roll Angle
±20°
Print Contrast Ratio
30%
Width of Field
140mm (13Mil Code39)
Memory
2MB (20,000 barcodes)
Typical D.O.F
(Environment: 800 lux)
4 Mil Code 39 : 38 ~ 81mm
5 Mil Code 39 : 32 ~ 107mm
10 Mil Code 39 : 28 ~ 212mm
15 Mil Code 39 : 41 ~ 316mm
LED Indicator
Function Button/
Power Button/
Toggle iOS keyboard
Exit Window
Velcro Strap
Micro USB port
(with protective cover)
Reset Button
(insert pin into the hole)
Touch-Activated
Trigger Button

MT500 User’s Manual V1.0
8
13 Mil UPC/EAN : 38 ~ 238mm
Physical Characteristics
Dimension
W27.5 x L46.2 x H26.8 mm
Weight
20.5g
Color
Black
Material
PC+ABS
Cable Micro(M) to USB A(M) Cable, 1.5M
Trigger Touch Switches (Trigger Buttons)
Function/Power Button
Indicator
LED, Buzzer
Electrical
Operation Voltage
3.7 VDC ± 5%
Working Current
< 110mA
Standby Current
< 25mA
Battery
3.7V, 240mAh, Li-Polymer Battery
Number of Scan
(per full charge)
7000 scans
(1 scan/ 5 secs, Bluetooth connected)
Connectivity
Radio
Bluetooth 5.0 dual mode (Class 2)
Range
66 ft/ 20m (line of sight)
Interface/ Profile
BT HID
BT SPP
USB HID
USB VCP
Memory
User Environment
Operating Temperature
-10 ~ 50˚C
Storage Temperature
-20 ~ 60˚C
Humidity
0% ~ 95%RH (Non-condensing)
Drop Durability
1.5M
Sealing
IP42
Ambient Light
70,000 Lux (Sunlight)
1D Symbologies
UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2
of 5, Codabar, Matrix 2 of 5, Code 11, Code
93, Code 32, Code 128, Standard Code 39,
Full ASCII Code 39, Interleaved 2 of 5, China
Postal Code, MSI Plessy Code, UK Plessy
Code, EAN/UCC 128, Telepen Code, IATA
Code, GS1 Databar
Regulatory

MT500 User’s Manual V1.0
9
ESD Functional after 4KV contact, 8KV air
discharge
EMC/RF
TELEC
Safety Approval
EN/IEC62471 (Exempt Group)
Environmental
WEEE, RoHS 2.0
Beeper Indication
Beeper Status
Single beep
Good read
Single short beep The scanner reads a Code39 ASCII during
multi-step configuration
Two beeps
Wireless connection
The scanner successfully reads a
configuration barcode
Three beeps
Wireless disconnection
Three short beeps
The scanner reads a barcode while
disconnected
The scanner reads an unexpected barcode
during multi-step configuration. (Please
scan “
Abort
” and start over)
Memory Full
Four beeps (Hi-Lo-Hi-Lo)
Out of range / Poor connection
Five beeps
Low power
LED Indication
LED Status
Off
Power off / Standby / Connected
Flashing blue
Disconnected / Discoverable
One green flash
Good read
Flashing red
Low power
Solid red
Charging

MT500 User’s Manual V1.0
10
Chapter 2 General Settings
Barcode Configurability
Scanning below configuration barcodes will allow/prohibit user to change settings by scanning
configuration barcodes in this manual.
Enable Barcode Configurability*
Disable Barcode Configurability
Factory Default
Scanning below configuration barcode will reset all parameters to factory default settings (the ones
with *asterisk mark)
Factory Default
Check Version
To check firmware version, please scan below configuration barcode.
Check Version

MT500 User’s Manual V1.0
11
Button Preference
Scan one of below barcodes to determine which touch-sensing button to enable according to
your habit:
Right Button Only
Left Button Only
(For Left-handed User) (For Right-handed User)
Both Button*
Good Read Indicator
Beep Tone
Off
Beep Low (2.0KHz)
Beep Medium (2.7KHz)
Beep High (4.0KHz)*

MT500 User’s Manual V1.0
12
Beep Mode
Normal*
Warning Beep Only
Mute

MT500 User’s Manual V1.0
13
Data Format
HT/CR/ESC Converts to TAB/ENTER/ESCAPE
Off*
On
Note:
1. By default, HT [$I], CR [$M] and ESC [%A] is transmitted as <0x09>, <0x0D> and <0x1B>
respectively.
2. When enabled, HT [$I], CR [$M] and ESC [%A] is transmitted as <TAB>, <ENTER> and
<ESCAPE> on keyboard respectively.
Function Code Conversion
Off
On*
Note:
Once disabled, the scanner will output the original encoded data of the barcodes in Appendix -
Function/Navigation/Modifier Keys.

MT500 User’s Manual V1.0
14
Numeric Key
Numeric Key
Alphanumeric Key*
Note:
1. By default, the alphanumeric key is used for trasmitting digits. Scan NUMERIC KEY if you want
to use the keys on the numeric keypad.
2. If you select NUMERIC KEY, the Num Lock status of the physical keyboard should be ON.
Capslock Mode
Capslock Off* Capslock On
Capslock Free
Note:
When barcode scanner is set to Capslock Free mode, no matter keyboard Capslock LED indicator
is ON or OFF, output will be always the same as the Original barcode. In other words, what you see
is what output is.

MT500 User’s Manual V1.0
15
Keyboard Layout
English (US)* English (UK)
Danish Spanish
Hungarian (QWERTZ) Hungarian (QWERTY)
Canadian French Dutch
Italian French
German Swiss German

MT500 User’s Manual V1.0
16
Swiss French
Swedish
Czech (QWERTZ) Czech (QWERTY)
Norwegian Belgian
Portuguese Slovak
Brazilian (QWERTY) Canadian (Traditional)
Japanese
Alt Code

MT500 User’s Manual V1.0
17
Intercharacter Delay
The configurable range is from 0 to 255ms. The larger the number, the longer the delay.
Set Intercharacter Delay
(Default = 4ms)
Example: Set Intercharacter Delay to 8ms
Step1: Scan Set Intercharacter Delay
Step2: Scan “0” “0” “8” in Appendix - Numbers
Step3: Scan Set Intercharacter Delay
Interblock Delay
The configurable range is from 0 to 2550ms. The larger the number, the longer the delay.
Set Interblock Delay
(Default = 0ms)
Example: Set Interblock Delay to 20ms
Step1: Scan Set Interblock Delay
Step2: Scan “0” “0” “2” in Appendix - Numbers
Step3: Scan Set Interblock Delay

MT500 User’s Manual V1.0
18
BCC (Binary Check Character)
On
Off*
Note:
Once enabled, a checksum will be added to the end of each data to conduct Xor calculation. For
Bluetooth SPP & USB VCP, the BCC is 1 byte. For Bluetooth HID & USB HID, the BCC are 2 bytes.
Example:
The barcode data is “TEST” with terminator <CR><LF>
1. BT SPP & USB VCP:
Data Format = <T> + <E> + <S> + <T> + <CR> + <LF> + <BCC>.
BCC = 54h ^ 45h ^ 53h ^ 54h ^ 0Dh ^ 0Ah = 11h
2. BT HID & USB HID:
Data Format = <T> + <E> + <S> + <T> + <Enter> + <BCC>
BCC = 54h ^ 45h ^ 53h ^ 54h ^ E7h = F1h
However, since control character cannot be displayed in Bluetooth HID, BCC will be converted into
2 bytes of characters.
As a result, the data will be: TEST + <Enter> + F + 1
Imaging Settings
Inverse Barcode
Disable Inverse Barcode* Enable Inverse Barcode

MT500 User’s Manual V1.0
19
Chapter 3 Interface
BT HID
Getting Connected
1. Press the function button on the top to power up the scanner.
2. Scan “Disconnect”, the scanner will emit two beeps.
Disconnect
3. Scan “BT HID”, the scanner will emit two beeps.
BT HID
4. Select “Wireless Scanner” from discovered device list.
5. If Bluetooth application prompts you to enter a pincode, please follow the steps in Pincode
Setup section.
6. The scanner will emit two beeps as indication that the Bluetooth connection has established
successfully.
7. While conneted with the scanner as physical keyboard, the touch keyboard on iOS/Android
device might disappear. To resolve this issue please do the following:
(1) For iOS device, simply press the function button on the top once.
(2) For Android device, go to “Settings” > “Language & Input”, tap on “Default keyboard” and
turn off “Physical keyboard” or turn on “On-screen keyboard”.

MT500 User’s Manual V1.0
20
Pincode Setup
If Bluetooth application prompts you to enter a pincode, please follow the steps:
1. Scan “Pincode Start”
Pincode Start
2. Scan numeric barcodes below according to the pincode generated by the Bluetooth application.
0
1
2
3
4
5
6
7
8
9
3. Scan “Enter”
Enter
