Martin XHD QC 1 User manual

MARTIN®XHD QC™ #1
Primary cleaner
Installation manual
M3504UK

© Martin Engineering GmbH M3504UK-10/15

© Martin Engineering GmbH 1 M3504UK-10/15
Contents
1 Contents
1 Contents ............................................................................ 1
2 Introduction ...................................................................... 3
2.1 About this Installation sManual .......................................... 3
2.1.1 Scope ............................................................................ 3
2.1.2 Copyright ....................................................................... 3
2.1.3 Disclaimer ...................................................................... 3
2.1.4 Reference to additional documentation ......................... 4
2.1.5 Classification of hazards................................................ 5
2.2 Appropriate Use ................................................................. 6
2.2.1 Conveyor belt systems with open transfer systems ...... 6
2.2.2 Use in EX-protection areas ............................................ 6
2.2.3 Operating limits of this product ...................................... 6
2.3 Safety in the Workplace ..................................................... 7
2.3.1 Safety instructions, safety in the workplace ................... 7
2.3.2 Obligations of the operator ............................................ 7
2.3.3 Authorised personnel ..................................................... 7
3 Product Description ......................................................... 8
3.1 Design and Function .......................................................... 8
3.2 Tensioners ......................................................................... 8
3.3 Type explanation................................................................ 9
4 Installation Preparation ................................................. 10
4.1 Prior to Installation ........................................................... 10
4.1.1 Materials and tools required ........................................ 10
4.1.2 Preparatory measures ................................................. 10
5 Installation ...................................................................... 12
5.1 Safety instructions............................................................ 12
5.2 Installation procedure....................................................... 13
5.2.1 Determining the installation position ............................ 13
5.2.2 Installing the tensioner ................................................. 16
5.2.3 Installing the primary cleaner ....................................... 16
5.2.4 Centre the primary cleaner axis below
the conveyor belt ......................................................... 17
5.2.5 Adjust the primary cleaner parallel
to the conveyor belt ..................................................... 18
5.2.6 Levelling the primary cleaner ....................................... 18
5.2.7 Install locking sleeve .................................................... 19
5.2.8 Tensioning the primary cleaner blade ......................... 19
5.3 Probelauf.......................................................................... 20
5.4 Installation - Check-list .................................................... 21
5.5 Attaching the warning label or the warning tag ................ 22
6 Maintenance ................................................................... 23
6.1 Safety instructions............................................................ 23
6.2 Weekly maintenance........................................................ 23
6.3 Replacing the cleaner blades........................................... 25
7 Troubleshooting ............................................................. 27
7.1 Safety instructions............................................................ 27

© Martin Engineering GmbH 2 M3504UK-10/15
Contents
7.2 Troubleshooting ................................................................ 27
8 Storage, deinstallation, disposal ...................................29
8.1 Packing and transportation ............................................... 29
8.2 Storage ............................................................................. 29
8.3 Deinstallation .................................................................... 29
8.4 Disposal ............................................................................ 29
9 Part numbers ...................................................................30
9.1 Part numbers - Explanation .............................................. 30
9.2 Tensioners ........................................................................ 31
9.3 Martin®Inspection Doors.................................................. 31
9.4 Installation manuals .......................................................... 31
9.5 Accessories....................................................................... 31
9.6 Warning labels / Warning trailers...................................... 31
9.7 Martin®XHD QC™ #1 Pre-cleaner................................... 32
9.8 Martin®XHD QC™ #1 Pre-cleaner (dual blade)............... 36
10 Declaration of Incorporation ..........................................39

© Martin Engineering GmbH 3 M3504UK-10/15
Introduction
2 Introduction
2.1 About this Installation sManual
Non-compliance with this installation manual may lead to compen-
sation claims for loss or damage and/or warranty claims becoming
null and void.
2.1.1 Scope
This installation manual applies exclusively to the product described
herein and is aimed at those individuals who install dasthis product,
put it into operation and monitor its use.
2.1.2 Copyright
The product described and this installation manual are protected by
copyright. Copying without a license will be legally prosecuted. All
rights to this document are reserved, including the reproduction and/
or distribution in any thinkable way or form. The reprinting of this
document is only allowed with written permission from Martin Engi-
neering.
The technical standard at the time of delivery of the product and
technical documentation is decisive, as long as no other information
is given. We reserve the right to make technical changes without any
announcement. Earlier documents will no longer be valid. Martin En-
gineering General Conditions of Sale and Delivery apply.
2.1.3 Disclaimer
Martin Engineering guarantees the faultless operation of the product
according to the advertising, edited product information, and techni-
cal documentation. Martin Engineering does not accept any liability
for the efficiency and proper operation, if this product is used for any
other purpose, other than as described in the section "Appropriate
Use"; or for any damage caused by the use of accessories and/or
spare parts, that were not delivered and/or certified by Martin Engi-
neering.
The products from Martin Engineering are designed for a long ser-
vice life. They conform to the respective current state-of-the-art sci-
ence and technology and they have been thoroughly tested prior to
delivery. In addition to continuous advanced development of prod-
ucts, Martin Engineering also conducts constant product and market
analyses.

© Martin Engineering GmbH 4 M3504UK-10/15
Introduction
In the event of faults and/or technical problems Martin Engineering
offers professional support. Appropriate steps will be taken immedi-
ately. Martin Engineering's warranty conditions apply, which can be
sent if required.
2.1.4 Reference to additional documentation
The following documents are referred to in this installation manual:
• Installation manual for the MARTIN®Inspection Door,
document no. M3127.
• Installation manual for the MARTIN®XHD tensioners,
document no. M3713 or M3714.
• Operating instructions for the MARTIN®XHD Turnbuckle
Spring Tensioner
Document no. PRO 0724.
The following standards and directives were applied when compos-
ing this installation manual:
• EU Machinery Directive (2006/42/EC)
• ISO/IEC Guide 37 "Installation instructions for end-
consumer used products“, edition 1995
• DIN 1421 "Structure and numbering in texts", edition 1983-
01
• DIN/EN 12100 "Safety of machinery - Basic concepts,
general principles of design", edition 2013-08
• DIN / ISO 16016 "Technical product documentation -
Protection notices for restricting the use of documents and
products", edition 2007-12
• DIN/EN 60204-1 "Safety of machinery - Electrical
equipment of machines, Part 1, General requirements",
edition 2007-06
• DIN EN 82079-1 Preparation of instructions for use -
Structuring, content and presentation - Part 1: General
principles and detailed requirements.

© Martin Engineering GmbH 5 M3504UK-10/15
Introduction
2.1.5 Classification of hazards
DANGER!
This indicates an imminent danger that leads to serious physical
injuries or death, if not avoided.
WARNING!
This indicates a potentially dangerous situation that could lead to
serious physical injuries or death, if not avoided.
CAUTION!
Indicates a potentially dangerous situation that could lead to minor
bodily injury and/or damage to property if not avoided.
NOTE
Contains information to the installation or use of the product and
points to situations, that cause neither injuries nor property dam-
age, but is nevertheless important information.

© Martin Engineering GmbH 6 M3504UK-10/15
Introduction
2.2 Appropriate Use
The MARTIN®XHD QC™#1 primary cleaner is only used for clean-
ing conveyor belts. It can be used on conveyor belts with a width of
up to 3,000 mm and a belt speed of up to 6 m/s. The primary cleaner
can only be used directly on the head drum.
Any other use of this product is deemed to be inappropriate. If you
wish to use the product for any other purpose, please contact Martin
Engineering Customer Service. We will be happy to assist you with
product configuration.
2.2.1 Conveyor belt systems with open transfer systems
This installation manual describes the installation on a conveyor belt
system with an encapsulated delivery system. For the installation on
open delivery systems different MARTIN®installation consoles can
be used.
If installation conditions prove to be difficult, as is the case with im-
passable static components, or using the head drum as the tension
point, Martin Engineering or a representative can help with the posi-
tioning or find customised solutions.
2.2.2 Use in EX-protection areas
Under certain circumstances, this product can also be used in po-
tentially explosive areas. Contact Martin Engineering for more infor-
mation on use in potentially explosive areas.
The use of the cleaner in a device protection category that is higher
than that specified or under operating conditions other than those
specified by Martin Engineering is not permissible or may be done
only if Martin Engineering has granted its approval.
2.2.3 Operating limits of this product
The use of the product mentioned here is allowed only within the
specified specifications. Using it in a higher than specified equip-
ment category or under operating conditions other than those
named and previously specified by Martin Engineering is considered
to be inappropriate use and can only be carried out if approved by
Martin Engineering.
If the product mentioned here is to be used for a different purpose,
then Martin Engineering or a representative can help with the prod-
uct configuration.

© Martin Engineering GmbH 7 M3504UK-10/15
Introduction
2.3 Safety in the Workplace
2.3.1 Safety instructions, safety in the workplace
This installation manual must be read through in full prior to com-
mencing work on the product or the customer's conveyor belt.
The operator must ensure that all installation, inspections, and main-
tenance tasks are carried out exclusively by authorised experts.
All work on conveyor belts and their accessories must always be
carried out only when the system is at a standstill. It is essential that
the procedures described in the respective installation manual, -
which explain how to shut-down the conveyor system are followed.
Upon completion of work, all safety equipment and protective
guards must be reinstalled and put back into operation.
Prior to commissioning, installation must be completed. Before the
conveyor belt can be put back into operation, the flawless execution
of all steps should be checked and verified. All notes on installation
and commissioning of the product should be observed.
2.3.2 Obligations of the operator
The operator of this product must ensure that the personnel entrust-
ed with the installation, maintenance and use of this product are only
those personnel who
• are fully aware of regulations governing safety at work and
accident prevention,
• are instructed in the use of the product and have read and
understood this installation manual in full.
2.3.3 Authorised personnel
Personnel are considered to be authorised when they have complet-
ed the necessary training, hold the technical experience, knowledge
of the relevant standards and directives and are also in a position to
assess any task in order to recognise a critical situation in a timely
fashion and at an early stage.
Operational, Maintenance and Installation Personnel
Personnel are considered to be authorised if they have been in-
structed in the use of the product and have read and understood this
installation manual in full.

© Martin Engineering GmbH 8 M3504UK-10/15
Product Description
3 Product Description
3.1 Design and Function
The XHD QC™#1 belt cleaner (VHD = eXtra Heavy Duty) is de-
signed for extremely heavy-duty applications; it can be used on con-
veyor belts with a width of up to 3000 mm and a belt speed of up to
6 m/sec. Placing the installation position of the primary cleaner at
the head drum and the primary cleaner (e.g. QC™#2) just after the
head drum ensures that scraped-off material is again added to the
material flow.
The pre-cleaner and the primary cleaner can be used individually,
but for optimum cleaning results it is recommended to install a com-
bined system of pre- and primary cleaners.XXX
3.2 Tensioners
The MARTIN®XHD QC™#1 belt cleaner and the Martin Engineering
tensioners, specifically developed for it, provide the best results and
conform to the general state-of-the-art technology.
Martin Engineering recommends the following tensioners for the
MARTIN®XHD QC™#1 belt cleaner:
•MARTIN
®XHD Spring Tensioner (with rubber dampers),
part no. 38003+E
•MARTIN
®XHD Turnbuckle Spring Tensioner, part no.
35978+E
•MARTIN
®XHD Air Tensioner, Part no. 32135+E
NOTE
A product that has not been installed properly or correctly may dis-
rupt the conveyance process and contaminate the bulk material to
be transported.
The operator is therefore responsible for implementing the neces-
sary counter measures.
When using with contaminants Martin Engineering or a represent-
ative can help with the positioning or customized solutions.

© Martin Engineering GmbH 9 M3504UK-10/15
Product Description
3.3 Type explanation
Cleaner blades for the XHD QC™#1 primary cleaner are available
in different materials. The required material can be selected to
match the respective material conditions. The selection of different
materials for blades is listed in the section on ‘Part numbers’.

© Martin Engineering GmbH 10 M3504UK-10/15
Installation Preparation
4 Installation Preparation
4.1 Prior to Installation
4.1.1 Materials and tools required
In addition to the standard tools, the following special instruments
may be needed for the installation and maintenance of the
product.
• Lifting device with a capacity greater than the weight of the
coneveyor belt cleaner (note the weight on the delivery
note).
4.1.2 Preparatory measures
1. Check the delivery with respect to the following:
• Is the delivery complete? Is the number of pallets/cases/
containers the same as the number on the delivery note?
• Does all the transport packaging appear to be undamaged?
Is there damage which may indicate that the contained
products may be damaged?
2. If the delivery is incomplete or there is any transit damage,
make sure that this is documented and have the freight forward-
er confirm the same. All damaged products should be saved for
inspection.
NOTE
Pay attention to the following checks and carry them out carefully
and completely.
The freight forwarder is responsible for any transport damage!
For any damage claims, please contact the freight forwarder.
NOTE
A product that has not been installed properly or correctly may dis-
rupt the conveyance process and contaminate the bulk material to
be transported.
The operator is therefore responsible for implementing the neces-
sary counter measures.
For applications involving dirt or impurities, please contact Martin
Engineering or
one of its representatives for advice.

© Martin Engineering GmbH 11 M3504UK-10/15
Installation Preparation
3. Depending on the scope of the order, the delivery should con-
tain the following parts:
•MARTIN
®XHD QC™#1 primary cleaner,
• any accessories as ordered,
• Two warning labels for conveyor belt products
Part no. 23395G
4. Missing or damaged parts must be reported to Martin Engineer-
ing or the authorised dealer.

© Martin Engineering GmbH 12 M3504UK-10/15
Installation
5 Installation
5.1 Safety instructions
NOTE
Read this section thoroughly prior to commencing any work.
WARNING! DANGER OF INJURY!
Body parts and/or clothing may get caught and pulled in by rotat-
ing parts or by the moving conveyor belt.
Before any installation or maintenance work is carried out, ensure
that all power sources to the conveyor belt system and its acces-
sories are switched off and secured against inadvertent switching-
on. Use warning signs!
WARNING! EXPLOSION HAZARD!
In enclosed areas there is an increased risk of explosion when
using a cutting torch or welding equipment!
Before use, check the level of gas and dust in the air.

© Martin Engineering GmbH 13 M3504UK-10/15
Installation
5.2 Installation procedure
5.2.1 Determining the installation position
Determining the position of the mainframe and the tensioner of the
MARTIN®QC™#1 primary cleaner must be done on both sides of
the chute wall. In the process, those positions are determined where
the mainframe of the MARTIN®XHD QC™#1 primary cleaner pass-
es through the chute wall or where the tensioner is installed on the
chute wall.
The MARTIN®XHD QC™#1 primary cleaner is operated along with
a tensioner. This is disassembled at the factory before delivery and
is reassembled during the installation along with the primary clean-
er.
The installation of the MARTIN®XHD QC™#1 primary cleaner and
the spring tensioner is described in this manual and the installation
manual of the tensioner.
There follows an overview of the installation steps:
There may be different local conditions that require different working
steps, which are shown below:
Installation on an encapsulated delivery system
• Carry out the instructions given in section 5.2.2 onwards.
Installation on an encapsulated delivery system with existing instal-
lation openings and brackets for belt cleaners.
• Carry out the instructions given in section 5.2.3 onwards.
Installation on an open delivery system
• Use the local resources to ensure that the dimensions for
the installation are correctly maintained.
1. Before starting with the work of installing the conveyor belt sys-
tem, switch off all accessories and secure them against being
switched on again inadvertently.
No. Installation step Instruction
1 Installing the scraper M3504
2Installing the tensioner Tensioner
3 Tensioning the scraper Tensioner
Tab. 1: Installation steps

© Martin Engineering GmbH 14 M3504UK-10/15
Installation
2. Determine the midpoint position of the mainframe as described
below for the primary cleaner.
3. Mark the vertical and horizontal centre line of the driving drum
on the operator side of the chute wall to determine the midpoint
(1, Fig.1) of the driving drum. The vertical line must run at right
angles to the conveyor line.
NOTE
The MARTIN®XHD QC™#1 primary cleaner is installed only in the
front lower quarter of a head pulley. The specified installation
measurements must be strictly observed.
Fig. 1: Marking the installation radius
NOTE
Martin Engineering recommends the installation of a MARTIN®
inspection door for improved access during maintenance and
repair.
1
A + X

© Martin Engineering GmbH 15 M3504UK-10/15
Installation
4. Determine or measure the radius (measurement A) of the driv-
ing drum including the thickness of the covering and the con-
veyor belt.
5. Add measurement X from table 2 to measurement A.
6. On the chute wall, mark a circular arc around the midpoint with
the measurement determined in step 5 (1, Fig.1).
7. Mark a horizontal line below the horizontal centre line of the
head drum at a distance of 355 mm. The intersection with the
arc marked in step 5 is the midpoint of the mainframe (3, Fig.2).
Diameter of the drum* in mm Measurement X in
mm
400 146
500 140
600 133
700 127
750 - 3000 120
*incl. Friction material and conveyor belt
Tab. 2: X values for the positioning of the blade shaft
Fig. 2: Marking the installation height
WARNING! DANGER OF INJURY!
The primary cleaner is heavy and can cause serious injury if it falls
when being lifted or moved.
Only lift the secondary cleaner using suitable lifting device or with
several persons. Do not stand under suspended loads.
390°
355
90°
mm

© Martin Engineering GmbH 16 M3504UK-10/15
Installation
8. Repeat steps 1 to 7 on the opposite side of the chute wall.
5.2.2 Installing the tensioner
Observe the respective instructions on installing the tensioner in the
respective operating manual of the tensioner used. (See Chapter
2.1.4).
5.2.3 Installing the primary cleaner
1. First remove the scraper blade from the mainframe as de-
scribed below:
• Open the safety clip (1, Fig.3) and pull it out for this
purpose.
• Then pull out the cleaner blade (2, Fig.3) from the spring
dowel sleeve (3, Fig.3).
2. Remove the two spring tensioners from the mounting plates.
NOTE
This is the best possible installation position recommended by
Martin Engineering for the MARTIN®XHD QC™#1 primary cleaner
to achieve optimum cleaning results. Should this not be possible
for structural reasons, the primary cleaner can, in consultation with
Martin Engineering, also be installed at an angle of 20° above or
below, but the installation radius must be adhered to in every
case.
Fig. 3: Installing the primary cleaner
2
1
3

© Martin Engineering GmbH 17 M3504UK-10/15
Installation
3. Slide one spring bushing of the spring tensioner each on both
sides onto the mainframe. Slide the spring bushing with the
shaft into the mounting plates
4. Slide one side of the primary leaner shaft through the mounting
plate on the opposite side.
5. Then slide the other end into the mounting plate on the operator
side.
6. Slide the scraper blade on the shaft into the coiled spring pin.
7. Secure the scraper blade with the safety clip.
5.2.4 Centre the primary cleaner axis below the conveyor belt
Measure on both sides the distance (A) to (B) between the edge of
the cleaning elements and the conveyor belt edge.
Slide the cleaner until distance A is equal to distance B. The convey-
or belt should protrude about 50 to 100 mm on both the left and the
right sides. The scraper blade must be positioned in the centre be-
low the conveyor belt.
Fig. 4: Installing the primary cleaner
Fig. 5: Centring the cleaner shaft (example)
A = B
AB

© Martin Engineering GmbH 18 M3504UK-10/15
Installation
5.2.5 Adjust the primary cleaner parallel to the conveyor belt
Measure the distance on both sides between the scraper blade and
the head drum. To do this, place the scraper blade against the con-
veyor belt. The measurements on both sides must be equal.
5.2.6 Levelling the primary cleaner
Level the primary cleaner shaft to the head drum or check that the
scraper blade is positioned evenly against the conveyor belt.
Once all the measurements are correct and the primary cleaner is
adjusted it can then be fixed in position; if not, it should be reinstalled
or re-positioned.
Fig. 6: Adjust the primary cleaner shaft parallel to the head drum
(example)
Fig. 7: Levelling the primary cleaner shaft (example)
B
A = B B
A
A
A = B
A
B
A = B
