Masimo RD SET Adapter Cable Series User manual
© 2016 Masimo Corporation
RD SET™
Adapter Cable Series
Images 2
en English 3-5
29147A-eIFU-0116
RD SET™
Adapter Cable Series
Fig. 1
Fig. 2 Fig. 3
Fig. 4
Fig. 5 Fig. 6
39147A-eIFU-0116
en
RD SET™
Adapter Cable Series
DIRECTIONS FOR USE
Reusable
LATEX
PCX-2108A
02/13
Not made with natural rubber latex Non-Sterile
INDICATIONS
The RD SET™ Adapter Cable Series have the same indications for use as the applicable sensors. Please see the compatible
sensor’s directions for use for indications for use and prescribed information.
DESCRIPTION
The RD SET Adapter cables allow Masimo RD SET sensors to be used on PC or M-LNC and RC patient cables on Masimo® SET®
or Masimo rainbow® SET devices.
RD SET Adapter Cable Series consist of the following:
• RD to PC Adapter Cable
• RD to M-LNC Adapter Cable
The RD SET Adapter Cable Series have been veried using Masimo SET or Masimo rainbow SET technology.
WARNING: Masimo sensors and cables are designed for use with devices containing Masimo rainbow SET oximetry or
licensed to use Masimo sensors.
WARNINGS
• Always refer to the oximeter module operator’s manual for complete instructions or additional instructions.
• Ensure the cable is physically intact, with no broken or frayed wires or damaged parts. Visually inspect the cable and
discard if cracks or discoloration are found.
• All sensors and cables are designed for use with specic monitors. Verify the compatibility of the monitor, cable and
sensor before use, otherwise degraded performance and/or patient injury can result.
• Carefully route patient cable to reduce the possibility of patient entanglement or strangulation.
• Failure to properly connect the sensor or the oximeter module to the cable will result in intermittent readings,
inaccurate results, or no reading.
• To avoid damage to the cable, always hold it by the connector rather than the cable when connecting or disconnecting
either end.
• To prevent damage, do not soak or immerse the sensor or cable in any liquid solution. Do not attempt to sterilize the
cable or sensor.
• Do not attempt to reprocess, recondition or recycle Masimo sensors or patient cables as these processes may damage
the electrical components, potentially leading to patient harm.
INSTRUCTIONS
A)
Attaching the RD SET Adapter Cable to a Patient Cable
RD
to PC Adapter Cable
1. Refer to Fig. 1. Orient the connecting tab so that the “shiny” contacts are facing up and mate to the patient cable.
2. Insert the connector into the patient cable connector until there is a tactile or audible click of connection.
3. Gently tug on the connectors to ensure a positive contact.
RD
to M-LNC Adapter Cable
1. Refer to Fig. 2. Properly orient and insert the connector completely into the patient cable connector.
2. Refer to Fig. 3. Completely close the protective latch.
B) Disconnecting the RD SET Adapter Cable from a Patient Cable
RD to PC Adapter Cable
1.
Refer to Fig. 4.
Place thumb and index finger on the buttons on either side of the connector.
2. Press firmly on the buttons and pull to remove.
RD
to a M-LNC Adapter Cable
1. Refer to Fig. 5. Lift the protective latch to gain access to the connector.
2. Refer to Fig. 6. Pull firmly on the connector to remove from the patient cable. To avoid damage, pull on the connector, not
the cable.
CLEANING
1. Remove the sensor from the patient and disconnect it from the adapter cable .
2. Clean the surface of the cable by wiping it with a 70% isopropyl alcohol pad .
3. Wipe all surfaces of the cable
4. Saturate another cloth or gauze pad with sterile or distilled water and wipe all surfaces of the cable .
5. Dry the cable by wiping all surfaces with a clean cloth or dry gauze pad.
CAUTION:
• Do not immerse the connector on the cable in any liquid solution.
• Do not sterilize by irradiation, steam, autoclave, or ethylene oxide.
• Do not clean with chemicals not approved above.
49147A-eIFU-0116
ENVIRONMENTAL
Operating Temperature 41°F to 104°F (5°C to 40°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Relative Humidity 10% to 95% non-condensing
WARRANTY
Masimo warrants to the initial buyer only that these products, when used in accordance with the directions provided with the
Products by Masimo, will be free of defects in materials and workmanship for a period of six (6) months. Single use products
are warranted for single patient use only.
THE FOREGOING IS THE SOLE AND EXCLUSIVE WARRANTY APPLICABLE TO THE PRODUCTS SOLD BY MASIMO TO BUYER. MA-
SIMO EXPRESSLY DISCLAIMS ALL OTHER ORAL, EXPRESS OR IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION ANY
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE. MASIMO’S SOLE OBLIGATION AND BUYER’S EX-
CLUSIVE REMEDY FOR BREACH OF ANY WARRANTY SHALL BE, AT MASIMO’S OPTION, TO REPAIR OR REPLACE THE PRODUCT.
WARRANTY EXCLUSIONS
This warranty does not extend to any product that has been used in violation of the operating instructions supplied with
the product, or has been subject to misuse, neglect, accident or externally created damage. This warranty does not extend
to any product that has been connected to any unintended instrument device or system, has been modied, or has been
disassembled or reassembled. This warranty does not extend to sensors or cables that have been reprocessed, reconditioned
or recycled.
IN NO EVENT SHALL MASIMO BE LIABLE TO BUYER OR ANY OTHER PERSON FOR ANY INCIDENTAL, INDIRECT, SPECIAL OR CON-
SEQUENTIAL DAMAGES (INCLUDING WITHOUT LIMITATION LOST PROFITS), EVEN IF ADVISED OF THE POSSIBILITY THEREOF. IN
NO EVENT SHALL MASIMO’S LIABILITY ARISING FROM ANY PRODUCTS SOLD TO BUYER UNDER A CONTRACT, WARRANTY,
TORT OR OTHER CLAIM EXCEED THE AMOUNT PAID BY BUYER FOR THE LOT OF PRODUCTS INVOLVED IN SUCH CLAIM.
IN NO EVENT SHALL MASIMO BE LIABLE FOR ANY DAMAGES ASSOCIATED A PRODUCT THAT HAS BEEN REPROCESSED,
RECONDITIONED OR RECYCLED. THE LIMITATIONS IN THIS SECTION SHALL NOT BE DEEMED TO PRECLUDE ANY LIABILITY
THAT, UNDER APPLICABLE PPRODUCTS LIABILITY LAW, CANNOT LEGALLY BE PRECLUDED BY CONTRACT.
NO IMPLIED LICENSE
Purchase or possession of this RD SET Adapter Cable does not carry any express or implied license to use this RD SET Adapter
Cable with any device that is not an authorized device or separately authorized to use RD SET Adapter Cables.
CAUTION: FEDERAL LAW (U.S.A.) RESTRICTS THIS DEVICE TO SALE BY OR ON THE ORDER OF A PHYSICIAN.
For professional use. See instructions for use for full prescribing information, including indications, contraindications, warn-
ings, precautions and adverse events.
59147A-eIFU-0116
The following symbols may appear on the product or product labeling:
SYMBOL DEFINITION SYMBOL DEFINITION
i
GR-10184A
Consult Instructions for Use Separate collection for electrical and electronic equipment
(WEEE).
GR-10199B
(blue background) Follow Instructions for Use LOT Lot code
Title: Graphic, Manufacturer Symbol, Masimo
PCX-1986
Revision A
DRO-23934
05/09
Manufacturer REF Catalogue number (model number)
Date of Manufacture Masimo reference number
Use By YYYY-MM Body weight
NON
STERILE
LATEX
Title:Graphics, Sensor/Cable symbols, 03/06
GR-14231
DRO-13914
-40 C
+70 C
+1060 hPa - +500 hPa
795 mmHg - 375 mmHg
5%-95% RH
5%
95%
%
Do not discard >Greater than
Non-Sterile <Less than
LATEX
PCX-2108A
02/13
Not made with natural rubber latex Storage Humidity Limitation
R
x
Only
Federal law (USA) restricts this device to sale by or on the
order of a physician
Storage Temperature Limitation
Mark of Conformity to European Medical Device Directive
93/42/EEC Keep Dry
EC REP Authorized representative in the European community Do not use if package is damaged
X
Light Emitting Diode (LED)
LED emits light when current ows through
Instructions/Directions for Use/Manuals are available in
electronic format @
http://www.Masimo.com/TechDocs
Note: eIFU is not available for CE mark countries.
Patents: http://www.masimo.com/patents.htm
Masimo, SET, , and rainbow are federally registered trademarks of Masimo Corporation.
RD SET and rainbow SET are trademarks of Masimo Corporation.
Printed in USA.
© 2016 Masimo Corporation
Masimo Corporation
40 Parker
Irvine, CA 92618
USA
www.masimo.com
Manufacturer: EU Authorized Representative for Masimo
Corporation:
EC REP
MDSS GmbH
Schigraben 41
D-30175 Hannover, Germany
9147A-eIFU-0116
