Masimo SafetyNet Radius PPG Manual

Apply Sensor
See instructions on the back
showing how to apply the sensor
to your wrist and finger
and insert the chip.
Pair Sensor
Under Masimo SafetyNet App
Settings, enter the Add Device menu,
and follow instructions for pairing the
Radius PPG sensor to your phone.
1
2
3
Setup Instructions
Radius PPGTM
GET TO KNOW YOUR SYSTEM
see back for sensor application
Masimo SafetyNet displays Oxygen Saturation,
Pulse Rate, Respiration Rate and other data from
Radius PPG. It also sends data to your care provider.
Masimo SafetyNet App
page 1 of 2
Getting Started
Masimo SafetyNet™
Set-up Masimo
SafetyNet App
Follow instructions from the email
or text message invitation to
download the Masimo SafetyNet
App and create an account.
Warning: Do not self-diagnose or self-medicate on the basis of the
measurements. Always consult your doctor.
© 2020 Masimo. All rights reserved. 301295/10689C-0620
Radius PPGTM Sensor
Worn on your wrist and fingertip, the
sensor measures Oxygen Saturation,
Pulse Rate, and Respiration Rate.
Radius PPGTM Chip
Snapped into the wrist portion
of the sensor, the chip sends your
data to the Masimo SafetyNet App.
Wearable Sensors
For additional resources,
including videos and instructions,
visit mymasimo.com
Masimo Safetynet | Build 1.0.0.0
Masimo SafetyNetTM
RadiusT °

2.1 Sensor Set Up
How to Apply your Sensor
2.2 Apply Finger Sensor
2.3 Insert Chip
3. Place sensor on wrist as shown and
carefully thread the tip of the strap
through the open red loop
4. Wrap the loose end of the strap
around your wrist and press
1. Remove sensor from pouch 2. Peel off yellow label
to activate battery
Listen for click
to confirm
chip placement
Look for light to
confirm chip
connection to sensor
1. Insert the chip into the open
compartment on the sensor
2. Press down on the chip to secure
page 2 of 2
Place black
square ( )
on finger pad
1. Remove part of the plastic film
and place star ( ) on top of
fingernail of ring finger
2. Wrap halfway around finger. Make
sure the star and square are lined
up directly across from each other
4. Remove plastic film
and continue to
wrap remainder
around finger
3. Squeeze top and
bottom of wrap
to secure
5. Adjust cable to
comfortable length
For additional resources, including videos and instructions, visit mymasimo.com
