MASINGO Soprano X1 User manual

Do not expose this product
to water, moisture, heat, or
steam. Do not place objects
filled with liquid on this
product.
Replace battery only with
the same or equivalent type
and size. Danger of explosion
if battery is incorrectly
replaced.
Check the machine for
damage before each use.
Clean and store the machine
after each use.
Do not expose battery to
excessive heat such as
sunshine, fire, or other heat
sources to reduce risk of fire
or explosion.
Do not use the machine with
attachments not approved
by the manufacturer.

Machine
How to charge the machine
Connect the charger plug into the machine’s DC15V/2A Charging
Cable Input and to a polarized outlet. Be sure to charge fully before
each use. The indicator light will turn on to indicate charging.
How to turn the machine on/o
Press the left side of the Power switch on the machine’s function
board labeled MACHIN ON, DISCO ON to turn on the machine
along with the LED lights and disco ball.
Press the right side of the Power switch on the machine’s function
board labeled MACHIN ON, DISCO OFF to turn on the machine
without the LED lights or disco ball.
To turn o the machine (as well as the LED lights and disco ball if
they are on), return the Power switch to its original middle position.

Microphones
How to charge the microphones
Plug the MicroUSB included into the bottom of the microphone
and into a wall outlet. Be sure to charge fully before each use.
While charging, the battery icon on the display will flash, then
stop flashing when the battery is full.
How to turn the microphones on
Turn on the microphones using the Power button on each handle.
They will automatically connect to the machine.
Note: The microphones will automatically turn o after 15 minutes
of no use.
How to set up the microphone
he A-B button controls both the microphone’s channel and the
microphone’s frequency band.
IMPORTANT: When using both microphones simultaneously, each
microphone must be set to a dierent frequency band (that is,
one must be set to CHA while the other one is set to CHB). If both
microphones are set to the same frequency band, the microphone
audio may cut in and out.
Changing the Frequency Band: The frequency band is represented
by the letters CHA or CHB in the bottom left corner of the LED
display. To change the microphone’s frequency band, hold the
A-B button for one second until the desired band is reached. One
microphone MUST be set to CHA while the other MUST be set to
CHB.
Changing the Microphone Channel: Channel is represented on
the microphone LED screen as a number from CH1 to CH8. To
cycle through possible channels, click the A-B button until the
desired channel is reached. Unlike frequency bands, having both
mics on the same numbered channel will not negatively impact
performance.

How to customize your microphone vocal mix
To adjust the volume of your singing over the music, click the
Volume +/- buttons up or down as desired. Use the EQ button to
choose between 5 dierent equalizer selections.
Music
How to set up playback
Your machine has 6 dierent playback options: Bluetooth, SD,
AUX, USB, FM, and PA. Each has its own hook up location (diagram
on page 7) and set-up method (see the subsections below).
How to connect to Bluetooth
Playing music from your device
Click the Mode button on the machine’s function board until the
digital display indicates you are in Bluetooth mode. Then, search
for the machine name “MASINGO” under your device’s Bluetooth
connection settings and click to connect.
How to use SD mode
Playing music from an SD card
Plug your MicroSD card into the MicroSD Slot on the machine’s
function board. The stored music on your SD card will begin
playing automatically.
How to start AUX mode
Playing music from an AUX-compatible device
Plug the AUX cable into the AUX Input on the machine’s function
board to activate AUX mode. Plug the other end of the cable into
the designated input on your device and play your music just as
you normally would.

How to connect to a TV
Plug the AXU-RCA cable into the AUX input on the machine’s
function board to activate AUX mode in order to connect a TV.
Insert the other end into the designated port on your TV and play
your music just as you would in regular AUX mode.
How to start USB mode
Playing music from a USB drive
Plug your USB into the USB Port on the machine’s function board.
The stored music on your USB will begin playing automatically.
How to connect to FM mode
Playing music from an FM radio station
Click the Mode button on the function board of the machine until
“FM” appears on the display screen.
Once the FM mode has been activated, press and hold the
button on either the remote control or function board for the
machine to begin seeking and storing all of your local radio station
channels.
After the scanning is complete, you can browse your saved
channels by pressing SCAN on the remote control or simply
switching through the channels by clicking or on either the
remote control or function board to select the radio station of your
choice..
How to use PA mode
When there is no music playing, this machine will automatically
start PA Mode. Simply use the microphones by ensuring that they
are turned on. Adjust the microphone’s volume and echo on the
machine’s function board or the microphone itself.

How to record
Begin by inserting a suitable recording device into the function
board via the MicroSD slot or USB port. Ensure that the microphone
is turned on and then proceed to press REC on the function board.
Speak or sing into the microphone and when finished recording,
click REC again to stop it.
To listen to the recorded audio, remove and then reinsert the USB
or MicroSD recording device. The recording will begin playing
automatically.
How to use multiple playback modes
To use playback modes interchangeably, simply activate each
mode according to the instructions above, then click Mode to
switch between the inputs.

Maintenance
How to clean
Turn the machine and microphone o and unplug all wires.
Gently wipe the outside of the machine using a clean, dry cloth.
Keep all vents, buttons, and openings free of lint and dirt. Do not
immerse the machine in water and do not use any harsh cleaners.
How to store
Charge the machine so that it’s ready the next time you want to
use it.
Make sure that the machine is clean and dry.
Bind the unplugged cord gently with an electrician-approved
fastener.
Do not wrap the cord around the machine.
Store the machine in a cool, dry place away from damaging
elements.
For best results, clean and store the machine after each use.
How to transport
The Soprano X1 was designed intentionally with wheels at the
bottom for easy transportation.
Simply unplug all wires and extend the handle on the machine to
roll it around just like a suitcase.
Place the microphones in a suitable bag and carry them
separately.

Problem Solution
Machine will not turn on or
powers on and then shuts
down
The battery is depleted. Be
sure to charge the machine
after each use.
USB or Micro-SD mode will
not work
Turn o the selected mode,
unplug either the USB or Micro-
SD, turn it back on, and plug the
USB or Micro-SD back in.
Please note that the MicroSD
card can only be inserted in one
direction. Do not force it into
its slot. If the card cannot be
inserted easily, remove it and try
reinserting in another direction.
Microphone audio output is
low quality or experiencing
interference
To prevent interference, do
not hold the microphones too
close to the karaoke machine.
The maximum distance for
the microphones to wirelessly
connect and work properly is
approximately 30 meters or 98
feet from the machine.
The microphone’s sound
quality and wireless range
may also be aected by low
battery. Ensure that both
microphones are adequately
charged before use.

The remote control is not
working
Because the remote control
is wireless, it must be within
close proximity to the karaoke
machine and pointed towards
it in order to work.
If the remote control is still
not working, try replacing the
battery.
No sound is playing from the
speaker
Ensure that the volume on the
machine, remote, and your
device (if applicable) are all
turned up.
Also check to see whether you
are on Mute mode by pressing
Mute on the remote control to
see if the audio resumes.
Button or knob on the
machine/remote control is
not working properly
Power o the machine and
turn it back on.
Display screen on the
function board is not working
or showing anything while
LED lights are functioning as
usual
Charge the machine’s battery
for at least 8 consecutive
hours before trying to power
it back on. Low battery is
sometimes able to power the
LED lights but will not be able
to power the whole machine
and all its functions.

Machine is not playing the
microphone vocals
Ensure that each microphone
is on a separate frequency
band. This is represented by
CHA or CHB in the bottom left
corner of the microphone LED
screen. (To switch channels,
hold down the A-B button for
one second). Microphones will
not work properly unless one
mic is set to CHA while the
other mic is set to CHB.
After 15 minutes of inactivity,
the microphones will turn o.
If any of these issues persist or if any part of the machine becomes
damaged, discontinue use and consult a licensed electrician for repair.
Do not attempt to modify or repair the machine yourself. You can also
contact our customer service department (see back cover).
FCC:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

We’re here for you.
If you encounter any issues with your machine or
have any questions or comments, please feel free
to contact us. Have your warranty information on
hand for faster service.
