MASSEY FERGUSON MF 4707 User manual

Operator's Manual
MF 4700 - Operation - Maintenance
MF 4707 MF 4708 MF 4709
Beauvais
AGCO S.A.S. - 41 avenue Blaise Pascal - 60000
Beauvais - France - RC B562 104 539
© AGCO 2017
Original Operator's Manual
January 2017
ACW005123C
English

Find manuals at https://best-manuals.com

Foreword
We would like to welcome you to the ever-growing number of people who own a Massey Ferguson
tractor; people who appreciate quality. We are proud of every tractor that leaves our factories, each being
technically advanced and of a high quality.
This Operator's Manual contains the specifications for your new tractor. Please ensure that all operators
read the instructions and follow them carefully. The pages that follow contain vital information on your
tractor; please read them carefully.
Your Massey Ferguson dealer will guarantee you quality servicing and will provide you with all the
assistance you need. When it comes to servicing, remember that your dealer knows your tractor best and
that he wants you to be completely satisfied.
Please leave this Operator's Manual in the tractor if resold. The subsequent owner will need the
information it contains.
All information and specifications in this manual are up to date at the time of publication. However, our
ongoing policy to improve our products obliges us to reserve the right to make alterations at any time
without notice.
Please note that this manual relates to all models and refers to both standard and optional equipment. You
may therefore find details relating to equipment that is not fitted on your tractor.
This Operator's Manual complies with Directive 2010/52 EC.
Massey Ferguson
GUID-2AC6B9E1-4D9D-4D81-BE03-6CDCD396726A [V2]
.
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

.
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

MF 4700 - Operation - Maintenance
1 Tractor identification ......................................................11
1.1 Locating serial numbers .............................................13
1.1.1 Locating serial numbers ............................................13
1.2 Tractor identification ...............................................14
1.2.1 Your tractor identification details ......................................14
2 Safety instructions and safety points - Warranty ............................15
2.1 Introduction ........................................................17
2.1.1 Introduction - Safety instructions ......................................17
2.2 Safety — Symbols and terms ........................................19
2.2.1 Safety — Symbols and terms ........................................19
2.3 Safety decals and instructions .......................................20
2.3.1 Checking and replacing the safety decals and instructions ...................20
2.3.2 Presentation and location of the safety decals and instructions ................21
2.4 General safety instructions .........................................26
2.4.1 Awareness of the safety instructions and symbols .........................26
2.4.2 Operator familiarity in the use of the tractor ..............................26
2.4.3 Filling the fuel tank ................................................27
2.4.4 Mounting and dismounting the operator's seat ...........................27
2.4.5 Mandatory procedure before dismounting the tractor .......................27
2.5 Special instructions .................................................28
2.5.1 Specific recommendations for agricultural and forestry tractors ................28
2.6 Special safety instructions for preparing the tractor for use ............30
2.6.1 Protective clothing ................................................30
2.6.2 Safety devices and items ...........................................30
2.6.3 Checking the tractor ...............................................30
2.7 Specific safety instructions for starting the tractor ....................32
2.7.1 Protection of persons other than the operator ............................32
2.7.2 Start up safely ...................................................32
2.7.3 Checks to be carried out after start-up ..................................33
2.8 Specific safety instructions for using the tractor ......................34
2.8.1 General instructions ...............................................34
2.8.2 Protection of persons other than the operator ............................35
2.8.3 Overturning .....................................................35
2.8.4 Tractor towing ...................................................38
2.8.5 Regulatory data on maximum permitted trailed weights .....................38
2.8.6 Road use .......................................................39
2.8.7 Park brake ......................................................40
2.8.8 Power take-off ...................................................40
2.8.9 Implements .....................................................41
2.8.10 Front-end loader .................................................44
2.9 Specific safety instructions for servicing the tractor ...................45
2.9.1 Pollution warning to observe when servicing the tractor .....................45
2.9.2 General instructions ...............................................45
2.9.3 Handling instructions ..............................................46
2.9.4 Special instructions for cleaning the tractor ..............................47
2.10 Protective structures ..............................................48
2.10.1 Protective structures: use and accreditation .............................48
2.10.2 ROPS (Roll Over Protective Structure) .................................48
2.10.3 Seat belt ......................................................48
Table of contents
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

2.11 Warranty .........................................................49
2.11.1 General .......................................................49
2.11.2 Pre-delivery inspection and commissioning on the user’s premises ............49
2.11.3 Warranty procedure ..............................................49
2.11.4 Procedure to follow if changing region .................................49
2.11.5 Servicing during and after the warranty period ...........................50
3 Usage ....................................................................51
3.1 Operator environment ..............................................55
3.1.1 Standard steering console, Footstep tractor ..............................55
3.1.2 Standard steering console, Platform tractor ..............................56
3.1.3 Essential steering console, Platform tractor ..............................57
3.1.4 Instrument panel: Standard option .....................................58
3.1.5 Instrument panel Essential option ....................................61
3.1.6 Control unit .....................................................69
3.1.7 Start switch .....................................................69
3.1.8 Start switch .....................................................69
3.1.9 Pedals .........................................................70
3.1.10 Steering wheel ..................................................72
3.1.11 Seat .........................................................72
3.2 Body ...............................................................75
3.2.1 Opening the engine cover ...........................................75
3.2.2 Tool box .......................................................75
3.3 Engine .............................................................76
3.3.1 Running-in ......................................................76
3.3.2 Start-up ........................................................76
3.3.2.1 Starting the engine with preheating on the steering console. ...........76
3.3.3 Stopping the engine ..............................................77
3.3.4 Engine speed ....................................................78
3.3.5 Filling with fuel ..................................................79
3.4 Transmission .......................................................81
3.4.1 8X8 CMS gearbox for Tier 2/Stage II engine .............................81
3.4.2 8X8 SMS gearbox with mechanical reverse shuttle ........................82
3.4.3 gearbox .......................................................83
3.4.4 12X12 SPS gearbox ...............................................85
3.4.5 Clutch function ...................................................86
3.4.6 Super creeper gears ...............................................88
3.4.7 Tractor towing ...................................................89
3.5 Brakes .............................................................91
3.5.1 Brake pedals ....................................................91
3.5.2 Hydraulic trailer brake ..............................................92
3.5.3 Park brake ......................................................93
3.6 Steering ...........................................................94
3.6.1 Steering ........................................................94
3.7 Standard linkage console ...........................................95
3.7.1 Four-wheel drive front axle ..........................................95
3.7.1.1 Control locations ...........................................95
3.7.1.2 Operation ................................................95
3.7.1.3 Permissible load on the front axle ..............................96
3.7.2 Differential lock ..................................................97
3.7.2.1 Control locations ...........................................97
3.7.2.2 Operation ................................................97
3.7.3 Live PTO .......................................................98
3.7.3.1 Control locations ...........................................98
3.7.3.2 Operation ................................................98
3.7.3.3 Selecting the power take-off speed .............................99
Table of contents
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

3.7.3.4 Interchangeable 540 and 1000 rpm PTO .........................102
3.7.3.5 GSPTO ................................................. 102
3.7.3.6 Economy PTO ............................................103
3.7.3.7 Power take-off protection ....................................103
3.7.3.8 Coupling to the PTO shaft ................................... 105
3.7.4 Linkage ....................................................... 105
3.7.4.1 Control locations .......................................... 105
3.7.4.2 Operation ............................................... 105
3.7.4.3 Rear linkage external controls .................................108
3.8 Electronic linkage console ..........................................109
3.8.1 Four-wheel drive front axle ......................................... 109
3.8.1.1 Control locations .......................................... 109
3.8.1.2 Operation ............................................... 109
3.8.1.3 Permissible load on the front axle ............................. 110
3.8.2 Differential lock ................................................. 111
3.8.2.1 Control locations .......................................... 111
3.8.2.2 Operation ............................................... 111
3.8.3 Live PTO ...................................................... 112
3.8.3.1 Control locations .......................................... 112
3.8.3.2 Operation ............................................... 112
3.8.3.3 Selecting the power take-off speed ............................ 113
3.8.3.4 Interchangeable 540 and 1000 rpm PTO .........................116
3.8.3.5 GSPTO ................................................. 116
3.8.3.6 Economy PTO ............................................117
3.8.3.7 Power take-off protection ....................................117
3.8.3.8 Coupling to the PTO shaft ................................... 119
3.8.4 Linkage ....................................................... 119
3.8.4.1 Control locations .......................................... 119
3.8.4.2 Operation ............................................... 119
3.8.4.3 Rear linkage external controls .................................124
3.9 Linkage ........................................................... 125
3.9.1 General ....................................................... 125
3.9.2 Three-point linkage ...............................................125
3.9.3 Top link ....................................................... 125
3.9.4 Bottom links ................................................... 127
3.9.5 Adjusting the lift rods ............................................. 128
3.9.6 Stabilisers ..................................................... 129
3.9.6.1 Stabilizers with manual telescopic adjustment .....................130
3.9.7 Multi-hole drawbar ...............................................132
3.9.8 Swinging drawbar ............................................... 132
3.9.8.1 Settings ................................................ 132
3.9.8.2 Hitching an attachment ..................................... 133
3.9.8.3 Drawbars, ISO standard .....................................133
3.9.8.4 Drawbars, SAE standard .................................... 134
3.9.9 Linkage type ................................................... 135
3.9.9.1 Standard hitch ............................................135
3.9.9.2 Standard hitch with ladder ................................... 135
3.9.9.3 Short ladder hitch with high load capacity ........................ 140
3.9.9.4 Pick-up hitch ............................................. 141
3.9.10 Pick-up hitch .................................................. 142
3.9.10.1 General ................................................142
3.9.10.2 Using the pickup hitch for pulling ............................. 142
3.10 Auxiliary hydraulics ...............................................144
3.10.1 Types of spool valve .............................................144
3.10.2 Hydraulic spool-valve controls ......................................145
3.11 Wheels and tires ..................................................147
3.11.1 Wheel studs ...................................................147
Table of contents
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

3.11.2 Installation points of the axle stands ................................. 147
3.11.3 Adjustment of the front track width, 2-wheel drive .......................147
3.11.3.1 Adjustment of position 1 of the axle ........................... 148
3.11.3.2 Adjustment of position 2 of the axle ........................... 149
3.11.3.3 Adjustment of position 3 of the axle ........................... 150
3.11.3.4 Adjustment of position 4 of the axle ........................... 151
3.11.3.5 Adjustment of position 5 of the axle ........................... 152
3.11.4 Adjustment of the front track width, 4-wheel drive .......................153
3.11.5 Adjusting the rear wheel track width .................................154
3.11.6 Adjusting the 4WD front axle stops ..................................156
3.11.7 Tires ........................................................ 156
3.11.8 Tire pressures ................................................. 157
3.11.9 Radial loads and standard inflation pressures ........................... 158
3.11.10 Ballasting the tractor ............................................160
3.11.11 Liquid ballasting ............................................... 161
3.12 Additional weight ................................................ 163
3.12.1 Additional weight ............................................... 163
4 Maintenance .............................................................165
4.1 Service Guide ..................................................... 167
4.1.1 Service Guide ...................................................167
4.2 ROPS (Roll Over Protective Structure) ...............................170
4.2.1 Attaching the ROPS .............................................. 170
4.2.2 Reducing the height of the ROPS .................................... 170
4.3 Engine ............................................................ 171
4.3.1 Recommended products .......................................... 171
4.3.2 3-cylinder engine AGCO Power Tier 2 ................................. 172
4.3.3 4-cylinder engine AGCO Power Tier 2 ................................. 172
4.3.4 3-cylinder AGCO Power Tier 4i/Stage IIIB engine engine ................... 173
4.3.5 Engine oil level check .............................................173
4.3.6 Draining the engine oil ............................................ 174
4.3.7 Replacing the engine oil filter ....................................... 174
4.3.8 Breather system .................................................175
4.3.9 Fuel system: fuel prefilter ..........................................176
4.3.9.1 Draining the water .........................................176
4.3.9.2 Replacing the filter element ..................................177
4.3.10 Fuel filter fuel system ............................................178
4.3.11 Fuel system: Fuel tank ........................................... 179
4.3.12 Fuel system: bleeding ............................................179
4.3.13 Fuel system: injection pump, regulator and injectors ......................179
4.3.14 Air filter ...................................................... 179
4.3.15 Cooling system, engine with expansion tank ........................... 180
4.3.15.1 Checking the level and quality of the coolant .....................180
4.3.15.2 Filling to top up the coolant level ..............................181
4.3.15.3 Draining the cooling system .................................181
4.3.15.4 Cleaning the radiator ...................................... 182
4.3.16 Check and replace the main fan/alternator belt ..........................182
4.3.16.1 Procedure for tensioning the Poly-V main belt for the AGCO Power
engine ....................................................... 183
4.3.17 Fuel quality requirements ......................................... 183
4.3.17.1 Biodiesel blends ......................................... 184
4.3.18 Fuel: Safety instructions and storage .................................185
4.4 Transmission ......................................................188
4.4.1 Recommended products .......................................... 188
4.4.2 Checking the hydraulic system level .................................. 188
4.4.3 Draining the hydraulic system .......................................189
4.4.4 Replacing the filter and strainer ......................................190
Table of contents
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

4.4.4.1 Replacing the strainer ...................................... 190
4.4.4.2 Replacing the high-pressure filter .............................. 190
4.4.5 Transmission oil cooler ............................................191
4.4.6 Clutch ........................................................ 191
4.4.7 Lubricating the rear axle shaft bearings ................................ 192
4.5 Brakes ............................................................ 193
4.5.1 Mechanically controlled brakes ...................................... 193
4.5.2 Hydraulically controlled brakes ...................................... 193
4.6 Front axle and steering .............................................195
4.6.1 Recommended products .......................................... 195
4.6.2 Two-wheel drive front axle: lubrication .................................195
4.6.3 Two-wheel drive front axle and four-wheel drive front axle: Check the wheel
alignment .......................................................... 196
4.6.4 Four-wheel drive front axle: checking the oil level in the final drives ............197
4.6.5 Four-wheel drive front axle: draining the oil in the final drives ................ 197
4.6.6 Four-wheel drive front axle: Checking the front axle beam oil level ............ 197
4.6.7 Four-wheel drive front axle: draining the oil from the front axle beam .......... 198
4.6.8 Four-wheel drive front axle: lubrication ................................ 199
4.6.9 Adjusting the front axle oscillation ....................................200
4.7 Linkage ........................................................... 201
4.7.1 Recommended products .......................................... 201
4.7.2 Three-point linkage: lubrication ...................................... 201
4.8 Electrical equipment ............................................... 202
4.8.1 Batteries ......................................................202
4.8.2 Alternator ......................................................202
4.8.3 Power socket (ISO) .............................................. 203
4.8.4 Power socket (ASAE) ............................................. 204
4.8.5 Accessories sockets (ISO) ......................................... 204
4.8.6 Accessories sockets (ASAE) ........................................ 205
4.8.7 Adjusting the headlights ...........................................205
4.8.8 Main fuse boxes .................................................206
4.8.8.1 AGCO Power Tier 2/Stage II engine - Mechanical reverse shuttle/Main
fuse box ...................................................... 206
4.8.8.2 AGCO Power Tier 2/Stage II engine - PowerShuttle/Main fuse box ......209
4.8.8.3 AGCO Power Tier 4i/Stage IIIB engine (EEC) - Mechanical reverse shuttle/
Main fuse box ..................................................213
4.8.8.4 AGCO Power Tier 4i/Stage IIIB engine (EEC) - PowerShuttle/Main fuse
box ..........................................................216
4.8.9 Additional fuse boxes .............................................220
4.8.9.1 AGCO Power Tier 2/Stage II engine - Mechanical reverse shuttle/
Additional fuse box .............................................. 220
4.8.9.2 AGCO Power Tier 2/Stage II engine - PowerShuttle/Additional fuse box ..220
4.8.9.3 AGCO Power Tier 4i/Stage IIIB engine (EEC) ......................222
4.8.9.4 AGCO Power Tier 4i/Stage IIIB engine (EEC) - PowerShuttle/Additional
fuse box ...................................................... 222
4.8.10 Fuse boxes on the side of the battery ................................ 223
4.8.10.1 AGCO Power Tier 2/Stage II engine - Fuse box on the side of the battery
............................................................. 223
4.8.10.2 AGCO Power Tier 4i/Stage IIIB engine (EEC) - Main fuse box on the side
of the battery .................................................. 225
4.8.11 Battery isolator .................................................228
4.9 Pressure washing ..................................................230
4.9.1 Pressure washing ................................................230
4.10 Storing your tractor .............................................. 231
4.10.1 Storing your tractor ..............................................231
4.11 Faults and solutions .............................................. 232
4.11.1 General table of faults ............................................232
Table of contents
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

4.11.2 Indicator light panel ............................................. 234
4.11.3 Error codes ................................................... 237
4.11.4 Engine error codes - AGCO Power ...................................242
5 Technical specifications ...................................................259
5.1 General specifications ..............................................261
5.1.1 Model MF 4707 ................................................. 261
5.1.2 Model MF 4708 .................................................262
5.1.3 Model MF 4709 .................................................264
5.2 Operator environment ............................................. 266
5.2.1 Noise levels (dBA) at operator's ears: Tier 4i/Stage IIIB engine engine ..........266
5.2.2 Level of vibration of the operator's seat ................................266
5.3 Engine ............................................................ 267
5.3.1 Specifications: Tier 2/Stage II engine ..................................267
5.3.2 Specifications: Tier 4i/Stage IIIB engine ................................267
5.3.3 Fuel system and air filter .......................................... 268
5.3.4 Cooling ....................................................... 268
5.3.5 Tightening torques ...............................................268
5.4 Transmission ......................................................269
5.4.1 Forward speed at 2200 rpm with 8x8 gearbox and 16.9x34 tires - 30 km/h option
for Tier 2/Stage II engine tractors ......................................... 269
5.4.2 Forward speed at 2200 rpm with a 12x12 gearbox and 16.9x34 tires - 30 km/h
pour les tracteurs Tier 2/Stage II engine option ............................... 269
5.4.3 Forward speed at 2200 rpm with 12x12 gearbox and 16.9x34 tires - option 40 km/
h pour les tracteurs Tier 4i/Stage IIIB engine .................................269
5.4.4 Gearbox .......................................................270
5.4.5 Final drives .................................................... 270
5.4.6 Rear differential lock ..............................................270
5.5 Brakes ............................................................ 271
5.5.1 Brake technical specifications ....................................... 271
5.6 Front axle and steering .............................................272
5.6.1 Two-wheel drive front axle ......................................... 272
5.6.2 Four-wheel drive front axle ......................................... 272
5.6.3 Steering .......................................................272
5.6.4 Tightening torques ...............................................272
5.7 Power take-off .....................................................273
5.7.1 Specifications ...................................................273
5.7.2 Tightening torques ...............................................273
5.8 Hydraulic linkage .................................................. 274
5.8.1 Rear linkage ....................................................274
5.9 Auxiliary hydraulics (according to specification or country) ........... 275
5.9.1 Standard hydraulic flow rate ........................................ 275
5.10 Electrical equipment ..............................................276
5.10.1 Electrical equipment technical specifications ........................... 276
5.11 Wheels and tires ..................................................277
5.11.1 Wheels ...................................................... 277
5.11.2 Tires ........................................................ 277
5.11.3 Tires compatible with MF 4700 tractors ...............................286
5.11.4 Tightening torques .............................................. 293
5.12 Capacities and dimensions ........................................ 294
5.12.1 Capacities .................................................... 294
5.12.2 Dimensions and weights ..........................................296
5.12.3 Attachment points for 3-cylinder engines ..............................298
5.12.4 Attachment points for 4-cylinder engines for MF 4708 tractors with Tier 2/Stage
II engine ........................................................... 300
Table of contents
MF 4700 - Operation - Maintenance
ACW005123C
Find manuals at https://best-manuals.com

1. Tractor identification
1.1 Locating serial numbers ..................................................13
1.1.1 Locating serial numbers .................................................13
1.2 Tractor identification ....................................................14
1.2.1 Your tractor identification details ...........................................14
Table of contents
MF 4700 - Operation - Maintenance 11
ACW005123C

Table of contents
12 MF 4700 - Operation - Maintenance
ACW005123C

1.1 Locating serial numbers
1.1.1 Locating serial numbers
IMPORTANT: Tell your dealer or agent the tractor serial number.
GUID-E43DD9C1-CDEB-41C7-A062-A8FC4F758DD5-high.jpg [High]
Fig. 1
(1) ROPS serial number
(2) Name plate
(3) Engine serial number
(4) Chassis serial number
(5) Front axle serial number
[V]
GUID-4DAD119B-821E-44EA-859B-1DFDB76B1CE3 [V7]
1. Tractor identification
MF 4700 - Operation - Maintenance 13
ACW005123C

1.2 Tractor identification
1.2.1 Your tractor identification details
Model:
Serial number:
Engine serial number:
Owner's name:
Street:
Postcode:
Town:
County:
Country:
Dealer code:
Tractor received from (tick one of the following):
Factory Other dealer (transfer)
Notes:
[V]
GUID-57220CEF-4B8D-4FEC-833A-AF9A48C690AB [V1]
1. Tractor identification
14 MF 4700 - Operation - Maintenance
ACW005123C

2. Safety instructions and safety points -
Warranty
2.1 Introduction .............................................................17
2.1.1 Introduction - Safety instructions ...........................................17
2.2 Safety — Symbols and terms .............................................19
2.2.1 Safety — Symbols and terms .............................................19
2.3 Safety decals and instructions ............................................20
2.3.1 Checking and replacing the safety decals and instructions ........................20
2.3.2 Presentation and location of the safety decals and instructions .....................21
2.4 General safety instructions ..............................................26
2.4.1 Awareness of the safety instructions and symbols ..............................26
2.4.2 Operator familiarity in the use of the tractor ...................................26
2.4.3 Filling the fuel tank .....................................................27
2.4.4 Mounting and dismounting the operator's seat ................................27
2.4.5 Mandatory procedure before dismounting the tractor ............................27
2.5 Special instructions ......................................................28
2.5.1 Specific recommendations for agricultural and forestry tractors .....................28
2.6 Special safety instructions for preparing the tractor for use .................30
2.6.1 Protective clothing .....................................................30
2.6.2 Safety devices and items ................................................30
2.6.3 Checking the tractor ....................................................30
2.7 Specific safety instructions for starting the tractor .........................32
2.7.1 Protection of persons other than the operator .................................32
2.7.2 Start up safely ........................................................32
2.7.3 Checks to be carried out after start-up .......................................33
2.8 Specific safety instructions for using the tractor ...........................34
2.8.1 General instructions ....................................................34
2.8.2 Protection of persons other than the operator .................................35
2.8.3 Overturning ..........................................................35
2.8.4 Tractor towing ........................................................38
2.8.5 Regulatory data on maximum permitted trailed weights ..........................38
2.8.6 Road use ............................................................39
2.8.7 Park brake ...........................................................40
2.8.8 Power take-off ........................................................40
2.8.9 Implements ..........................................................41
2.8.10 Front-end loader ......................................................44
2.9 Specific safety instructions for servicing the tractor ........................45
2.9.1 Pollution warning to observe when servicing the tractor ..........................45
2.9.2 General instructions ....................................................45
2.9.3 Handling instructions ...................................................46
2.9.4 Special instructions for cleaning the tractor ...................................47
2.10 Protective structures ...................................................48
2.10.1 Protective structures: use and accreditation ..................................48
2.10.2 ROPS (Roll Over Protective Structure) ......................................48
2.10.3 Seat belt ...........................................................48
2.11 Warranty ..............................................................49
2.11.1 General ............................................................49
2.11.2 Pre-delivery inspection and commissioning on the user’s premises .................49
2.11.3 Warranty procedure ...................................................49
Table of contents
MF 4700 - Operation - Maintenance 15
ACW005123C

2.11.4 Procedure to follow if changing region ......................................49
2.11.5 Servicing during and after the warranty period ................................50
Table of contents
16 MF 4700 - Operation - Maintenance
ACW005123C

2.1 Introduction
2.1.1 Introduction - Safety instructions
Operator's Manual
IMPORTANT: This manual must always be kept with the tractor. For extra copies, contact your Massey
Ferguson dealer.
NOTE: This manual is for all users of Massey Ferguson tractors. The availability of the attachments
indicated, on the basic tractor or as accessories, may vary according to the region in which the tractor is
used. To find out which attachments are available in a region, contact a Massey Ferguson dealer.
This manual enables the owner and the operator to operate the tractor appropriately under normal
conditions of use. Providing they follow the instructions carefully, the tractor will give many years of
service in the Massey Ferguson tradition.
During commissioning of the equipment by the Massey Ferguson dealer on the user's premises, the user
must ensure that the operating and servicing instructions are properly understood. If the user has any
doubt regarding the operation or servicing of the tractor, the Massey Ferguson dealer should always be
contacted. It is essential that these instructions are understood and followed.
This manual covers all operating and safety instructions relevant to the Massey Ferguson tractor. For
implements and accessories that may be installed at the time of the tractor's delivery or later, the user
must refer to the Operator's Manuals relating to these implements and accessories.
This chapter supplements any safety instructions given in other chapters of this manual. It lists safety-
related situations that may be encountered during the normal operating and servicing of the tractor with
the purpose of enabling the user to work in complete safety.
Depending on the implements and accessories used, and the working conditions on-site or in the servicing
area, additional precautions should be followed. Massey Ferguson cannot exercise direct control over the
commissioning, operation, inspection, lubrication or servicing of the tractor. Consequently, Massey
Ferguson cannot be held responsible if the user fails to take appropriate safety precautions for the
implements and accessories used, or for the working conditions on-site or in the servicing area.
WARNING:
It is your responsibility to read and understand the instructions that appear in this chapter
before using the tractor. They must be followed by the user.
Servicing, spare parts, accessories and conditions of use
The user must perform daily servicing on the tractor and keep a logbook of operating hours.
Only genuine Massey Ferguson replacement parts should be used when the need arises. Massey
Ferguson dealers supply these genuine parts. Contact your dealer if you require any advice on their
installation and use. Massey Ferguson cannot be held responsible if the owner uses parts other than the
genuine parts sold by Massey Ferguson dealers. Similarly, only accessories specifically adapted to the
tractor should be used.
This tractor is designed for normal farming activities only. Use of the tractor for any other activity,
particularly forestry work, is considered to be contrary to normal use of the tractor.
If the tractor is to be used in abnormal conditions that could cause damage to it, such as in deep water or
in paddy fields, consult a Massey Ferguson dealer to obtain special instructions.
IMPORTANT: Massey Ferguson under no circumstances covers damage caused by the failure to observe
the conditions of use, servicing and repair for its tractors. There is thus no justification for a warranty claim
if the user fails to observe the recommendations for use, servicing and repair in this manual.
IMPORTANT: Massey Ferguson accepts no responsibility in the event of damage to equipment or
personal injury resulting from the failure to observe the conditions of use, servicing and repair for its
tractors.
[V]
GUID-BFCCC5AE-7D92-4FFF-93BE-E5A73ABBC43D [V4]
2. Safety instructions and safety points - Warranty
MF 4700 - Operation - Maintenance 17
ACW005123C

Always consult a Massey Ferguson dealer:
•For any advice regarding the conditions of use, servicing and repair for the tractor
• If there is any doubt regarding the safety instructions to be observed when using the tractor
• For any adjustments that may be necessary
• To order genuine spare parts
• In the event of after-sales problems
• If you have any questions relating to the tractor, genuine parts or implements and accessories that can
be adapted for the tractor.
2. Safety instructions and safety points - Warranty
18 MF 4700 - Operation - Maintenance
ACW005123C

2.2 Safety — Symbols and terms
2.2.1 Safety — Symbols and terms
Signal
This safety alert symbol means CAUTION! BE ALERT! YOUR
SAFETY DEPENDS ON IT!
The safety alert symbol identifies important safety notices on
machines, safety signs, in instruction books or elsewhere. When
you see this symbol, be alert to the risk of injury or death. Follow
the instructions in the safety notice.
SAFETY is paramount! Why?
•ACCIDENTS DISABLE AND KILL
• ACCIDENTS ARE COSTLY
• ACCIDENTS CAN BE AVOIDED
Terms
The terms DANGER, WARNING and CAUTION are used with the safety alert symbol. It is essential to
learn how to recognize these safety messages and to follow the recommended safety measures and
instructions.
DANGER:
indicates an imminently hazardous situation which, if not avoided, will result in DEATH or
VERY SERIOUS INJURY.
WARNING:
indicates a potentially hazardous situation which, if not avoided, could result in DEATH or
SERIOUS INJURY.
CAUTION:
indicates a potentially hazardous situation which, if not avoided, may result in MINOR or
MODERATE INJURY.
The terms IMPORTANT and NOTE are not directly related to personal safety, but are used to provide
additional information and advice on the operation or maintenance of equipment.
IMPORTANT: identifies specific instructions or procedures which, if not strictly applied, could damage or
destroy the tractor, its equipment or the surrounding area.
NOTE: identifies points of particular interest for the most effective and suitable operation or repair.
[V]
GUID-4C8E61C0-0783-4677-8F19-34694CB23997 [V2]
2. Safety instructions and safety points - Warranty
MF 4700 - Operation - Maintenance 19
ACW005123C

2.3 Safety decals and instructions
2.3.1 Checking and replacing the safety decals and instructions
WARNING:
Never remove or obscure the safety decals and instructions.
Replace any safety decals and instructions that are illegible or missing. Replacement decals are available
from the dealer in the event of loss or damage. If a second-hand tractor has been purchased, check that all
safety and instruction decals are correct, legible and in the correct location: To do this, refer to the section
on the presentation and location of decals.
[V]
GUID-C745940D-B900-4385-8FC2-3C5F997BD585 [V2]
2. Safety instructions and safety points - Warranty
20 MF 4700 - Operation - Maintenance
ACW005123C
