Massey Ferguson 6400
Workshop service manual
n° 3378405M4
CONTENTS
01 - Introduction - Specifications
02 - Splitting the tractor
03 - Engine
05 - Gearbox
06 - Rear axle
07 - Power take off
08 - Front axle
09 - Hydraulics
10 - Electrical equipment
11 - Electronics
12 - Cab and equipment
13 - Accessories
H

AGCO S.A. All rights reserved Beauvais FranceMarch 2006
Massey Ferguson 6400
¤
H

Massey Ferguson 6400 Contents - i
Introduction - Specifications
01 - Introduction - Specifications
CONTENTS
1A10 - Using the manual
1B10 - SPECIFICATIONS - General specifications
1B11 - SPECIFICATIONS - Ground speeds
1B12 - SPECIFICATIONS - Dimensions
1B13 - SPECIFICATIONS - Capacities
1C10 - Miscellaneous
¤
H

Massey Ferguson 6400Contents - ii
Introduction - Specifications
¤
H

Massey Ferguson 6400 - Issue 4.b 1A10.1
Using the manual
1A10 - Using the manual
CONTENTS
A . General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
B . Structure of the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
C . Service tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
D . Repairs and replacements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
¤
H

Massey Ferguson 6400 - Issue 4.b
1A10.2
Using the manual
¤
H

Massey Ferguson 6400 - Issue 4.b 1A10.3
Using the manual
A . General
The purpose of this manual is to assist Dealers and
Agents in the efficient installation, maintenance and
repair of AGCO equipment. Carrying out the proce-
dures as detailed, together with the use of special
tools where appropriate, will enable the operations to
be completed within the time stated in the Repair Time
Schedule.
B . Structure of the manual
Page numbering
The present manual is divided into chapters and
sections, and each page is numbered with the
following information:
Example: 10A12.1
10 = Chapter
A12 = Section
1= Page number within the section
The issue number is indicated at the bottom of the
page.
Contents
For quick reference, each chapter starts with a table of
contents, listing the various sections included in that
chapter.
Meaning of references
(..) : identification of parts and components
Amendments
Amended pages will be issued carrying the same page
number as the former pages: only the version number
will change.
Former pages should be destroyed.
C . Service tools
Where the use of a service tool is necessary to carry
out an operation, the tool reference is mentioned
following the relevant instruction.
Drawings for locally made tools are given at the end of
the relevant sections.
D . Repairs and replacements
When parts have to be replaced, it is essential that only
genuine AGCO parts are used.
The following points are of particular importance when
carrying out repairs and fitting replacement parts and
accessories.
Tractor safety features may be impaired if non-genuine
parts are fitted.
Legislation in certain countries prohibits the fitting of
parts that do not comply with the tractor manufac-
turer’s specifications. Torque wrench setting figures
given in the Workshop Service Manual must be strictly
adhered to. Locking devices must be fitted where
specified. If the efficiency of a locking device is
impaired during removal, it must be replaced.
The tractor warranty may be invalidated if non-genuine
AGCO parts are fitted. All AGCO spare parts have the
full backing of the manufacturer’s warranty. AGCO
Dealers and Agents are required to supply only
genuine service parts.
¤
H

Massey Ferguson 6400 - Issue 4.b
1A10.4
Using the manual
¤
H

Massey Ferguson 6400 - Issue 4.c 1B10.1
SPECIFICATIONS - General specifications
1B10 - SPECIFICATIONS - General specifications
CONTENTS
A . Model 6445 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Dynashift .......................................................................................................................... 3
Dyna -6 ............................................................................................................................. 4
B . Model 6455 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dynashift .......................................................................................................................... 5
Dyna -6 ............................................................................................................................. 6
C . Model 6460 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Dynashift .......................................................................................................................... 7
Dyna -6 ............................................................................................................................. 8
D . Model 6465 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dynashift .......................................................................................................................... 9
Dyna -6 ........................................................................................................................... 10
E . Model 6470 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Dynashift ........................................................................................................................ 11
Dyna -6 ........................................................................................................................... 12
F . Model 6475 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Dynashift ........................................................................................................................ 13
Dyna -6 ........................................................................................................................... 14
G . Model 6480 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Dynashift ........................................................................................................................ 15
Dyna -6 ........................................................................................................................... 16
H . Model 6485 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Dynashift ........................................................................................................................ 17
I . Model 6490 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Dynashift ........................................................................................................................ 18
J . Model 6495 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Dynashift ........................................................................................................................ 19
K . Model 6497 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Dynashift ........................................................................................................................ 20
Dyna-6 ............................................................................................................................ 21
¤
H

Massey Ferguson 6400 - Issue 4.c
1B10.2
SPECIFICATIONS - General specifications
L . Model 6499 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Dynashift ........................................................................................................................ 22
Dyna-6 ............................................................................................................................ 23
¤
H

Massey Ferguson 6400 - Issue 4.c 1B10.3
SPECIFICATIONS - General specifications
A . Model 6445
Dynashift
Engine
ISO power hp (kW) at
2200 rpm
90 (67)
Trademark PERKINS
Type 1104C-44T
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Lucas DP 210
Fan Viscostatic
Intercooler -
Alternator 80 A
Gearbox
Gearbox model GBA20 (4x4)
Clutch / Reverse shuttle PowerShuttle
Type Dynashift
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Semi-mounted trailer
hitch
eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 85
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 4
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control AUTOTRONIC 3
Instrument panel DCC2
Linkage calculator EHRC
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet optional
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c
1B10.4
SPECIFICATIONS - General specifications
Dyna -6
Engine
ISO power hp (kW) at
2200 rpm
90 (67)
Trademark PERKINS
Type 1104C-44T
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Lucas DP 210
Fan Viscostatic
Intercooler -
Alternator 80 A
Gearbox
Gearbox model GBA25 (6x4)
Clutch / Reverse shuttle PowerShuttle
Type Dyna -6
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Semi-mounted trailer
hitch
eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 85
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 4
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control two AUTOTRONIC 5s
Instrument panel DCC2
Linkage calculator AUTO 5
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet optional
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c 1B10.5
SPECIFICATIONS - General specifications
B . Model 6455
Dynashift
Engine
ISO power hp (kW) at
2200 rpm
100 (74)
Trademark PERKINS
Type 1104C-44T
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Lucas DP 210
Fan Viscostatic
Intercooler -
Alternator 80 A
Gearbox
Gearbox model GBA20 (4x4)
Clutch / Reverse shuttle PowerShuttle
Type Dynashift
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 85
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control AUTOTRONIC 3
Instrument panel DCC2
Linkage calculator EHRC
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet optional
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c
1B10.6
SPECIFICATIONS - General specifications
Dyna -6
Engine
ISO power hp (kW) at
2200 rpm
100 (74)
Trademark PERKINS
Type 1104C-44T
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Lucas DP 210
Fan Viscostatic
Intercooler -
Alternator 80 A
Gearbox
Gearbox model GBA25 (6x4)
Clutch / Reverse shuttle PowerShuttle
Type Dyna -6
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 85
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control two AUTOTRONIC 5s
Instrument panel DCC2
Linkage calculator AUTOTRONIC 5
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet optional
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c 1B10.7
SPECIFICATIONS - General specifications
C . Model 6460
Dynashift
Engine
ISO power hp (kW) at
2200 rpm
115 (84)
Trademark PERKINS EEM
Type 1104C-E44TA
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Bosch VP30
Fan Viscostatic
Intercooler Air / air
Alternator 80 A
Gearbox
Gearbox model GBA20 (4x4)
Clutch / Reverse shuttle PowerShuttle
Type Dynashift
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 105
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control AUTOTRONIC 3
Instrument panel DCC2
Linkage calculator EHRC
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet -
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c
1B10.8
SPECIFICATIONS - General specifications
Dyna -6
Engine
ISO power hp (kW) at
2200 rpm
115 (84)
Trademark PERKINS EEM
Type 1104C-E44TA
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Bosch VP30
Fan Viscostatic
Intercooler Air / air
Alternator 80 A
Gearbox
Gearbox model GBA25 (6x4)
Clutch / Reverse shuttle PowerShuttle
Type Dyna -6
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 105
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control two AUTOTRONIC 5s
Instrument panel DCC2
Linkage calculator AUTOTRONIC 5
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet -
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c 1B10.9
SPECIFICATIONS - General specifications
D . Model 6465
Dynashift
Engine
ISO power hp (kW) at
2200 rpm
120 (89,5)
Trademark PERKINS EEM
Type 1106C-E66TA
Number of cylinders /
Cylinder capacity
6 / 6.0 Turbo
Injection pump Bosch VP30
Fan Viscostatic
Intercooler Air / air
Alternator 80 or 120 A
Gearbox
Gearbox model GBA20 (4x4)
Clutch / Reverse shuttle PowerShuttle
Type Dynashift
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft optional
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2 or 3, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 5
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model 20.19
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T or 3.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 160cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control AUTOTRONIC 3
Instrument panel DCC2
Linkage calculator EHRC
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet -
Platform optional (*)
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c
1B10.10
SPECIFICATIONS - General specifications
Dyna -6
Engine
ISO power hp (kW) at
2200 rpm
120 (89,5)
Trademark PERKINS EEM
Type 1106C-E66TA
Number of cylinders /
Cylinder capacity
6 / 6.0 Turbo
Injection pump Bosch VP30
Fan Viscostatic
Intercooler Air / air
Alternator 80 or 120 A
Gearbox
Gearbox model GBA25 (6x4)
Clutch / Reverse shuttle PowerShuttle
Type Dyna -6
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft optional
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2 or 3, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 5
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model 20.19
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T or 3.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 160cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control two AUTOTRONIC 5s
Instrument panel DCC2
Linkage calculator AUTOTRONIC 5
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet -
Platform optional (*)
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c 1B10.11
SPECIFICATIONS - General specifications
E . Model 6470
Dynashift
Engine
ISO power hp (kW) at
2200 rpm
125 (91)
Trademark PERKINS EEM
Type 1104C-E44TA
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Bosch VP30
Fan Viscostatic
Intercooler Air / air
Alternator 80 A
Gearbox
Gearbox model GBA20 (4x4)
Clutch / Reverse shuttle PowerShuttle
Type Dynashift
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2 or 3, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 105
Type fixed
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control AUTOTRONIC 3
Instrument panel DCC2
Linkage calculator EHRC
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet -
Platform -
Reference (*): according to country
¤
H

Massey Ferguson 6400 - Issue 4.c
1B10.12
SPECIFICATIONS - General specifications
Dyna -6
Engine
ISO power hp (kW) at
2200 rpm
125 (91)
Trademark PERKINS EEM
Type 1104C-E44TA
Number of cylinders /
Cylinder capacity
4 / 4.4 Turbo
Injection pump Bosch VP30
Fan Viscostatic
Intercooler Air / air
Alternator 80 A
Gearbox
Gearbox model GBA25 (6x4)
Clutch / Reverse shuttle PowerShuttle
Type Dyna -6
Autodrive optional
Creeper unit 4/1 optional
Creeper unit 14/1 optional
Rear axle
Axle model GPA20
Final drive units HD
Wheel shaft Ø 76 mm
Straight shaft -
Flanged shaft standard
Brake discs per trumpet
housing
1
Handbrake discs 3
Differential lock Coupler
Linkage
Stabilisers telescopic
Perforated bar optional
3-point linkage cat. 2 or 3, hook or ball type (*)
Clevis pin-adjusting or quick-adjusting scale
Automatic clevis pin-adjusting or quick-adjusting scale
Hitch eye bolt eye bolt or automatic hook (*)
Swinging drawbar standard
Roller swinging
drawbar
optional
Power take-off
Type interchangeable / shiftable shaft
540/1000/eco optional (*)
540/750/1000 -
750/1000 optional (*)
Number of clutch discs 4
Power take-off brake hydraulic
Proportional PTO optional
Automated power
take-off
optional
Front power take-off optional
Front axle
Model AG 105
Type fixed or suspended (optional)
Rotational direction clockwise
Number of clutch discs 5
Swinging fender (4WD) optional
2WD optional
Front linkage (optional) 2.5 T
Hydraulics
57 l/min Open Centre optional
100 l/min TFLS optional
110 l/min Closed Centre optional
150 l/min Closed Centre -
Orbitrol steering unit 125cc
Brake master cylinder standard
Assisted braking optional
Trailer brake optional (*)
Auxiliary spool valves
(maximum number)
4 electrohydraulic (2 SMS)
or 4 mechanical
Couplers decompression
Electronics
Transmission control two AUTOTRONIC 5s
Instrument panel DCC2
Linkage calculator AUTOTRONIC 5
Draft sensors 2
Sensor capacity 4 T (standard) or 6 T (optional)
Datatronic optional
Dual control (front and
rear)
optional
TIC with / without draft
sensor
optional
Fieldstar optional
Cab
Suspension optional
Rear view mirrors manual (standard) or electrical (optional)
Air conditioning manual (standard) or automatic (optional)
Standard bonnet fixed
Optional bonnet tilting
Standard roof standard
High-visibility roof optional
Steep nose bonnet -
Platform -
Reference (*): according to country
¤
H
