MasterCraft 062-3424-6 User manual

model no. 062-3424-6
INSTRUCTION
MANUAL
IMPORTANT:
Please read this manual carefully before running
this pump and save it for reference.
Stainless Steel
IRRIGATION JET PUMP

model no. 062-3424-6 | contact us 1-800-689-9928
2

3
Technical Specifications 4
Safety 5
7
Installation Instructions
Operating Instructions 10
Parts List 12
Troubleshooting 14
Warranty 15
TABLE OF CONTENTS
TABLE OF CONTENTS
NOTE:
If any parts are missing or damaged, or if you have any questions, please call our
toll-free helpline at 1-800-689-9928.
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions.
Read all instructions and follow them with use of this product.

model no. 062-3424-6 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
Model Number
Voltage
Horsepower
Amps
Max. Head
Max. Flow
Discharge Size
Power Cord Length
062-3424-6
115 V / 60 Hz
3/4 HP
6.5 A
108' (32.9 m)
800 U.S. GPH (3028 L/h)
1" (2.5 cm)
7' (2.13 m)
TECHNICAL SPECIFICATIONS
20' (6.1 m) 60' (18.3 m) 90' (27.4 m) 100' (30.5 m)
800 GPH
(3028 L/h)
470 GPH
(1779 L/h)
300 GPH
(1136 L/h)
190 GPH
(719 L/h)
Max. Head
108' (32.9 m)
PERFORMANCE

5
SAFETY
SAFETY
Please read and understand this entire manual before attempting to assemble
operates or install the product. If you have any questions regarding the product,
please call customer service at 1-800-689-9928.
WARNING
• Running the pump without sufficient water will damage the pump and void the
pump's warranty.
• Do not pump flammable or explosive liquids such as oil gasoline kerosene
ethanol, etc. Do not use in the presence of flammable or explosive vapours.
Using this pump with or near flammable liquids can cause an explosion or fire,
resulting in property damage, serious personal injury and/or death.
• Always disconnect the pump from its power source before inspection .
• Do not stand in water when the pump is connected. Do not handle pump with
wet hands.
• Do not touch the pump housing while it is operating as the pump may be HOT
and can cause serious skin burns.
• Do not disassemble the motor housing. This pump has NO repairable internal
parts, and disassembling may cause dangerous electrical wiring issues.
CAUTION
• This pump is made of high-strength corrosion-resistant materials. It will provide
trouble-free service for many years when properly installed, maintained, and
used. However, inadequate electrical power or blockage by dirt could cause
damage to the pump and void the warranty. To minimize the potential for water
damage due to pump failure please read the section of this manual regarding
common pump problems and remedies or call one of our pump experts at
1-800-689-9928.
• This pump is not designed to function as a permanently installed pump. It is also
not engineered to be run continuously as a “fountain” or “waterfall” pump. The
pump should be used with a 5/8" (1.6 cm) or larger inside diameter garden hose.
• For safety, the pump motor has an automatically resetting thermal protector that
automatically will turn off the pump if it becomes too hot. Overuse of this feature
will damage the pump and void the warranty.
• Once the thermal protector detects that the pump has cooled to a safe
temperature, it will allow the pump to operate normally. If the pump is plugged
in, it may restart unexpectedly.

model no. 062-3424-6 | contact us 1-800-689-9928
6
SAFETY
ADDITIONAL SAFETY PRECAUTIONS
1. Know the pump applications, limitations, and potential hazards.
2. Make certain the electrical power source is adequate for the requirements of
the pump.
3. ALWAYS disconnect the power to the pump and drain all water from the system
before servicing.
4. Secure the pump on a solid base as close to the source of water as possible.
5. Secure the discharge hose before starting the pump. Pump torque may cause
an unsecured discharge hose to “whip”, possibly causing personal injury
and/or property damage.
6. Before using the pump, check the hose for holes or excess wear, which could
cause leaks, and ensure hose is not kinked or making sharp angles. A straight
hose allows the pump to move the greatest amount of water quickly.
7. Check that all hose connections are tight to minimize leaks.
8. Connect the pump directly to a grounded GFCI outlet.
9. Extension cords may not deliver sufficient voltage to the pump motor. Extension
cords present a life-threatening safety hazard if the insulation becomes
damaged or the connection ends fall into water. If using a 50' (15.2 m) cord,
use 16-gauge wire. If using 100' (30.5 m) cord, use 14-gauge wire.
10. Make certain the electrical circuit to the pump is protected by a 10 A or larger
fuse or circuit breaker.
11. Periodically inspect pump and system components to ensure that the pump
inlets are free of mud, sand and debris. DISCONNECT THE PUMP FROM THE
POWER SUPPLY BEFORE INSPECTING.
12. Wear safety glasses at all times when working with pumps.
13. Follow all electrical and safety codes, particularly the National Electrical Code
(NEC) or the Canadian Electrical Code (CEC), and in the workplace, the
Occupational Safety and Health Act (OSHA) or the Canadian Centre for
Occupational Health and Safety (CCOHS).
14. This unit is designed only for use on 115 V (single phase), 60 Hz, and is
equipped with an approved 3-conductor cord and 3-prong, grounding-type
receptacle. Do not use the pump with a 2-prong wall outlet. Replace the
2-prong outlet with a properly grounded 3-prong receptacle (a GFCI outlet)
installed in accordance with the NEC or CEC and local codes and ordinances.
AII wiring should be performed by a qualified electrician.
15. Protect the electrical cord from sharp objects, hot surfaces, oil, and chemicals.
Avoid kinking the cord. Do not use damaged or worn cords.

7
INSTALLATION PREPARATION
Estimated Assembly Time: 5 minutes
Materials Required for Assembly (sold separately): 3/4" (1.9 cm) foot valve,
1" (2.5 cm) discharge tee, 100# pressure gauge, thread tape, 3/4" (1.9 cm)
standard garden hose (for discharge), and 3/4" (1.9 cm) heavy-duty garden
hose (for suction).
This pump is designed to sprinkle lawns and small gardens from lakes, ponds,
or rivers, empty or fill stock tanks, remove standing water from flooded areas
or transfer water. Flammable liquids such as gasoline, chemicals, or corrosive
liquids should never be used with this pump.
INSTALLATION INSTRUCTIONS
CAUTION:
• Never install a shutoff valve in the suction or discharge of this pump. This will cause excessive friction
loss and will damage the pump and void the warranty.
• AII connections must be air tight. A single leak will prevent proper operation of the pump and may
cause the pump to run dry. If the pump runs dry, this will void the warranty.
NOTE:
• If standard garden hose is used for suction line, the hose could collapse, allowing the
pump to run dry. This could cause permanent damage and void warranty.
• This pump is not intended for permanent installation or long, extended periods of
continuous operation.
• This pump is not to be used with pop-up sprinklers.
WARNING:
• Always use handle to lift pump. Never use a power cord to lift pump. To avoid skin burns
unplug and allow time for the pump to cool after periods of extended use. Before
beginning assembly of product, make sure all parts are present. Compare parts with
package contents list. If any part is missing or damaged do not attempt to assemble the
product. Contact customer service for replacement parts.
• Place the pump on level support before operation.

model no. 062-3424-6 | contact us 1-800-689-9928
8
a. Place the pump as close as
possible to the water source,
keeping the vertical distance from
the water to the pump as small as
possible (max. lift is 25' (7.6 m)).
b. Place the pump (A) on level
support.
c. Install a 3/4" (1.9 cm) foot valve,
sold separately, when the suction
lift is over 10' (3 m) or when the
suction line is more than 10' (3 m)
long. The foot valve will keep the
pump primed when it is turned
off.
d. You can use a regular garden hose
(sold separately) as the discharge
line.
INSTALLATION INSTRUCTIONS
a. Wrap threads of discharge tee (sold
separately) with thread tape.
b. Thread a 1" (2.5 cm) discharge tee (2)
into the outlet of the pump.
c. Thread hose adaptors (B) into pump
outlet and into the discharge tee (2).
Positioning the Pump
NOTE: The inlet line may be PVC or
reinforced hose. Small leaks in the suction
line greatly reduce the efficiency of the
pump and may prevent priming.
Positioning the Hose Adaptors
1
2
A
A
Max. 25'
(7.6 m)
CAUTION:
A|I connections must be air tight. A single leak will prevent proper operation of the pump and may cause
the pump to dry. This will void the warranty.
NOTE: Discharge tee is optional.
B
B
2

9
INSTALLATION INSTRUCTIONS
1
NOTE: The inlet hose must be a reinforced
type when pumping from lakes, ponds, or
small streams. A regular garden hose will
collapse and lead to pump failure.
NOTE: A foot valve MUST be used to
maintain prime during operation. Foot valves
are sold separately.
NOTE: This pump (A) is not designed to be used
with underground, pop-up sprinklers (zoned
systems). If you have this type of system, purchase
a higher capacity law or irrigation pump.
Installing the Pump
3
4
a. Connect a 3/4" (1.9 cm) heavy-duty
garden hose (sold separately) to the
pump inlet (1). The inlet connection
can also be used with 1" (2.5 cm)
PVC pipe (Note: If you are using a
PVC pipe, you will need a 1" (2.5 cm)
male NPT X slip adaptor.)
b. Connect an outlet pipe or
3/4" (1.9 cm) standard garden hose
(sold separately) to the discharge tee
(2). The outlet connection is designed
for a 1" (2.5 cm) NPT thread. Rigid
pipes such as PVC or a garden hose
may be used.
Connect your discharge hose to a
standard lawn sprinkler
(Max. 2 sprinklers).
2
A

model no. 062-3424-6 | contact us 1-800-689-9928
10
OPERATING INSTRUCTIONS
NOTE:
• The pump must be filled with water
before operation. Running the pump dry
will cause damage to the shaft seal and
will void the warranty.
• Add thread tape on the discharge tee
cap a. Remove the prime plug (1) and
the discharge tee cap (2). Fill water into
top of discharge tee (3) until pump
overflows with water. Reinstall the prime
plug (1) and the discharge tee cap (2)
when finished priming.
• This pump is not designed to be used with under-ground pop-up sprinklers (zoned
systems) If you have this type of system, purchase a higher capacity lawn or
irrigation pump.
Usage: You can install a 100# pressure gauge (sold separately) on
top of the discharge tee cap in order to monitor pressure.
Priming the Pump:
Running the Pump:
1
2
DANGER:
Risk of electric shock. Always disconnect the electrical supply before attempting to install, service, or
perform any maintenance. If the power source is out of sight, lock and tag in the open (OFF) position to
prevent unexpected power application. Failure to do so could result in fatal electric shock. Only qualified
electricians should repair this unit. Improper repair could result in fatal electric shock.
A
1
2
3
WARNING:
Let the pump cool for at least 20 minutes before attempting to service. The motor may be extremely hot.
Personal injury may result.
a. Plug the power cord into a
GFCI-protected electrical outlet
and press the power switch to
the ON position. If the pump
does not pump water with in
2 minutes, turn the pump (A)
off. Refill with clean water and
make sure all connections are
air tight. To turn the pump off,
press the power switch to the
OFF position.

11
OPERATING INSTRUCTIONS
Storing the Pump:
3
a. Protect against flooding and excessive moisture by storing in a dry place.
WARNING:
• Do not run the pump with the outlet pipe or hose nozzle closed. This will cause damage to
the pump, or burst the hose from excessive pressure. This could result in death or serious
injury. Use only reinforced high-pressure hoses or pipes for the outlet connection or pipes
for the inlet (suction) connection.
• Never remove the ground prong on the power cord. Never hardwire the power cord. Cutting
the cord, hardwiring, or removing the ground prong can result in death or serious injury and
will void the warranty.
2
3
1A
a. Disconnect the suction (1) and
discharge (2) lines from the
pump (A).
b. Remove the water drain plug
(3) from the pump (A).
c. Drain all piping below the frost
line or store the piping indoors.
d. Store the pump indoors.
Draining the Pump for Winter:
4

model no. 062-3424-6 | contact us 1-800-689-9928
12
PARTS LIST
PARTS LIST
9 10 11 12 17 18 19 20 21 2213 14 15 16
6
1
3
4
5
8
7
2
24 25 26
33 34 35 36 37 38
39
40
41
42
4344
45
46
47
48
49
50
27
28
29
30
31
32
23

13
PARTS LIST
PARTS LIST
No. Qty.Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
2
2
3
1
2
6
2
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
2
3
1
Bolt
Spring washer
Washer
Pump support
Bracket for pump support
Screw
Dust cover
Pump body
O-ring
Screw
O-ring
Injector
Diffuser
Hexangular nut
Spring washer
Washer
Impeller
O-ring
Mechanical seal
Support cover
Waterproof ring
Motor flange
Circlip for shaft
Circlip for shaft
Shaft key
No. Qty.Description
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
1
1
3
0.12
1
2
1
4
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
0.18
0.02
Rotor
Stator
Connecting terminal
Line
Capacitor
Screw
Cord clip
Screw
Terminal box
Sealing ring
Sealing washer
Terminal nut
Cable
Fan cover
Fan
Wave spring
End plate
Hex bolt
Screw
Spring washer
Serrated lock washer
Terminal lug
Terminal lug
Heat shrinkable tube
Insulated flexible pipe

model no. 062-3424-6 | contact us 1-800-689-9928
14
TROUBLESHOOTING
Flow rate too
low
The seal leaks
TROUBLESHOOTING
1. There is a blown fuse or
tripped circuit breaker in your
home's breaker/fuse box.
2. The voltage is low.
3. The impeller is blocked.
4. The motor is defective.
1. There is an air leak in the
suction line.
2. The impeller is blocked.
3. The seal is worn
4. The suction lift is too high
5. The hose is kinked or looped
6. The fittings are not tight
7. The suction hose is out of water
8. The inlet is clogged.
The pump will
not start or
run
The pump will
not prime or
retain prime
after operating
1. If blown, replace with a proper sized
fuse or reset the breaker.
2. If the voltage is less than 108 V, check
the wiring size or use a shorter
extension cord.
3. Remove the blockage.
4. Contact customer service at
1-800-689-9928.
1. Repair or replace the suction line.
2. Remove the blockage.
3. Replace the seal.
4. Lower the pump.
5. Straighten the hose.
6. Tighten the fittings.
7. Submerge the suction hose end.
8. Clean the inlet.
Problem Possible Cause Corrective Action
1. The piping or hose is fouled or
damaged
2. The voltage is low.
3. The hose diameter is too small.
4. The discharge hose is too small
1. The seal is worn.
2. The shaft is grooved.
3. The pump head is loose on the
motor.
1. Clean or replace the piping or hose.
2. If the voltage is less than 108 V, check
the wiring size or use a shorter
extension cord.
3. Use a minimum 3/4" (1.9 cm)
heavy-duty garden hose.
4. Use as short a hose as possible (max.
50'/7.6 m).
1. Replace the seal. Call for replacements.
2. Replace the rotor. Call for replacements.
3. Ensure the pump is assembled properly
and that there is no obstruction.

15
WARRANTY
WARRANTY
PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE PUMP YOURSELF. DOING SO
COULD VOID THE WARRANTY AND CAUSE DAMAGE OR PERSONAL INJURY.
This Mastercraft product carries a three (3) year LIMITED warranty against defects in
workmanship and materials. This product is not guaranteed against wear or breakage
due to misuse and/or abuse.
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8
