MasterCraft 062-3422-0 User manual

model no. 062-3422-0
INSTRUCTION
MANUAL
IMPORTANT:
Please read this manual carefully before running
this pump and save it for reference.
Non-submersible
UTILITY TRANSFER PUMP

model no. 062-3422-0 | contact us 1-800-689-9928
2

3
Technical Specifications 4
Safety 5
Installation Instructions 7
Key Parts Diagram 9
Troubleshooting 10
Warranty 11
TABLE OF CONTENTS
TABLE OF CONTENTS
NOTE:
If any parts are missing or damaged, or if you have any questions, please call our
toll-free helpline at 1-800-689-9928.
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions.
Read all instructions and follow them with use of this product.

model no. 062-3422-0 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
For best performance, the maximum recommended hose length is 50' (15.2 m).
The pumping capacity or water flow rate of any pump depends on several factors.
The larger the inside diameter and the shorter the length of hose, the less
pressure that is lost (or the larger the flow rate). If the hose runs uphill or is
extra-long, use a larger diameter hose or rigid pipe.
062-3422-0
12 V / DC
1/10 HP
15 A
46' (14 m)
384 U.S. GPH (1454 L/h)
3/4" (1.9 cm)
11.8' (3.6 m)
TECHNICAL SPECIFICATIONS
0' (0 m) 10' (3 m) 20' (6.1 m) 30' (9.1 m) 40' (12.2 m) Max. Head
46' (14 m)
PERFORMANCE
Model Number
Voltage
Horsepower
Amps
Max. Head
Max. Flow
Discharge Size
Power Cord Length
384 GPH
(1454 L/h)
345 GPH
(1306 L/h)
296 GPH
(1120 L/h)
211 GPH
(799 L/h)
148 GPH
(560 L/h)

5
SAFETY
SAFETY
WARNING
• This pump is not submersible! Do not stand in water while this pump is plugged
in, and do not get the motor wet as it could cause electrocution, which could
lead to serious injury or death.
• Always make sure the pump is unplugged as soon as the water level reaches
1/8" (3.2 mm). At water levels less than 1/8" (3.2 mm), the pump is attempting
to pump air, which will cause the pump to overheat and wear out. Running the
pump without sufficient water will damage the pump and void the pump's
warranty.
• When the pump is running dry, it will be EXTREMELY LOUD. This is a sign to
unplug the pump.
• You must use the included clear suction hose on the inlet of this pump, as
marked on the pump.
• Always use the suction strainer included with this pump to prevent debris from
damaging the pump.
• Do not pump flammable or explosive liquids such as oil, gasoline, kerosene,
ethanol, etc. Do not use in the presence of flammable or explosive vapours.
Using this pump with or near flammable liquids can cause an explosion or fire,
resulting in property damage, serious personal injury and/or death.
• Always disconnect the pump from its power source before inspection.
• Do not stand in water when the pump is connected. Do not handle pump with
wet hands.
• Do not touch the pump housing while it is operating, as the pump may be HOT
and can cause serious skin burns.
CAUTION
• This pump is designed to pump only water. This pump is designed for portable
applications. It can drain or remove water from the following: flooded areas,
pool covers, clogged sinks, waterbeds, water basins, boats, stock tanks, etc. It
can also be used to fill tanks or water beds. This pump has not been tested or
approved for use in swimming pools or in salt-water marine areas. This pump
should not be used as a replacement for a sump pump.
• This pump cannot be used in sewage applications. Doing so will void warranty.
• This pump is made of high-strength materials. It will provide trouble-free service
for many years when properly installed, maintained, and used. However,
inadequate electrical power to the pump, or blockage by ice, dirt, or debris may
cause the pump to fail, potentially bringing about additional water damage. To
minimize the potential for water damage due to pump failure, please read the
section of this manual regarding common pump problems and remedies or call
1-800-689-9928.

model no. 062-3422-0 | contact us 1-800-689-9928
6
SAFETY
ADDITIONAL SAFETY PRECAUTIONS
1. Know the pump applications, limitations, and potential hazards.
2. Make certain the electrical power source is adequate for the requirements of
the pump.
3. ALWAYS disconnect the power to the pump and drain all water from the
system before servicing.
4. Secure the pump on a solid base to prevent the pump from tipping over and
possibly falling into the water.
5. Secure the discharge hose before starting the pump. Pump torque may cause
an unsecured discharge hose to “whip”, possibly causing personal injury
and/or property damage.
6. Before using the pump, check hose for holes or excess wear, which could
cause leaks, and be sure hose is not kinked or making sharp angles. A straight
hose allows the pump to move the greatest amount of water quickly.
7. Check that all hose connections are tight to minimize leaks. Ensure all hose
washers are in place.
8. Connect the pump DIRECTLY to a grounded, GFCI outlet.
9. Extension cords may not deliver sufficient voltage to the pump motor. If an
extension cord must be used, use no more than a 25' (7.6 m), 3-prong,
16 AWG, outdoor-grade cord.
10. Make certain the electrical circuit to the pump is protected by a 5 A minimum
(15 A maximum) fuse or circuit breaker.
11. Periodically inspect pump and system components to be sure pump inlets are
free of mud, sand, and debris. DISCONNECT PUMP FROM THE POWER SUPPLY
BEFORE INSPECTING.
12. Wear safety glasses at all times when working with pumps.
13. Follow all electrical and safety codes, particularly the National Electrical Code
(NEC) or the Canadian Electrical Code (CEC), and in the workplace, the
Occupational Safety and Health Act (OSHA) or the Canadian Centre for
Occupational Health and Safety (CCOHS).
14. This unit is designed only for use on 115 V (single phase), 60 Hz, and is
equipped with an approved 3-conductor cord and 3-prong grounded plug. DO
NOT REMOVE THE GROUND PIN UNDER ANY CIRCUMSTANCES. The 3-prong
plug must be directly inserted into a properly installed and grounded 3-prong,
grounding-type receptacle. Do not use pump with a 2-prong wall outlet.
Replace the 2-prong outlet with a properly grounded 3-prong receptacle (a
GFCI outlet) installed in accordance with the NEC or CEC and local codes and
ordinances. All wiring should be performed by a qualified electrician.
15. Protect the electrical cord from sharp objects, hot surfaces, oil, and chemicals.

7
INSTALLATION PREPARATION
Estimated Assembly Time (new installation): 5 minutes
Materials Required for Assembly (not included): Garden Hose (50'/15.2 m max. length)
Do not suspend the pump by the discharge hose or power cord.
• Keep the pump suction strainer clear.
• Do not install pump directly on sand or dirt.
Add water (approximately
1 – 2 Tbsp/15 – 30 mL) into
inlet to wet the impeller of
the pump (A).
INSTALLATION INSTRUCTIONS
NOTICE: Make sure the connection is
airtight. An air leak can cause the pump (A) to
run dry.
1
Thread the other end of the suction hose
(C) to the suction inlet of the pump (A).
NOTICE: Always ensure the washer in the hose
bib is not damaged. An airtight seal is necessary for
this pump to operate.
Make sure the suction hose (C) and
suction strainer (B) are in the water
before plugging in the pump (A).
3
2
C
A
C
A
C
B
Attach suction hose (C) by pushing the
male threaded end into the rubber
suction strainer (B). Then, place the
strainer in at least 1/2" (12.7 mm). of
water at the lowest point to be
pumped.

model no. 062-3422-0 | contact us 1-800-689-9928
8
NOTICE: DO NOT coil or kink the hoses.
This equipment is only for use with an automotive, tractor or marine type
battery fully charged to 12 V DC. Battery current can cause severe burns and
start a fire if the battery is short circuited. Battery posts, terminals and related
accessories contain lead and lead compounds, chemicals known to cause
cancer and reproductive harm. Wash hands after handling.
Use insulated crimp type connectors.
6
5Attach the pump (A) to a sturdy
base (table, board, etc.) to
prevent it from tipping over.
Make sure the hoses are as
straight as possible.
NOTICE: Make sure the end of the outlet
hose is not under water. If the outlet is
under water, the pump may not work.
4A
C
Thread a 5/8" (15.9 mm) or larger
garden hose (sold separately,
50'/15.2 m max. length) onto the
discharge outlet of the pump (A).
INSTALLATION INSTRUCTIONS
WARNING:
This pump CANNOT be submersed in water, and the motor CANNOT get wet at all. Getting the
motor wet could cause electrocution, which could lead to serious injury or death!
A
B
C
NO COILS
NO KINKS
Connect pump to power
source. Connect the red clamp
to the positive (+) type battery
terminal. Connect the black
clamp to the negative (-) type
battery terminal.
Power Supply: The pump is
designed for use with a 12 V
DC battery. Operation requires
a minimum 12 V power
supply.

9
KEY PARTS DIAGRAM
No. Description No. Description
6
7
8
9
10
Screw
Impeller cover
O-ring
Impeller
Pump body
Shaft
Battery terminal clamps
Power switch
Suction strainer
Suction hose
1
2
3
4
5
KEY PARTS DIAGRAM
PARTS LIST
1 2 345
8
6
109
7

model no. 062-3422-0 | contact us 1-800-689-9928
10
TROUBLESHOOTING
The pump
runs but
pumps little or
no water.
TROUBLESHOOTING
1. The cord set is loose.
2. The fuse is blown.
3. The battery has no charge.
1. The impeller is worn.
2. The suction is leaking.
3. The suction hose is kinked
or coiled.
The pump
stops without
warning.
The pump does
not prime.
1. Reconnect the cable.
2. Replace the fuse.
3. Recharge the battery or replace it
with a new battery.
1. Replace the impeller.
2. Replace the hose washer and check
for leaks in the hose.
3. Straighten out the suction hose.
Problem Possible Cause Corrective Action
1. The impeller is worn.
2. The suction or discharge
hose is kinked or coiled.
1. Replace the impeller.
2. Straighten out the hose.
The pump
leaks.
1. The shaft seal is leaking.
2. The cover O-ring is leaking.
1. Replace the pump.
2. Reassemble the cover O-ring.
NOTE
Do not disassemble the motor housing of the pump. This pump has NO repairable internal parts, and
disassembling may cause a dangerous electrical wiring conditions.

11
WARRANTY
WARRANTY
PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE PUMP YOURSELF. DOING SO
COULD VOID THE WARRANTY AND CAUSE DAMAGE OR PERSONAL INJURY.
This Mastercraft product carries a three (3) year LIMITED warranty against defects in
workmanship and materials. This product is not guaranteed against wear or breakage
due to misuse and/or abuse.
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8
