Masterflex I/P Series User manual

MASTERFLEX®I/P®SERIES
PRECISION MODULAR DRIVES
Quick Start Guide

Product Accessories
Bench Top Model 07591-20 Only
77595-35 Footswitch DB-9
07595-45 Connector, DB-9 Remote Control
07595-47 Cable, Remote Control DB-9, 25 FT.
07557-51 Cable, Motor Extension, 9 FT.
NEMA Wall-Mount Model 07591-30 Only
07595-43 Footswitch, Washdown
77300-32 Cable, Remote Control Washdown, 25 FT.
07557-51 Cable, Motor Extension, 9 FT
Replacement Cord/Plug Sets Ordering Information
Catalog
Number
Catalog
Number
Catalog
Number
Description Description Description
50001-60
50001-62
50001-64
50001-68
50001-69
50001-70
50001-72
50001-74
50001-76
50001-78
—
—
Australia
Denmark
India
U.S. STD. 115V
Israel
Europe
England
Switzerland
Italy
U.S. 230V
—
—
12
34

DANGER: Remove power from the pump before any cleaning operation is started.
High voltages exist and are accessible. Use extreme caution when servicing internal
components
WARNINGS: Remove power from the pump before attempting any maintenance.
A contactor or other device that routinely disconnects and reapplies the AC line to
the drive to start and stop the motor can cause drive hardware damage. The drive is
designed to use control input signals that will start and stop the motor.
WARNINGS: Tubing breakage may result in fluid being sprayed from pump. Use
appropriate measures to protect operator and equipment.
Turn Pump System off before removing or installing tubing. Fingers or loose clothing
could be caught in drive mechanism.
CAUTIONS: When changing flow direction, allow the pump to come to a complete stop
before starting again. Failure to do so could cause permanent damage to the motor.
Replace the fuse only with one of the same type and rating. The fuse rating and type are
stated on the rear panel.
CAUTIONS: To avoid electrical shock, the power cord protective grounding conductor
must be connected to ground. Not for operation in wet locations as defined by EN61010-1.
If the product is not used in a manner specified in the instructions, the protection
provided by the equipment may be impaired.
CAUTION: Risk of Danger. Consult Operator’s manual for nature of hazard and corrective
actions.
CAUTION: Risk of crushing. Keep fingers away from rotor while pump is in operation. Stop
pump before loading or unloading tubing.
CAUTION: Hot Surface. Do not touch.
CAUTION: Risk of electric shock. Consult Operator’s manual for nature of hazard and
corrective actions.
This product is not designed for, nor intended for use in patient connected applications;
including, but not limited to, medical and dental use, and accordingly has not been
submitted for FDA approval.
This product is not designed for, nor intended for use in hazardous duty areas as
defined by ATEX or the NEC (National Electrical Code); including, but not limited to
use with flammable liquids. Consult the factory for products suitable for these types of
applications.
SAFETY
PRECAUTIONS
!
!
Explanation of
Symbols !
!
WARNING:
Product Use
Limitation
C
12
year
warranty
70 dba @ 1M
-25C, -13F +65C, +149F
+0C, +32F +40C, +104F
EN809 MACH. DIR.
EN61010-1 L.V. DIR.
EN61326-1 EMC DIR.
EN60529 / IEC 60034-5
07591-20
21.8 lbs. (9.88 kg)
07591-20
39.7 lbs. (18.0 kg)
IP 07591-20 IP33
07591-30 IP66 (NEMA 4X)
6-650 rpm

US & Canada only
Toll Free 1-800-MASTERFLEX | 1-800-637-3739
Outside US & Canada
1-847-549-7600 | 1-847-381-7050
*EN809 manufactured by:
Cole-Parmer Instrument Company
28W092 Commercial Avenue, Barrington, IL 60010
[email protected] | www.masterflex.com
A-1299-1086B Edition 03
I/P Precision Pump
System with
I/P Easy Load Head
77962-20
I/P Nema Precision Pump
System with
I/P Easy Load Head
77962-30
