Matador RADIANT GO User manual

Retain manual for further reference.
Before using the
BBQ, remove any
packaging material
within and around
the BBQ supplied
for protection
during transit.
PORTABLE CHARCOAL BBQ
RADIANT GO

Contents
CONTACT INFORMATION
For spare parts, order from your nearest
Bunnings Warehouse. For service and
warranty queries, please contact
Mayo Hardware at
[email protected]
or call;
1300 360 211 (Aus)
09 415 6240 (NZ)
Features & Benefits 3
Important safety information 4
Do’s & Don’ts 5
Positioning the BBQ 6
Before you cook 7
Using the BBQ 8
Regulating temperature 8
Adding fuel during cooking 9
After-use safety 9
Proper care & maintenance 9
Exploded parts diagram 10
Part diagrams 11
Hardware list 12
Assembly instructions 13-20
Warranty 21-23
Notes 24-25

3
MATADOR INSTRUCTION MANUAL
Features & benets
BARBECUE DIMENSIONS
Length Width Height
373 mm 373 mm 510 mm
Lid Air Vent Heat Shield Removable
Ash Catcher
Quick Release
Clips
Charcoal
G r at e
Cooking
G r at e
Non-Scratch
Lid Clamps
Bottom
Damper
Damper
control
settings
Storage Bag
with Carry
Strap
Cool Touch
Handles

Important safety
information
Read the Instruction Manual thoroughly before
assembling or using the BBQ.
CAUTION: FOR OUTDOOR USE ONLY.
• Estimated assembly time is 30-45 minutes.
• Only use this BBQ on a hard, level, non-
combustible, stable surface (concrete, ground,
etc.) capable of supporting the weight of the
BBQ. Never use on wooden or other surfaces
that could burn.
• Place the BBQ in an area where children and
pets cannot come into contact with it. Close
supervision is necessary when the BBQ is in use.
• Do not use this grill for anything other than its
intended purpose.
• In windy weather, place the BBQ in an outdoor
area that is protected from the wind.
• Use caution when opening the lid. Keep hands,
face and body a safe distance away. Flash flare
ups may occur when air comes into contact with
fire or hot coals.
• Close the lid and bottom damper to suffocate
and extinguish the flame.
• Use caution during assembly and while
operating your BBQ to avoid scrapes or cuts
from sharp edges of metal parts. Use caution
when reaching into or under the BBQ.
• When adding charcoal and/or wood chips, use
extreme caution and follow instructions in the
“Adding Fuel During Cooking” section of this
manual.
• When grilling, grease from meat may drip into
the charcoal and cause a grease fire. If this
should happen, close the lid to suffocate the
flame. Do not use water to extinguish grease
fires.
• Use caution and common sense when operating
your grill.
• Never leave hot coals and ashes in the BBQ
unattended.
• Use caution when lifting or moving the BBQ to
prevent strains and back injuries. Wait for the
BBQ to cool down prior to moving.
• Ensure BBQ is cool before cleaning and placing
into the provided storage bag.
• With a garden hose, completely wet the surface
beneath and around the BBQ to extinguish any
ashes, coals or embers which may have fallen
during the cooking or cleaning process.
• We advise that a fire extinguisher be on hand.
Refer to your local authority to determine proper
size and type of fire extinguisher.
• Failure to adhere to safety warnings and
guidelines in this manual could result in bodily
injury or property damage.
• When operating and handling the BBQ and fuel,
always wear protective clothing and BBQ gloves.
• Do not allow charcoal and/or wood to rest on the
walls of the BBQ. Doing so will greatly reduce
the life of the metal and finish of your grill.
• Do not attempt to service the BBQ other than by
normal maintenance, as explained in the “After-
Use Safety” and “Proper Care & Maintenance”
sections of this manual.
• Recycle and/or dispose of all packaging
materials thoughtfully. Check with your local
council recycling rules for further information.
• Ensure manual remains in the possession of the
user for further reference.

5
MATADOR INSTRUCTION MANUAL
Do’s & Don’ts
DO’S
• We recommend the use of a charcoal chimney
starter to avoid the dangers associated with
charcoal lighter fluid. If you choose to use
charcoal lighter fluid, only use one approved
for lighting charcoal. Carefully read the
manufacturer’s warnings and instructions on the
charcoal lighter fluid and charcoal prior to using
them. Store charcoal lighter fluid safely away
from the BBQ.
• When using charcoal lighter fluid, allow the
charcoal to burn with the BBQ lid and vents open
until covered with a light ash (approximately 20
minutes). This will allow the charcoal lighter fluid
to burn off. Failure to do this could trap fumes
from charcoal lighter fluid in the BBQ and may
result in a flash fire or explosion when the lid is
opened.
DON’TS
• Do not use petrol, kerosene or alcohol for
lighting charcoal. Use of any of these or similar
products could cause an explosion possibly
leading to severe bodily injury.
• Never add charcoal lighter fluid to hot or even
warm coals, as flashback may occur causing
severe burns.
• Never use charcoal that has been pre-treated
with lighter fluid. Use only high grade charcoal
briquettes or charcoal lump wood.
• Do not leave the BBQ unattended when in use.
• Do not store or use the BBQ near flammable
liquids, gases or where flammable vapours may
be present.
• Do not store BBQ in Storage Bag when it is still
warm/hot from use.
• Do NOT attempt to remove legs of the BBQ
when it is still warm/hot.
• BBQ will become hot when in use. To avoid
burns and injury:
• DO NOT attempt to move the BBQ.
• Wear protective BBQ gloves.
• DO NOT touch any hot BBQ surfaces.
• Keep children away from hot surfaces.
• DO NOT wear loose clothing or allow hair
to come in contact with the grill.

Positioning the BBQ
• This BBQ should only be used in an above
ground, open air situation with natural
ventilation.
• When the BBQ is in use, maintain a clearance
of at least 1m between the hot BBQ and any
combustible materials such as bushes, trees,
wooden fences, buildings, etc.
• Any enclosure in which the BBQ is used shall
comply with one of the following:
• An enclosure with walls on one side, but at least
one permanent opening at ground level and no
overhead cover.
• Within a partial enclosure that includes an
overhead cover and no more than two walls.
• Within a partial enclosure that includes an
overhead cover and no more than two walls, the
following shall apply:
• At least 25% of the total wall area is
completely open; and
• At least 30% of the remaining wall area is
open and unrestricted.
• In case of balconies, at least 20% of the total of
the side, back and front wall areas shall be and
remain open and unrestricted.
• The BBQ must not be installed under or on any
combustible material. Minimum clearance from
any combustible materials on ALL sides of the
BBQ is 1m and 1m overhead.
• BBQ MUST BE ASSEMBLED IN ACCORDANCE
WITH THE MANUFACTURER’S INSTALLATION
INSTRUCTIONS.
• The following figures are diagrammatic
representations of outdoor areas described.
Rectangular areas have been used in these
figures – the same principle applies to any other
shaped area.
1 m
1 m
1 m
1. An enclosure
with walls on all
sides, but at least
one permanent
opening at ground
level and no
overhead cover.
2. Within a partial enclosure
that includes an overhead
cover and no more than two
walls (See example 2 & 3).
3. Within a partial enclosure that
includes an overhead cover and more
than two walls, the following will apply:
(i) At least 25% of the total wall area is
completely open, and
(ii) At least 30% of the remaining wall
area is open and unrestricted (see
Example 4 & 5).
(iii) In the case of balconies, at least 20%
of the total wall area shall be and remain
open and unrestricted.
1. 2. 3. 4. 5.

7
MATADOR INSTRUCTION MANUAL
Before you cook
Curing Your Grill
NOTE: It is important that the exterior of the BBQ
is not scraped or rubbed during the curing process.
Before first use, follow the instructions below
carefully to cure your BBQ. This process will
minimise damage to all finishes and remove any
paint odour that may impart unnatural flavours
during the first cook.
IMPORTANT: To protect your BBQ from excessive
rust, the unit must be properly cured and covered
at all times when not in use. It’s recommended that
you also cure the BBQ periodically.
Step 1
Lightly coat all interior surfaces of the BBQ with
vegetable oil or vegetable oil spray. Do not coat
charcoal or cooking grates.
Step 2
Follow the instructions below carefully to build a fire.
If using a charcoal chimney starter, follow all
manufacturer’s warnings and instructions regarding
the use of their product.
Instructions for reference only:
Step 1 - Remove the cooking grate from the BBQ.
Step 2 - Ensure all vents are open.
Step 3 - Roll a few sheets of paper and locate them
firmly into the underside of a charcoal chimney
starter.
Step 4 - Place the chimney starter on top of the
charcoal grate inside the BBQ.
Step 5 - Fill the chimney starter with charcoal to
about half way.
Step 6 - Light the paper in multiple places around the
perimeter of the chimney starter (via the air holes).
Step 7 - After the outer surface of the charcoal has
formed a light grey ash covering and is ready to
use, carefully pour the charcoal onto your charcoal
grate, handling the chimney starter by the handle
only. Always wear heat resistant BBQ gloves when
handling the chimney starter. Use charcoal tongs to
spread the charcoal as required.
Step 8 - Replace the lid onto the BBQ and let it
heat up for 30 minutes. This time will allow for the
heat to burn off any remaining fumes from the
manufacturing process and cure the BBQ.
Step 9 - Clean and prepare your BBQ for your first
cook!
NOTE: To extend the life of your BBQ, make sure
that hot coals and wood do not touch the walls of
BBQ.

Using the BBQ
Cooking Methods
There are several techniques of cooking that can
be applied with your Matador Radiant Go BBQ.
See below to choose the one that best suits your
needs. For additional information and tips, we also
recommend reading the instructions that come with
your preferred charcoal fuel.
Direct – Heat
This method of cooking uses a single layer of evenly
placed coals across your charcoal grate. This is a hot
and fast way to cook and best suited for thin cuts of
meat and other food that cooks quickly.
Indirect – Heat
When cooking larger cuts of meat or when a lower
temperature is required, the indirect method of
cooking is ideal. To achieve this, the charcoal is
pushed all the way to one side of the charcoal grate
leaving the other side empty.
This allows for a dual heat zone to be created within
your BBQ. This zoning of the BBQ creates one side
with a higher temperature for grilling and searing.
Whilst on the opposite side, away from the charcoal,
allows cooking at a lower temperature which is
perfect for roasting.
TIP: If space allows, place a small aluminum tray
directly under your meat to capture those succulent
juices that make your gravy so delicious and keep
your BBQ clean.
Regulating temperature
To regulate the temperature of your BBQ, there are
two main things that can be adjusted. These are;
1. The amount of airflow to your fuel.
2. How much physical fuel is placed into the BBQ.
Top Lid Vent
The top vent allows air to vent from the BBQ and
should be fully opened while trying to increase
the temperature. Once the desired temperature is
reached, the vent can then be partially closed to help
maintain a constant cooking temperature. Closing
this vent fully will help to suffocate and extinguish
the fuel.
Bottom Air Vent
You can increase and decrease the temperature
of your BBQ by adjusting the bottom air vent. Air
coming in through the bottom of the BBQ increases
the amount of oxygen accessible to the fuel source
and therefore regulates combustion. The more air
you allow into the BBQ the hotter it will become. So
remember to have it only partially open if cooking at
a lower temperature.
Charcoal Fuel
If you are doing a long cook or wish to reach a
higher temperature you may want to add more
charcoal to your BBQ. Increasing the amount of
charcoal will help to maintain your temperature for
longer or increase it if required. Please refer to the
“Adding Fuel During Cooking” section for further
details.

9
MATADOR INSTRUCTION MANUAL
Adding fuel during
cooking
Additional charcoal may be required to maintain or
increase cooking temperature.
Step 1 - Stand back and carefully lift off the BBQ lid.
Use caution since flames can flare-up when natural
air suddenly comes in contact with fire.
Step 2 - To access the charcoal grate you will firstly
need to remove your food from your cooking grate.
Step 3 - Wearing heat resistant BBQ gloves, lift up
the cooking grate to access the charcoal. DO NOT
touch the grate by hand. Put the cooking grate onto
a non-combustible surface whilst re-fueling.
Step 4 - Stand back at a safe distance and use
long charcoal tongs to lightly brush aside ashes
on hot coals. Use charcoal tongs to add charcoal
to charcoal grate being careful not to stir-up ashes
and sparks. If necessary, use your charcoal chimney
starter to light additional charcoal and add to
existing fire.
WARNING: Never add charcoal lighting fluid to hot
or even warm coals as flashback may occur causing
severe burns.
Step 5 - Once the charcoal has been added, carefully
replace the cooking grate wearing BBQ gloves.
Check the surrounding area for any hot coals, ash,
or embers which may have fallen from the BBQ. Be
sure to safely extinguish these before continuing to
cook.
After-use safety
WARNING:
• Always allow BBQ and all components to cool
completely before handling.
• Never leave hot coals and ashes in BBQ
unattended. Make sure coals and ashes are
completely extinguished before removing.
• Before the BBQ can be stored away, remaining
coals and ashes must be removed from BBQ.
Use caution to protect yourself and property.
Place remaining coals and ashes in a non-
combustible metal container and completely
saturate with water. Allow coals and water to
remain in metal container for 24 hours prior to
disposing.
• Extinguished coals and ashes should be placed a
safe distance from all structures and combustible
materials.
• With a garden hose, completely wet surface
beneath and around the grill to extinguish any
ashes, coals or embers which may have fallen
during the cooking or cleaning process.
• Return your BBQ to its storage bag and place it
in a protected area away from children.
Proper care &
maintenance
• Cure your BBQ periodically throughout the year
to protect against excessive rust.
• To protect your BBQ from excessive rust, the
unit must be properly cured and covered at all
times when not in use.
• Wash cooking grate and charcoal grate with hot
soapy water, rinse well and dry.
• Clean inside and outside of BBQ by wiping
off with a damp cloth. Apply a light coat of
vegetable oil or spray to the interior surface to
prevent rusting. Do not coat charcoal grate.
• If rust appears on the exterior surface of your
grill, clean and buff the affected area with steel
wool or fine grit emery cloth. Touch-up with a
good quality high-temperature resistant paint to
maintain the appearance.
• Never apply paint to the interior surface. Rust
spots on the interior surface can be buffed,
cleaned, and then lightly coated with vegetable
oil or vegetable oil spray to minimise rusting.

Exploded Parts Diagram

11
MATADOR INSTRUCTION MANUAL
Part diagrams
1. Lid Handle 2. Lid Handle Heat Shield 3. Lid Air Vent 4. Lid
5. Cooking Grate 6. Charcoal Grate 7. Fire Bowl 8. Fire Bowl Air Damper
9. Ash Catcher Ring 10. Ash Catcher 10A. Leg Cover 10B. Leg Tube Assembly

Hardware list
Part Name Hardware Image Quantity
ABOLT SQUARE SHOULDER -
M6 X 25 2
BBOLT - M6 X 35 4
CBOLT SQUARE SHOULDER -
M6 X 10 4
DBOLT - M5 X 10 1
EWASHER Ø6/12 6
FWASHER Ø9/16 6
GWING NUT - M6 3
HDOME NUT - M6 4
KLOCK NUT - M5 1
LSPACERS 2
MWASHER Ø5/10 1
NLID AIR VENT SPRING 1
PFIBRE WASHER 2

13
MATADOR INSTRUCTION MANUAL
Assembly Instructions
It is important to read these instructions thoroughly.
If you have any problems, difficulties or concerns
please contact the manufacturer or retailer.
Read all safety warnings and assembly instructions
carefully before assembling or operating your BBQ.
Inspect contents of the box to ensure all parts are
included and undamaged.
The following tools are required for assembly and
are not included:
• Phillips head screwdriver
• 10mm and 8mm spanner, adjustable
wrench or socket set with 10mm and 8mm
socket
SYMBOL: The following symbols will be shown in
each procedure for indication of tightening the bolt
and nut if necessary.
Hand Tighten Only at this stage:
Tighten with Tools at this stage:
Pay Attention at this stage:

Assembly Instructions
1.1 To attach the Lid Air Vent (3), firstly feed the threaded pin through the top of the Lid (4) so the vent is
sitting against the lid.
1.2 Place a Washer (F) onto the pin followed by the compression Spring (N).
1.3 Place the second Washer (F) onto the top of the spring and push down and hold it.
1.4 Whilst holding the washer down, attach the securing Wing Nut (G) to capture the assembly. You can
tighten and loosen this nut to control the stiffness of the air vents rotation as desired.
Step 1 - Attach the Lid Air Vent
Hardware Needed
FWASHER - Ø9/16 2
GWING NUT - M6 1
NSPRING 1

15
MATADOR INSTRUCTION MANUAL
Assembly Instructions
2.1 Place a M6 x 25 Bolt (A) through one side of the Lid Handle Heat Shield (2), then thread a Spacer (L) onto
the bolt.
2.2 Put these parts into the middle of the Lid Handle (1) and locate the Bolt (A) through the corresponding
hole in the Handle.
2.3 Whilst holding all of the parts together, place the bolt through hole on the top of the LId (4).
2.4 Keeping the parts attached to the Lid, turn over the assembly and attach the Washer (E) and secure
loosely with the Wing Nut (G).
2.5 Once attached, repeat the assembly process for the other side of the Handle Assembly.
2.6 Tighten both Wing Nuts (G) to do a final securing of the Handle Assembly.
Step 2 - Attach the Lid Handle Assembly
Hardware Needed
A
BOLT SQUARE
SHOULDER - M6
X 25
2
EWASHER Ø6/12 2
GWING NUT - M6 2
LSPACER 2
PFIBRE WASHER 2

Assembly Instructions
3.1 Locate the Ash Catcher Ring (9) to the underside of the Fire Bowl (7) and align the four mounting holes.
3.2 Take M6 x 10 Bolts (C) and thread them through the holes in the Ash Catcher Ring (9) so that the thread
showing on the inside of the Fire Bowl (7).
3.3 Take a Washer (F) and Dome Nut (H) and attach it to the M6 Bolt (C) to locate the Ash Catcher (9) to the
Fire Bowl.
3.4 Repeat this process for the other three remaining mounting holes.
3.4 Once all Dome Nuts (H) are attached by hand, go back and tighten them with a 10mm socket (or
adjustable wrench) to secure the Ash Catcher Ring (9) in place.
Step 3 - Attach the Ash Catcher Ring
Hardware Needed
C
BOLT SQUARE
SHOULDER
- M6 X 10
4
HDOME NUT - M6 4
FWASHER - Ø9/16 4
NOTE:
This stage will require a Phillips
head screwdriver and a 10mm
socket (or adjustable wrench) to
tighten the securing hardware.
Pay attention to align the Ash
Catcher Ring correctly with the Air
Vent details in the bottom of the
Fire Bowl. Refer to detail image
provided.
NOTE: Pay attention to the
alignment of the Bottom Air
Damper control slot with the
small cut out detail on one of the
Fire Bowl vents.

17
MATADOR INSTRUCTION MANUAL
Assembly Instructions
4.1 Thread the handle of the Bottom Damper (8) through the adjustment slot in the Ash Catcher Ring (9).
4.2 Make sure that the tab on the damper face is located inside the slot details on the underside of the Fire
Bowl (7) (Refer to inset detail below).
4.3 To secure the Bottom Damper, insert the Bolt - M5 x 10 (D) through the hole in the centre of the bottom
of the Fire Bowl (7), thread on the Washer (M) and then secure with the M5 Lock Nut (K).
Step 4 - Secure the Bottom Damper
Hardware Needed
DBOLT - M5 x 10 1
KLOCK NUT - M5 1
MWASHER - Ø5/10 1
NOTE:
This stage will require a Phillips
head screwdriver and a 8mm
socket (or adjustable wrench) to
tighten the securing hardware.

Assembly Instructions
5.1 Take a Leg Cover (10A) and slide it over the securing bracket that is welded to the inside of the Leg
Assembly (10B).
5.2 Locate this Leg and Cover Assembly into one of the four locating recesses around the outside of the Ash
Catcher (10).
5.3 Insert a Bolt - M6 x 35 (B) from the inside of the Ash Catcher (10) and secure to the threaded nut on the
Leg Assembly.
5.4 Repeat this process for the three remaining leg assemblies.
Step 5 - Connecting the Legs
NOTE:
This stage will require a Phillips
head screwdriver to tighten
the securing hardware. A short
handled screwdriver will give the
best adjustment.
Hardware Needed
BBOLT - M6 X 35 4
EWASHER Ø6/12 4

19
MATADOR INSTRUCTION MANUAL
Assembly Instructions
6.1 The Ash Catcher is designed to be clipped onto the Fire Bowl Assembly for easy cleaning and storage.
6.2 To secure the Ash Catcher (10), locate it on the bottom of the Fire Bowl and align the clips with the two
locking horizontal slots on the Ash Catcher Ring (9).
6.3 Locate the two clips into these slots and push their latches downwards to lock them in place.
6.4 To remove the Ash Catcher simply release the latches and remove the clips from the Ash Catcher Ring
(9).
Step 6 - Securing the Ash Catcher
Step 7 - Inserting the Internal Grates
7.1 Insert the Charcoal Grate (6) into the Fire Bowl and rest it on the lowest edge of the bowl.
7.2 Place the Cooking Grate (5) onto the top edge of the Fire Bowl to locate it in place.
7.3 Position the Lid (4) onto the Fire Bowl and secure in place by locking the three clips over the outside lip.

Assembly Instructions
8.1 The Radiant Go BBQ comes with a convenient storage bag which allows you to store and transport it
with ease.
8.2 Before starting, make sure the BBQ has cooled down from being used as residual heat from the fire
bowl could be harmful to the handler and cause damage to the Storage Bag.
8.3 Once cool, make sure you thoroughly clean the ash and grease from inside the BBQ and empty the Ash
Catcher prior to placing the BBQ into the Storage Bag.
8.4 The Radiant Go’s Ash Catcher and Legs are designed to be stored inside the BBQ.
8.5 Remove the Ash Catcher and Legs by releasing the two locking clips, place inside the BBQ and secure
the Lid for storage. Refer to image below for placement orientation of Legs.
8.6 Replace the Lid over the Legs and secure the three lid Locking Clips.
8.7 Place the secured BBQ inside the Storage Bag.
8.8 Be sure to align the Lid Handle with the corresponding opening in the top half of the Storage Bag. The Lid
Handle is designed to protrude through this opening in the Storage Bag so you can access it for handling.
8.9 Close the zipper on the Storage Bag and fasten the strap that sits under the Handle to secure the Storage
Bag ready for transit.
8.10 Attach the Storage Bag Strap to the Bag for easy handling.
Step 8 - Storing the Radiant GO
ATTENTION:
MAKE SURE THE BBQ HAS COOLED DOWN BEFORE STARTING THE STORAGE PROCESS
