Matrix U-1X-F User manual

1
Issue date 2017-03-14 Edition 01 Doc No. SM-TM-AF-
017
Revision
date 01 Page 22
Johnson
Approval Review Editor
Kyle Schweitzer Dora Feng
U-1X-F & R-1X-F
Service Manual
Johnson Industries (Shanghai) Co.,Ltd

2
Production Browse
U-1X-F

3
Production Browse
R-1X-F

4
Contents
Chapter 1: Serial Number Location…………………………………………………………..5
Chapter 2: Troubleshooting
2.1 Electrical Diagram……………………………………………………………………….6
2.2 MCB Instruction………………………………………………………………………… 9
2.3 No Power to the Console……………………………………………………………...10
2.4 Heart Rate Issue/Quick Keypad ……………………………………………………..11
2.5 No Resistance or Incorrect Resistance……………………………………………...12
Chapter 3: Part Replacement
3.1 Console Replacement…………………………………………………………………13
3.2 Handlebar Replacement………………………………………………………………13
3.3 Console Mast Replacement…………………………………………………………..14
3.4 Pedal Set Replacement……………………………………………………………….15
3.5 Crank Replacement………………………… ………………………………………..15
3.6 Side Cover Replacement……………………………………………………………...16
3.7 Generator Replacement……………………………………………………………….17
3.8 MCB Replacement……………………………………………………………………..18
3.9 Seat Carriage Replacement…………………………………………………………..19
3.10 Drive Belt Replacement……………………………………………………………....20
3.11. Drive Axle replacement………………………………………………………………21

5
CHAPTER 1: Serial Number Location
Serial Number Location
Serial Number Location
U-1X-F
Notes: please refer to console service manual to get more information

6
CHAPTER 1: Serial Number Location
Serial Number Location
R-1X-F
Serial Number Location
Notes: please refer to console service manual to get more information

7
CHAPTER 2: Troubleshooting
2.1 ELECTRICAL DIAGRAM
2.1.1 U-1X-F Electrical Diagram

8
CHAPTER 2: Troubleshooting
2.1 ELECTRICAL DIAGRAM
2.1.2 R-1X-F Electrical Diagram

9
CHAPTER 2: Troubleshooting
2.2 MCB Instruction
When the LED10 Error light turns on, it means to check the related
error code on the console. See console service manual.

10
CHAPTER 2: Troubleshooting
2.3 No power to the console
Symptom:
No power to the console.
2) Solution:
a. The adapter for this model is 12V - 5A. Check to make sure the power adapter on the unit is cor-
rect. Test the power adapter in a known good outlet. Replace the adapter if it is defective.
b. Check the connection of the console cable at the console (Fig1). Unplug the console cable from
console, and use a multi-meter to check the voltage through the console cable. Pin 1 or 2 and pin 7
or 8. it should be 12VDC. If no voltage is present, the console cable is defective, replace it.
c. If the voltage through the console cable is 12VDC, the console is defective, replace it.
Fig1
