Matrix AURA Series User manual

MATRIX FITNESS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
Toll Free 866.693.4863 | matrixfitness.com | Fax [phone]
PART # 0000000000
REV. 1.8
AURA SERIES
G3-S70 LEG PRESS
PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. If applicable, adjust seat pads, leg pads, foot pads, range of motion
adjustment, or any other type of adjustment mechanisms to a
comfortable start position. Make certain that the adjusting mechanism is
fully engaged to prevent unintentional movement and to avoid injury.
4. Sit on bench (if applicable) and get into appropriate position for exercise.
5. Exercise using no more weight than you can safely lift and control.
6. In a controlled manner, perform exercise.
7. Return weight to its fully-supported start position.
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
Lubricate Guide Rods † As Needed
* Upholstery & Grips should be cleaned with a mild soap and water
or a non-ammonia based cleaner.
† Guide rods should be lubricated with Teon based lubricant. Apply the
lubricant to a cotton cloth and then apply up and down the guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum Training Weight 175 kg / 385 lbs.
Product Weight 433 kg / 954 lbs.
Overall Dimensions
(L x W x H)*
211 x 125 x 185 cm /
83” x 49” x 73”
* Ensure a minimum clearance width of 914 mm / 36” for access to and
passage around MATRIX strength equipment.
WARRANTY
Valid in North America only
Frame (not coatings) * 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specied 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
Accessories 6 months
* Frame is dened as the welded metal base of the unit and does not include
removable parts.
Product specications subject to change without notice.
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX products to instruct all
individuals, whether they are the end user or supervising personnel on proper usage
of the equipment.
It is recommended that all users of MATRIX exercise equipment be informed of the
following information prior to its use.
Do not use any equipment in any way other than designed or intended by the
manufacturer. It is imperative that MATRIX equipment be used properly to avoid injury.
INSTALLATION
1. STABLE AND LEVEL SURFACE: MATRIX exercise equipment must be installed
on a stable base and properly leveled.
2. SECURING EQUIPMENT: Manufacturer recommends that all stationary MATRIX
strength equipment be secured to the oor to stabilize equipment and eliminate
rocking or tipping over. This must be performed by a licensed contractor.
All anchor points must be able to withstand 750 lbs. (3.3 kN) pull-out force.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken parts.
Use only replacement parts supplied by your country’s local MATRIX dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason.
They contain important information. If unreadable or missing, contact your
MATRIX dealer for a replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth
operating equipment as well as keeping your liability to a minimum. Equipment
needs to be inspected at regular intervals.
4. Ensure that any person(s) making adjustments or performing maintenance or
repair of any kind is qualied to do so. MATRIX dealers will provide service and
maintenance training at our corporate facility upon request.
ADDITIONAL NOTES
This equipment should only be used in supervised areas where access and control is
specically regulated by the owner. It is up to the owner to determine who is allowed
access to this training equipment. The owner should consider a user’s: degree of
reliability, age, experience, etc.
This training equipment meets industry standards for stability when used for its
intended purpose in accordance with the instructions provided by the manufacturer.
This training equipment is in compliance with EN 957-1 and the relevant portions of
EN 957-2 and EN 957-4.
WARNING
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS
TO AVOID INJURY!
1. NEVER allow children on strength training equipment. Teenagers must be supervised at all times
while using this equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
3. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
4. NEVER allow resistance straps, ropes or other means to be attached to this equipment, as this may
result in serious injury. NEVER use this equipment for support during stretching, as this may result in
serious injury.
5. ALWAYS use a spotter.
6. Do not exceed the weight capacity of this equipment.
7. Balance the weight applied to this equipment and/or any barbell. Where applicable, use retention
devices to retain weight discs.
8. Injuries to health may result from incorrect or excessive training. Cease exercise if you feel faint or
dizzy. Obtain a medical exam before beginning an exercise program.
9. Keep body, hair, clothing, and tness accessories free and clear of all moving parts.
10. Manufacturer recommends that all equipment be secured to the oor to stabilize and eliminate
rocking or tipping over. Use a licensed contractor.
11. DO NOT REMOVE THIS LABEL. REPLACE IF DAMAGED OR ILLEGIBLE.
12. For Smith Machines: Visually ensure lifting bar catch rods are fully engaged and seated in the hooks
before releasing the load and exiting the machine.
13. For Smith Machines: ALWAYS set both adjustable stops to the same height when using this machine.
14. Adjustable safety stops, if present, must be used at all times.
15. For equipment with adjustable stops: PROPER adjustable stop height depends on the exercise
performed.Adjust as follows:
• Remove weight from lifting bar.
• For squats, perform the exercise and determine the lowest comfortable position of the bar that
ensures no spinal compression. For other exercises, perform the movement and determine the
lowest point of bar travel that is comfortable without the bar contacting your body.
• Position both stop catches to stop the bar at this point. Ensure that they are completely seated on
the stop rods or catch plate.
• Load weights onto the lifting bar and carefully perform the exercise.
16. When adjusting any adjustable mechanism (seat position, pad location, range of motion limiter, pulley
carriage, or any other type of adjuster), make certain that the adjusting pin is fully engaged in the hole
to avoid injury.
17. Keep hands and feet clear at all times from moving parts to avoid injury.

AURA SERIES (G3-S70) LEG PRESS
UNPACKING (G3-S70) LEG PRESS
Thank you for purchasing a MATRIX Fitness product. Your AURA SERIES (G3-S70) LEG PRESS is inspected before it is packaged. It is shipped in multiple
pieces to facilitate the compact packaging of the machine. Prior to assembly, conrm all the components by matching them with the exploded diagrams. Carefully
unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
To avoid injury to yourself and prevent damage to the frame components, be sure to have proper assistance removing the frame pieces from this box. Please be
sure to install the equipment on a stable base, properly level the machine and leave at least two feet of clearance to enter and exit the machine.
TOOLS REQUIRED FOR ASSEMBLY (not included)
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench Phillips Screwdriver
5MM L-Shaped Allen Wrench 8MM Open-End Wrench
6MM L-Shaped Allen Wrench 17MM Open-End Wrench
8MM L-Shaped Allen Wrench Guide Rod Lubrication
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Step 3
C30
D26
D32
D33
D34
D39
D40
F31
K17
L10
L11
B72
B70
S-20 clamp (C-shaped)
Ring
Lock Washer
Lock Washer (M12)
Flat Washer (M12)
Screw (M12x25L)
Bushing
Wavy Washer
Screw (M8X20L)
Flat Washer (M8)
Lock Washer (M8)
Screw (M8x18L)
Description Panel
4
4
4
6
6
6
2
2
6
6
6
2
1
Item Description Qty
Input Detail
D40
D26
D26
K17
B72
B70
D39
D34
D39
D33
D33
D34
F31
D39
D39
D39
F31
D33
D34
D39
D33
D34
L11
L10
D34
D33
D33
D34
C30
C30
C30
C30
D40
D32
D32
D32
D32
Step 4
C20 Screw (M10x35L) 10
Item Description Qty
Upholstery Detail
C20
C20
Step 1
C22
C60
C61
Flat Washer (M10)
Arc-Flat Washer
Screw (M10X25L)
15
8
23
Item Description Qty
Frame Detail
Screw
Flat Washer
Flat Washer
Screw
Screw
Arc-flat Washer
C61
C22
C61
C60
C61
C22
Step 2
C61
C22
C60
C19
C31
Screw (M10x25L)
Flat Washer (M10)
Arc-flat Washer
Nylon Nut (M10)
Screw (M10x85L)
6
6
2
2
2
Item Description Qty
Frame Detail
C22
C31 C22
C61
C61
C22
C60
C61
C19
The assembly of seat pulley and eccenter
Step 6
F02 Tightwire 1
Item Description Qty
Weight Stack Detail
F02
F02
Step 7
B47
B28
B43
B51
Q01
Q02
Q05
Q06
Water Bottle Holder
Screw (M8x30L)
Screw (M4x12L)
Internal Tooth Lock Washer
Weight Shield
Upper Cover
Rubber Shield Spacer
Rubber Tip Weight
Shield Bolt (M8x40L)
1
2
6
6
1
2
6
6
Item Description Qty
Weight Stack Detail
B47
Q01
AB3
B51
B43
B51
B43
B51
B43
Upper Cover
Q02
B28
Towel / Water
Bottle Holder
Q05
Q06
Weight Shield
Step 5
F11
K13
K18
K17
L11
L13
L14
K07
Flat Washer (M5)
E-Clipper
Flat Washer (M8)
Screw (M8x20L)
Lock Washer (M8)
Lock Washer (M5)
Screw (M5x16L)
Rubber Block (Elastomer)
4
4
2
2
2
4
4
2
Item Description Qty
Weight Stack Detail
K13
K17
F11
L13
L14
K18 L11
Guide Sleeve
Guide Rod
Screw
Selector Pin
Top Weight
K07
10
