Matrox Graphics Architecture
Matrox Productiva G100 Multi-Monitor Series
User Guide
10627-301-0130
1999.03.12
ENGLISH
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2 Matrox Productiva G100 Multi-Monitor Series – User Guide
Contents
Using this guide 4
Overview 5
Hardware supplied..............................................................................................................5
Software supplied ...............................................................................................................6
Installation overview...........................................................................................................6
Hardware installation 7
Connection setup 11
Quick connection setup.....................................................................................................11
SCART information .........................................................................................................13
Matrox video input............................................................................................................14
Software installation 15
Matrox PowerDesk software 16
Monitor setup....................................................................................................................16
Display setup.....................................................................................................................17
Multi-display setup...........................................................................................................17
Software overview ............................................................................................................17
Matrox PC-VCR Remote program 19
Input setting ......................................................................................................................20
Video file input .................................................................................................................20
TV tuner input...................................................................................................................21
Video line input ................................................................................................................22
Mini remote.......................................................................................................................23
More features....................................................................................................................24
Matrox VidCap driver 26
Video source settings........................................................................................................26
Video format settings........................................................................................................27
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 3
Troubleshooting 28
Graphics............................................................................................................................ 28
Video ................................................................................................................................ 36
Sound................................................................................................................................ 40
Display information 42
Graphics............................................................................................................................ 42
Video (Matrox TV tuner required).................................................................................. 43
Hardware information 44
Customer support 46
Warranty 49
Index 51
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4 Matrox Productiva G100 Multi-Monitor Series – User Guide
Using this guide
This guide assumes you’re familiar with basic functions like click, right-click and double-click,
and that you’re familiar with the basics of the operating system you’re using. Also, we use the
following conventions:
Bold for text that appears on-screen, subheadings and labels.
Italics for file names, paths, publication titles, and new terms.
Bold Italics for emphasis.
Keyboard keys in square brackets, with a plus sign separating keys that you press
simultaneously. For example: press [Ctrl]+[Alt]+[Del] to restart your computer.
Arrows (“”) to separate ordered directions. For example, “click OK Close OK” is the
same as “click OK, then click Close, then click OK”.
When viewing online, green for cross-references and underlined green for links to Web pages.
Click green text to jump to what is being referenced. (To jump to Web pages, your system first
needs to have full Internet access.)
More information
We provide additional documentation in help files, readme files, and Adobe Acrobat PDF
(Portable Document Format) files. To view or print PDF files, use the Acrobat Reader program,
which you can install from the “Matrox Installation” CD-ROM. This guide is available on the
CD-ROM as a PDF file (Doc\Inst\inst_en.pdf). The online version of this guide has additional
information, including the following sections: “Customer support”, “Warranty” and “Software
license agreement”.
For context-sensitive help where available, click the “ ” icon in the title bar, then click the
item you want help on. Right-click a help topic for a pop-up menu that lets you print or copy it.
Also, be sure to check for any last-minute release notes at the end of this manual and in the
Matrox CD-ROM readme file.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 5
Overview
Thank you for purchasing a Productiva G100 MMS (Multi-Monitor Series) graphics card. Your
Matrox MMS card is a high-performance graphics card that plugs into an expansion slot inside
your personal computer. This card lets you use 2 or 4 monitors at a time with Windows 98, NT 4.0
or NT 3.51.
The Matrox graphics engine gives you superior performance with Windows, digital video and 3D
graphics. To accelerate 3D programs, your Matrox card uses bus mastering and has hardware-
accelerated features, including texture mapping, Gouraud shading and Z-buffering.
Your Matrox graphics card is 100% VGA compatible and supports all VESA standards: VBE 2.0
(Super VGA modes), DPMS (energy saving), and DDC-2B (Plug-and-Play monitor).
Also, you can upgrade your Matrox card with hardware add-ons. For a list of available upgrades,
see “Hardware information”, page 44. For more information on available upgrades, see the Matrox
Web site (www.matrox.com/mga).
Hardware supplied
Productiva G100 MMS card*
* Pictured is a G100-Quad card with a TV tuner.
Dual-monitor adapter†
†Two dual-monitor adapters are included with Matrox MMS-Quad products. An adapter with a composite video (RCA)
connector is included only with Matrox MMS products that include a TV tuner.
Internal audio cable‡
‡ Matrox TV tuner required. Only certain Matrox MMS products include a TV tuner.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6 Matrox Productiva G100 Multi-Monitor Series – User Guide
Software supplied
Matrox PowerDesk – to use your Matrox graphics hardware
Matrox Video Tools*† – to use your Matrox video capture hardware
Adobe Acrobat Reader for Windows
Online documentation
Installation overview
To install your Matrox product:
1Install the hardware – see “Hardware installation”, page 7.
2Connect your video input – see “Connection setup”, page 11.
3Install the software –
for Windows 98 and Windows NT 4.0, see “Software installation”, page 15.
for Windows NT 3.51, see the readme file in the root folder of the “Matrox Installation”
CD-ROM.
* Matrox TV tuner required. Only certain Matrox MMS products include a TV tuner.
† Matrox Video Tools software isn’t supported for Windows NT 3.51.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 7
Hardware installation
1Switch to the standard VGA display driver
If you’re running Windows 98 on your computer, this step isn’t necessary. If you’re using
another operating system (for example, Windows NT 4.0), see its documentation for how to
switch to VGA mode.
2Open your computer and remove
your existing graphics card
aTurn off your computer and all
peripherals such as your monitor or
printer.
bOpen the computer and remove your
existing graphics card. (If you have a
display adapter built into your computer
motherboard, it should automatically
disable itself after your Matrox card is
installed.)
WARNING: Static electricity can severely damage electronic parts. Before touching any
electronic parts, drain the static electricity from your body. You can do this by touching the
metal frame of your computer. When handling a card, hold it by its edges, and avoid touching
its circuitry.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8 Matrox Productiva G100 Multi-Monitor Series – User Guide
3Choose an expansion slot
aMost computers have different types of
expansion slots. Choose a PCI slot for
your graphics card. Your system manual
should identify the location of each type
of expansion slot in your computer.
bRemove the cover for the slot you intend
to use (if it’s not already removed). Save
the screw for the mounting bracket. (If
another slot is uncovered, you can seal it
with the cover you just removed.)
4Insert your Matrox card
aPosition your Matrox card over the
expansion slot you’ve chosen, then push
the card in firmly and evenly until it’s fully
seated.
bReplace the screw to secure the bracket of
your Matrox card to the computer frame.
WARNING: Inserting your Matrox card into
the wrong type of slot could damage your
card, your computer, or both.
AGP slot
PCI slot
ISA slot
(Back of
computer)
AGP cardPCI card
Plastic
tab
Graphics
card
Bracket screw
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 9
5If your Matrox product
includes a TV tuner:
Connect the internal audio cable
To use audio from your Matrox TV tuner,
connect the internal audio cable included
with your Matrox product.
aNote how your sound card is connected
to your CD-ROM or DVD-ROM drive
and then disconnect it from your drive.
bPlug the end of the cable from your
sound card into the AUDIO OUT
connector on your Matrox card.
cUse the audio cable included with your
Matrox product. Plug the end labeled
MATROX BOARD into the AUDIO IN
connector on your Matrox card.
dPlug the other end of the Matrox audio
cable (labeled DRIVE) into the audio out
connector on your CD-ROM or
DVD-ROM drive.
ePut your computer cover back on.
Note – If your sound card has a TV tuner
connector or your computer doesn’t have a
CD-ROM or DVD-ROM drive: use the
Matrox audio cable; plug the end labeled
DRIVE into the AUDIO OUT connector on
your Matrox card; plug the other end into
your sound card using its TV tuner
connector (if it exists) or its audio input
connector.
Sound cardMatrox card
CD-ROM or
DVD-ROM
drive
Sound cardMatrox card
CD-ROM or
DVD-ROM
drive
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 Matrox Productiva G100 Multi-Monitor Series – User Guide
6Connect your monitors
aAttach your Matrox dual-monitor
adapters*to the connectors on the bracket
of your Matrox MMS card. Make sure the
adapters snap into place.
If you have an MMS-Quad card with a
TV tuner, connect the dual-monitor
adapter with the composite video (RCA)
connector to the connector on the upper
part of the bracket (#1/#2).
bPlug your monitor cables into the dual-
monitor adapters. Make sure the
connectors are firmly in place. Monitors
are numbered consecutively based on
which connector each is attached to.
Numbering starts with the primary display
– the one that first displays information
when you restart your computer.
cMake sure the other end of each monitor
cable is properly connected to its monitor.
See your monitor manuals for more
information.
Your Matrox card is now installed. If your Matrox product includes a TV tuner, connect your
external devices before restarting your computer (see “Connection setup”, page 11). After
connecting your external devices, restart your computer and install your Matrox software (see
“Software installation”, page 15).
* Only one dual-monitor adapter is included with Matrox MMS-Dual cards.
Monitor cable
Dual
monitor
adapter
Matrox card
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 11
Connection setup
(Matrox TV tuner required)
Quick connection setup
1Connect video input
To use a video camera or video player*as a
video source, you need a composite video
(RCA) cable. This type of cable is available at
most electronics stores.
aPlug one end of your video cable into the
video connector on your dual-monitor
adapter.
bPlug the other end into the VIDEO OUT†
connector (usually yellow) on your video
camera or video player.
For more information on video input devices,
see “Matrox video input”, page 14.
*A
video player can be any device that generates a video signal. For example, a VCR, videodisc player or DVD
player.
† The labels on your devices may not be consistent with what’s in this guide. Different manufacturers sometimes use
different labels for the same type of controls and connectors. For example, the VIDEO IN connector on your TV
may be labeled VIDEO 1 (or VIDEO 2). To match labels, see the documentation for your video devices.
TV tuner
Composite video
(RCA) connector
(“VIDEO IN”)
TV antenna or cable TV
connector (“ANT/CABLE”)
Dual-monitor
adapter
(Matrox Productiva G100-Quad card with a TV tuner)
This section is only for Matrox
products that include a TV tuner.
Video camera or
video player
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12 Matrox Productiva G100 Multi-Monitor Series – User Guide
2Connect audio input
To connect the audio output of your video
camera or video player, you need an audio
cable with a stereo jack on one end and two
RCA connectors on the other end. This type of
cable is available at most electronics stores.
aPlug the stereo-jack end of the audio cable
into the LINE IN connector on your sound
card.
bPlug the other end into left (L) and right
(R) AUDIO OUT on the video device you
connected to in step 1. (On the audio
cable, white is for “left” and red is for
“right”. If your video device has only one
audio connector, use the left audio
connector on the cable.)
Formoreinformation on audioinputtypes, see
“Matrox video input”, page 14.
3Connect TV antenna or cable TV
Connect a TV antenna or cable TV to
ANT/CABLE on your Matrox product.
If the cable from your antenna is flat and ends
with twin leads, you need a 300-to-75-ohm
adapter to connect to the ANT/CABLE
connector (see below). You can find this type
of adapter at most electronics stores.
SCART connectors: If your video camera or video player only uses a
SCART audio/video connector (see picture), you may need to purchase
a SCART adapter. For more information, see “SCART information”,
page 13.
Video camera or
video player
300-to-75-ohm
adapter
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 13
SCART information
Some video devices in Europe only have SCART
connectors. This type of connector includes video
and audio, whereas composite connectors include
only video.
If your video camera or video player only has a
SCART connector, you need a SCART cable
adapter to connect to your graphics card. If you
don’t already have a SCART adapter, you should
be able to purchase one from your local
electronics store.
To connect your video camera or video player to
Matrox input, you need a SCART adapter with 3
connectors – 2 audio and 1 video.
To use a SCART adapter, connect your
audio/video cables to the SCART adapter, then
connect the adapter to your video camera or video
player. Depending on the type of SCART adapter
you’re using, you may need male-to-male
adapters to attach your audio/video cables to it.
For more information on connecting to a video
camera or video player, see steps 1and 2starting
on page 11.
Composite SCART adapter
with 3 connectors
Male-to-male adapter (RCA)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14 Matrox Productiva G100 Multi-Monitor Series – User Guide
Matrox video input
Video player as input
If you connect the output of your video player to
your computer, you can view, record and edit the
video from your video player on your computer.
To connect, see steps 1and 2starting on page 11.
For more information, see your video player
manual.
Video camera as input
If you connect a video camera to your computer,
you can view, record and edit live video on your
computer. You can also video conference. To
connect, see steps 1and 2starting on page 11. For
more information, see your video camera manual.
TV antenna or cable TV as input
You can connect a TV antenna or cable TV
directly to your Matrox product. With this setup,
you can use software to watch TV, change
channels and record TV programs like a VCR*. To
connect, see step 5, page 9, and step 3, page 12.
Copyrightinformation: Unauthorizedrecording or use ofbroadcast televisionprogramming,
video tape or other copyrighted material may violate copyright laws. Matrox assumes no
responsibility for the illegal duplication, use or other acts which infringe on the rights of
copyright owners. Your Matrox product may not let you record from a copy-protected video
source.
* You can also use a VCR as a TV tuner for your computer by connecting your TV antenna or cable TV to your VCR
(see your VCR manual), and connecting your VCR to your computer.
Video player
Video camera
TV antenna
or cable TV
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 15
Software installation
This section describes how to install Matrox software for Windows 98 or Windows NT 4.0.
1Restart your computer.
If you’re using Windows 98, it detects new hardware when you restart. If Matrox display
drivers haven’t been previously installed, Windows reports finding a PCI adapter.
If you see the Add New Hardware Wizard dialog box, click Next Next Next Next Finish,
then Yes to restart your computer.
Atthis point, Windows is using adisplay driverthat doesn’tfullysupport your Matrox graphics
card.
2After your computer has restarted, insert the “Matrox
Installation” CD-ROM in your CD-ROM drive – the setup
program automatically starts.*This setup program works
with Windows 98 and Windows NT 4.0, and detects which
operating system you’re using. Follow the on-screen
instructions.
3The setup program prompts you to restart your computer. Leave the CD-ROM in your
CD-ROM drive and click Restart Computer to continue. After you restart your computer, the
CD-ROM setup program starts again. The main menu lists other software you can install from
the CD-ROM. To install, select an item, click Install, then follow the on-screen instructions.
After the installation of an item is finished, you can return to the main menu to install another.
Click Exit when you’re done.
If this is a first-time installation, your display is using a 640 × 480 resolution with 256 colors –
supported by most monitors. To adjust software monitor settings:
for Windows NT 4.0, see “Matrox PowerDesk software”, page 16.
for Windows 98, see Windows 98 online help under “Multiple Display support”.
* If Windows doesn’t automatically start the setup program, you can start it manually from the root folder of the
CD-ROM.
Note: For more information on software included with your Matrox product, see the CD-ROM
readme file.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16 Matrox Productiva G100 Multi-Monitor Series – User Guide
Matrox PowerDesk software
(for Windows NT 4.0)
To access PowerDesk programs and online documentation, click Programs Matrox
PowerDesk NT. You can also access PowerDesk features by clicking the Matrox QuickDesk icon
( ) on the Windows taskbar.
Monitor setup
To check your monitor settings
1Click Programs Matrox PowerDesk NT Matrox Display Properties Monitor.
2In the Current display box, select the display you want to change monitor settings for. When
you select a number, it appears briefly on the corresponding display.
3If you have a Plug-and-Play monitor:
Make sure the Plug-and-Play (DDC) monitor button is selected. If
so, the Matrox display driver automatically uses the correct settings for your monitor. If not,
click this button, then click Apply.
If you don’t have a Plug-and-Play monitor:
See if the Default monitor (60 Hz) button is selected. If so, use the
Matrox monitor selection method. For more information on Matrox monitor selection, see the
online Matrox PowerDesk guide.
4Repeat steps 2and 3for each number in the Current display box.
Note: The Matrox display driver for Windows 98 supports multiple displays. However,
Matrox PowerDesk features are disabled in multi-display mode. To change your display
settings while in multi-display mode, use Windows controls. For more information on multi-
display mode, see Windows 98 online help under “Multiple Display support”. Windows 95
doesn’t support multiple displays.
Note: In multi-display mode, each monitor has its own monitor settings.
Note: Many Plug-and-Play monitors don’t automatically report if they’re capable of
1152 × 864 or 1600 × 1200 and higher display resolutions. To use these resolutions, or higher
refresh rates than those reported by the monitor, you can use the Matrox monitor selection
method.
WARNING: If incorrect software monitor settings are applied, some monitors can be
permanently damaged. For more information, see your monitor manual.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 17
Display setup
After checking your monitor software settings, you can change your display resolution, color
palette and other Matrox PowerDesk settings. To access Matrox display property sheets, click
Programs Matrox PowerDesk NT Matrox Display Properties. To change your display
resolution or color palette, click the Settings tab. For more information on changing your display
settings, see the Matrox PowerDesk online guide.
Multi-display setup
To set up a multi-display resolution, click Programs Matrox PowerDesk NT Matrox
Display Properties Settings Multi-Display Desktop ( ). Change the setup of your multi-
display desktop by moving the Desktop area slider.
Software overview
Matrox PowerDesk for Windows NT 4.0 includes
Matrox display driver with:
Multi-display support to use up to 4 monitors at a time.
Plug-and-Play (DDC-2B) monitor support.
Settings property sheet to change your display settings. This sheet provides access to Matrox
PowerDesk features such as:
Desktop mode buttons to set up a proportional, horizontal or vertical virtual desktop.
Desktop mode button to set up a multi-display desktop.
Display schemes to easily switch to a pre-defined display setting.
Monitor property sheet to inform the Matrox display driver of your monitor’s capabilities.
Information property sheet for information on your display hardware and software.
Performance property sheet to configure advanced driver settings.
PowerDesk property sheet with settings for:
PixelTOUCH to zoom in and pan on your view area.
CenterWINDOW to center opened windows in your view area.
MaxVIEW to maximize windows over the entire desktop or in a single display.
Note: In multi-display mode under Windows NT 4.0, the same display settings are used for
each display.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18 Matrox Productiva G100 Multi-Monitor Series – User Guide
Center dialogs boxes – to force dialog or message boxes to open in the center of program
windows or in the center of a certain display.
Open program windows in display – to force program windows to open in a designated
display.
Use single display before logon – to force single-display mode before you log on to
Windows.
Prevent display spanning – to prevent dialog boxes, message boxes and program windows
from spanning more than one display.
Save/restore window positions – to save and restore the size and position of program
windows.
Matrox Desktop Navigator (DeskNav)programto quickly change theviewarea of yourdesktop
and give you quick access to the PixelTOUCH zoom and CenterWINDOW features.
Matrox QuickDesk menu to quickly switch to a saved display scheme, and to access other
Matrox PowerDesk features.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Matrox Productiva G100 Multi-Monitor Series – User Guide 19
Matrox PC-VCR Remote program
If your Matrox product includes a TV tuner, the Matrox PC-VCR Remote program lets you use
your computer like you would a TV or VCR. To start, double-click the PC-VCR Remote icon ( )
on the Windows desktop background. The first time you start PC-VCR Remote, you see the
PC-VCR Remote and its video window. Use the PC-VCR Remote to control what you see in the
video window and what you record to file.
PC-VCR Remote interface
Menu window
TV channel up
Raise volume
Closed Captioning
Turn sound on or off
Exit PC-VCR Remote
Video file input
Pause video file or
freeze live video image
Skip to previous
video file in playlist
Open video files Take video snapshot
Skip to next
video file in playlist
Record to video file
Play video file Stop and rewind
video file
TV channel
selection buttons
Jump to previous channel
Turn “favorite” channel
selection on or off
Matrox TV tuner input
Matrox video line input
TV channel down
Lower volume
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
