Matsusada DJOP Series User manual

Compact high speed bi-polar power supply
DJOP Series
www.matsusada.com
USA/canada : [phone]
other countries : [phone]
FAX
Four-quadrant fast response
bi-polar power supply
DJOP series
Output voltage : 0V to ±60V
Maximum output power : 60W
Frequency bandwidth : DC to 30kHz
NEW
NEW

DJOPseries
±10（7）
±20（14）
±30（21）
±60（42）
DJOP10-5
DJOP20-3
DJOP30-2
DJOP60-1
±5（3.5）
±3（2.1）
±2（1.4）
±1（0.7）
50
60 3DC to 30
Please consult with our sales office about the specifications except the following list.
Four-quadrant fast response
bi-polar power supply
DJOP series is four-quadrant bi-polar power supply which source and sink electric power. They can be used in 2-mode of a
constant voltage (CV) or a constant current (CC). Thanks to the original design, phenomenal light weight and compact size power
supply, which is 140mm width, and weigh 3kg has been achieved. They are ultra compact and high speed, driving output propor-
tional to the input waveform such as a sine wave, triangular wave, saw wave, and square wave. All the models are completely
solid-state with output voltage between ±10V to ±60V.
DJOP series is most appropriate for evaluation test such as solar panels, the instruments driven by battery and the IC which
control battery.
Even faster model, DOS series, amplifier with function generator,
DOPF series, or more high power model, DOP series, are available.
Contact to local sales office for details.
Applications
Features
Lineup
Suitable to evaluate battery driven equipment to use as a simulated battery
Inductive load such as coil and transformer
Capacitive load like capacitor
Various motor tests
voltage regulation tests for in-vehicle electrical component
Evaluation test for solar panel related devices
For surface treatment
Wide lineup
Select a model fitting for your applications from the lineup of various
output voltage and current.
DC bias
10-turn potentiometer to be used for the output setting volume when used
as the DC power supply and for the bias setting when used as AC power
suppluy is equipped.
DC output meter
3-digit digital meter displays the DC value of the output voltage and
current. (The option of rms indication is available.)
Constant voltage (CV) / Constant current (CC)
A single switch selects between CV and CC modes.
Four-quadrant action
DJOP Series can be used both as a high speed response DC power
supply and as an electronic load.
Complete protective function
Protective function against over voltage/current and protective
measures against output short-circuit are completely provided.
Master-slave
The option of Master-slave control will resolve power shortages.
Compact & light weight
For maximum compactness and light weight, DJOP Series has been
improved for small footprint and easy carry.
Response speed
Newly developed DJOP Series is the most appropriate for transient
response test with such high power and broad bandwidth.
Model Weight
kg
Output voltage
V(rms value)
Output current
A (rms value)
Output power
W
Frequency bandwidth
kHz (-3dB)

Specifications
Protections
Input voltage
Input current
External control voltage
(Vcon-in)
Output display
(DC value)
DC bias
Ripple
Stability
Setting accuracy
Distortion
85V to 264Vac / 50/60Hz / single phase
1.5A max @115Vac input
- 10V to +10V
(input impedance : more than 10kΩ)
Voltage : 3-digit digital meter ±999
Current : 3-digit digital meter ±999
- 100% to +100% by 10-turn potentiometer
<CV mode> less than 0.02%rms
<CC mode> less than 0.2%rms
0.016%/Hr typ.
±0.5%F.S.
<CV mode> 0.05% <CV mode> 0.5%
(at rated output or resistor load)
DOP series is a bi-polar power supply which can perform
four-quadrant operation. They can supply (source) and
absorb (sink) current in the field of the drawing on the right.
+Vo max
-Vo max
Vo max : rated output voltage
Io max : rated output current
+Io max
-Io max
Range of AC operation (with 50Hz or more frequency and 50 %
of duty and without any DC bias)
Range of DC operation
Ⅰ(SOURCE）Ⅱ（SINK）
Ⅳ（SINK）Ⅲ（SOURCE）
High speed over current protection
DOP series is provided with 2 types of over current protections, high speed over current
protection to limit the pulse current, and standard over current protection to limit the
static current.
The standard over current protection limits the static current, responding at around 1ms.
Additional high speed over current protection can limit pulse current of square waveforms
or from capacitor at approx. 2 times more current of rating.
DOP series is equipped with over voltage protection, which
protects load by limiting voltage up to approx. 120% of the
rated output voltage even at abnormal conditions.
Vo
Io
1ms
I limit
I peak
Over voltage protection (O.V.P)
DOP series is also equipped with over current protection,
which protects power supplies and load by limiting current
up to approx. 120% of the rated output current.
Over current protection (O.C.P)
*-LVl option(output voltage limitter) enable to control the output in 0 to approx. 110% range. *-LIl option(output current limitter) enable to control the output in 0 to approx. 110% range.
Regulation
Temperature coef.
Output monitor
Protections
Operating temp.
Storage temp.
Humidity
Accessories
Input : 0.05% (for ±10% input change)
Load : 0.05%
(for 10% to 100% load change)
200ppm / ºC
Output voltage :
- 10V to +10V ±1%F.S.
Output current : - 10V to +10V ±1%F.S.
Output impedance : 1kΩ
Over voltage protection, over current
protection, against short-circuit and blackout
0ºC to +40ºC
- 20ºC to +70ºC
20% to 80%RH (no condensation)
AC input cable 2.5m (1)
(3-pin connector 125V type)
Instruction manual (1)
Output range

1
2
3
4
5
6
7
8
9
10
11
POWER ON/OFF switch
OUTPUT ON/OFF switch
Output voltage meter
Output current meter
CV/CC select switch
Vcon-in terminal
Bias ON/OFF switch
Bias setting dial
Control connector
Output terminal
AC input terminal
0.91
(23) 16.93(430)
0.59
(15)
POWER
OUTPUT
CV
Vcon-in ON
BIAS
V
CC
A
5.51(140)
1
2
34
5
7
89
6
11
10
4.88
(124)
Dimensions inch(mm) / Functions
AC input cable
Front
Side
Rear
4.88
(124)
0.31
(8)
Inputting voltage via Vcon-in enables
the control of output voltage V when CV
control is selected and output current A
when CC control is selected.
CV/CC setting selection Use of BIAS
In CV mode In CC mode
When the “BIAS ON/OFF switch” is flipped
to ON, bias can be changed with the “BIAS
setting dial.” Bias of the voltage can be set
when CV control is selected, and that of the
current can be when CC control is selected.
Vcon Output
voltage Output current
- 10V
0V
+10V
- Rating
0V
+Rating
- Rating
0A
+Rating
In CV mode In CC mode
Scale Output
voltage Output current
000(ccw)
500
1000(cw)
- Rating
0V
+Rating
- Rating
0A
+Rating
CABLE TYPE 4
250V / 10A
(Separately)
CABLE TYPE 1 CABLE TYPE 3
125V / 10A
(Standard) (up to 120V)
250V / 10A
(Separately)

USA/canada : [phone]
other countries : [phone]
FAX
Remote switch
-LS
Door switch
-LD
When ordering, suffix the following option mark to the model number.
<e.g> DJOP60-1-LDS (Alphabetical order)
Rise time
Capacitative load
Capacitative load may cause oscillation.
In such cases, placed a power resistance in series with the output.
Be careful that the frequency bandwidth is limited depending on the resistance and
capacitance placed in series when capacitative load.
Inductive load
Some inductance of inductive load may cause resonance in CC mode.
In such cases, connect a C-R series circuit between output terminals to prevent resonance.
Response speed
When accurate output waveforms are required, select a amplifier with a frequency
bandwidth higher enough than the operating frequency.
In case of using sine waves, 3 to 5 times more frequency bandwidth is required, and around
10times more in case of square waves in general. Inadequate bandwidth causes not only
decrease in the output amplitude but much difference between the input and output phases.
Therefore operating the product while monitoring the actual output waveforms is
recommended.
(Stepping time):The response time is sometimes described by the rise time (as shown
in the drawing on the right).
The rise time of an amplifier at a response speed of (= frequency bandwidth) Fc (Hz)
is generally acquired by "tr 0.35/fc."
Fall time tf is the same as tr.
Frequency bandwidth
: at 30kHz or lower, tr = tf = around 12 µs
: at 20kHz or lower, tr = tf = around 18 µs
Options
Characteristic of amplifier
NEW
0.1fc 0.01fc
0dB
3dB
f(Hz)
0.5fc fc
DC
0
70%
92%
100%
Vcon-in
OUTPUT
0％
10％
0％
100％
90％
tr tf
