Matsusada HARS Series User manual

Instruction Manual
F-RA-001-3R3
MODEL HARSseries
B/N 277.9.002 *277.9.002*Rev. 0.1

Note
All rights reserved.

No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form, or by any means, mechanical, electronic, photocopying,
recording, or otherwise, without the prior written permission of Matsusada Precision.

No patent liability is assumed with respect to the use of the information contained
herein. Moreover, because Matsusada Precision is constantly striving to improve its
high-quality products, the information contained in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual.
Nevertheless, Matsusada Precision assumes no responsibility for errors or omissions.
Neither is any liability assumed for damages resulting from the use of the information
contained in this publication.
Trademarks
Company names and product names in this document are the trademarks or registered
trademarks of their respective companies.
Warranty
For details, refer to the following website.
https://www.matsusada.com/support/manufacturer_warranty.html

i
HARS series
For Safe Use of the Product
◆Introduction
The product generates high-voltage and high-energy.
Therefore, wrongly handling or operating the product may result in death or serious injury and maybe
property damage as well. In order to use the product safely, read the instruction manual thoroughly before
use to understand how to use and operate it properly.
Please note that we will not be held responsible for any damage or loss caused by not following the
warnings, cautions, and procedures described in the manual.
Keep the manual with you so that you can read it whenever you want.
◆Symbols
Symbols are used in the manual and product, which indicate precautions to be observed for safe use.
Understand these symbols first and then read the manual thoroughly.
Some symbols below are not used in products.
Indicates a potentially hazardous situation, which, if not avoided, may
result in serious injury or death.
Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury or in property damage.
Indicates danger/warning/caution. Refer to
the instruction manual when this symbol
appears on the unit.
Frame or chassis terminal
Indicates the possible danger of electric
shock under specific conditions, which
may result in serious injury or death.
Ground terminal
High Temperature Caution:
Indicates the possible danger of injury by
high temperature under specific
conditions.
Power ON
Indicates general prohibitions, including
warnings.
Power OFF
Indicates what must be followed.
Standby
Protective earth terminal (ground terminal
for preventing electric shock)
Bistable push button switch
ON
Indicates the possible danger of death if
you drink it and burns or blindness if it
attaches.
Bistable push button switch
OFF
Indicates the possible danger of exposure
to radiation.
Alternative Current

ii
HARS series
Understand the risks.
The Product generates high-voltage and high-energy.
The product is designed for electrical engineers or the equivalents who install, wire, and operate it.
Read the instruction manual thoroughly before use and familiarize yourself with the proper use and
danger of the product.
Make sure to allow only specific people to handle the product.
Make sure to allow only the following people to handle the product:
1. who are electrical engineers or the equivalents and have already familiarized themselves with the
proper use and danger of the product, or
2. who are electrical engineers or the equivalents and have already been trained by the
above-mentioned people, or
3. who work under the supervision of the above-mentioned people.
If people other than those listed above install, wire, or operate the product, it may cause electric
shock, burnout, or injury.
Do not open or remove the case or panel of the product.
Do not disassemble, repair, or modify the product by yourself. High-voltage is applied to the inside of it.
Otherwise, it may cause electric shock, fire, or malfunction.
Moreover, if you do it, the safety and functions are not covered with the warranty.
The product does not suit to install and use in places where children may be present.
The product is designed to be installed in places such as factories or laboratories. Do not install and use it
where children may be present.
Make sure to ground it.
When the product has a protection ground terminal or GND terminal, make sure to ground it.
When the AC line input of it is an inlet type, connect the attached power cable or a power cable suitable for
your area to an outlet with the ground. Otherwise, it may result in electric shock or fire.
Regarding power cable
When a power cable is enclosed or attached to the product, do not use it for other products.
When no power cable is enclosed with the product, prepare the power cable suitable for the usage
environment and area by yourself.
Regarding the connection of power cable
Electrical engineers or the equivalents who have already been familiarized with the proper use and danger
of the product should connect the power cable to the AC input by referring to the instruction manual.
Regarding products that have acquired the safety standard, check the page describing the over-voltage
categories too.
Do not process or damage power cables
It may result in electric shock or fire.
Regarding the input voltage
Check the page describing the input terminals and input voltage in the instruction manual.
Do not provide any voltage out of the specifications.

iii
HARS series
Regarding the fuse
The product builds in a protective fuse. In the case where a fuse holder is arranged outside of the product,
you can replace it by yourself. Refer to the instruction manual to replace it.
In the case where a fuse holder is not arranged outside of the product, you cannot replace it by yourself.
In this case, do not open the case or panel of the product and contact us.
The product is designed for indoor use.
Use the product indoors only, not outdoors. Even indoors, do not use it if there is a possibility of water
leakage, flooding, or snow covering.
Regarding operating temperature and humidity
Use the product within the range of the specifications describing in the instruction manual.
Do not use it in a place where the ambient temperature exceeds the specified range or a closed place.
Do not install the product in places where condensation may occur.
Otherwise, insulation deteriorates and it may cause electric shock, fire, or malfunction.
Do not place anything on top of the product.
Otherwise, they may fall or tumble from it.
Do not put anything into the product.
Do not put foreign objects such as metal or liquid into the product through the air inlets, air outlets, or other
openings. Otherwise, it may result in electric shock, fire, or malfunction.
Operate the product with the right hand.
Use only your right hand to operate the product and keep your left hand away from it, which can reduce
the risk of electric current flowing through the left hand to the vital organs of the body in the event of an
electric shock.
Do not touch the wiring/load connected to the output and any terminals/connectors during the
operation or just after turning output off.
Very high-voltage is on the terminals and connectors during the operation and even just after the output is
turned off. Touching them may result in serious injury or death by electric shock.
The terminals here mean all terminals like input and output terminals and terminals for communications
and remote controls.
Turn off the product before touching the wiring/load connected to the product and any
terminals/connectors on the product and cut it off from the AC input.
Before touching the terminals/connectors and wiring/load, turn off the product and unplug the AC input
cable from the outlet or turn off the AC input breaker. Then, check there is no voltage remained using a
tester.
Since the output and sense terminals are connected to condensers in it, there is high-voltage remained on
them even just after it is turned off.
In order to avoid electric shock, ground the terminals to discharge using a short-circuit grounding
apparatus and check the voltage again.
The terminals here mean all terminals like input and output terminals and terminals for communications
and remote controls.

iv
HARS series
Level the product out to use for good heat dissipation.
Do not install the product upside down or sideways. If not, the inner heat dissipation will be insufficient.
It may result in smoke or fire due to components deterioration.
Do not install the product in a place where cold air directly blows to it.
It may result in electric leakage or burnout due to condensation.
Do not install the product in a place where it is exposed to corrosive gases or liquids.
It may result in smoke or burnout due to components deterioration.
Do not store or use the product in a place where conductive dust, such as iron powder, can enter
through the air inlet/outlet.
Doing so may cause a short circuit, resulting in electric leakage, burnout, fire, or malfunction.
Do not install the product in a dusty place.
Accumulating dust in the air inlet will make hard to cool it down it, it may result in malfunction.
In that case, remove dust immediately.
Do not block the air inlet and outlet.
Secure 30 cm space at least around the openings.
If they are blocked, the product cannot show the rated performance due to the internal temperature
increase. Moreover, components deteriorate and it may result in smoke or fire.
Remove wiring to and from the product when work like welding near it is done.
Do not wipe the equipment with a dust cloth wet with chemicals (thinner or the like) or water.
Otherwise, it may result in an electric shock, electric leakage, or burnout due to water getting inside.
Regarding fan replacement
When products equip a fan, it has a lifetime. It will be worn out and deteriorated with the time passed and
its operation may become unstable. Also, its lifetime greatly varies depending on the usage environment
such as temperature, humidity, dust. It requires to be replaced at regular intervals to extend the lifetime.
For the replacement, contact us.
(It requires a replacement charge separately. Do not replace it by yourself, as there is a risk of electric
shock.)

Table of Contents
v
HARS series
Table of Contents
Page
For Safe Use of the Product .............................................................................................................................ⅰ
Table of Contents ............................................................................................................................................. v
1 Features and Specifications ..................................................................................................................1
1-1 Greetings..................................................................................................................................................1
1-2 Overview...................................................................................................................................................1
1-3 Features....................................................................................................................................................1
1-4 Output Specifications................................................................................................................................2
2 Before Using This Product.....................................................................................................................3
2-1 General Information..................................................................................................................................3
2-2 Initial Inspection........................................................................................................................................3
2-3 Method of Transport.................................................................................................................................3
2-4 Handling Precautions...............................................................................................................................4
2-5 Installation.................................................................................................................................................4
2-5-1 Installation Conditions.............................................................................................................................4
2-5-2 Ventilation ...............................................................................................................................................5
2-5-3 Fan Replacement....................................................................................................................................5
2-5-4 Operating Conditions ..............................................................................................................................6
2-5-5 Attaching the Rubber Feet......................................................................................................................7
2-6 External Appearance................................................................................................................................8
2-6-1 Front Panel..............................................................................................................................................8
2-6-2 Rear Panel (Shared Interfaces)..............................................................................................................8
2-6-3 Dimensions .............................................................................................................................................9
3 Connecting..........................................................................................................................................13
3-1 Connecting the AC Input........................................................................................................................13
3-1-1 AC input cable connection (500W/1kW)...............................................................................................13
3-1-2 AC input cable connection (2kW/3kW) .................................................................................................14
3-2 Connecting the GND..............................................................................................................................15
3-2-1 No grounding for the load frame (Models at rated current 1.3A or higher)...........................................15
3-2-2 No grounding for the load frame (Models at rated current 1.3A or lower) ............................................15
3-2-3 Grounding the load frame (Models at rated current 1.3A or higher).....................................................16
3-2-4 Grounding the load frame (Models at rated current 1.3A or lower) ......................................................16
3-3 Connecting the load................................................................................................................................17
4 Basic Operation and Screens..............................................................................................................18
4-1 Operating Modes....................................................................................................................................18
4-1-1 Constant Voltage Mode (CV Mode)......................................................................................................18
4-1-2 Constant Current Mode (CC Mode)......................................................................................................18
4-1-3 Crossover Operation.............................................................................................................................18
4-2 Home Screen.......................................................................................................................................... 19
4-3 Status LED..............................................................................................................................................19
4-4 Screen Structure and Hierachy..............................................................................................................20

Table of Contents
vi
HARS series
4-5 Error Display...........................................................................................................................................21
4-5-1 Overtemperature protection..................................................................................................................21
4-5-2 AC input voltage abnormality protection...............................................................................................21
4-5-3 Overvoltage protection..........................................................................................................................22
4-5-4 Overcurrent protection ..........................................................................................................................22
4-5-5 Interlock function...................................................................................................................................22
4-5-6 ERROR display.....................................................................................................................................23
5 Operating on the Main Unit..................................................................................................................24
5-1 Basic Operations....................................................................................................................................24
5-1-1 Power ON..............................................................................................................................................24
5-1-2 Power OFF............................................................................................................................................24
5-1-3 Setting Output Voltage and Current......................................................................................................24
5-1-4 Turning the OUTPUT ON/OFF .............................................................................................................25
5-1-5 Locking the Key Lock............................................................................................................................25
5-1-6 Switching Monitor Screen .....................................................................................................................26
5-1-7 Setting Protections and Limits ..............................................................................................................26
5-1-8 Configuring Multiset Memory ................................................................................................................27
5-1-9 Setting Arc Count Protection.................................................................................................................28
5-1-10 Setting External Switch Function........................................................................................................30
5-1-11 Setting Interlock Function ...................................................................................................................31
5-1-12 Setting Power Failure Protection Function .........................................................................................32
5-1-13 Returning to local................................................................................................................................33
5-1-14 Adjusting Screen Brightness...............................................................................................................34
5-1-15 Touch Calibration................................................................................................................................35
5-1-16 System Reset......................................................................................................................................36
5-1-17 Unit ID Setting.....................................................................................................................................37
5-1-18 Checking LAN Information..................................................................................................................38
5-1-19 Delimiter Setting..................................................................................................................................39
5-1-20 Baudrate setting..................................................................................................................................40
5-1-21 Interface setting...................................................................................................................................41
5-2 Sequence Operation (Pulse/Ramp Sequence)......................................................................................42
5-2-1 Overview ...............................................................................................................................................42
5-2-2 Feature..................................................................................................................................................42
5-2-3 Pulse Sequence Setting........................................................................................................................42
5-2-4 Ramp feature ........................................................................................................................................44
5-2-5 Ramp Setting ........................................................................................................................................44
6 Operating by Analog Remote Control..................................................................................................46
6-1 Analog Remote Terminal (TB1) Contents.............................................................................................. 46
6-2 External Switch....................................................................................................................................... 47
6-3 Using Interlock........................................................................................................................................ 49
6-4 Analog Remote Control of Voltage and Current Settings......................................................................50
6-5 Output Voltage Program by External Voltage........................................................................................ 51
6-6 Output Current Program by External Voltage........................................................................................ 52
6-7 Monitoring Output Voltage/Current ........................................................................................................52
6-8 Status Output.......................................................................................................................................... 53

Table of Contents
vii
HARS series
7 Operating with Digital Control..............................................................................................................54
7-1 Overview.................................................................................................................................................54
7-1-1 Connector..............................................................................................................................................54
7-1-2 Setting Network.....................................................................................................................................54
7-2 SCPI Command Program....................................................................................................................... 55
7-2-1 Overview of SCPI Commands..............................................................................................................55
7-2-2 Multi-command......................................................................................................................................55
7-3 SCPI Command List...............................................................................................................................56
7-4 Description of SCPI Commands.............................................................................................................57
7-5 Tutorial.................................................................................................................................................... 60
7-5-1 Remote/local Mode Setting...................................................................................................................60
7-5-2 Output Settings .....................................................................................................................................60
7-5-3 Protection Setting..................................................................................................................................60
7-5-4 Output Measurement ............................................................................................................................60
7-6 Original Command program by Matsusada Precision...........................................................................61
7-6-1 Summary of Syntax...............................................................................................................................61
7-6-2 Multiple command.................................................................................................................................61
7-6-3 Command response..............................................................................................................................62
7-6-4 Character set of command....................................................................................................................62
7-7 Original Command list of Matsusada Precision.....................................................................................63
7-8 Description of Original Command of Matsusada Precision ...................................................................64
7-9 Range for Voltage Setting and Crrent Setting........................................................................................69
8 Web Interface......................................................................................................................................70
8-1 Features of Web Interface...................................................................................................................... 70
8-2 Displaying Web Interface .......................................................................................................................70
8-3 Home Page.............................................................................................................................................71
8-4 Config Page............................................................................................................................................72
8-5 Control Page...........................................................................................................................................73
8-6 Security Page.........................................................................................................................................74
8-7 Setting page............................................................................................................................................75
8-8 Links Page.............................................................................................................................................. 76
9 Option..................................................................................................................................................77
9-1 RS-232C/485 interface (-LRs option)..................................................................................................... 77
9-2 Optical Interface (-LGob option).............................................................................................................78
10 Troubleshooting for Digital Control ....................................................................................................79
10-1 Troubleshooting for Digital Control....................................................................................................... 79
10-2 Inquiry...................................................................................................................................................79
11 When You Were In Trouble ...............................................................................................................80

1 Features and Specifications
1
HARS series
1 Features and Specifications
1-1 Greetings
Thank you for purchasing HARS Series product.
Matsusada Precision takes every precaution to ensure the quality of our products. Please follow the
instructions in the manual to ensure full performane and safe use of the product.
We have made every effort to provide all of the necessary information in this manual. However, if you
notice any errors or omissions, please contact us.
1-2 Overview
With 1kW output in a 19-inch rackmouint 1U chassis or 3kW output in 2U, the HARS series offers as a
high power density as ever had.
In addition, unique high-frequency switching technology allows high output and low noise in a compact
body.
1-3 Features
Dial/touchscreen for setting voltage, current, and power from zero to the rated output.
Automatic crossover switching of voltage, current and power mode.
Compact and lightweight through the use of unique high-frequency switching technology.
Lock function to prevent erroneous operation.
High precision and advanced functionality through microcomputer control.

1 Features and Specifications
2
HARS series
1-4 Output Specifications
Model
Rated output
voltage [kV]
Rated output current
[mA]
Rated output
power [W]
HARS-1*500
1
500
500
HARS-1*1000
1
1000
1000
HARS-1*2000
1
2000
2000
HARS-1*3000
1
3000
3000
HARS-1.5*333
1.5
333
500
HARS-1.5*666
1.5
666
1000
HARS-1.5*1333
1.5
1333
2000
HARS-1.5*2000
1.5
2000
3000
HARS-3*166
3
166
500
HARS-3*333
3
333
1000
HARS-3*666
3
666
2000
HARS-3*1000
3
1000
3000
HARS-6*83.3
6
83.3
500
HARS-6*166
6
166
1000
HARS-6*333
6
333
2000
HARS-6*500
6
500
3000
HARS-10*50
10
50
500
HARS-10*100
10
100
1000
HARS-10*200
10
200
2000
HARS-10*300
10
300
3000
HARS-30*16.6
30
16.6
500
HARS-30*33.3
30
33.3
1000
HARS-30*66.6
30
66.6
2000
HARS-30*100
30
100
3000
HARS-60*8.33
60
8.33
500
HARS-60*16.6
60
16.6
1000
HARS-60*33.3
60
33.3
2000
HARS-60*50
60
50
3000
HARS-100*5
100
5
500
HARS-100*10
100
10
1000
HARS-100*20
100
20
2000
HARS-100*30
100
30
3000
HARS-120*4.16
120
4.16
500
HARS-120*8.33
120
8.33
1000
HARS-120*16.6
120
16.6
2000
HARS-120*25
120
25
3000
The output type is described in * with P or N. (P: Posituve polarity output N: Negative polarity output)
The voltage, current, and power that are shown in the table are output to the output
terminals on this product.
Do not touch the output terminals or loads while the product is operating, or immediately
after operation has stopped.
Before touching the output terminals or load, set the output voltage/current to zero and
turn off the OUTPUT switch. Make sure that the values for voltage/current are zero on the
display. Turn off the POWER ON/OFF switch, and turn off the main power supply. Ground
between the output terminals and the GND terminals, and use a voltmeter to confirm that
the voltage value is zero.

2 Before Using This Product
3
HARS series
2 Before Using This Product
2-1 General Information
After unpacking the product and checking the power supply, make sure all of the following accessories are
included.
[Accessories]
□
Instruction Manual
1
□
Cover for analog remote connector
1
□
Output cable
1
□
AC input cable
1
□
AC input terminal cover (for 2kW and 3kW)
1
□
RS-485 Connector (-LRs option)
1
□
CO-OPT cable (with -LGob option)
1
□
Rubber feet
6
2-2 Initial Inspection
Before operating the product, thoroughly check the unit for abnormalities.
(Do not yet connect the power cable, or any other cables.)
1. Check the front panel, rear panel, top, and the chassis for dents, etc.
2. If an abnormality is found, contact both Matsusada Precision and the delivery company.
2-3 Method of Transport
This product should be carried by at least two people.
Hold it by the bottoms of the front panel and rear panel.
When placing the product onto a surface, be sure to avoid pinching your fingers underneath the unit.
Avoid placing a load on the handle on the front panel.
Otherwise, the product could be damaged and injury could occur.
or

2 Before Using This Product
4
HARS series
2-4 Handling Precautions
For equipment (systems) that uses a high-voltage power supply of 750 V or higher,
faults that are caused by high voltage might be generated by the equipment.
Although the unit has protections against instantaneous short circuits, avoid any
operation where there are repetitive short circuits that lead to discharge.
All possible measures have been taken against noise, however if you find hang up
or unintended voltage output, turn off the power supply once to reset the unit, and
then, check the display for abnormal output voltage/current while sending the
command again from the controller.
When changing the load, first turn off all power that is supplied to the
unit.
2-5 Installation
2-5-1 Installation Conditions
Never place objects on top of the power supply unit.
Avoid using the unit in locations that are subject to dust and corrosive gas.
Do not install the power supply in locations that are prone to condensation.
Do not allow liquids or metals to get inside the power supply via ventilation
holes or other openings. Doing so could lead to breakdown, electric shock, or
fire.
Do not store or use the product in a place where conductive dust, such as iron
powder, can enter through the air inlet/outlet.
Doing so may cause a short circuit, resulting in electric leakage, burnout, fire,
or malfunction.
The product is designed to be installed in a 19-inch rack. Use guides to support
the chassis when mounting the power supply.
Avoid supporting the unit only by the installation holes on the front panel.
The handle on the front panel is used to change the direction the power supply
is facing and to pull the unit out of rack in which it is mounted. Avoid placing the
full weight on the handle.
Install and use the unit in a horizontal orientation.
Be sure to maintain a space of at least 30 cm at the front and rear of the power
supply unit, and do not block the intake/exhaust ports.
Ensure that the external cabinet also has intake and exhaust ports that are
the same size as the openings on the power supply.
Do not install the power supply in a sealed cabinet or similar enclosure, and
provide ventilation to ensure that exhaust heat from the exhaust port does not
return through the intake port.
Promptly remove any dust that accumulates in the intake port.
If dust accumulates in the intake port, it will interfere with the cooling of the unit
and lead to breakdown.
Do not impact to protrusions on the front panel when you move the product.
Never take impat to the encoder especially because it causes degrading
component life significantly.
If welding or similar work will be performed near the power supply, first
disconnect all connection wires from the power supply.

2 Before Using This Product
5
HARS series
2-5-2 Ventilation
The front and rear of the power supply unit are equipped with air intake and exhaust ports for cooling.
Provide enough space around these ports to ensure sufficient air circulation, and please use the
product in a well-ventilated area with a space of 30cm or more.
Promptly remove any dust that accumulates in the intake port.
If dust accumulates in the intake port, it will interfere with the cooling of the unit and
lead to breakdown.
2-5-3 Fan Replacement
The fan in this power supply has a limited service life. As it becomes worn and deteriorates
with use, its operation might become unstable. Note that the service life of the fan will vary
greatly depending on the usage environment (temperature, humidity and dust). In order to
use this power supply for a long time, it is necessary to replace the fan at regular intervals.
Please contact Matsusada Precision for assistance in replacing the fan. (A separate repair
fee is required to replace the fan. Do not replace the fan by yourself as it may cuase electric
shock.)

2 Before Using This Product
6
HARS series
2-5-4 Operating Conditions
This product is designed to be used under the conditions listed in the table below.
HARS series
500W
1kW
2kW
3kW
Rated Input
Voltage
100 - 240Vac
200 - 240Vac
Voltage Tolerance
±10%.
phase number
Single-phase
Three-phase
Frequency
50/60Hz
Power
700VA
1300VA
2600VA
380VA
Protection fuse
15A
30A
15A
30A
Operating environment
Indoor use, OVC II *1
Pollution degree
Pollution degree 2 *2
Operating temperature
0°C to +50°C
Operating humidity
20% to 80% RH (no condensation)
Storage temperature
-20°C to +70°C
Storage Humidity
20% to 80% RH (no condensation)
Installation altitude
2000m or lower
*1 Over Voltage Category
OVC I: Equipment connected to a treated circuit to limit transient overvoltage to a low level
OVC II: Energy-consuming devices that are supplied with power from fixed equipment
OVC III: Devices that meet the special requirements for reliability and effectiveness for use in fixed equipment
OVC IV: Devices used at the inlet for equipment
*2 Pollution degree
Pollution degree 1: No pollution, or only dry non-conductive pollution. No effect due to pollution.
Pollution degree 2: Only non-conductive pollution, except for temporary conductivity due to condensation.
Pollution degree 3: Conductive pollution or dry non-conductive pollution that becomes conductive due to
expected condensation.
Pollution degree 4: Dust with conductive pollution, or that becomes permanently conductive due to rain or snow.
Confirm the input voltage that is displayed on the rear panel of the unit to enter
the correct voltage.
If an incorrect voltage is entered, the equipment could be damaged.
Wait at least 20 seconds after turning off the POWER ON/OFF switch before
turning it on again.
Repeatedly turning the POWER ON/OFF switch ON and OFF at short intervals
will cause a breakdown of the inrush current limiting circuit, shortening the
service life of the input fuse, POWER ON/OFF switch, and other components.
* If the POWER ON/OFF switch is turned ON and OFF repeatedly at short
intervals, an input voltage drop error might occur in order to protect the internal
circuitry.
Model

2 Before Using This Product
7
HARS series
2-5-5 Attaching the Rubber Feet
The supplied rubber feet can be attached to this product.
Refer to the figure below to attach the six rubber feet to the unit.
The unit is heavy. Use caution when attaching.
Bottom of the unit
Rubber feet attached

2 Before Using This Product
8
HARS series
2-6 External Appearance
2-6-1 Front Panel
(1)
POWER ON/OFF switch
(2)
Air inlet
(3)
OUTPUT ON/OFF switch
(4)
Touch panel display
(5)
Setting dial (also used as a switch)
2-6-2 Rear Panel (Shared Interfaces)
(1)
Output connector
(2)
GND terminal
(3)
Analog remote connector
(4)
Air outlet
(5)
Input connector
(6)
LAN connector
(7)
USB connector (Type-B) for communication control (models 10kV or lower)
(8)
For option (Refer to the Option chapter.)
(1) (2) (3) (4) (5)
(1) (2) (3) (4) (5)
(6) (7) (8)

2 Before Using This Product
9
HARS series
2-6-3 Dimensions
a) Models 500W/1kW, 60kV or lower

2 Before Using This Product
10
HARS series
b) Models 500W/1kW, 100kV/120kV
