Maxcess FIFE D-MAXE 3 User manual

CDP-01 to D-MAXE 3 Upgrade Kit
Cable Connection Reference
www.maxcessintl.com
Retrofit CDP-01 to D-MAXE 3
MI 1-934 1
Page 1 of 2
Before disconnecting or connecting any cables, ensure that power is off to the
CDP-01 and the D-MAXE components.
Complete safety instructions can be found in the D-MAXE Operating Instructions.
D-MAXE 3 Upgrade kit part numbers*
This document is intended to be used as a
quick reference guide for connecting your
existing peripherals to the D-MAXE drop-in
module.
The kit is designed to be installed using the
same mounting holes and hardware as your
CDP-01.
Use Fife power cable (1). Ensure that the
cable retainer clip is properly engaged.
See the D-MAX OI-TS Quick Start Guide (2)
for an introduction to the user interface.
Standard software
290002903
Custom software
290002906
(1)
Fife Part No.
78234-000 [length as specified]
78234-001 [16 feet]
(2)
Fife Part No. MI 1 5013
*Standard single drive kit is pictured at left.
Dimensions (D-MAXE 3 kit)

AMERICAS
Tel [phone]
Fax [phone]
[email protected]
www.maxcessintl.com
EUROPE, MIDDLE EAST
AND AFRICA
Tel [phone]
Fax [phone]
[email protected]
www.maxcess.eu
CHINA
Tel [phone]
Fax [phone]
[email protected]m.cn
www.maxcessintl.com.cn
INDIA
Tel [phone]
Fax [phone]
[email protected]
www.maxcess.in
JAPAN
Tel [phone]
Fax [phone]
[email protected]
www.maxcess.jp
KOREA, TAIWAN,
AND SE ASIA
[email protected]
www.maxcess.asia
© 2017 Maxcess
Connections: CDP-01 to D-MAXE
Connections
CDP-01 D-MAXE 3
Description
X1
X5
Sensor (Edge)
X2
X9
Sensor (Edge)
X3
X11
Sensor (Line Guide)
X4
N/A
RGPC
X5
X3
Servo Center 1 / Encoder 1
X6
X4
Drive 1
X7
X1
Parallel I/O
X8
N/A
Serial Communications
X9
X7
Servo Center 2 / Encoder 2
X10
X10
Drive 2
X11
X12
Servo Center 3 / Encoder 3
X12
X13
Drive 3
N/A
X6
Connected from D-MAXE from internal power supply
N/A
X8
Connected from D-MAXE operator interface (OI-TS)
Connections: D-MAXE 3 (triple drive)
D-MAXE module front view
Power end view
Ethernet end view
